1. jgs
   CSC 307
   Introduction to Software Engineering
   Lecture 12:
   Design Patterns III
   Dr. Javier Gonzalez-Sanchez
   javiergs@calpoly.edu
   www.javiergs.com
   Building 14 -227
   Office Hours: By appointment


   View Slide

2. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 3
   GoF Patterns


   View Slide

3. jgs
   Decorator & Composite
   Design Patterns


   View Slide

4. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 5
   Decorator


   View Slide

5. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 6
   Decorator


   View Slide

6. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 7
   Decorator


   View Slide

7. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 8
   abstract class Component {
   public abstract void operation();
   }
   Component


   View Slide

8. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 9
   class ConcreteComponent extends Component {
   @override
   public void operation() {
   System.out.print("ConcreteComponent-Operation()");
   }
   }
   ConcreteComponent


   View Slide

9. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 10
   abstract class Decorator extends Component {
   protected Component component;
   public void setComponent(Component component) {
   this.component = component;
   }
   @override
   public void operation() {
   if (component != null) {
   component.operation();
   }
   }
   }
   Decorator


   View Slide

10. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 11
    class ConcreteDecoratorA extends Decorator {
    @override
    public void operation() {
    super.operation();
    System.out.println("ConcreteDecoratorA-Operation()”);
    }
    }
    ConcreteDecoratorA


    View Slide

11. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 12
    class ConcreteDecoratorB extends Decorator {
    @override
    public void operation() {
    super.operation();
    addedBehavior();
    System.out.println("ConcreteDecoratorB-Operation()");
    }
    void addedBehavior() {
    }
    }
    ConcreteDecoratorB


    View Slide

12. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 13
    class MainApp {
    static void main() {
    // Create ConcreteComponent and two Decorators
    ConcreteComponent c = new ConcreteComponent();
    ConcreteDecoratorA d1 = new ConcreteDecoratorA();
    ConcreteDecoratorB d2 = new ConcreteDecoratorB();
    // Link decorators
    d1.SetComponent(c);
    d2.SetComponent(d1);
    d2.Operation();
    }
    }
    Main


    View Slide

13. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 14
    class MainApp {
    static void main() {
    // Create ConcreteComponent and two Decorators
    ConcreteComponent c = new ConcreteComponent();
    ConcreteDecoratorA d1 = new ConcreteDecoratorA();
    ConcreteDecoratorB d2 = new ConcreteDecoratorB();
    // Link decorators
    d1.SetComponent(c);
    d2.SetComponent(d1);
    d2.Operation();
    }
    }
    Main
    ConcreteComponent - Operation()
    ConcreteDecoratorA - Operation()
    ConcreteDecoratorB - Operation()


    View Slide

14. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 15
    § Both allow you to change how an object behaves
    § The decorator pattern can be used to make it possible to extend (decorate)
    the functionality of a certain object at runtime.
    § Inheritance adds behavior at compilation-time.
    Decorator vs Inheritance


    View Slide

15. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 16
    Scenario
    CompanionHelper
    CompanionTroll
    Companion


    View Slide

16. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 17
    Scenario
    CompanionHelper
    CompanionTroll
    Companion
    CompanionTrollHelper


    View Slide

17. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 18
    Scenario
    CompanionHelper
    CompanionTroll
    Companion
    CompanionTrollHelper


    View Slide

18. jgs
    Test Yourselves
    Connecting all


    View Slide

19. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 35
    Assignment 03


    View Slide

20. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 36
    Assignment 03


    View Slide

21. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 37
    Assignment 03 - UI
    Main
    JFrame ActionListener
    PlotPanel
    JButton
    Run


    View Slide

22. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 38
    Assignment 03 – Observer Pattern
    Main
    Observable
    PlotPanel
    Run
    Source
    Observer


    View Slide

23. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 39
    Assignment 03 – Decorator Pattern
    Main
    PlotPanel
    Observer
    Worker
    WorkerStandard
    Tool
    ToolLine ToolSquare


    View Slide

24. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 40
    Assignment 03 – Decorator Pattern
    ToolBar
    ToolSquare
    WorkerStandard
    ToolSquare
    WorkerStandar
    WorkerStandar


    View Slide

25. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 41
    Assignment 03 – Singleton Pattern
    PlotPanel
    Run
    << Singleton >>
    Configurator


    View Slide

26. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 42
    Source


    View Slide

27. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 43
    World (1/2)


    View Slide

28. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 44
    World (2/2)


    View Slide

29. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 45
    PlotPanel


    View Slide

30. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 46
    WorkerStandard


    View Slide

31. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 47
    WorkerTool


    View Slide

32. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 48
    WorkerToolLine


    View Slide

33. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 49
    ToolSquare


    View Slide

34. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 50
    Questions


    View Slide

35. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 51
    Office Hours
    Tuesday and Thursday 3 - 5 pm
    But an appointment required
    Sent me an email – javiergs@calpoly.edu


    View Slide

36. jgs


    View Slide

37. jgs
    CSC 307
    Introduction to Software Engineering
    Lab 12:
    Complete Assignment 02
    Dr. Javier Gonzalez-Sanchez
    javiergs@calpoly.edu
    www.javiergs.com
    Building 14 -227
    Office Hours: By appointment


    View Slide

38. jgs
    Part A
    Requirements


    View Slide

39. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 55
    Let’s Work
    Let’s review Assignment 01


    View Slide

40. jgs
    Part B
    Design Patterns


    View Slide

41. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 57
    Project – User selects Cluster and clicks Run
    ✅
    ✅


    View Slide

42. jgs
    CSC 307 Introduction to Software Engineering
    Javier Gonzalez-Sanchez, Ph.D.
    javiergs@calpoly.edu
    Summer 2023
    Copyright. These slides can only be used as study material for the class CSC308 at Cal Poly.
    They cannot be distributed or used for another purpose.


    View Slide
