SciTokens: Capability-Based Secure Access to Remote Scientific Data

Presented at PEARC18: https://www.pearc18.pearc.org/
Pre-print: https://arxiv.org/abs/1807.04728
Full Paper: https://doi.org/10.1145/3219104.3219135
Project Home: https://scitokens.org/

Abstract:
The management of security credentials (e.g., passwords, secret keys) for computational science workflows is a burden for scientists and information security officers. Problems with credentials (e.g., expiration, privilege mismatch) cause workflows to fail to fetch needed input data or store valuable scientific results, distracting scientists from their research by requiring them to diagnose the problems, re-run their computations, and wait longer for their results. In this paper, we introduce SciTokens, open source software to help scientists manage their security credentials more reliably and securely. We describe the SciTokens system architecture, implementation design, and initial experimental deployment results to address use cases from the Laser Interferometer Gravitational-Wave Observatory (LIGO) Scientific Collaboration and the Large Synoptic Survey Telescope (LSST) projects. We also present our integration with widely-used software that supports distributed scientific computing, including HTCondor, CVMFS, and XrootD. SciTokens uses IETF-standard OAuth tokens for capability-based secure access to remote scientific data. The access tokens convey the specific authorizations needed by the workflows, rather than general-purpose authentication impersonation credentials, to address the risks of scientific workflows running on distributed infrastructure including NSF resources (e.g., LIGO Data Grid, Open Science Grid, XSEDE) and public clouds (e.g., Amazon Web Services, Google Cloud, Microsoft Azure). By improving the interoperability and security of scientific workflows, SciTokens 1) enables use of distributed computing for scientific domains that require greater data protection and 2) enables use of more widely distributed computing resources by reducing the risk of credential abuse on remote systems.

Transcript

1. SciTokens: Capability-Based Secure
   Access to Remote Scientific Data
   Jim Basney
   https://www.scitokens.org/
   This material is based upon work supported by the National Science Foundation under Grant
   No. 1738962. Any opinions, findings, and conclusions or recommendations expressed in this material
   are those of the author(s) and do not necessarily reflect the views of the National Science Foundation.


   View Slide

2. SciTokens Project
   • The SciTokens project:
   • Introduces a capabilities-based authorization infrastructure
   for distributed scientific computing,
   • Provides a reference platform, combining CILogon, HTCondor,
   CVMFS, and XRootD, and
   • Implements specific use cases to help our science
   stakeholders (LIGO and LSST) better achieve their scientific
   aims.


   View Slide

3. SciTokens uses standards
   • RFC 6749: OAuth 2.0 Authorization Framework
   • token request, consent, refresh
   • RFC 7519: JSON Web Token (JWT)
   • self-describing tokens, distributed validation
   • RFC 8414: OAuth 2.0 Authorization Server Metadata
   • token signing keys, policies, endpoint URLs
   • OAuth 2.0 Token Exchange (IETF OAuth WG I-D)
   • token delegation, drop privileges


   View Slide

4. Example Token, Decoded
   • The decoded token contains
   multiple scopes - basically
   filesystem authorizations.
   • The audience narrows who the
   token is intended for.
   • The issuer identifies who created
   the token; value used to locate the
   public keys needed to validate
   signature.
   • The subject is an opaque identifier
   for the resource owner. In this case,
   it also happens to be the identity.
   • The expiration is a Unix timestamp
   when the token expires. A typical
   lifetime is 10 minutes.


   View Slide

5. User ID
   Name
   Email
   CILogon and SciTokens
   CILogon
   • Federated Identity Management
   • OpenID Connect
   • ID Tokens
   SciTokens
   • Federated Authorization
   • OAuth 2.0
   • Access Tokens
   InCommon IdP
   CILogon
   SciTokens
   Resource
   User Info
   VO Info
   Groups
   Access Rights


   View Slide

6. SciTokens System Architecture
   Job Submission Job Execution
   Data Access
   condor_submit
   condor_schedd
   condor_credd
   condor_shadow
   condor_startd
   condor_starter
   User’s job
   Token Server
   Data Server
   (CVMFS / XRootD)
   User
   Policy DB
   = refresh tokens
   A
   A A
   R
   R A = access tokens
   A
   Identity Provider


   View Slide

7. User Experience
   user@chtc$ condor_submit workflow.jdl
   Visit https://chtc.example.edu/authorize to authorize your jobs.
   user@chtc$
   Your HTCondor jobs require the following permissions:
   • Read from /frames on LIGO Frame Server
   • Write to /users/dbrown/pycbc-32931 on LIGO Data Server
   Allow Deny


   View Slide

8. Early results on OSG
   • End-to-end token-based auth{z,n} workflow for
   the OSG VO submit service
   • Includes patches to Xrootd to validate tokens
   presented via HTTPS and to write files out with
   the correct Unix user permissions
   • Details:
   • instead of using OAuth2 to generate the token,
   we keep a signing key on the submit host.
   • only one token needed.
   • submit host and storage server owned by OSG.


   View Slide

9. Give SciTokens a try!
   • https://demo.scitokens.org/ - token generator
   • https://github.com/scitokens/ - open source software
   • Java and Python implementations
   • SciTokens-aware token server
   • CVMFS, Nginx, and XRootD plugins
   • Docker image for XRootD setup
   • https://scitokens.org/ - docs, email lists


   View Slide
