1. A uniform Modulesystem for Distributed Enterprise Applications Motivation and basic Concept Integrating Architecture Apps for the Enterprise
2. © 2014 Integrating Architecture Seite: 2 Content Problem Reason Challenge Basic Idea Architecture Implementation Kontakt Backup Unification Traceability Client Server Architecture JEE Vulnerabilities
3. © 2014 Integrating Architecture Seite: 3 The Problem Enterprise development and maintenance is elaborated, risky and expensive Costs for new features and changes increase exponentially with the scope of the systems Business driven development is getting constantly slower, more error prone and increasingly restrictive Iterative and agile processes are more and more hindered and slowed down with increasing system size
4. © 2014 Integrating Architecture Seite: 4 The Reason Over the decades, although software architectures, processes and technologies have continuously improved … but the problem has remained !?! Because one thing has not changed over time that complex monoliths are built That is, as if one uses continuous improving technologies to build square wheels – always wondering that they do not roll. Monoliths are for continuance - NOT for evolution!
5. © 2014 Integrating Architecture Seite: 5 The Challenge Enterprise Systems are much more than a piece of software! They reflect the challenges of a company and have to constantly evolve with these But they can only do so – if they are constructed like companies from individual units with responsibilities and limitations achieving common goals by cooperation and management
6. © 2014 Integrating Architecture Seite: 6 The basic Idea “Individual units with responsibilities and limitations, driven by a management to achieve common goals by cooperation” ? – that is a modular System! Modules are unique, self sufficient units with clearly defined functions, a protected inside and public interfaces for cooperation Systems consist of any number of modules combined under one name which together realize a bigger task driven by a management Development is change of modules over versions Functional size is the number of modules
7. © 2014 Integrating Architecture Seite: 7 Everything is a unique, versioned Module – everyone just works with modules – and a module may be “anything” needed e.g. subject for: business requirements, specification, modeling, planning, controlling, operation etc. and at the same time neutral software artifact like service, database, technology, external system, GUI, interface etc. At last a module is a unique name (e.g. com.ModuleXY-1.0) and a file with this name in a central repository. Everything else is usage and technical automatism. The Architecture
8. © 2014 Integrating Architecture Seite: 8 The Implementation Enterprise Apps provide without effort - platform independent Modularity - and technology independent Communication In this way they enable the construction of Enterprise Systems from easily to handle, versioned service modules, that are located in a central repository and provided by an On Demand management as modular applications and central services of a service broker. Enterprise Apps free from middleware technology, from deployment, from complex designs and transformations and aslo from versioning- and update problematics – just simple modules JEE Server+Broker established and powerful Modulemanager dynamic and automated Platform base Individual, modular and automated systemes Central Repository including all Modules
9. Andreas Weidinger Mobile: 0160 97627398 Mail: info@integrating-architecture.de Home: www.integrating-architecture.de Integrating Architecture IT Consulting
10. © 2014 Integrating Architecture Seite: 10 Backup – Unification Enterprise Apps modules are the same from the specification to operation. In this way they unify all technologies and platforms in one evolving architecture. Unification of Technologies and Platforms Windows Linux / Unix Apps for the Enterprise Rich Internet Application Mobile Java SE + EE HTML / JavaScript Server Modules Smart Client Modules Web Client Modules Mobile Client Modules Central Module Repository - Modules - Services - Rules 1 - The presentation as a layer is just vor illustration purpose. Enterprise Apps are NO technical layer and also NO technical object types. 1
11. © 2014 Integrating Architecture Seite: 11 Backup – Traceability Transparency, reliable Management and Governance through Arbitrary patrs and functional requirements for Services and Systems … …are represented and realized by unique Modules in a central Repository Module Repository CRM ModuleXY-1.0.0 CRM ModuleXY-2.0.0 Module KT-DB-3.0.0 Module Messaging-1.0.5 Management and the Service Broker (both free of business logic) provide the Modules On-Demand Projects Unique linking and mapping of all parts of an IT Landscape CRM Module4711-1.0.0 System-CRM … etc. Module SAP Service- 2.1.0 1 1 -That means project structures in development like IDE or SCM projects – not organizational management projects, they stay independent IT Systemlandscape
12. © 2014 Integrating Architecture Seite: 12 Backup – Client Server Architecture Entire separation of business logic from platform and technology JEE Application Server ISA Service Broker Application ISA Module System knows calls SF Session SL Session Servlet MDB/JMS WebService ISA JEE Adapter delegates central Repository : Object : Module resp. App : Call automated, system- and user specific configuration und replication - Business implementation only resides in modules resp. apps - The central repository is a Single Point of Access, it contains all versions of all modules divided into systems – for clients and server 1 2 - The JEE Adapters are generic. They contain NO business code and always delegate to the module management 3 - The Service Broker resp. the corresponding JEE application(.ear) is only about 50 KB in size 4 - The module system is totally encapsulated an runs in its own classloader context 1 4 3 2 : optional uses Manager 5 - The ISA Smart Client is not mandatory. Any application can access the broke local Repository ISA Modul System Manager 1‘ calls knows 5 Connector multi protocol Server Server oder File Server Smart Client network Web Client Rich Internet Application http Service Consumer Any Application Connector multi protocol
13. © 2014 Integrating Architecture Seite: 13 Backup – JEE Vulnerabilities JEE based systems are monoliths by specification because the deployment model only knows closed applications JEE violates the SoC princip because JEE forces the implementation of business requirements as platform components (e.g. as WebService, EJB etc.) JEE components are bind to distinct distributed communication technologies (e.g. RMI, HTTP, JMS etc.) JEE does not provide a usable module system and its container structure hinders the use of external module systems The problem with JEE is NOT the concept of an application server providing a distributed infrastructure – the problem is, that JEE tries to claim any purpose and binds applications to its monolithic platform and its technologies. 1 - Separation of Concerns – at this point separation of business logic and technology 1
