VMware Cloud on AWS (VMC) is een unieke en revolutionaire cloud dienst waarmee een breed scala aan hybrid cloud use cases op eenvoudige wijze mogelijk gemaakt worden dankzij de unieke integratie van VMware SDDC technologie en AWS cloud services. Voorheen waren deze use cases simpelweg niet te realiseren of vereisten ze een enorme investering van tijd en geld. Tijdens deze presentatie leert u met welk gemak u uw cloud strategie kunt uitvoeren met inzet van VMware Cloud on AWS en integratie met AWS cloud services.

624399ae037438fdd9ae8166943915e0?s=128

Jeffrey Kusters

September 26, 2019
Tweet

Transcript

  1. VMware Cloud on AWS The fastest path to hybrid cloud

    Jeffrey Kusters Technology Officer VCDX-DCV | VCDX-NV | AWS Certified SAA
  2. virtual machines in on-premises data centers Source: Gartner - Four

    Trends Changing Server Virtualization Decisions 70M
  3. “Amazon reported that its web services division, the leader in

    providing rented computing infrastructure from its data centers, saw revenue grow 45 percent in the fourth quarter” Source: Bloomberg - Cloud-Computing Giants Keep Growing Despite Slowdown Fears
  4. “Nearly all enterprises that AWS works with today start out

    with a significant on-premises footprint and take a hybrid approach to cloud computing.” --- Andy Jassy, CEO Amazon Web Services
  5. Consistency Skillsets & Tools Cloud Governance Enterprise-class App SLA Vendor

    Lock-in
  6. None
  7. Strategic goal: Push as many workloads as technically feasible and

    through business criteria to the top of the platform hierarchy. Hardware IaaS CaaS PaaS PaaS FaaS SaaS
  8. Many applications are COTS … you don’t have access to

    the source code
  9. Refactoring and Rearchitecting is hard

  10. Big US Earth Moving Company: 2 workloads out of 200

    in 2 years Big European Aircraft manufacturer: 7 workloads out of 700 in 18 months Big UK Oil Company: 2 workloads in 1 year
  11. None
  12. Benefits Effort

  13. Amazon Compute Service Level Agreement Unavailable” and “Unavailability” mean: •

    For Single EC2 Instances, when your Single EC2 Instance has no external connectivity. • For Amazon EC2 (other than Single EC2 Instances), Amazon ECS, or Amazon Fargate, when all of your running instances or running tasks, as applicable, deployed in two or more AZs in the same AWS region (or, if there is only one AZ in the AWS region, that AZ and an AZ in another AWS region) concurrently have no external connectivity. Single EC2 Instances: • AWS will use commercially reasonable efforts to ensure that each individual Amazon EC2 instance (“Single EC2 Instance”) has an Hourly Uptime Percentage of at least 90% of the time in which that Single EC2 Instance is deployed during each clock hour (the “Hourly Commitment”). In the event any Single EC2 Instance does not meet the Hourly Commitment, you will not be charged for that instance hour of Single EC2 Instance usage. Last Updated: March 19, 2019
  14. Reliability continues to be a problem for [… beep …]

    customers. The cloud has seen several service disruptions over the last year, with many of those outages leaving customers no controls to mitigate downtime. Source: Gartner - Gartner's 2019 Magic Quadrant For Cloud IaaS
  15. So, can your applications scale across Availability Zones?

  16. Cloud economics is all about ‘pay-as-you-go’ … but what if

    you just keep going and going?
  17. Leading compute, storage and network virtualization capabilities Support for a

    broad range of workloads De-facto standard for the enterprise DC Flexible consumption economics Broadest set of cloud services Global scale and reach Jointly engineered solution delivers the best of VMware and AWS for customers
  18. Customer Datacenter vSphere vSAN NSX vCenter vCenter Operational Management VMware

    Cloud™ on AWS Powered by VMware Cloud Foundation AWS Global Infrastructure
  19. AWS Global Infrastructure Customer Datacenter vSphere vSAN NSX Amazon EC2

    Amazon S3 Amazon RDS AWS Direct Connect AWS IAM AWS IoT … … … … vCenter vCenter Operational Management VMware Cloud™ on AWS Powered by VMware Cloud Foundation AWS Native Services
  20. on-premises Datacenter vCenter Server vCenter Server Software Defined Data Center

    VMware Cloud on AWS NSX VDS or VSS vSphere vSphere Storage Content Library Hybrid Linked Mode AWS Global Infrastructure VSAN
  21. Provisioning Operations Maintenance

  22. GDPR Available Regions US West (Oregon) US East (N. Virginia)

    US West (N. California)* US East (Ohio) GovCloud US-West Canada (Central)* South America (Sao Paulo)* Europe (London) Europe (Frankfurt) Europe (Ireland) Europe (Paris) Asia Pacific (Sydney) Asia Pacific (Tokyo) Asia Pacific (Singapore) Asia Pacific (Seoul) Asia Pacific (Mumbai)
  23. I3.metal R5.metal Typical Use Case General Purpose Clusters Storage Bound

    Clusters Compute CPU Type Intel Xeon E5-2686 Intel Xeon Skylake CPU Cores 36 Cores @ 2.3Ghz 48 Cores @ 2.5 Ghz Memory RAM 512 GiB 768 GiB Storage Type SSD On-host EBS Only Capacity Tier ~10,600 GiB 15,000 GiB to 35,000 GiB Network Physical Speed 25 Gbps 25 Gbps
  24. 576 108 8192 1536 TO TO CORES GiB CORES GiB

    16 NODE CLUSTER 3 NODE CLUSTER
  25. 2 Disk Groups 8 self-encrypting NVMe devices 10.2TB raw capacity

    per host Deduplication & Compression Enabled Highly performant and resilient storage system Disk Group #1 Disk Group #2 Cache Tier Capacity Tier
  26. 768 144 12288 2304 TO TO CORES GiB CORES GiB

    16 NODE CLUSTER 3 NODE CLUSTER
  27. New diskless host instance R5.metal VMware vSAN integrated with Amazon

    Elastic Block Store (EBS) Higher capacity per host for better VM consolidation – raw capacity ranging from 15TiB to 35TiB Faster remediation of host failures Can be the first cluster provisioned in a VMware Cloud on AWS SDDC Lowers cost for Disaster Recovery use case Disk Group #1 Disk Group #2 Cache Tier Capacity Tier Disk Group #3 15TB 20TB 25TB 30TB 35TB
  28. vSAN Amazon EC2 R5.metal Amazon EC2 R5.metal Amazon EC2 R5.metal

    Amazon EC2 i3.metal Amazon EC2 i3.metal Amazon EC2 i3.metal … Management VMs Customer workload VMs
  29. Elastic vSAN Amazon EC2 R5.metal Amazon EC2 R5.metal Amazon EC2

    R5.metal EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS EBS Amazon EC2 R5.metal Amazon EC2 R5.metal Amazon EC2 R5.metal … Management VMs Customer workload VMs
  30. vSAN Cluster HOST IS ADDED 1. AUTOMATIC NETWORK CONFIGURATION 2.

    3. vSAN Cluster Management Network vMotion Network vSAN Network VXLAN Network vSAN Cluster vSAN DATASTORE CAPACITY INCREASE
  31. HOST FAILS, OR PROBLEM IDENTIFIED NEW HOST ADDED TO CLUSTER.

    DATA FROM PROBLEM HOST REBUILT, AND/OR MIGRATED PREVIOUS HOST EVACUATED FROM CLUSTER, FULLY REPLACED BY NEW HOST 1. 2. 3. vSAN Cluster vSAN Cluster vSAN Cluster
  32. CPU Memory Storage vSAN Cluster

  33. AWS Global Infrastructure AWS Region vSphere Cluster SDDC Availability Zone

    vSAN Cluster Single-AZ Deployment 99.9%
  34. x AWS Global Infrastructure AWS Region vSphere Cluster Availability Zone

    Availability Zone Multi-AZ Deployment SDDC vSAN Cluster 99.99%
  35. SRM On-prem site 1 (Production) SRM On-prem site 2 (Production)

    VMware Site Recovery VMware Cloud on AWS SDDC 2 (DR site) VMware Cloud on AWS SDDC 1 (Production) VMware Site Recovery (99.999%)
  36. AWS Global Infrastructure AWS Global Infrastructure Native AWS Services Workloads

    EMR Redshift EC2 Auto Scaling Lambda RDS Rekognition CloudFront S3 Glacier S3 GuardDuty Lake Formation ELB vSphere vSAN NSX VMware Cloud on AWS SDDC 25Gbps ENI
  37. Compute Storage Network SDDC On-Premises Data Center VMware Cloud on

    AWS Compute Storage Network SDDC VMware Cloud on AWS Network A Network B Network A Network B
  38. Active Migrated VMs CROSS-VERSION HYBRIDITY SECURITY On-Premises Cloud LARGE SCALE

    WARM MIGRATION Hybrid Interconnect Any-to-Any vSphere Migration vSphere 5.0+ VMware Cloud on AWS
  39. Data Center Extension Cloud Migrations Next Generation Apps Disaster Recovery

  40. ITQ Cloud Navigator adoption framework • Determine (Strategy - Why)

    • Design (Plan - What) • Deploy (Execute - How) • Drive (Optimize) • Focus on Technology, People & Process
  41. Questions?

  42. Thank you!
