  1. jgs
    CSE 240
    Introduction to Programming Languages
    Lecture 17: new and delete
    Dr. Javier Gonzalez-Sanchez
    [email protected]
    javiergs.engineering.asu.edu | javiergs.com
    PERALTA 230U
    Office Hours: By appointment

    View Slide

  2. jgs
    Previously

    View Slide

  3. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 3
    jgs
    Example in One File: queue.cpp
    1. #include
    2. using namespace std;
    3. class Queue {
    4. private:
    5. int queue_size;
    6. protected:
    7. int *buffer;
    8. int front;
    9. int rear;
    10. public:
    11. Queue(int v) {
    12. cout<<"constructor\n";
    13. }
    14. void enqueue(int v) {
    15. cout<<"enqueue\n";
    16. }
    17. int dequeue(void){
    18. cout<<"dequeue\n"; return 5;
    19. }
    20. };
    21. int main(){
    22. Queue q1(5);
    23. Queue *q2 = new Queue(5);
    24.
    25. // Access Object
    26. q1.enqueue(2);
    27. q1.enqueue(8);
    28.
    29. // Access Object Pointer
    30. q2->enqueue(25);
    31. int x = q2->dequeue();
    32. return 0;
    33. }

    View Slide

  4. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 4
    jgs
    Example in Two Files: time.h
    1. class Time {
    2. public:
    3. Time(); // constructor
    4. void setTime( int, int ); // set hour, minute
    5. void printMilitary(); // print military time format
    6. void printStandard(); // print standard time format
    7.
    8. private:
    9. int hour; // 0 - 23
    10. int minute; // 0 - 59
    11. };

    View Slide

  5. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 5
    jgs
    Example in Two Files: time.cpp
    1. #include
    2. #include "time.h”
    3. using namespace std;
    4. Time::Time() { // constructor
    5. hour = minute = 0;
    6. }
    7. void Time::setTime( int h, int m) { // Set a new mil Time
    8. hour = ( h >= 0 && h < 24 ) ? h : 0;
    9. minute = ( m >= 0 && m < 60 ) ? m : 0;
    10.}
    11.void Time::printMilitary() { // Print time in military format
    12. cout << ( hour < 10 ? "0" : "" ) << hour << ":"
    13. << ( minute < 10 ? "0" : "" ) << minute; // add "0"
    14.}

    View Slide

  6. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 6
    jgs
    Example in Two Files: time.cpp
    15. void Time::printStandard() { // Print in standard format
    16. cout << ( ( hour == 0 || hour == 12 ) ? 12 : hour % 12 )
    17. << ":" << ( minute < 10 ? "0" : "" ) << minute
    18. << ( hour < 12 ? " AM" : " PM" ) << endl; //endl is equal to “\n”
    19. }
    20.
    21. int main() {
    22. Time t; // new is not mandatory - instantiate object t of class Time
    23. cout << "The initial military time is ";
    24. t.printMilitary();
    25. cout << "\nThe initial standard time is ";
    26. t.printStandard();
    27. t.setTime(15, 27);
    28. cout << "\n\nMilitary time after setTime is ";
    29. t.printMilitary();
    30. cout << "\nStandard time after setTime is ";
    31. t.printStandard();
    32. return 0;
    33. }

    View Slide

  7. jgs
    Next: Memory Management

    View Slide

  8. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 8
    jgs
    Outline
    § static,
    § constructor and destructor,
    § new and delete

    View Slide

  9. jgs
    static

    View Slide

  10. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 10
    jgs
    Example
    1. #include
    2. using namespace std;
    3. class Foo {
    4. public:
    5. void counting();
    6. int getCounterB();
    7. static int counterA;
    8. private:
    9. int counterB;
    10. };
    11.
    12. // initial value to static member variable
    13. int Foo::counterA = 0;
    14. int counter = 0;
    A static variable is shared by all the
    objects from a class. Therefore,
    changes made to a static variable will
    impact all objects from the class

    View Slide

  11. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 11
    jgs
    Example
    1. #include
    2. using namespace std;
    3. class Foo {
    4. public:
    5. void counting();
    6. int getCounterB();
    7. static int counterA;
    8. private:
    9. int counterB;
    10. };
    11.
    12. // initial value to static member variable
    13. int Foo::counterA = 0;
    14. int counter = 0;
    static versus global Variables
    static variables prevents functions
    outside the class to access the
    variable. As a global variable, all
    other functions can read/write it.
    A static variable is shared by all the
    objects from a class. Therefore,
    changes made to a static variable will
    impact all objects from the class

    View Slide

  12. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 12
    jgs
    Example
    18. void Foo::counting() { // Set a new mil Time
    19. counterA++;
    20. counterB++;
    21. }
    22. int Foo::getCounterB() {
    23. return counterB;
    24. }
    25. int main() {
    26. Foo f1, f2, f3;
    27. f1.counting();
    28. f2.counting();
    29. f2.counting();
    30. f3.counting();
    31. cout << Foo::counterA<32. cout << f1.getCounterB()<33. cout << Foo::counterA<34. cout << f2.getCounterB()<35. return 0;
    36. }
    A static variable go out of scope only
    if the program terminated. And it can
    be used even without creating an
    object from the class.

    View Slide

  13. jgs
    Constructors and destructors

    View Slide

  14. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 14
    jgs
    Constructor and Destructor
    A constructor in a class:
    § is a function whose name is same as the class name, and
    § is used to automatically initialize objects.
    A destructor in a class:
    § is a function whose name is same as the class name (with a ~ as prefix), and
    § is used to collect garbage.

    View Slide

  15. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 15
    jgs
    Constructor and Destructor
    #include
    using namespace std;
    class Queue {
    private:
    int queue_size;
    protected:
    int *buffer;
    int front;
    int rear;
    public:
    Queue();
    Queue(int n);
    ~Queue();
    };
    Queue::Queue() { // constructor
    cout << "constructor(void)"<// code...
    }
    Queue::Queue(int n) { // constructor overload
    cout << "constructor (int)"<// code...
    }
    Queue::~Queue(void) {
    cout << "destructor"<// code...
    }
    int main () {
    Queue myQueue1(500);
    Queue myQueue2;
    // more code...
    return 0;
    }

    View Slide

  16. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 16
    jgs
    Constructor and Destructor
    #include
    using namespace std;
    class Queue {
    private:
    int queue_size;
    protected:
    int *buffer;
    int front;
    int rear;
    public:
    Queue();
    Queue(int n);
    ~Queue();
    };
    Queue::Queue() { // constructor
    cout << "constructor(void)"<// code...
    }
    Queue::Queue(int n) { // constructor overload
    cout << "constructor (int)"<// code...
    }
    Queue::~Queue(void) {
    cout << "destructor"<// code...
    }
    int main () {
    Queue myQueue1(500);
    Queue myQueue2;
    // more code...
    return 0;
    }

    View Slide

  17. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 17
    jgs
    When is a destructor called?
    § When a local object (from stack) with block scope goes out of scope.
    § When a program (main function) ends and global or static objects exist (OS
    will collect them anyway).
    § When the destructor is explicitly called.
    § When the delete keyword is called.

    View Slide

  18. jgs
    new and delete

    View Slide

  19. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 19
    jgs
    new and delete
    int main () {
    Queue myQueue2(500);
    // declare a pointer only
    Queue *myQueue;
    // reserve memory for an object
    myQueue = new Queue(500);
    // use the object
    myQueue->enqueue(23);
    myQueue2.enqueue(8);
    // delete will call ~Queue();
    delete myQueue;
    ...
    delete myQueue2;//no needed
    }

    View Slide

  20. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 20
    jgs
    new and delete with constructors and destructors
    #include
    using namespace std;
    class Queue {
    private:
    int queue_size;
    protected:
    int *buffer;
    int front;
    int rear;
    public:
    Queue();
    Queue(int n);
    ~Queue();
    };
    Queue::Queue() { // constructor
    cout << "constructor(void)"<// code...
    buffer = NULL;
    }
    Queue::Queue(int n) { // constructor overload
    cout << "constructor (int)"<// code...
    buffer = new int[queue_size];
    }
    Queue::~Queue(void) {
    cout << "destructor"<// code...
    delete [] buffer;
    }
    int main () {
    Queue myQueue1(500);
    Queue myQueue2;
    Queue *myQueue3 = new Queue(100);
    // more code...
    delete myQueue3;
    return 0;
    }

    View Slide

  21. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 21
    jgs
    Summary
    • If an object is on the stack, instead of on the heap, destructor will be called
    when the object goes out of scope. No delete operation is necessary.
    • All heap objects must be explicitly deleted before leaving the function, if
    they are no longer needed.
    • The function delete will implicitly call the destructor of the class, so that
    an object linked to a variable in the to-be-deleted object can be de-
    allocated too, i.e., using delete for variables created in the class (normally in
    the constructor).

    View Slide

  22. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 22
    jgs
    delete and Array of Objects
    #include
    using namespace std;
    #define size 4
    class arrayObject {
    public:
    int x; double y;
    arrayObject() { cout << "arrayObject's constructor called" << endl; }
    ~arrayObject() { cout << "arrayObject's destructor called" << endl; }
    };
    int main() {
    arrayObject *p, *q; // declare two pointers
    p = new arrayObject[size]; // Create an array of objects
    for (q = p; q < p + size; q++) { // Initialize the objects
    q->x = 10; q->y = 1.5;
    }
    for (q = p; q < p + size; q++) {
    cout << "Element address " << q << " Element x value: " << q->x << endl;
    cout << "Element address " << q << " Element y value: " << q->y << endl;
    }
    delete[] p;
    return 0;
    }

    View Slide

  23. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 23
    jgs
    Summary
    § How do we delete an array of objects?
    We can use a loop to delete each element,
    § However, the language provides a library function to delete all the
    elements one by one without the user to explicitly use a loop:
    delete[] array;

    View Slide

  24. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 24
    jgs
    Summary
    Java
    § Primitive variables (int, float, boolean) use value type.
    § All other variables (string, array, user defined classes) use reference type. (Java uses
    automatic garbage collection).
    C++
    § Both value and reference types exist:
    § if value semantics is used then memory will be allocated on stack. Memory de-
    allocation is done automatically.
    § if reference semantics is used (e.g. variable is a pointer to an object), then memory
    must be allocated explicitly using new and explicitly de-allocated using delete

    View Slide

  25. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 25
    jgs
    Summary
    // in C++
    Report r; // an object is allocated to r
    Report *rp1, *rp2; // two pointers declared
    rp1 = &r; // rp1 points to object r
    rp2 = new Report(); // an object is created, linked to rp2
    // ..
    delete rp2;
    // in Java
    Report r; // an reference is allocated
    r = new Report (); // an object is created and linked to r

    View Slide

  26. Javier Gonzalez-Sanchez | CSE240 | Fall 2021 | 26
    jgs
    Questions

    View Slide

  27. jgs
    CSE 240 Introduction to Programming Languages
    Javier Gonzalez-Sanchez, Ph.D.
    [email protected]
    Fall 2021
    Copyright. These slides can only be used as study material for the class CSE240 at Arizona State University.
    They cannot be distributed or used for another purpose.

    View Slide
