Automated Unit & Functional Tests for HTML5 Mobile Apps [Workshop]

HTML5 and hybrid mobile apps are becoming increasingly important, whether as alternative instances of successful web apps, or as mobile-only experiences. A combination of JS unit testing and functional UI testing helps ensure every HTML5 project stays bug-free throughout release cycles, and opens up the possibility for continuously-delivered mobile apps.

In this workshop, we’ll get hands-on with QUnit (for unit testing) and Appium (for functional testing), and write some tests together for a jQuery Mobile-based HTML5 site packaged as a cross-platform hybrid mobile app using Phonegap/Cordova. Then we’ll run the tests using the Sauce Labs cloud service, dig into the results, and talk about speeding up build times using parallelisation of test runs.

Transcript

1. mobile automation made awesome
   Jonathan Lipps • Director of Ecosystem & Integrations • Sauce Labs
   @AppiumDevs • @jlipps • @saucelabs
   jQueryUK Workshop • Oxford, UK
   May 16 2014


   View Slide

2. Ecosystem &
   Integrations
   Project Lead &
   Architect
   Unit/Functional Mobile Testing with Appium and Sauce Labs
   Jonathan Lipps • Director of Ecosystem & Integrations • Sauce Labs
   @AppiumDevs • @jlipps • @saucelabs


   View Slide

3. appium introduction


   View Slide

4. The Dev Cycle of
   Optimal Happiness
   [ ]


   View Slide

5. appium is the cross-platform
   solution for native and hybrid
   mobile automation


   View Slide

6. Philosophy
   R1. Test the same app you submit to the
   marketplace
   R2. Write your tests in any language, using
   any framework
   R3. Use a standard automation specification
   and API
   R4. Build a large and thriving open-source
   community effort


   View Slide

7. View Slide

8. appium architecture


   View Slide

9. Automation Orchestra
   Apple Instruments & UIAutomation for iOS
   Google UiAutomator for Android (4.2.1 up)
   Selendroid for older Android
   WebDriver interface


   View Slide

10. appium is an HTTP server
    that creates and handles
    WebDriver sessions


    View Slide

11. appium extends the
    WebDriver protocol with
    mobile-specific behaviors


    View Slide

12. appium setup


    View Slide

13. Requirements (1/2)
    • Mac (10.8/10.9)
    • Android automation works on PC/Linux too
    • Node >= 0.10
    • Xcode 5.1 with CLI tools and iOS 7.1


    View Slide

14. Requirements (2/2)
    • Android Developer Tools >= 22
    • http://developer.android.com/sdk/index.html
    • mv to /usr/local/adt
    • export ANDROID_HOME=/usr/local/adt/sdk
    • add (.bashrc, .zshrc, etc):
    export PATH=”$PATH:$ANDROID_HOME/tools:
    $ANDROID_HOME/platform-tools”


    View Slide

15. Install HAXM for Android Speed!
    • open /usr/local/adt/sdk/extras/intel/
    Hardware_Accelerated_Execution_Manager/
    IntelHAXM.dmg
    • https://software.intel.com/en-us/android/
    articles/intel-hardware-accelerated-
    execution-manager


    View Slide

16. Make an Android Device
    • android
    • Check ‘Intel x86 Atom System Image’ - Android (4.4)
    • Click ‘Install 1 package...’
    • Tools > Manage AVDs
    • New...


    View Slide

17. • AVD Name: workshop
    • Device: Nexus S
    • Target: Android 4.4
    • CPU: Intel/Atom
    • Skin: hw controls
    • Host GPU
    Create the Image


    View Slide

18. Launch AVD
    • In a new terminal window:
    • emulator @workshop -netfast
    • Go through the new device tour
    • $ANDROID_HOME/sdk/tools/emulator @workshop -netfast (without env)


    View Slide

19. Get the workshop code
    • git clone https://github.com/jlipps/
    jqueryuk-workshop-2014.git
    • cd jqueryuk-workshop-2014


    View Slide

20. Install dependencies
    • npm install -g appium # no sudo!
    • npm install -g cordova
    • npm install -g mocha
    • npm install .


    View Slide

21. unit tests


    View Slide

22. Run local server
    • node server.js
    • # visit http://localhost:8081


    View Slide

23. View Slide

24. Run QUnit tests
    • http://localhost:8081/test.html
    • # moviesearch/www/test.html
    • # moviesearch/www/test.js


    View Slide

25. Set up Sauce Labs env vars
    • http://saucelabs.com/signup/plan/free
    • http://saucelabs.com/account
    • # add to .bashrc or equivalent
    • export SAUCE_USERNAME=”myusername”
    • export SAUCE_ACCESS_KEY=”xxxxxxxx”


    View Slide

26. Get Sauce Connect
    • https://saucelabs.com/docs/connect
    • cp ~/Downloads/sc-4.2-osx/bin/sc \
    /usr/local/bin


    View Slide

27. Start Sauce Connect
    • sc -u $SAUCE_USERNAME -k $SAUCE_ACCESS_KEY


    View Slide

28. Run JS unit tests on Sauce Labs
    • ./test/jsunit.sh
    • http://saucelabs.com/tests


    View Slide

29. appium test model


    View Slide

30. Start/stop a session


    View Slide

31. Find & Interact with Elements


    View Slide

32. Automate a WebView


    View Slide

33. appium tests


    View Slide

34. Build & run sample apps
    • ./go_ios.sh
    • ./go_android.sh


    View Slide

35. Launch Appium
    • sudo authorize_ios
    • appium


    View Slide

36. Moment of truth...
    • mocha -t 90000 -R spec test/ios.js
    • mocha -t 90000 -R spec test/android.js


    View Slide

37. Upload app to Sauce Storage
    • ./test/upload.sh
    • # or use pre-uploaded app url


    View Slide

38. Run Appium tests on Sauce
    • SAUCE=1 mocha -t 90000 -R spec test/ios.js


    View Slide

39. Questions?
    http://appium.io
    https://github.com/appium/appium
    @AppiumDevs • @jlipps • @saucelabs


    View Slide

40. Thanks!
    http://appium.io
    https://github.com/appium/appium
    @AppiumDevs • @jlipps • @saucelabs


    View Slide
