  1. jgs
    CSE 240
    Introduction to Programming Languages
    Lecture 18: Inheritance in C++
    Dr. Javier Gonzalez-Sanchez
    [email protected]
    javiergs.engineering.asu.edu | javiergs.com
    PERALTA 230U
    Office Hours: By appointment

    View Slide

  2. jgs
    Previously …

    View Slide

  3. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 3
    jgs
    new and delete
    int main () {
    Queue myQueue2(500);
    // declare a pointer only
    Queue *myQueue;
    // reserve memory for an object
    myQueue = new Queue(500);
    // use the object
    myQueue->enqueue(23);
    myQueue2.enqueue(8);
    // delete will call ~Queue();
    delete myQueue;
    ...
    delete myQueue2;//no needed
    }

    View Slide

  4. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 4
    jgs
    new and delete with constructors and destructors
    #include
    using namespace std;
    class Queue {
    private:
    int queue_size;
    protected:
    int *buffer;
    int front;
    int rear;
    public:
    Queue();
    Queue(int n);
    ~Queue();
    };
    Queue::Queue() { // constructor
    cout << "constructor(void)"<// code...
    buffer = NULL;
    }
    Queue::Queue(int n) { // constructor overload
    cout << "constructor (int)"<// code...
    buffer = new int[queue_size];
    }
    Queue::~Queue(void) {
    cout << "destructor"<// code...
    delete [] buffer;
    }
    int main () {
    Queue myQueue1(500);
    Queue myQueue2;
    Queue *myQueue3 = new Queue(100);
    // more code...
    delete myQueue3;
    return 0;
    }

    View Slide

  5. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 5
    jgs
    Summary
    • If an object is on the stack, instead of on the heap, destructor will be called
    when the object goes out of scope. No delete operation is necessary.
    • All heap objects must be explicitly deleted before leaving the function, if
    they are no longer needed.
    • The function delete will implicitly call the destructor of the class, so that
    an object linked to a variable in the to-be-deleted object can be de-
    allocated too, i.e., using delete for variables created in the class (normally in
    the constructor).

    View Slide

  6. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 6
    jgs
    delete and Array of Objects
    #include
    using namespace std;
    #define size 4
    class arrayObject {
    public:
    int x; double y;
    arrayObject() { cout << "arrayObject's constructor called" << endl; }
    ~arrayObject() { cout << "arrayObject's destructor called" << endl; }
    };
    int main() {
    arrayObject *p, *q; // declare two pointers
    p = new arrayObject[size]; // Create an array of objects
    for (q = p; q < p + size; q++) { // Initialize the objects
    q->x = 10; q->y = 1.5;
    }
    for (q = p; q < p + size; q++) {
    cout << "Element address " << q << " Element x value: " << q->x << endl;
    cout << "Element address " << q << " Element y value: " << q->y << endl;
    }
    delete[] p;
    return 0;
    }

    View Slide

  7. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 7
    jgs
    Summary
    § How do we delete an array of objects?
    We can use a loop to delete each element,
    § However, the language provides a library function to delete all the
    elements one by one without the user to explicitly use a loop:
    delete[] array;

    View Slide

  8. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 8
    jgs
    Summary
    Java
    § Primitive variables (int, float, boolean) use value type.
    § All other variables (string, array, user defined classes) use reference type. (Java uses
    automatic garbage collection).
    C++
    § Both value and reference types exist:
    § if value semantics is used then memory will be allocated on stack. Memory de-
    allocation is done automatically.
    § if reference semantics is used (e.g. variable is a pointer to an object), then memory
    must be allocated explicitly using new and explicitly de-allocated using delete

    View Slide

  9. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 9
    jgs
    Summary
    // in C++
    Report r; // an object is allocated to r
    Report *rp1, *rp2; // two pointers declared
    rp1 = &r; // rp1 points to object r
    rp2 = new Report(); // an object is created, linked to rp2
    // ..
    delete rp2;
    // in Java
    Report r; // an reference is allocated
    r = new Report (); // an object is created and linked to r

    View Slide

  10. jgs
    Inheritance

    View Slide

  11. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 11
    jgs
    Inheritance
    § Can be used for defining new classes by extending existing classes
    § Java: parent (super) class and child (sub) class
    § C++: base class and derived class
    § New class inherits existing members (variables and functions) and may add
    members or redefine members

    View Slide

  12. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 12
    jgs
    Example
    #include
    using namespace std;
    class Base {
    public:
    Base(int n) {
    cout << "Base constructor"<}
    void function() {
    cout << "fuction"<}
    ~Base() {
    cout << "Base destructor"<}
    };
    class Derived : public Base {
    public:
    // constructor calls constructor base
    Derived(int n) : Base(n) {
    cout << "Derived constructor"<}
    ~Derived() {
    cout << "Derived destructor"<}
    };

    View Slide

  13. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 13
    jgs
    Example
    #include
    using namespace std;
    class Base {
    public:
    Base(int n) {
    cout << "Base constructor"<}
    void function() {
    cout << "fuction"<}
    ~Base() {
    cout << "Base destructor"<}
    };
    class Derived : public Base {
    public:
    // constructor calls constructor base
    Derived(int n) : Base(n) {
    cout << "Derived constructor"<}
    ~Derived() {
    cout << "Derived destructor"<}
    };

    View Slide

  14. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 14
    jgs
    Example
    int main() {
    Derived myPQ1(50);
    myPQ1.function(); // inherited
    myPQ1.function(); // inherited
    Derived *myPQ2;
    myPQ2 = new Derived(50);
    myPQ2->function(); // inherited
    myPQ2->function(); // inherited
    delete myPQ2;
    }

    View Slide

  15. jgs
    One more thing about Inheritance

    View Slide

  16. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 16
    jgs
    Multiple Inheritance
    § A class can inherit members from more than one class;
    § The semantics of multiple inheritances is complex and error prone. It must be used
    with caution.
    § The diamond problem
    name and age
    needed only once

    View Slide

  17. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 17
    jgs
    Example
    #include
    using namespace std;
    class A {
    public:
    A() { cout << "A's constructor called" << endl; }
    };
    class B {
    public:
    B() { cout << "B's constructor called" << endl; }
    };
    class C: public B, public A { // Note the order
    public:
    C() { cout << "C's constructor called" << endl; }
    };
    int main() {
    C c;
    return 0;
    }

    View Slide

  18. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 18
    jgs
    Polymorphism
    A pointer to a derived class is type-compatible with a pointer to its base class.
    // pointers to base class
    #include
    using namespace std;
    class Figure {
    protected:
    int width, height;
    public:
    void set_values (int a, int b) {width=a; height=b;}
    int area () { return 0; }
    };
    class Rectangle: public Figure {
    public:
    int area() { return width*height;}
    };
    class Triangle: public Figure {
    public:
    int area() { return width*height/2; }
    };
    int main () {
    Rectangle rectangle;
    Triangle triangle;
    Figure * f1 = &rectangle;
    Figure * f2 = &triangle;
    f1->set_values (10,20);
    f2->set_values (30,40);
    cout << rectangle.area() << "\n";
    cout << triangle.area() << "\n";
    cout << f1->area() << '\n';
    cout << f2->area() << '\n';
    return 0;
    }

    View Slide

  19. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 19
    jgs
    Polymorphism
    A virtual member is a member function for which dynamic dispatch is facilitated.
    // pointers to base class
    #include
    using namespace std;
    class Figure {
    protected:
    int width, height;
    public:
    void set_values (int a, int b) {width=a; height=b;}
    virtual int area () { return 0; }
    };
    class Rectangle: public Figure {
    public:
    int area() { return width*height;}
    };
    class Triangle: public Figure {
    public:
    int area() { return width*height/2; }
    };
    int main () {
    Rectangle rectangle;
    Triangle triangle;
    Figure * f1 = &rectangle;
    Figure * f2 = &triangle;
    f1->set_values (10,20);
    f2->set_values (30,40);
    cout << rectangle.area() << "\n";
    cout << triangle.area() << "\n";
    cout << f1->area() << '\n';
    cout << f2->area() << '\n';
    return 0;
    }

    View Slide

  20. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 20
    jgs
    Questions

    View Slide

  21. Javier Gonzalez-Sanchez | CSE240 | Spring 2018 | 21
    jgs
    Questions

    View Slide

  22. jgs
    CSE 240 Introduction to Programming Languages
    Javier Gonzalez-Sanchez, Ph.D.
    [email protected]
    Fall 2021
    Copyright. These slides can only be used as study material for the class CSE240 at Arizona State University.
    They cannot be distributed or used for another purpose.
