UP Lecture 19

Compilers
Semantic Analysis II
(202404)

Transcript

1. jgs Compilers Lecture 19: Semantic Analysis II Dr. Javier Gonzalez-Sanchez jgonzalezs@up.edu.mx
2. jgs Previously …
3. Dr. Javier Gonzalez-Sanchez | Compilers | 3 jgs Semantic Analysis 1. Declaration and Unicity. Review for uniqueness and that the variable has been declared before its usage. 2. Types. Review that the types of variables match the values assigned to them. 3. Array’s indexes. Review that the indexes are integers. 4. Conditions. Review that all expressions on the conditions return a boolean value. 5. Return type. Review that the value returned by a method matches the type of the method. 6. Parameters. Review that the parameters in a method match the type and number with the declaration of the method.
4. Dr. Javier Gonzalez-Sanchez | Compilers | 4 jgs A3 :: Parser Update VARIABLE void rule_variable( ) { . . . if (tokens.get(currentToken1).getType().equals(“identifier”)) { SemanticAnalizer.CheckVariable( tokens.get(currentToken-1).getWord(), tokens.get(currentToken).getWord() ); currentToken++; } else { error (6); } . . .
5. Dr. Javier Gonzalez-Sanchez | Compilers | 5 jgs Symbol Table int i; char j; int m; void method(int n, char c) { int n; short l; i = j; i = m; } void method() { int i = 5; int j = i + i; } int k; int method(int i) { if (i>5) { ++i; } while (i + 1) { ++i; } do {++i; } while (i); for (i = 0; m; ++i) { k++; } } name type scope value i int global j char global m int global method-int-char void function n int method-int-char l short method-int-char method void function i int method j int method k int global method-int int function i Int method-int
6. jgs Next
7. Dr. Javier Gonzalez-Sanchez | Compilers | 7 jgs Semantic Analysis 1. Declaration and Unicity. Review for uniqueness and that the variable has been declared before its usage. 2. Types. Review that the types of variables match the values assigned to them. 3. Array’s indexes. Review that the indexes are integers. 4. Conditions. Review that all expressions on the conditions return a boolean value. 5. Return type. Review that the value returned by a method matches the type of the method. 6. Parameters. Review that the parameters in a method match the type and number with the declaration of the method.
8. Dr. Javier Gonzalez-Sanchez | Compilers | 8 jgs Type matching | Example 1 int x, y, z; char p, q, r; float a, b, c; boolean foo; void method() { x = a * c + p; } x * + a c p =
9. Dr. Javier Gonzalez-Sanchez | Compilers | 9 jgs Type matching | Cube fill one sheet for each operator in the language cube
10. Dr. Javier Gonzalez-Sanchez | Compilers | 10 jgs Type matching | Cube OPERATOR int float char strin g boolea n void int float char string boolean void cube
11. Dr. Javier Gonzalez-Sanchez | Compilers | 11 jgs Type matching | Cube OPERATOR + int float char strin g boolea n void int int float X string X X float float float X string X X char X X X string X X string string string string string string X boolean X X X string X X void X X X X X X cube
12. Dr. Javier Gonzalez-Sanchez | Compilers | 12 jgs Type matching | Cube OPERATOR & int float char strin g boolea n void int X X X X X X float X X X X X X char X X X X X X string X X X X X X boolean X X X X boolean X void X X X X X X cube
13. Dr. Javier Gonzalez-Sanchez | Compilers | 13 jgs Type matching | Cube OPERATOR < int float char string boolean void int boolea n boolea n X X X X float boolea n boolea n X X X X char X X X X X X string X X X X X X boolean X X X X X X void X X X X X X cube
14. Dr. Javier Gonzalez-Sanchez | Compilers | 14 jgs Type matching | Cube OPERATOR = int float char strin g boolea n void int OK X X X X X float OK OK X X X X char X X OK X X X string X X X OK X X boolean X X X X OK X void X X X X X OK cube
15. Dr. Javier Gonzalez-Sanchez | Compilers | 15 jgs Type matching | Cube OPERATOR - int float char strin g boolea n void int float X X X X cube (- unary) OPERATOR + int float char strin g boolea n void int int float X string X X float float float X string X X char X X X string X X string string string string string string X boolean X X X string X X void X X X X X X cube (- binary)
16. Dr. Javier Gonzalez-Sanchez | Compilers | 16 jgs Type matching | Example 1 int x, y, z; char p, q, r; float a, b, c; boolean foo; void method() { x = a * c + p; } x * + a c p =
17. Dr. Javier Gonzalez-Sanchez | Compilers | 17 jgs Type matching | Example 2 int a; int c (int b) { return b * 3 * 2 * 1 ; } void main () { a = 1; boolean a= c(14)/2 > 1; } cube for matching types symbol table stack
18. Dr. Javier Gonzalez-Sanchez | Compilers | 18 jgs Programming Assignment 3 Level 2 Reviewing Type Matching
19. Dr. Javier Gonzalez-Sanchez | Compilers | 19 jgs Handwritten Notes / / Definition of the cube of types and operators int cube [][][]; public static int OP_PLUS = 1; public static int OP_MINUS = 2; public static int OP_MULT = 3; / / … public static int INTEGER = 1; public static int FLOAT = 2; / / … cube [OP_PLUS][INTEGER][INTEGER] = INTEGER; cube [OP_PLUS][FLOAT][INTEGER] = FLOAT; cube [OP_PLUS][INTEGER][FLOAT] = FLOAT;
20. Dr. Javier Gonzalez-Sanchez | Compilers | 20 jgs Grammar <PROGRAM> à '{' <BODY> '}’ <BODY> à {<PRINT>';'|<ASSIGNMENT>';'|<VARIABLE>';’|<WHILE>|<IF>|<RETURN>';'} <ASSIGNMENT> à identifier '=' <EXPRESSION> <VARIABLE> à ('int'|'float'|'boolean'|'char’|'string'|'void')identifier <WHILE> à 'while' '(' <EXPRESSION> ')' <PROGRAM> <IF> à 'if' '(' <EXPRESSION> ')' <PROGRAM> ['else' <PROGRAM>] <RETURN> à 'return' <PRINT> à ’print’ ‘(‘ <EXPRESSION> ‘)’ <EXPRESSION> à <X> {'|' <X>} <X> à <Y> {'&' <Y>} <Y> à ['!'] <R> <R> à <E> {('>'|'<'|'=='|'!=') <E>} <E> à <A> {(’+'|'-’) <A>} <A> à <B> {('*'|'/') <B>} <B> à ['-'] <C> <C> à integer | octal | hexadecimal | binary | true | false | string | char | float | identifier|'(' <EXPRESSION> ')'
21. Dr. Javier Gonzalez-Sanchez | Compilers | 21 jgs Error Recovery PROGRAM BODY ASSIGNMENT VARIABLE WHILE IF RETURN PRINT C EXPRESSION X Y R E A B
22. Dr. Javier Gonzalez-Sanchez | Compilers | 22 jgs Assignment 2 | Code C 1. / / except for the open parenthesis SemanticAnalizer.pushStack( tokens.get(currentToken).getToken() );
23. Dr. Javier Gonzalez-Sanchez | Compilers | 23 jgs Parser 1. Store in a flag (operatorWasUSed): Did the operator ‘-’ exist? 2. if (operatorWasUsed) String x = SemanticAnalizer.popStack(); String result = SemanticAnalizer.checkCube (x, “-” ); SemanticAnalizer.pushStack(result); }
24. Dr. Javier Gonzalez-Sanchez | Compilers | 24 jgs Parser 1. Store in a flag (twiceHere): Did we pass this point twice? 3. if (twiceHere) String x = SemanticAnalizer.popStack(); String y = SemanticAnalizer.popStack(); String result = SemanticAnalizer.checkCube (x, y, operator ); SemanticAnalizer.pushStack(result); twiceHere = false; / / reset the flag } 2. Store the operator that creates the loop?
25. Dr. Javier Gonzalez-Sanchez | Compilers | 25 jgs Parser 1. Store in a flag (twiceHere): Did we pass this point twice? 3. if (twiceHere) String x = SemanticAnalizer.popStack(); String y = SemanticAnalizer.popStack(); String result = SemanticAnalizer.checkCube (x, y, operator ); SemanticAnalizer.pushStack(result); twiceHere = false; / / reset the flag } 2. Store the operator that creates the loop?
26. Dr. Javier Gonzalez-Sanchez | Compilers | 26 jgs Parser 1. Store in a flag (twiceHere): Did we pass this point twice? 3. if (twiceHere) String x = SemanticAnalizer.popStack(); String y = SemanticAnalizer.popStack(); String result = SemanticAnalizer.checkCube (x, y, operator ); SemanticAnalizer.pushStack(result); twiceHere = false; / / reset the flag } 2. Store the operator that creates the loop?
27. Dr. Javier Gonzalez-Sanchez | Compilers | 27 jgs Parser 1. Store in a flag (operatorWasUSed): Did the operator ‘-’ exist? 2. if (operatorWasUsed) String x = SemanticAnalizer.popStack(); String result = SemanticAnalizer.checkCube (x, “!” ); SemanticAnalizer.pushStack(result); }
28. Dr. Javier Gonzalez-Sanchez | Compilers | 28 jgs Parser 1. Store in a flag (twiceHere): Did we pass this point twice? 2. if (twiceHere) String x = SemanticAnalizer.popStack(); String y = SemanticAnalizer.popStack(); String result = SemanticAnalizer.checkCube (x, y, “&” ); SemanticAnalizer.pushStack(result); twiceHere = false; / / reset the flag }
29. Dr. Javier Gonzalez-Sanchez | Compilers | 29 jgs Parser 1. Store in a flag (twiceHere): Did we pass this point twice? 2. if (twiceHere) String x = SemanticAnalizer.popStack(); String y = SemanticAnalizer.popStack(); String result = SemanticAnalizer.checkCube (x, y, “&” ); SemanticAnalizer.pushStack(result); twiceHere = false; / / reset the flag }
30. Dr. Javier Gonzalez-Sanchez | Compilers | 30 jgs Assignment 2 | Code String x = SemanticAnalizer.popStack(); String y = SemanticAnalizer.popStack(); String result = SemanticAnalizer.checkCube (x, y, “=” ); if (!result.equals(“OK”) { error(2); }
31. Dr. Javier Gonzalez-Sanchez | Compilers | 31 jgs Homework Programming Final Version of Your Parser
32. Dr. Javier Gonzalez-Sanchez | Compilers | 32 jgs Extra If time allows it start with your Semantic Analyzer (more details/work is coming)
33. Dr. Javier Gonzalez-Sanchez | Compilers | 33 jgs Questions
34. jgs Compilers Javier Gonzalez-Sanchez, Ph.D. jgonzalezs@up.edu.mx Spring 2024 Copyright. These slides can only be used as study material for the Compilers course at Universidad Panamericana. They cannot be distributed or used for another purpose.
