  1. 1.

    US West Oregon US East N. Virginia EU London Kick-start

    your Cloud Journey with VMware Cloud on AWS
  2. 2.

    About me Technology Officer at ITQ VCDX #252 AWS Certified

    SAA jeffreykusters.nl @jeffreykusters linkedin.com/in/jeffreykusters
  3. 9.

    It’s potentially high on risk “Monthly Uptime Percentage” is calculated

    by subtracting from 100% the percentage of minutes during the month in which Amazon EC2 or Amazon EBS, as applicable, was in the state of “Region Unavailable” “Region Unavailable” means that more than one Availability Zone in which you are running an instance, within the same Region, is “Unavailable” to you.”
  4. 11.

    Data Center Team • Application architectures • Security best practices

    • APIs and management tools You’re adding complexity Google Team • Application architectures • Security best practices • APIs and management tools Azure Team • Application architectures • Security best practices • APIs and management tools AWS Team • Application architectures • Security best practices • APIs and management tools Organizational Complexity Operational Complexity Increased Risk Exposure IBM Team • Application architectures • Security best practices • APIs and management tools
  5. 12.

    If you can’t scale down, cost will just go up!

    Cloud economics is all about ‘pay-as-you-go’ … but what if you just keep going and going? Can your applications scale down or easily be turned off and on again on demand? Cloud Resources
  6. 13.
  7. 15.

    Forecast ahead: Growing clouds on the horizon This can feel

    like an incredible opportunity. To get there, organizations need to be ready to act. Analysts predict increasing cloud adoption Speed is the new currency Public cloud market by 2020, up from $146B in 2017 – Forrester *1 Projected growth for IaaS market in 2017, the highest for cloud services – Gartner *2 of organizations committed to hybrid architectures by 2018 – IDC *3 $236B 37% 80% 1. “The Public Cloud Services Market Will Grow Rapidly To $236 Billion in 2020”. Forrester. September 1, 2016. 2. “http://www.gartner.com/newsroom/id/3616417 3. “Enterprise Adoption Driving Strong Growth of Public Cloud Infrastructure as a Service, According to IDC.” Press release. IDC. July 14, 2016.
  8. 19.

    “ W H Y A R E N ’ T

    W E I N T H E C L O U D Y E T ? ! ”
  9. 23.

    Introducing VMware Cloud on AWS AWS Global Infrastructure AWS Global

    Infrastructure Customer Datacenter vSphere vSAN NSX Amazon EC2 Amazon S3 Amazon RDS AWS Direct Connect AWS IAM AWS IoT … … … … vCenter vCenter • ESXi on Dedicated Hardware • Support for VMs and Containers • vSAN on Flash and EBS Storage • Replication and DR Orchestration • NSX Spanning on- premises and cloud • Advanced Networking & Security Services Operational Management VMware Cloud™ on AWS Powered by VMware Cloud Foundation AWS Native Services
  10. 24.

    What is VMware Cloud on AWS (VMC) • VMC is

    delivered ‘as-a-service’ • AWS manages the physical infrastructure • VMware manages the virtualization and management layers • The customer manages the VMs • VMware Cloud Foundation • vSphere • vSAN • NSX
  11. 25.

    Runs on dedicated bare metal hosts • AWS I3 Instance

    Family hosts • 36 CPU cores and 512GB RAM • 8 x 2TB NVMe SSD • Minimum of 4 hosts in a cluster • ESXi boots from Elastic Block Storage • 25Gbps networking per ESXi host • Max. 32 ESXi hosts per cluster • Max. 10 clusters per SDDC • That’s 11.520 CPUs • 160 TB RAM • 5 PB raw NVMe SSD storage
  12. 26.

    User friendly VMC Console Pictures courtesy of Humair Ahmed (Sr.

    Technical Product Manager NSBU) and Chris Wagner (Principal Engineer)
  13. 29.

    CPU Memory Storage Cluster VMC SDDC Features and Add-ons •

    Elastic DRS Pictures courtesy of Frank Denneman (Senior Staff Architect – VMware Cloud Platform)
  14. 30.

    Cluster VMC SDDC Features and Add-ons • Elastic DRS •

    Auto Remediation Pictures courtesy of Frank Denneman (Senior Staff Architect – VMware Cloud Platform)
  15. 31.

    VMC SDDC Features and Add-ons • Elastic DRS • Auto

    Remediation • Hybrid Linked Mode
  16. 32.

    VR VR AWS Global Infrastructure SDDC Availability Zone Management Resource

    Pool Workload Resource Pool Cluster SRM Customer Data Center vCenter SRM VMC SDDC Features and Add-ons • Elastic DRS • Auto Remediation • Hybrid Linked Mode • VMware Site Recovery
  17. 34.

    Direct integration with native AWS VM VSAN VM NSX ESXi

    CGW EC2 Instances ENI S3 VPC Endpoint EC2 Instances DynamoDB VPC Endpoint Amazon Redshift Logical Network 172.31.1.0/24 VPC Subnet – 10.1.1.0/24 VPC Subnet – 10.1.2.0/24 VMware Cloud on AWS SDDC Account Customer Owned AWS Account SDDC
  18. 35.

    NSX is the magic sauce MGW CGW Internet vSAN Cluster

    Managed by VMware Managed by Customer VC NSX … VM VM VM VM VM VPN VPN DLR
  19. 36.

    NSX Logical Networks linked to an ENI • An ENI

    is used to communicate to the NSX logical network subnets in VMware Cloud on AWS Example: eni-e753b5d is used to route directly from the AWS VPC to NSX logical network subnet 10.61.4.0/28 Pictures courtesy of Humair Ahmed (Sr. Technical Product Manager NSBU)
  20. 37.

    First, bridge the initial technology gap … • VMware data

    centers and native clouds are inherently different • VMware data centers are infrastructure centric • Native clouds are application centric • Different technology and operational silos
  21. 38.

    ... then replatform/refactor your apps using native AWS services •

    Amazon RDS • Amazon Redshift • Amazon Load Balancers • Amazon S3, Glacier • Amazon EFS • Amazon Greengrass (IoT) • Amazon Lamda • Amazon Route 53 • Amazon Quicksight • Amazon CloudFront • AWS Certificate Manager • AWS WAF • AWS Shield/Shield Advanced • Amazon CloudWatch • Amazon Kinesis Firehose • Amazon Elasticsearch Service • Amazon Athena • …
  22. 39.

    VMware Cloud VPC ESXi Amazon EC2 ESXi ESXi ESXi Resource

    Pool RDS Aurora (shared) AWS Customer VPC AZ A AZ B AZ C ELB VMware Cloud ENI App3 ASG RWP (SDDC) Amazon EFS OS DB1 Customer Data Center VPC S3 Endpoint AWS Shield Amazon ES Route53 CloudFront WAF & ACM- enabled Edge Location(s) SSL Encrypted Traffic NFS S3-backed Cluster File System Compute Gateway Compute Gateway AWS Region Services AWS CloudTrail VPC Flow logs Reverse Web Proxy & Application Load- Balancer OS APP2 OS APP2 OS APP2 OS APP1 OS RWP Amazon Kinesis Firehose Amazon CloudWatch Amazon QuckSight Amazon Athena Management Gateway OS DMZ-Out (Public) DMZ-In (Private) App (Private) DMZ-Out (Public) ACM Amazon S3 IGW IGW Endless possibilities OS DB1 Pictures courtesy of Paul Bockelman (AWS Principal Solutions Architect) and Haider Witwit (AWS Senior Solutions Architect)
  23. 40.

    March 7 release updates • VMware Cloud on AWS available

    in Europe! (London and very soon Frankfurt) • Multi-AZ Stretched Cluster • Developer Center • VMware Hybrid Cloud Extension • Infrastructue as Code (AWS CloudFormation and Terraform) • And many more improvements …
