CSC307 Lecture 15

Introduction to Software Engineering
Software Metrics II
(202307)

Transcript

1. jgs
   CSC 307
   Introduction to Software Engineering
   Lecture 15:
   Software Metrics II
   Dr. Javier Gonzalez-Sanchez
   javiergs@calpoly.edu
   www.javiergs.com
   Building 14 -227
   Office Hours: By appointment


   View Slide

2. jgs
   Code Metrics


   View Slide

3. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 4
   Metrics
   Size
   LOC
   eLOC
   lLOC
   Complexity
   Average, Max, Min LOC
   Cyclomatic Complexity
   Software Metrics


   View Slide

4. jgs
   Structural Metrics


   View Slide

5. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 6
   Example A


   View Slide

6. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 7
   Example B


   View Slide

7. jgs
   Abstractness


   View Slide

8. jgs
   Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 10
   § Express the portion of contained abstract types.
   § It is a value 0 to 1:
   0 (only concrete classes) to
   1 (only interfaces and abstract classes)
   Abstractness of a Package


   View Slide

9. jgs
   Instability


   View Slide

10. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 12
    § Indicates whether
    (a) the item is mainly used by others (stable – hard to change); or
    (b) it mainly depends on other items (instable – changeable).
    § It is a value between 0 and 1:
    0 only incoming dependencies to
    1 (only outgoing dependencies)
    Instability


    View Slide

11. jgs
    Distance


    View Slide

12. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 14
    § Distance: how far a package is away from
    the Main Sequence
    § D = A + I – 1
    § Values -1 to 1
    § Absolute Distance |D|
    Distance


    View Slide

13. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 15
    Stable Abstraction Principle
    Abstract
    concrete
    Stable
    Hard to Change
    Only incoming dependencies
    Unstable
    Changeable
    Only outgoing dependencies


    View Slide

14. jgs
    Test Yourselves


    View Slide

15. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 17
    Question
    project3.common.model
    project3.client.UI
    project3.server.controller


    View Slide

16. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 18
    Question


    View Slide

17. jgs
    Key Ideas


    View Slide

18. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 20
    Project Presentation
    Product
    Process You


    View Slide

19. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 21
    Demo of your project.
    Show your project running.
    First Act – Demo


    View Slide

20. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 22
    Taiga à Stories, Backlogs, and Task board
    Stories (INVEST), Sprint backlog, product backlog.
    Estimation (story points)
    Talk about tasks; who is doing what?
    Everybody is doing some programming!
    Show and explain your Burndown Chart.
    Second Act – Your process


    View Slide

21. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 23
    Show your class diagram.
    Use colors as needed
    (Single Responsibility Principle)
    What are the A, I, or D in the new class?
    (show the 2D plot regarding where your classes are in terms of the pain zone)
    Third Act – Software Design


    View Slide

22. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 24
    Show US your GitHub
    Who is doing What?
    (everyone is adding or updating code)
    Show US your Code and Code Metrics
    Are your metrics OK (LOC, eLOC, lLOC, CC)?
    Any significant aspect that you want to share?
    Fourth Act – Code


    View Slide

23. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 25
    Review
    What is Good in the product?
    What is next for the product (next features to be added)?
    (your promise for the next sprint presentation)
    Retrospective (Process & People)
    What went well?
    What did not go well?
    Fifth Act – Review and Retrospective


    View Slide

24. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 26
    Questions


    View Slide

25. jgs
    Javier Gonzalez-Sanchez | CSC 308 | Winter 2023 | 27
    Office Hours
    Tuesday and Thursday 3 - 5 pm
    But an appointment required
    Sent me an email – javiergs@calpoly.edu


    View Slide
