  1. GPUをフル活⽤するた
    めの TF.DATA の使い⽅
    板垣 正敏
    2019/11/2
    Python機械学習勉強会in新潟 & TFUG Niigata
    合同勉強会

    View Slide

  2. TF.DATAとは︖

    View Slide

  3. 機械学習モデルへの⼊⼒パ
    イプライン構築ツール
    ■ 機械学習モデルにデータを供給するためのパイプラインを
    構成する
    ■ 下記のような操作を⾏う
    – データの読み込み
    – データのデコード
    – データの前処理
    – データのシャッフル
    – データの繰り返し
    – データのキャッシュ
    – データのバッチ化

    View Slide

  4. tf.data.Datasetとサブクラス
    ■ tf.data.Dataset
    – tf.data.TFRecordDataset
    – tf.data.TextLineDataset
    – tf.data.FixedLengthDataset

    View Slide

  5. tf.data.Dataset
    ■ from_generator()
    ■ from_tensor_slices()
    ■ from_tensors()
    ■ list_files()
    ■ apply()
    ■ batch()
    ■ cache()
    ■ concatenate()
    ■ enumerate()
    ■ filter()
    ■ flat_map()
    ■ interleave()
    ■ map()
    ■ options()
    ■ padded_batch()
    ■ prefetch()
    ■ range()
    ■ reduce()
    ■ shard()
    ■ shuffle()
    ■ skip()
    ■ take()
    ■ unbatch()
    ■ window()
    ■ with_options()
    ■ zip()

    View Slide

  6. tf.data.TFRecordDataset
    ■ TFRecord 形式のファイルからデータセットを⽣成
    ■ TFRecord 形式はプロトコルバッファ形式の tf.Example を
    ベースにしたフバイナリファイルフォーマットであり、連
    続して効率的にデータを読み込むことを⽬的としている
    ■ モデルの処理速度に対してデータの読み込みスピードがボ
    トルネックになるような場合に使⽤すると良い

    View Slide

  7. tf.data.TextLineDataset
    ■ テキストファイルの⾏からデータセットを作成する
    ■ ⼊⼒として複数のファイルを取ることができる

    View Slide

  8. tf.data.FixedLengthRecordDataset
    ■ 固定⻑のバイナリファイルからデータを読み込む

    View Slide

  9. TensorFlow I/Oというのがあ
    るらしい
    ■ TensorFlow coreではサポートされないさまざまなデータ
    ソースからのデーセット⽣成を⾏うライブラリ
    ■ データソースの例
    ■ Apache Ignite, Apache Kafka, Amazon Kinesis, Apache Arrow,
    WebP and TIFF, LIBSVM, FFmpeg, Apache Parquet, LMDB,
    MNIST, Google Cloud Pub/Sub, Google Cloud Bigtable,
    Alibaba Cloud Object Storage Service, Apache Avro, WAV,
    gRPC server, HDF5, Text file with archive, Pcap, Microsoft
    Azure Storage, Google Cloud BigQuery, GCS
    Configuration, Prometheus, DICOM, JSON

    View Slide

  10. GPU環境でのベスト
    プラクティス
    https://www.tensorflow.org/guide/data_performance より

    View Slide

  11. パイプラインが必要な理由
    ■ パイプラインがない場合
    ■ パイプライン化後(prefetch活⽤)

    View Slide

  12. データ変換の並列化
    ■ 並列化なし
    ■ 並列化あり

    View Slide

  13. I/Oの並列化
    ■ シーケンシャル I/O
    ■ パラレル I/O

    View Slide

  14. 処理順序に注意
    ■ Map と Batch
    – Mapによる処理が重い場合には処理をベクトル化してBatch
    全体に適⽤できないか考える
    ■ Map と Cache
    – メモリに余裕があれば、Map処理後のデータをキャッシュ
    する
    ■ Map と Interleave / Prefetch / Shuffle
    – Mapでデータサイズが変わる場合にはバッファを必要とす
    る処理との順番を考慮する
    ■ Repeat と Shuffle
    – シャッフルの前にリピート ⇒ エポック間のデータが混ざる
    – リピートの前にシャッフル ⇒ エポックごとにシャッフルの
    時間がかかる

    View Slide

  15. コーディング例

    View Slide

  16. import tensorflow as tf
    import pathlib
    import time
    import random
    print(tf.__version__)
    # 画像データのダウンロード
    data_root_orig = tf.keras.utils.get_file(
    origin='https://storage.googleapis.com/download.tensorflow.org/example_images/f
    lower_photos.tgz',
    fname='flower_photos', untar=True)
    data_root = pathlib.Path(data_root_orig)
    # 画像ファイルの⼀覧作成(画像はクラスごとのディレクトリに⼊っている)
    all_image_paths = list(data_root.glob('*/*'))
    all_image_paths = [str(path) for path in all_image_paths]
    random.shuffle(all_image_paths)
    image_count = len(all_image_paths)
    画像分類のサンプル(1/3)

    View Slide

  17. # ラベルの取得とインデックス割り当て
    label_names = sorted(item.name for item in data_root.glob('*/') if item.is_dir())
    label_to_index = dict((name, index) for index,name in enumerate(label_names))
    all_labels = [path.split('/')[-2] for path in all_image_paths]
    all_indices = [label_to_index[label] for label in all_labels]
    # Datasetの設定
    AUTOTUNE = tf.data.experimental.AUTOTUNE
    image_size = (192, 192)
    batch_size = 40
    list_ds = tf.data.Dataset.from_tensor_slices(all_image_paths)
    # 前処理⽤関数
    def load_and_preprocess_image(file_path):
    image = tf.io.read_file(file_path)
    image = tf.image.decode_jpeg(image, channels=3)
    image = tf.image.resize(image, image_size)
    image = 2 * (image / 255.0) - 1.0 # [0, 255] -> [-1, 1]
    return image
    画像分類のサンプル(2/3)

    View Slide

  18. # Datasetの組み⽴て
    image_ds = list_ds.map(load_and_preprocess_image, num_parallel_calls=AUTOTUNE)
    indices_ds = tf.data.Dataset.from_tensor_slices(all_indices)
    ds = list_ds.zip((image_ds, indices_ds)) ¥
    .cache() ¥
    .shuffle(buffer_size=image_count) ¥
    .batch(batch_size) ¥
    .prefetch(buffer_size=AUTOTUNE)
    # モデルの構築
    mobile_net = tf.keras.applications.MobileNetV2(input_shape=(192, 192, 3),
    include_top=False)
    mobile_net.trainable=False
    model = tf.keras.Sequential([
    mobile_net,
    tf.keras.layers.GlobalAveragePooling2D(),
    tf.keras.layers.Dense(len(label_names), activation='softmax')])
    # モデルのコンパイル
    model.compile(loss='sparse_categorical_crossentropy',
    optimizer='adam',
    metrics=['acc'])
    # モデルの訓練
    model.fit(ds, epochs=10, verbose=2)
    画像分類のサンプル(3/3)

    View Slide

  19. # Datasetの組み⽴て
    image_ds = list_ds.map(load_and_preprocess_image,
    num_parallel_calls=AUTOTUNE)
    indices_ds = tf.data.Dataset.from_tensor_slices(all_indices)
    ds = list_ds.zip((image_ds, indices_ds)) ¥
    .cache() ¥
    .shuffle(buffer_size=image_count) ¥
    .batch(batch_size) ¥
    .prefetch(buffer_size=AUTOTUNE)
    並列実⾏の多重度を指定
    バッファサイズ注意
    バッファサイズ注意
    核⼼部分の補⾜

    View Slide

  20. ベンチマーク

    View Slide

  21. 実験環境
    ■ CPU: Intel(R) Core(TM) i9-9900K CPU @ 3.60GHz
    ■ Memory: 32GB
    ■ GPU: NVIDIA GeForce RTX 2080 Ti メモリ11GB
    ■ OS: Ubuntu Desktop 18.04.2
    ■ NVIDIA Driver Version: 418.87.01 CUDA Version: 10.0
    ■ Storage: NVMe 480GB
    ■ docker ce/nvidia-docker2
    ■ tensorflow/tensorflow:latest-gpu-py3

    View Slide

  22. import tensorflow as tf
    import pathlib
    import time
    print(tf.__version__)
    # 画像データのダウンロード
    data_root_orig = tf.keras.utils.get_file(
    origin='https://storage.googleapis.com/download.tensorflow.org/example_images/
    flower_photos.tgz',
    fname='flower_photos', untar=True)
    data_root = pathlib.Path(data_root_orig)
    # ラベルの取得とインデックス割り当て
    label_names = sorted(item.name for item in data_root.glob('*/') if item.is_dir())
    label_to_index = dict((name, index) for index,name in enumerate(label_names))
    ⽐較対象︓
    tf.keras で ImageDataGeneratorの
    flow_from_directory を使⽤

    View Slide

  23. # ImageDataGeneratorの設定
    image_size = (192, 192)
    batch_size = 40
    def rescale_for_mobilenet(input):
    return 2*(input/255.0) - 1.0
    image_data_generator = tf.keras.preprocessing.image.ImageDataGenerator(
    preprocessing_function=rescale_for_mobilenet)
    train_generator = image_data_generator.flow_from_directory(data_root,
    target_size=image_size,
    batch_size=batch_size)
    # モデルの構築
    mobile_net = tf.keras.applications.MobileNetV2(input_shape=(192, 192, 3),
    include_top=False)
    mobile_net.trainable=False
    model = tf.keras.Sequential([
    mobile_net,
    tf.keras.layers.GlobalAveragePooling2D(),
    tf.keras.layers.Dense(len(label_names), activation='softmax')])
    # モデルのコンパイル
    model.compile(loss='categorical_crossentropy', optimizer='adam', metrics=['acc'])
    # モデルの訓練
    start_time = time.perf_counter()
    model.fit_generator(train_generator, epochs=10, verbose=2)
    end_time = time.perf_counter()
    train_time = end_time - start_time
    print("Training Time: {} sec.".format(train_time))

    View Slide

  24. 簡易ベンチマーク結果
    構成 学習時間(10エポック)
    tensorflow/tensorflow
    :latest-gpu-py3 CUDA 10.0
    TensorFlow 2.0.0
    nvcr.io/nvidia/tensorflow :
    19.09-py3 CUDA 10.1
    TensorFlow 1.14.0
    Tf.keras + ImageDataGenerator
    (リサイズ+標準化のみ)
    125.22 Sec. 112.45 Sec.
    116.36 Sec.(Profiling)
    Tf.data /
    map.cache.shuffle.repeat.batch.pr
    efetch
    (リサイズ+標準化のみ)
    28.462 Sec. 21.653 Sec.
    23.128 Sec.(Profiling)
    Tf.data /
    map.cache(file).shuffle.repeat.batc
    h.prefetch
    (リサイズ+標準化のみ)
    28.996 Sec.(1回⽬)
    28.594 Sec.(2回⽬)
    19.761 Sec.(1回⽬)
    19.072 Sec.(2回⽬)
    Tf.keras + ImageDataGenerator
    (データ拡張あり)
    259.82 Sec. 261.05 Sec
    261.81 Sec. (Profiling)
    Tf.data/map.cache.shuffle.repeat.
    map(aug).batch.prefetch
    (データ拡張あり)
    24.218 Sec. 20.184 Sec.
    22.493 Sec. (Profiling)

    View Slide

  25. PROFILING

    View Slide

  26. ProfilingでGPUの使⽤状況を
    可視化する
    ■ かつてはnvprofとNVIDIA Visual Profiler(nvvp)が使われて
    いたが、最近のGPUでは動かないらしい
    ■ NVIDIA Nsight Systemsを使⽤してプロファイリング
    ■ https://developer.nvidia.com/nsight-systems
    ■ ローカルシステムやリモートシステムにSSHで接続しても
    プロファイリング可能だが、今回はDocker環境のため、
    CLIのnsysをDocker内で起動してプロファイルを取得した。

    View Slide

  27. tf.keras + ImageDataGenerator

    View Slide

  28. tf.data + map.cache.shuffle.repeat.batch.prefetch
