1. Testing Android Security
   José Manuel Ortega
   @jmortegac
   AMSTERDAM 11-12 MAY 2016


   View Slide

2. https://speakerdeck.com/jmortega
   http://jmortega.github.io


   View Slide

3. AGENDA
   ▪ Development Cycle
   ▪ Static and Dynamic Analysis
   ▪ Components Security
   ▪ Hybrid Automatic tools
   ▪ Best Practices & OWASP


   View Slide

4. DEVELOPMENT CYCLE


   View Slide

5. WHITE BOX /BLACK BOX
   ✓
   ✓
   ✓
   ✓
   ✓
   ✓


   View Slide

6. TESTING ANDROID SECURITY


   View Slide

7. FORENSICS


   View Slide

8. FORENSICS
   ▪
   ▪
   ▪
   ▪
   ▪
   ▪


   View Slide

9. STATIC ANALYSIS
   ✓
   ✓
   ✓
   ✓
   ✓
   ✓
   ✓


   View Slide

10. CODE REVIEW / SOURCE CODE ANALYSIS


    View Slide

11. ANDROID LINT


    View Slide

12. ANDROID STUDIO INSPECT CODE


    View Slide

13. ANDROID SONAR PLUGIN


    View Slide

14. ANDROID SONAR PLUGIN >RULES


    View Slide

15. SONAR SECURITY


    View Slide

16. ANDROWARN


    View Slide

17. QARK
    ▪ Quick Android Review Kit
    ▪ https://github.com/linkedin/qark
    ▪ Static code analysis tool
    ▪ Look for potential vulnerabilities


    View Slide

18. QARK
    ▪ Identifies permissions and exported components
    (activities,services..) on Manifest
    ▪ Looks for WORLD_READABLE and
    WORLD_WRITABLE files
    ▪ Looks for X.509 certificates validation issues


    View Slide

19. QARK


    View Slide

20. QARK REPORT


    View Slide

21. REVERSE ENGINEERING
    ▪ Decompile dalvik to smali
    ▪ classes.dex in APK
    ▪ APKTOOL
    ▪ DEX2JAR
    ▪ Java Decompiler


    View Slide

22. APK STRUCTURE


    View Slide

23. DISASSEMBLY AND DECOMPILATION


    View Slide

24. JADX-GUI


    View Slide

25. APKTOOL


    View Slide

26. DYNAMIC ANALYSIS TOOLS


    View Slide

27. WIRESHARK


    View Slide

28. BURP SUITE
    ▪ Intercepting network traffic
    ▪ HTTP proxy tool
    ▪ Able to intercept layer traffic and allows users to
    manipulate the HTTP request and response


    View Slide

29. DROZER
    ▪ https://labs.mwrinfosecurity.com/tools/drozer/
    ▪ Find vulnerabilities automatically
    ▪ Automate security testing
    ▪ Interact with your Apps with debugging
    disabled


    View Slide

30. INSIDE DROZER


    View Slide

31. DROZER


    View Slide

32. DROZER PACKAGE INFO
    ▪ app.package.info


    View Slide

33. DROZER COMMANDS


    View Slide

34. DROZER CONTENT PROVIDERS


    View Slide

35. FINDING SQL INJECTION IN CONTENT PROVIDERS


    View Slide

36. EXPLOITING SQL INJECTION VULNERABILITY


    View Slide

37. ANDROID MANIFEST
    android:debuggable=true
    android:exported=true


    View Slide

38. ANDROID MANIFEST EXPORTED ATTRIBUTE
    …
    …
    …


    View Slide

39. COMPONENTS SECURITY
    ▪ AndroidManifest.xml
    ▪ Activities
    ▪ Content Providers
    ▪ Services
    ▪ Shared Preferences
    ▪ Webview


    View Slide

40. LOG INFORMATION
    public static final boolean SHOW_LOG =
    BuildConfig.DEBUG;
    public static void d(final String tag, final String
    msg) {
    if (SHOW_LOG)
    Log.d(tag, msg);
    }


    View Slide

41. THRID PARTY LIBRARIES


    View Slide

42. VULNERABILITIES IN CORDOVA 3.5


    View Slide

43. SECURITY IN CONTENT PROVIDERS
    ▪ Components provide a standardized interface
    for sharing data between applications
    ▪ URI addressing scheme
    ▪ Can perform queries equivalent to SELECT,
    UPDATE,INSERT, DELETE


    View Slide

44. SQLCIPHER
    ▪ SQLCipher is a SQL extension that provides
    transparent AES encryption of database files
    ▪ 256-bit AES Encrypt SQLite database
    ▪ http://sqlcipher.net/sqlcipher-for-android


    View Slide

45. SECURED PREFERENCES
    ▪ https://github.com/scottyab/secure-preferences
    ▪ Encrypt your app’s shared preferences
    ▪ Android Share Preferences wrapper that
    provides encryption for keys and values


    View Slide

46. SECURED PREFERENCES


    View Slide

47. DATA STORAGE


    View Slide

48. PROTECTING DATA FILES


    View Slide

49. SECURE COMMUNICATIONS
    ▪ Ensure that all sensitive data is encrypted
    ▪ Certificate pinning for avoid MITM attacks


    View Slide

50. CERTIFICATES
    SSLSocketFactory.ALLOW_ALLHOSTNAME_VERIFIER
    TrustManager where checkServerTrusted() always
    returns true


    View Slide

51. CERTIFICATE PINNING


    View Slide

52. X.509 CERTIFICATES


    View Slide

53. HTTPS Connection


    View Slide

54. HTTPS Connection


    View Slide

55. ENCRYPT NETWORK REQUESTS
    ▪ Best practice is to always encrypt network
    communications
    ▪ HTTPS and SSL can protect against MitM attacks
    and prevent casual sniffing traffic.
    ▪ Server certificate validity is checked by default


    View Slide

56. VALIDATE SERVER CERTIFICATE
    ▪ https://www.ssllabs.com/ssltest


    View Slide

57. CHECK CERTIFICATES TOOLS
    ▪ OpenSSL
    ▪ Keytool
    ▪ Jarsigner


    View Slide

58. Runtime Permissions
    ▪ All permissions granted at install time
    ▪ Dangerous permissions require user
    confirmation
    ▪ Prompt for dangerous permissions at
    runtime
    ▪ Granted/revoked by permission group
    ▪ Managed per app, per user
    ▪ /data/system/users/0/runtime-permissions.xml


    View Slide

59. Group permissions on Android M


    View Slide

60. Permissions FLOW on Android M


    View Slide

61. Permissions on Android M


    View Slide

62. Permissions on Android M


    View Slide

63. OBFUSCATION
    ▪ The obfuscator can use several techniques to protect
    a Java/Android application:
    ▪ change names of classes, methods, fields
    ▪ modify the control flow
    ▪ code optimization
    ▪ dynamic code loading
    ▪ change instructions with metamorphic technique


    View Slide

64. PROGUARD
    ▪ File shrinker: detects and removes unused
    classes, fields, methods,and attributes
    ▪ Optimizer: optimizes bytecode and removes
    unused instructions
    ▪ Obfuscator: renames classes, fields, and
    methods using short meaningless names


    View Slide

65. OBFUSCATION WITH PROGUARD


    View Slide

66. OBFUSCATION WITH PROGUARD


    View Slide

67. HYBRID AUTOMATIC ONLINE TOOLS
    ▪ SandDroid
    ▪ ApkScan
    ▪ Visual Threat
    ▪ TraceDroid
    ▪ CopperDroid
    ▪ APK Analyzer
    ▪ ForeSafe
    ▪ AndroTotal
    ▪ NowSecure Lab


    View Slide

68. VULNERABILTIY ANALYSIS


    View Slide

69. HYBRID AUTOMATIC ONLINE TOOLS
    ▪ http://sanddroid.xjtu.edu.cn/#home


    View Slide

70. SANDROID


    View Slide

71. SANDROID


    View Slide

72. TRACEDROID


    View Slide

73. NOWSECURE LAB


    View Slide

74. NOWSECURE LAB


    View Slide

75. NOWSECURE LAB


    View Slide

76. BEST PRACTICES
    ▪ Don’t hardcode sensitive information
    ▪ Don’t store sensitive information
    ▪ Don’t store at easily readable location like
    memory card
    ▪ Encrypt the stored data
    ▪ Implement SSL


    View Slide

77. BEST PRACTICES
    ▪ Protect the webserver against application layer
    attacks
    ▪ Prefer encryption over encoding or obfuscation
    ▪ Sanitize inputs, use prepared statements
    (protection against sql injection)


    View Slide

78. BEST PRACTICES


    View Slide

79. Android Secure Coding Checklist
    ▪ Use least privilege in request permissions
    ▪ Don’t unnecessarily export components
    ▪ Handle intents carefully
    ▪ Justify any custom permissions
    ▪ Mutually authenticate services
    ▪ Use APIs to construct ContentProvider URIs
    ▪ Use HTTPS
    ▪ Follow best practices from OWASP project http://owasp.
    org/index.php/OWASP_Mobile_Security_Project


    View Slide

80. OWASP MOBILE TOP 10 RISKS


    View Slide

81. OWASP MOBILE TOP 10 RISKS


    View Slide

82. Open Android Security Assesment Methodology


    View Slide

83. PENTESTING TOOLS / SANTOKU LINUX
    o
    o
    o


    View Slide

84. PENTESTING TOOLS / NOWSECURE
    ▪ https://www.nowsecure.com/resources/freetools/


    View Slide

85. REFERENCES
    ▪ http://proguard.sourceforge.net
    ▪ http://code.google.com/p/dex2jar
    ▪ http://code.google.com/p/android-apktool
    ▪ https://labs.mwrinfosecurity.com/tools/drozer
    ▪ http://sqlcipher.net/sqlcipher-for-android
    ▪ https://www.owasp.org/index.
    php/OWASP_Mobile_Security_Project
    ▪ https://developer.android.
    com/training/articles/security-tips.html


    View Slide

86. BOOKS


    View Slide

87. BOOKS


    View Slide

88. Thanks!
    @jmortegac
    AMSTERDAM 9-12 MAY 2016


    View Slide
