  1. jgs
    SER 431
    Advanced Graphics
    Lecture 07: Environment
    Javier Gonzalez-Sanchez
    [email protected]
    PERALTA 230U
    Office Hours: By appointment

    View Slide

  2. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 1
    jgs
    Fog

    View Slide

  3. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 2
    jgs
    Fog

    View Slide

  4. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 3
    jgs
    Add this Code to your init() method
    glEnable(GL_FOG);
    // specifies the equation to be used to compute the fog blend factor.
    // GL_LINEAR, GL_EXP, and GL_EXP2.
    // initial fog mode is GL_EXP
    glFogi(GL_FOG_MODE, GL_LINEAR);
    // the fog color. Color components are in the range [0,1].
    // the initial fog color is (0, 0, 0, 0).
    GLfloat fogColor[4] = { 0.5, 0.5, 0.5, 1.0 };
    glFogfv(GL_FOG_COLOR, fogColor);
    //Used in exponential fog equations. The initial fog density is 1.
    // Only nonnegative densities are accepted.
    glFogf(GL_FOG_DENSITY, 0.25);
    // the near distance used in the linear fog equation. The initial near distance is 0
    glFogf(GL_FOG_START, 10.0);
    // the far distance used in the linear fog equation. The initial far distance is 1.
    glFogf(GL_FOG_END, 6000.0);

    View Slide

  5. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 4
    jgs
    Fog Mode and Density

    View Slide

  6. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 5
    jgs
    Test Yourselves
    § Test 1. Add fog to your quiz 2
    § Test 2. Add a menu that allows enable/disable the fog

    View Slide

  7. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 6
    jgs
    Reflection and Shadows

    View Slide

  8. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 7
    jgs
    Reflection and Shadows
    We will use the Stencil Buffer

    View Slide

  9. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 8
    jgs
    Buffers (Color + Depth)
    § An extra data buffer, in addition to the color buffer and depth buffer
    § Depth-buffer. it keep track of the depth of every pixel on the screen

    View Slide

  10. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 9
    jgs
    Buffers (Stencil)
    § Stencil-buffer. it is used to limit the area of rendering (stenciling)
    § Usually contains 8 bits per stencil value that amounts to a total
    of 256 different stencil values

    View Slide

  11. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 10
    jgs
    Example

    View Slide

  12. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 11
    jgs
    Step 1. main()
    // main
    void main(int argc, char* argv[]) {
    glutInit(&argc, argv);
    glutInitDisplayMode(
    GLUT_DEPTH | GLUT_DOUBLE | GLUT_RGBA | GLUT_STENCIL
    );
    // main as usual here...
    }

    View Slide

  13. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 12
    jgs
    Step 2. init()
    // init
    void init() {
    // init as usual here...
    //define the value to use as clean.
    glClearStencil(0);
    }

    View Slide

  14. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 13
    jgs
    Step 3. display()
    void display(void) {
    glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT | GL_STENCIL_BUFFER_BIT);
    //Start using the stencil
    glEnable(GL_STENCIL_TEST);
    //Disable writing colors in frame buffer
    glColorMask(GL_FALSE, GL_FALSE, GL_FALSE, GL_FALSE);
    glStencilFunc(GL_ALWAYS, 1, 1); //Place a 1 where rendered
    //Replace where rendered
    glStencilOp(GL_REPLACE, GL_REPLACE, GL_REPLACE);
    //Render stencil box
    glDisable(GL_DEPTH_TEST);

    View Slide

  15. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 14
    jgs
    glMatrixMode(GL_PROJECTION);
    glLoadIdentity();
    glOrtho(-50.0, 50, -50.0, 50.0, 1.0, -1.0);
    glMatrixMode(GL_MODELVIEW);
    glLoadIdentity();
    glPushMatrix();
    glTranslatef(0, 0, 0);
    glBegin(GL_TRIANGLES);
    glVertex2f(-20.0, -20.0);
    glVertex2f( 20.0, -20.0);
    glVertex2f( 0.0, 20.0);
    glEnd();
    glPopMatrix();

    View Slide

  16. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 15
    jgs
    // re-enable color
    glColorMask(GL_TRUE, GL_TRUE, GL_TRUE, GL_TRUE);
    // where a 1 was not rendered.. try GL_NOTEQUAL
    glStencilFunc(GL_EQUAL, 1, 1);
    // keep the pixel
    glStencilOp(GL_KEEP, GL_KEEP, GL_KEEP);
    glEnable(GL_DEPTH_TEST);
    // display as usual here...
    glDisable(GL_STENCIL_TEST);
    glutSwapBuffers();
    }

    View Slide

  17. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 16
    jgs
    Example

    View Slide

  18. Javier Gonzalez-Sanchez | SER431 | Fall 2018 | 17
    jgs
    Next step

    View Slide

  19. jgs
    SER431 Advanced Graphics
    Javier Gonzalez-Sanchez
    [email protected]
    Fall 2018
    Disclaimer. These slides can only be used as study material for the class SER431 at ASU. They cannot be
    distributed or used for another purpose.
