Distributed Tracing: Understanding how your components work together - MicroCPH 2018

Understanding failures or latencies in monoliths or small systems usually starts with looking at a single component in isolation. Microservices architecture invalidates this assumption because end user requests now traverse dozen of components and a single component simply does not give you enough information: each part is just one side of a bigger story.

In this talk we’ll look at distributed tracing which summarizes all sides of the story into a shared timeline and also distributed tracing tools like Zipkin, which highlights the relationship between components, from the very top of the stack to the deepest aspects of the system.

Transcript

1. Distributed Tracing Understand how your components work together
2. About me José Carlos Chávez • Software Engineer at Typeform focused on the responses services aggregate. • Zipkin core team, DataDog consultant and open source contributor for Distributed Tracing projects.
3. Distributed Systems
4. Distributed systems A collection of independent components appears to its users as a single coherent system. Characteristics: • Concurrency • No global clock • Independent failures #microcph / @jcchavezs
5. Water heater Gas supplier Cold water storage tank Shutoff valve First floor branch Tank valve 爆$❄#☭ Distributed systems
6. Auth service Images service Videos service DB2 DB3 DB4 TCP error (2003) 500 Internal Error 500 Internal Error GET /media/u1k API Proxy Distributed systems: Understanding failures DB1 Media API
7. Water heater Gas supplier Cold water storage tank Shutoff valve First floor branch Tank valve 爆$❄#☭ I AM HERE! First floor distributor is clogged! Distributed systems: Understanding failures
8. We do have that, it is called logs!
9. API Proxy Auth service Media API Images service Videos service DB2 DB3 DB4 TCP error (2003) 500 Internal Error 500 Internal Error GET /media/u1k Logs: Concurrency DB1
10. [24/Oct/2017 13:50:07 +0000] “GET /media HTTP/1.1” 200 … **0/13548” [24/Oct/2017 13:50:07 +0000] “GET /media HTTP/1.1” 200 … **0/23948” [24/Oct/2017 13:50:08 +0000] “GET /media HTTP/1.1” 200 … **0/12396” [24/Oct/2017 13:50:07 +0000] “GET /videos HTTP/1.1” 200 … **0/23748” [24/Oct/2017 13:50:07 +0000] “GET /images HTTP/1.1” 200 … **0/23248” [24/Oct/2017 13:50:07 +0000] “GET /auth HTTP/1.1” 200 … **0/26548” [24/Oct/2017 13:50:07 +0000] “POST /media HTTP/1.1” 200 … **0/13148” [24/Oct/2017 13:50:07 +0000] “GET /media HTTP/1.1” 200 … **0/2588” [24/Oct/2017 13:50:07 +0000] “GET /auth HTTP/1.1” 500 … **0/3248” [24/Oct/2017 13:50:07 +0000] “POST /media HTTP/1.1” 200 … **0/23548” [24/Oct/2017 13:50:07 +0000] “GET /images HTTP/1.1” 200 … **0/22598” [24/Oct/2017 13:50:07 +0000] “GET /videos HTTP/1.1” 200 … **0/13948” ... ? ? Logs
11. Distributed Tracing to unclog your pipes
12. Distributed Tracing • Understanding Latency issues across services • Identifying dependencies and critical paths • Visualizing concurrency • Request scoped • Complementary to other observability means #microcph / @jcchavezs
13. Distributed tracing as observability mean Credits: Peter Bourgon
14. API Proxy Auth service Media API Images service Videos service DB2 DB3 DB4 TCP error (2003) Can’t connect to server 500 Internal Error 500 Internal Error GET /media/u1k Distributed microservices architecture DB1
15. [24/Oct/2017 13:50:07 +0000] “GET /media HTTP/1.1” 200 … **0/13548” [24/Oct/2017 13:50:07 +0000] “GET /media HTTP/1.1” 200 … **0/23948” [24/Oct/2017 13:50:08 +0000] “GET /media HTTP/1.1” 200 … **0/12396” [24/Oct/2017 13:50:07 +0000] “GET /videos HTTP/1.1” 200 … **0/23748” [24/Oct/2017 13:50:07 +0000] “GET /images HTTP/1.1” 200 … **0/23248” [24/Oct/2017 13:50:07 +0000] “GET /auth HTTP/1.1” 200 … **0/26548” [24/Oct/2017 13:50:07 +0000] “POST /media HTTP/1.1” 200 … **0/13148” [24/Oct/2017 13:50:07 +0000] “GET /media HTTP/1.1” 200 … **0/2588” [24/Oct/2017 13:50:07 +0000] “GET /auth HTTP/1.1” 500 … **0/3248” [24/Oct/2017 13:50:07 +0000] “POST /media HTTP/1.1” 200 … **0/23548” [24/Oct/2017 13:50:07 +0000] “GET /images HTTP/1.1” 200 … **0/22598” [24/Oct/2017 13:50:07 +0000] “GET /videos HTTP/1.1” 200 … **0/13948” ... Logs
16. API Proxy Media API Auth Videos Images | Time [1508410470] error TCP (2003) 500 [1508410442] no cache for resource, retrieving from DB ip_1027301 error error Distributed tracing
17. Elements of Distributed Tracing • A trace shows an execution path through a distributed system • A context includes information that should be propagated across services • A span in the trace represents a logical unit of work (with a beginning and end) • Tags and logs (optional) add complementary information to spans. #microcph / @jcchavezs
18. Client / Producer Extract() TraceID: fAf3oXLoD SpanID: dZ0qHIBa1 Sampled: true … TraceID: fAf3oXLoD ParentSpanID: dZ0qHIBa1 SpanID: oYa7m31wq Sampled: true ... Elements of Distributed Tracing #microcph / @jcchavezs Extract() Format DB Call Inject()
19. Benefits of Distributed Tracing • Effective monitoring • System insight, clarifies non trivial interactions • Visibility to critical paths and dependencies • Observe E2E latency in near real time • Request scoped, not request’s lifecycle scoped. #microcph / @jcchavezs
20. What about overhead? • Observability tools are unintrusive • Sampling reduces overhead • Instrumentation can be delegated to common frameworks • (Don’t) trace every single operation #microcph / @jcchavezs
21. Introducing Zipkin
22. (open)Zipkin • Distributed tracing tool • Based on Google Dapper (2010) • Created by twitter (2012) • Open source (2015) • Mature tracing model • Strong community: ◦ @zipkinproject ◦ github.com/openzipkin #microcph / @jcchavezs
23. Service (instrumented) Transport Collect spans Collector API UI Storage DB Visualize Retrieve data Store spans http/kafka/grpc Receive spans Deserialize and schedule for storage Cassandra/MySQL/ElasticSearch Zipkin: architecture
24. Zipkin: traces
25. Zipkin: traces
26. Zipkin: traces
27. Zipkin: trace overview
28. Zipkin: tags and logs
29. Zipkin: traces with errors
30. Zipkin: traces for async operations
31. Zipkin: dependency graph
32. Zipkin: dependency graph
33. Q&As @jcchavezs Look around resources: https://goo.gl/rMXLmp
