What's new in Jetpack Google IO 22

GDSC HUFS Google I/O 22 Extended 발표자료 입니다.

Transcript

1. #androidjetpack What’s New in Jetpack Jaesung Lee GDSC HUFS
2. Adobe Stock#243026154 GDSC HUFS HUFS I.C.E Android Developer Jaesung Lee @jdoongxx @JaesungLeee
3. https://www.youtube.com/watch?v=jTd82lcuHTU Google I/O 22
6. Activity AppCompat Camera Compose DataBinding Fragment Hilt LifeCycle MaterialDesignComponent Navigation Paging Room Test WorkManager WindowManager DataStore Prerference BenchMark Core Emoji2 RecyclerView ConstraintLayout Media Macrobenchmark JankStats SavedState BaselineProfiles https://developer.android.com/jetpack/androidx/explorer?case=all
7. Rewritten from Java to Kotlin Support for Kotlin! Google I/O 2017 https://android-developers.googleblog.com/2017/05/android-announces-support-for-kotlin.html
8. TimeLine 2017 Kotlin 2018 KTX Android Jetpack Official Language
9. TimeLine 2017 Kotlin 2018 KTX Android Jetpack 2019 BenchMark Kotlin first! Official Language Many New Jetpack APIs and features will be offered first in Kotlin!
10. TimeLine 2017 Kotlin 2018 KTX Android Jetpack 2019 BenchMark Kotlin first! Official Language 2020 Paging3 Window DataStore https://developer.android.com/jetpack/androidx/versions/alpha-channel#august_11_2020 Compose
11. TimeLine 2017 Kotlin 2018 KTX 2019 BenchMark 2020 Paging3 2022 Navigation 2.4 Annotation 1.4 Collection 1.2 Fragment 1.4 Activity 1.4 Partially rewritten by Kotlin!
12. // Navigation.java public final class Navigation { @NonNull public static View.OnClickListener createNavigateOnClickListener( @IdRes final int resId) { return createNavigateOnClickListener(resId, null); } @NonNull public static View.OnClickListener createNavigateOnClickListener( @IdRes final int resId, @Nullable final Bundle args) { return new View.OnClickListener() { @Override public void onClick(View view) { findNavController(view).navigate(resId, args); } }; } }
13. // Navigation.kt public object Navigation { @JvmStatic @JvmOverloads public fun createNavigateOnClickListener( @IdRes resId: Int, args: Bundle? = null ): View.OnClickListener { return View.OnClickListener { view -> findNavController(view).navigate(resId, args) } } }
14. TimeLine 2017 Kotlin 2018 KTX Android Jetpack 2019 BenchMark Kotlin first! Official Language 2020 Paging3 Window DataStore Compose https://developer.android.com/jetpack/androidx/versions/alpha-channel#august_11_2020 2022 Navigation 2.4 Annotation 1.4 Collection 1.2 Fragment 1.4 Activity 1.4 2023 (?) Room 2.5 Work 2.8 SavedState 1.2 …
15. // WorkManager 2.7.1 val constraints = Constraints.Builder() .setRequiresCharging(true) .setRequiresBatteryNotLow(true) .setRequiresDeviceIdle(true) .build() // WorkManager 2.8.0-alpha02 val constraints = Constraints( requiresCharging = true, requiresBatteryNotLow = true, requiresDeviceIdle = true, ) Enhanced APIs for Kotlin users!
16. Room, WorkManager, and more… Android Architecture Components
17. androidx.room:room:2.4.2 Room Stable Database persistence layer designed for usability, safety, and testability
18. Room Stable Auto Migrations Support for Kotlin 1.6 Room written in Kotlin starting from 2.5.0 Performance Improvements with KSP in 2.4.0 Room-Paging Support (Paging 3.0) Relational Query Methods androidx.room:room:2.4.2 https://developer.android.com/jetpack/androidx/releases/room#2.4.0
19. // Auto Migrations @Database( version = 2, entities = [User::class], autoMigrations = [ AutoMigration ( from = 1, to = 2, spec = AppDatabase.MyAutoMigration::class ) ] ) abstract class AppDatabase : RoomDatabase() { @RenameTable(fromTableName = "User", toTableName = "AppUser") class MyAutoMigration : AutoMigrationSpec } https://developer.android.com/training/data-storage/room/migrating-db-versions#automated
20. // Supports multimap return types // like Map, SparseArray, LongSparseArray, etc. // 1:1 Relation Map @Query("SELECT * FROM Song JOIN Artist ON Song.artistId = Artist.artistId") fun getSongAndArtist(): Map<Song, Artist> // 1:N Relation Map @Query("SELECT * FROM Artist JOIN Album ON Artist.id = Album.artistId") fun getArtistAndAlbums(): Map<Artist, List<Album>> https://developer.android.com/training/data-storage/room/accessing-data#multimap
21. androidx.paging:paging:3.1.1 Paging Stable Load and display small chunks of data to improve network and system resources consumption.
22. Paging Stable Stable support for Rx and Guava integrations Improvements to handling of invalid or stale data More comprehensive callbacks New introductory codelab for Paging 3 androidx.paging:paging:3.1.1 https://developer.android.com/jetpack/androidx/releases/paging#3.1.0
23. androidx.navigation:navigation:2.4.1 Navigation Stable Framework for navigating between destinations within an app, now with multiple backstacks
24. Navigation Stable Integration between Navigation with Jetpack Compose Support for Multiple Back Stacks Support for two-pane layouts All artifacts rewritten in Kotlin androidx.navigation:navigation:2.4.2 https://developer.android.com/jetpack/androidx/releases/navigation#2.4.0
25. Adobe Stock#243026154 Phone Tablet
26. class NavigationActivity : AppCompatActivity(R.layout.activity_navigation) <!-- res/layout/activity_navigation.xml --> <androidx.fragment.app.FragmentContainerView android:id="@+id/nav_host_fragment" android:name="androidx.navigation.fragment.NavHostFragment" app:navGraph="@navigation/main_nav_graph" app:defaultNavHost="true" ... /> <!-- res/navigation/main_nav_graph.xml --> <navigation app:startDestination="@+id/two_pane"> <fragment android:id="@+id/two_pane" android:name="com.example.navigation.TwoPaneFragment" /> </navigation> https://github.com/CesarValiente/navigation-foldable
27. https://github.com/CesarValiente/navigation-foldable class TwoPaneFragment : AbstractListDetailFragment() { override fun onCreateListPaneView( inflater: LayoutInflater, container: ViewGroup?, savedInstanceState: Bundle? ): View { return ListPaneBinding.inflate(inflater, container, false) } override fun onListPaneViewCreated(view: View, savedInstanceState: Bundle?) { oneFragmentButton.setOnClickListener { openDetails(R.id.one_fragment) } } ... } <!-- res/layout/list_pane.xml --> <Button android:id="@+id/one_fragment_button android:text="Fragment ONE" />
28. class TwoPaneFragment : AbstractListDetailFragment() { ... private fun openDetails(destinationId: Int) { val detailNavController = detailPaneNavHostFragment.navController detailNavController.navigate( resId = destinationId, args = null, navOptions = navOptions { popUpTo(detailNavController.graph.startDestinationId) { inclusive = true } } ) slidingPaneLayout.open() } override fun onCreateDetailPaneNavHostFragment(): NavHostFragment { return NavHostFragment.create(R.navigation.detail_pane_nav_graph) } } https://github.com/CesarValiente/navigation-foldable
29. <!-- res/navigation/detail_pane_nav_graph.xml --> <navigation app:startDestination="@+id/one_fragment"> <fragment android:id="@+id/one_fragment" android:name="com.example.navigation.OneFragment" /> <fragment android:id="@+id/two_fragment" android:name="com.example.navigation.TwoFragment" /> <fragment android:id="@+id/three_fragment" android:name="com.example.navigation.ThreeFragment" /> </navigation> class OneFragment : Fragment(R.layout.one_fragment) class TwoFragment : Fragment(R.layout.two_fragment) class ThreeFragment : Fragment(R.layout.three_fragment) https://github.com/CesarValiente/navigation-foldable
30. androidx.datastore:datastore:1.0.0 DataStore Stable Data storage solution that provides a simple, robust alternative to SharedPreferences
31. DataStore Stable MAD Skills: DataStore goo.gle/mad-skills-datastore How to migrate from SharedPreferences to Proto DataStore. d.android.com/codelabs/android-proto-datastore#7 androidx.datastore:datastore:1.0.0 https://developer.android.com/jetpack/androidx/releases/datastore#1.0.0
32. Lifecycle Stable Deprecated @OnLifecycleEvent Integration between ViewModel and Jetpack Compose Restartable Lifecycle-aware coroutines androidx.lifecycle:lifecycle:2.4.1 https://developer.android.com/jetpack/androidx/releases/lifecycle RC androidx.lifecycle:lifecycle:2.5.0+ ViewModel CreationExtras
33. // You can use DefaultLifecycleObserver or LifecycleEventObserver instead. - class MyObserver(...) : LifecycleObserver { + class MyObserver(...) : DefaultLifecycleObserver { - @OnLifecycleEvent(Lifecycle.Event.ON_RESUME) fun onResume() { ... } - @OnLifecycleEvent(Lifecycle.Event.ON_PAUSE) fun onPause() { ... } } https://developer.android.com/training/data-storage/room/accessing-data#multimap Stable
34. // Restartable Lifecycle-aware coroutines viewLifecycleOwner.lifecycleScope.launch { viewLifecycleOwner.repeatOnLifecycle(Lifecycle.State.STARTED) { viewModel.someDataFlow.collect { // Process item } } } https://developer.android.com/topic/libraries/architecture/coroutines#restart Stable
35. // Lifecycle-aware flow collection viewLifecycleOwner.lifecycleScope.launch { exampleProvider.exampleFlow() .flowWithLifecycle(viewLifecycleOwner.lifecycle, Lifecycle.State.STARTED) .collect { // Process the value. } } viewLifecycleOwner.lifecycleScope.launch { viewLifecycleOwner.repeatOnLifecycle(Lifecycle.State.STARTED) { launch { flow1.collect { /* Process the value. */ } } launch { flow2.collect { /* Process the value. */ } } } } https://developer.android.com/topic/libraries/architecture/coroutines#lifecycle-aware Stable
36. // current class MyActivity : AppCompatActivity() { private val viewModel: MyViewModel by viewModels() ... } class MyViewModel( private val savedStateHandle: SavedStateHandle, ) : ViewModel() { fun loadData(id: String) { ... } } RC
37. // current class MyActivity : AppCompatActivity() { private val viewModel: MyViewModel by viewModels() override fun getDefaultViewModelProviderFactory(): ViewModelProvider.Factory { return super.getDefaultViewModelProviderFactory() // SavedStateViewModelFactory } } class MyViewModel( private val savedStateHandle: SavedStateHandle, ) : ViewModel() { fun loadData(id: String) { ... } } RC
38. class MyActivity : AppCompatActivity() { private val viewModel: MyViewModel by viewModels() } class MyViewModel( private val savedStateHandle: SavedStateHandle, + private val id: String, ) : ViewModel() { - fun loadData(id: String) { - ... - } } https://developer.android.com/topic/libraries/architecture/coroutines#restart RC
39. class MyActivity : AppCompatActivity() { + private val key = object : CreationExtras.Key<String> {} private val factory = object : ViewModelProvider.Factory { @Suppress("UNCHECKED_CAST") override fun <T : ViewModel> create( modelClass: Class<T>, + extras: CreationExtras, ): T { val savedStateHandle = extras.createSavedStateHandle() + val id = extras[key].orEmpty() return MainViewModel( savedStateHandle = savedStateHandle, + id = id, ) as T } } override fun getDefaultViewModelProviderFactory(): ViewModelProvider.Factory = factory ... } https://pluu.github.io/blog/android/2022/03/12/creationextras/ RC
40. MAD Skills : Architecture Stable Materials on the best practices for Modern Android Development (MAD) http://goo.gle/mad-skills-architecture
41. Baseline profiles, JankStats, Benchmarking and more.. Performance
42. androidx.metrics:metrics-performance JankStats Alpha Track and analyze jank performance problems in your app’s UI
43. JankStats Alpha Compatible down to API Level 16 Identifies performance issues using internal heuristics Provides UI context to attribute data to user states and actions Reports results on every frame via a listener androidx.metrics:metrics-performance:1.0.0-alpha01 https://developer.android.com/topic/performance/jankstats
44. androidx.profilesinstaller:profileinstaller:1.1.0 Baseline Profiles Stable Create profiles for your app that prepopulate ahead of time compilation tracest to reduce startup times and reduce jank
45. Baseline Profiles Stable Provide custom profile rules in apps and libraries Startup and jank performance improvements Profiles added to popular Jetpack libraries androidx.profileinstaller:profileinstaller:1.1.0 https://developer.android.com/jetpack/androidx/releases/navigation#2.4.0
46. androidx.benchmark:benchmark-macro:1.1.0 Macrobenchmark Stable Accurately measure app startup and scrolling performance, both locally and in CI
47. Macrobenchmark Stable Now supports down to API Level 23 Add custom trace-based timing measurement with TraceSectionMetric Allow detection of audio underruns with AudioUnderrunMetric Added BaselineProfileRule to generate profiles for critical workflows androidx.benchmark:benchmark-macro:1.1.0 https://developer.android.com/topic/performance/benchmarking/macrobenchmark-overview
48. androidx.tracing:tracing:1.1.0 Tracing Stable Write trace events to the system trace buffer
49. LargeScreen, WindowManager, AppCompat and more.. User Interface
50. androidx.slidingpanelayout:slidingpanelayout:1.2.0 SlidingPaneLayout Stable supports showing two panes side by side on larger devices and foldables, while automatically adapting to show only one pane at a time on smaller devices
51. SlidingPaneLayout Stable Support for two-pane UX For Large Screen androidx.slidingpanelayout :slidingpanelayout:1.2.0 https://d.android.com/jetpack/androidx/releases/slidingpanelayout#1.2.0
52. <!-- two_pane.xml --> <androidx.slidingpanelayout.widget.SlidingPaneLayout xmlns:android="http://schemas.android.com/apk/res/android" android:id="@+id/sliding_pane_layout" android:layout_width="match_parent" android:layout_height="match_parent"> <!-- Left Pane --> <androidx.recyclerview.widget.RecyclerView android:id="@+id/list_pane" android:layout_width="280dp" android:layout_height="match_parent" android:layout_gravity="start"/> <!-- Right Pane --> <androidx.fragment.app.FragmentContainerView android:id="@+id/detail_container" android:layout_width="300dp" android:layout_weight="1" android:layout_height="match_parent" android:background="#ff333333" android:name="com.example.SelectAnItemFragment" /> </androidx.slidingpanelayout.widget.SlidingPaneLayout> https://developer.android.com/guide/topics/ui/layout/twopane
53. <!-- two_pane.xml --> <androidx.slidingpanelayout.widget.SlidingPaneLayout xmlns:android="http://schemas.android.com/apk/res/android" android:id="@+id/sliding_pane_layout" android:layout_width="match_parent" android:layout_height="match_parent"> <!-- Left Pane --> <androidx.recyclerview.widget.RecyclerView android:id="@+id/list_pane" android:layout_width="280dp" android:layout_height="match_parent" android:layout_gravity="start"/> <!-- Right Pane --> <androidx.fragment.app.FragmentContainerView android:id="@+id/detail_container" android:layout_width="300dp" android:layout_weight="1" android:layout_height="match_parent" android:background="#ff333333" android:name="com.example.SelectAnItemFragment" /> </androidx.slidingpanelayout.widget.SlidingPaneLayout> https://developer.android.com/guide/topics/ui/layout/twopane
54. // A method on the Fragment that owns the SlidingPaneLayout, // called by the adapter when an item is selected. fun openDetails(itemId: Int) { childFragmentManager.commit { setReorderingAllowed(true) replace<ItemFragment>(R.id.detail_container, bundleOf("itemId" to itemId)) // If we're already open and the detail pane is visible, // crossfade between the fragments. if (binding.slidingPaneLayout.isOpen) { setTransition(FragmentTransaction.TRANSIT_FRAGMENT_FADE) } } binding.slidingPaneLayout.open() } https://developer.android.com/guide/topics/ui/layout/twopane
55. androidx.window:window:1.0.0 WindowManager Stable Support new device form factors and multi-window environments
56. Supports foldable phones to adjust how content is displayed Smart layout avoids placing content in occluded areas Already integrated into SlidingPaneLayout WindowManager Stable androidx.window:window:1.0.0 https://developer.android.com/jetpack/androidx/releases/window#1.0.0
57. androidx.preference:preference:1.2.0 Preference Stable Support users to change the functionality and behavior of an application
58. Stable Preference Support for two-pane preference androidx.preference:preference:1.2.0 https://d.android.com/jetpack/androidx/releases/preference#1.2.0 https://github.com/CesarValiente/preferences-foldable
59. Adobe Stock#243026154 Phone Tablet
60. class PreferenceActivity : AppCompatActivity(R.layout.activity_preference) <!-- res/layout/activity_preference.xml --> <androidx.fragment.app.FragmentContainerView android:name="com.example.preferences.TwoPanePreference" ... /> class TwoPanePreference : PreferenceHeaderFragmentCompat() { override fun onCreatePreferenceHeader(): PreferenceFragmentCompat { return HeaderPreference() } } class HeaderPreference : PreferenceFragmentCompat() { override fun onCreatePreferences(savedInstanceState: Bundle?, rootKey: String?) { setPreferencesFromResource(R.xml.preferences, rootKey) } } https://github.com/CesarValiente/preferences-foldable
61. <!-- res/xml/preference.xml --> <PreferenceScreen> <Preference android:fragment="com.example.preferences.OneFragment" android:key="pref_one" ... /> <Preference android:fragment="com.example.preferences.TwoFragment" android:key="pref_two" ... /> <Preference android:fragment="com.example.preferences.ThreeFragment" android:key="pref_three" ... /> </PreferenceScreen> https://github.com/CesarValiente/preferences-foldable
62. androidx.dragandrop:draganddrop DragAndDrop Stable Accept drag-and-drop data with a consistent user experience
63. DragAndDrop Stable Simplifies ingesting dropped data Drop target highlighting androidx.draganddrop:draganddrop:1.0.0 https://developer.android.com/jetpack/androidx/releases/draganddrop#1.0.0
64. // Use the DragStartHelper class to easily support initiating drag and drop in response to // both long press and mouse drag events. Note the call to attach() at the end. Without it, // the listener would never actually be attached to the view. Also note that attach() replaces // any OnTouchListener or OnLongClickListener already attached to the view. DragStartHelper(binding.textDragItem) { view, _ -> val text = (view as TextView).text // Create the ClipData to be shared val dragClipData = ClipData.newPlainText(/*label*/"Text", text) // Use the default drag shadow val dragShadowBuilder = View.DragShadowBuilder(view) // Initiate the drag. Note the DRAG_FLAG_GLOBAL, which allows for drag events to be istened // to by apps other than the source app. view.startDragAndDrop(dragClipData, dragShadowBuilder, null, DRAG_FLAG_GLOBAL) }.attach() https://github.com/android/user-interface-samples/tree/main/DragAndDrop
65. DropHelper.configureView( /* activity */ this, binding.textDropTarget, /* mimeTypes */ arrayOf( ClipDescription.MIMETYPE_TEXT_PLAIN, "application/x-arc-uri-list" // Support external items on Chrome OS Android 9 ), DropHelper.Options.Builder() .setHighlightColor(getColor(R.color.purple_300)) .build() ) { view, payload -> resetDropTarget() val item = payload.clip.getItemAt(0) val (_, remaining) = payload.partition { it == item } if (payload.clip.description.hasMimeType(MIMETYPE_TEXT_PLAIN) { binding.textDropTarget.text = item.text } // Allow the system to handle any remaining ClipData.Item objects if applicable // remaining } https://github.com/android/user-interface-samples/tree/main/DragAndDrop
66. androidx.appcompat:appcompat AppCompat Stable Access the latest foundational UI features from earlier API levels
67. AppCompat Stable Emoji2 integration allows default support for the latest emojis Custom locale selection backported from Tiramisu (Android 13) Uses Play splits to download additional locales androidx.appcompat:appcompat:1.4.2 https://developer.android.com/guide/topics/ui/look-and-feel/emoji2 androidx.appcompat:appcompat:1.6.0+
68. // Get app locales val locales: LocaleListCompat = AppCompatDelegate.getApplicationLocales() // Set app locales val locales: LocaleListCompat = LocaleListCompat.forLanguageTags("xx-YY") // or LocaleListCompat.create(Locale.KOREA) AppCompatDelegate.setApplicationLocales(locales) https://developer.android.com/about/versions/13/features/app-languages#androidx-impl
69. override fun attachBaseContext(newBase: Context) { if (SDK_INT < 33) { // Preferred locales are managed automatically on API level 33+, // but we need to load them manually on earlier platform versions. val locales = loadLocalesFromPreferences() AppCompatDelegate.setApplicationLocales(locales) } super.attachBaseContext(newBase) } <service android:name="androidx.appcompat.app.AppLocalesMetadataHolderService" android:enabled="false" android:exported="false"> <meta-data android:name="autoStoreLocales" android:value="true" /> </service> https://developer.android.com/about/versions/13/features/app-languages#androidx-impl
70. override fun attachBaseContext(newBase: Context) { if (SDK_INT < 33) { // Preferred locales are managed automatically on API level 33+, // but we need to load them manually on earlier platform versions. val locales = loadLocalesFromPreferences() AppCompatDelegate.setApplicationLocales(locales) } super.attachBaseContext(newBase) } <service android:name="androidx.appcompat.app.AppLocalesMetadataHolderService" android:enabled="false" android:exported="false"> <meta-data android:name="autoStoreLocales" android:value="true" /> </service> https://developer.android.com/about/versions/13/features/app-languages#androidx-impl
71. androidx.constraintlayout:constraintlayout:2.2.0+ ConstraintLayout Stable Allows to create large and complex layouts with a flat view hierarchy
72. ConstraintLayout Alpha Support Grid Helper Androidx.constraintlayout: constraintlayout:2.2.0+ https://github.com/androidx/constraintlayout/wiki/What's-New-in-2.2
73. <androidx.constraintlayout.widget.ConstraintLayout> <Button android:id="@+id/clear" android:text="C" /> ... <TextView android:id="@+id/calculatorText" android:background="@color/cardview_shadow_start_color" android:text="100" android:gravity="bottom|right" /> <Button android:id="@+id/btn0" android:text="0" /> ... </androidx.constraintlayout.widget.ConstraintLayout> https://speakerdeck.com/fornewid/whats-new-in-jetpack-2022
74. <androidx.constraintlayout.widget.ConstraintLayout> <androidx.constraintlayout.helper.widget.Grid android:id="@+id/grid" android:layout_width="match_parent" android:layout_height="match_parent" app:constraint_referenced_ids=" calculatorText,btn0, clear,neg,percent,div,btn7,btn8,btn9,mult,btn4, btn5,btn6,sub,btn1,btn2,btn3,plus,btn0,dot,equal" app:grid_columns="4" app:grid_rows="7" app:grid_horizontalGaps="5dp" app:grid_verticalGaps="5dp" app:grid_orientation="horizontal" app:grid_spans="0:2x4,24:1x2" /> </androidx.constraintlayout.widget.ConstraintLayout> https://speakerdeck.com/fornewid/whats-new-in-jetpack-2022
75. <androidx.constraintlayout.widget.ConstraintLayout> <androidx.constraintlayout.helper.widget.Grid android:id="@+id/grid" android:layout_width="match_parent" android:layout_height="match_parent" app:constraint_referenced_ids=" calculatorText,btn0, clear,neg,percent,div,btn7,btn8,btn9,mult,btn4, btn5,btn6,sub,btn1,btn2,btn3,plus,btn0,dot,equal" app:grid_columns="4" app:grid_rows="7" app:grid_horizontalGaps="5dp" app:grid_verticalGaps="5dp" app:grid_orientation="horizontal" app:grid_spans="0:2x4,24:1x2" /> </androidx.constraintlayout.widget.ConstraintLayout> https://speakerdeck.com/fornewid/whats-new-in-jetpack-2022
76. <androidx.constraintlayout.widget.ConstraintLayout> <androidx.constraintlayout.helper.widget.Grid android:id="@+id/grid" android:layout_width="match_parent" android:layout_height="match_parent" app:constraint_referenced_ids=" calculatorText,btn0, clear,neg,percent,div,btn7,btn8,btn9,mult,btn4, btn5,btn6,sub,btn1,btn2,btn3,plus,btn0,dot,equal" app:grid_columns="4" app:grid_rows="7" app:grid_horizontalGaps="5dp" app:grid_verticalGaps="5dp" app:grid_orientation="horizontal" app:grid_spans="0:2x4,24:1x2" /> </androidx.constraintlayout.widget.ConstraintLayout> https://speakerdeck.com/fornewid/whats-new-in-jetpack-2022
77. <androidx.constraintlayout.widget.ConstraintLayout> <androidx.constraintlayout.helper.widget.Grid android:id="@+id/grid" android:layout_width="match_parent" android:layout_height="match_parent" app:constraint_referenced_ids=" calculatorText,btn0, clear,neg,percent,div,btn7,btn8,btn9,mult,btn4, btn5,btn6,sub,btn1,btn2,btn3,plus,btn0,dot,equal" app:grid_columns="4" app:grid_rows="7" app:grid_horizontalGaps="5dp" app:grid_verticalGaps="5dp" app:grid_orientation="horizontal" app:grid_spans="0:2x4,24:1x2" /> </androidx.constraintlayout.widget.ConstraintLayout> https://speakerdeck.com/fornewid/whats-new-in-jetpack-2022
78. Now in 1.2 beta! Jetpack Compose
79. > 100 Top 1K apps
80. “All new Play Store features are built on top of this framework. Compose has been instrumental in unlocking better velocity and smoother landings for the app.” 01 “Compose makes it much easier to define our own components and to make their API contracts more explicit, flexible, and intuitive.” 02 “Jetpack Compose is a critical part of our technical strategy. The productivity gains are massive.” 03 Jetpack Compose Google Play Twitter AirBnB
81. Downloadable Fonts androidx.compose.ui:ui-text-google-fonts https://developer.android.com/jetpack/compose/text#downloadable-fonts Compose 1.2
82. val provider = GoogleFont.Provider( providerAuthority = "com.google.android.gms.fonts", providerPackage = "com.google.android.gms", certificates = R.array.com_google_android_gms_fonts_certs ) val MontserratFont = GoogleFont(name = "Montserrat") val MontserratFontFamily = FontFamily( Font(googleFont = MontserratFont, fontProvider = provider) ) Text( fontFamily = MontserratFontFamily, text = "Hello World!" ) https://github.com/android/compose-samples/pull/787
83. Nested Scrolling Interop Compose 1.2 androidx.compose.ui:ui:1.2.0-alpha08 + https://d.android.com/jetpack/compose/interop/compose-in-existing-ui#nested-scrolling
84. Scrolling Compose in View
85. <androidx.coordinatorlayout.widget.CoordinatorLayout> <com.google.android.material.appbar.AppBarLayout> <com.google.android.material.appbar.CollapsingToolbarLayout> <androidx.appcompat.widget.AppCompatImageView /> <androidx.appcompat.widget.Toolbar /> </com.google.android.material.appbar.CollapsingToolbarLayout> </com.google.android.material.appbar.AppBarLayout> <androidx.compose.ui.platform.ComposeView android:id="@+id/compose_view" app:layout_behavior="@string/appbar_scrolling_view_behavior" /> <com.google.android.material.floatingactionbutton.FloatingActionButton /> </androidx.coordinatorlayout.widget.CoordinatorLayout> Nested Scrolling Interop Phase 1: Scrolling compose in cooperating view (I5d1ac)
86. @ExperimentalComposeUiApi class ComposeInAndroidCoordinatorLayout : ComponentActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContentView(R.layout.compose_in_android_coordinator_layout) findViewById<ComposeView>(R.id.compose_view).apply { setContent { val nestedScrollInterop = rememberNestedScrollInteropConnection(this) LazyColumn(modifier = Modifier.nestedScroll(nestedScrollInterop)) { items(20) { item -> Box(...) { Text(item.toString()) } } } } } } } Nested Scrolling Interop Phase 1: Scrolling compose in cooperating view (I5d1ac)
87. Scrolling View in Compose
88. <!-- res/layout/android_in_compose_nested_scroll_interop.xml —> <FrameLayout> <androidx.recyclerview.widget.RecyclerView android:id="@+id/main_list" android:layout_width="match_parent" android:layout_height="match_parent" /> </FrameLayout> <!-- res/layout/android_in_compose_nested_scroll_interop_list_item.xml —> <FrameLayout> <TextView android:id="@+id/list_item" /> </FrameLayout> Nested Scrolling Interop Phase 2: A scrolling view child inside a compose parent (If7949)
89. val ToolbarHeight = 48.dp @Composable private fun NestedScrollInteropComposeParentWithAndroidChild() { val toolbarHeightPx = with(LocalDensity.current) { ToolbarHeight.roundToPx().toFloat() } val toolbarOffsetHeightPx = remember { mutableStateOf(0f) } val nestedScrollConnection = remember { object : NestedScrollConnection { override fun onPreScroll(available: Offset, source: NestedScrollSource): Offset { val delta = available.y val newOffset = toolbarOffsetHeightPx.value + delta toolbarOffsetHeightPx.value = newOffset.coerceIn(-toolbarHeightPx, 0f) return Offset.Zero } } } ... } Nested Scrolling Interop Phase 2: A scrolling view child inside a compose parent (If7949)
90. @Composable private fun NestedScrollInteropComposeParentWithAndroidChild() { ... Box( Modifier .fillMaxSize() .nestedScroll(nestedScrollConnection) ) { TopAppBar( modifier = Modifier .height(ToolbarHeight) .offset { IntOffset(x = 0, y = toolbarOffsetHeightPx.value.roundToInt()) }, title = { Text("toolbar offset is ${toolbarOffsetHeightPx.value}") } ) ... } ) } Nested Scrolling Interop Phase 2: A scrolling view child inside a compose parent (If7949)
91. @Composable private fun NestedScrollInteropComposeParentWithAndroidChild() { ... AndroidView( { context -> LayoutInflater.from(context) .inflate(R.layout.android_in_compose_nested_scroll_interop, null).apply { with(findViewById<RecyclerView>(R.id.main_list)) { layoutManager = LinearLayoutManager(context, VERTICAL, false) adapter = NestedScrollInteropAdapter() } }.also { ViewCompat.setNestedScrollingEnabled(it, true) } }, modifier = Modifier.padding(top = ToolbarHeight).fillMaxWidth(), ) } Nested Scrolling Interop Phase 2: A scrolling view child inside a compose parent (If7949)
92. Compose in RecyclerView Compose 1.2 androidx.compose.ui:ui-1.2.0-beta02+ androidx.recyclerview:recyclerview:1.3.0-alpha02+ https://d.android.com/jetpack/compose/interop/compose-in-existing-ui#compose-recyclerview
93. // Compose 1.1 + RecyclerView 1.2 import androidx.compose.ui.platform.ComposeView class MyComposeAdapter : RecyclerView.Adapter<MyComposeViewHolder>() { override fun onCreateViewHolder(...): MyComposeViewHolder { return MyComposeViewHolder(ComposeView(parent.context)) } override fun onViewRecycled(holder: MyComposeViewHolder) { + holder.composeView.disposeComposition() } } class MyComposeViewHolder(val composeView: ComposeView) : RecyclerView.ViewHolder(composeView) { init { + composeView.setViewCompositionStrategy( + ViewCompositionStrategy.DisposeOnViewTreeLifecycleDestroyed + ) } } https://d.android.com/jetpack/compose/interop/compose-in-existing-ui#compose-recyclerview
94. // Compose 1.2 + RecyclerView 1.3 import androidx.compose.ui.platform.ComposeView class MyComposeAdapter : RecyclerView.Adapter<MyComposeViewHolder>() { override fun onCreateViewHolder(...): MyComposeViewHolder { return MyComposeViewHolder(ComposeView(parent.context)) } // override fun onViewRecycled(holder: MyComposeViewHolder) { // holder.composeView.disposeComposition() // } } class MyComposeViewHolder(val composeView: ComposeView) : RecyclerView.ViewHolder(composeView) { // init { // composeView.setViewCompositionStrategy( // ViewCompositionStrategy.DisposeOnViewTreeLifecycleDestroyed // ) // } } https://d.android.com/jetpack/compose/interop/compose-in-existing-ui#compose-recyclerview
95. Lazy Layouts Compose 1.2 androidx.compose.foundation:foundation https://developer.android.com/jetpack/compose/lists Lazy Layouts in Compose
96. @OptIn(ExperimentalFoundationApi::class) LazyVerticalGrid( columns = GridCells.Fixed(2), verticalArrangement = Arragement.spaceBy(16.dp), horizontalArrangement = Arragement.spaceBy(16.dp), ) { items(data) { item -> Item(item) } } https://speakerdeck.com/fornewid/whats-new-in-jetpack-2022
97. // New! LazyHorizontalGrid( rows = GridCells.Fixed(2), verticalArrangement = Arragement.spaceBy(16.dp), horizontalArrangement = Arragement.spaceBy(16.dp), ) { items(data) { item -> Item(item) } } https://speakerdeck.com/fornewid/whats-new-in-jetpack-2022
98. Not Available Instead of androidx.recyclerview.widget. StaggeredGridLayoutManager https://issuetracker.google.com/issues/182882362 Staggered Grids
99. Text Magnifier Compose 1.2 androidx.compose.foundation:foundation I30b38, b/139320979
100. Show Layout Bounds immediately Compose 1.2 androidx.compose.ui:ui:1.2.0-beta03 I843d5, b/225937688
101. Tools What’s New in Android Studio Live Edit Recomposition debugging Compose Animation Preview
102. Recommended
103. Thank you! Android Developer / GDSC HUFS HUFS I.C.E @jdoongxx @JaesungLeee https://speakerdeck.com/jaesungleee/whats-new-in-jetpack-2022 viki0114@naver.com https://d.android.com/jetpack https://www.youtube.com/watch?v =jTd82lcuHTU&t=242s Resources Jaesung Lee
