Testing Docker Images Security NoConName edition 2017

En esta conferencia se presentarán las mejores praćticas a nivel de revisiones de seguridad en las imágenes de docker. En primer lugar, se verá una descripción general del proceso de despliegue de una imagen en el repositorio oficial docker hub. En segundo lugar, se comentarán las principales superficies de ataque y las amenazas sobre dichas imágenes. Por último, se verá cómo se puede detectar vulnerabilidades en las imágenes con herramientas que permite automatizar éste proceso y otras técnicas de análisis de código junto con las mejores prácticas que explican cómo remediar estas vulnerabilidades. Se harán demos con herramientas Opensource y algunos casos de uso con python.

Transcript

1. WhoamI
   Testing Docker Images Security
   José Manuel Ortega
   Noviembre 2017


   View Slide

2. WhoamI
   @jmortegac
   jmortega.github.io
   about.me/jmortegac


   View Slide

3. WhoamI
   Introduction to docker security
   Security best practices
   3. Tools for auditing docker host
   Tools for auditing docker images
   Demo


   View Slide

4. WhoamI


   View Slide

5. WhoamI


   View Slide

6. WhoamI
   ● Docker uses several mechanisms:
   ○ Linux kernel namespaces
   ○ Linux Control Groups (cgroups)
   ○ The Docker daemon
   ○ Linux capabilities (libcap)
   ○ Linux security mechanisms like
   ○ AppArmor,SELinux,Seccomp


   View Slide

7. WhoamI
   ● Provides an isolated view of the system where
   processes cannot see other processes in other
   containers
   ● Each container also gets its own network stack.
   ● A container doesn’t get privileged access to
   the sockets or interfaces of another container.


   View Slide

8. WhoamI
   ● Cgroups: kernel feature that limits and
   isolates the resource usage (CPU, memory,
   network) of a collection of processes.
   ● Linux Capabilities: divides the privileges of
   root into distinct units and smaller groups of
   privileges


   View Slide

9. WhoamI


   View Slide

10. WhoamI


    View Slide

11. WhoamI


    View Slide

12. WhoamI


    View Slide

13. WhoamI


    View Slide

14. WhoamI


    View Slide

15. WhoamI


    View Slide

16. WhoamI


    View Slide

17. WhoamI


    View Slide

18. WhoamI


    View Slide

19. WhoamI
    ● We can verify the integrity of the image
    ● Checksum validation when pulling image
    from docker hub
    ● Pulling by digest to enforce consistent


    View Slide

20. WhoamI


    View Slide

21. WhoamI


    View Slide

22. WhoamI


    View Slide

23. WhoamI
    ● A capability is a unix action a user can perform
    ● Goal is to restrict “capabilities”
    ● Privileged process = all the capabilities!
    ● Unprivileged process = check individual user
    capabilities
    ● Example Capabilities:
    ○ CAP_CHOWN
    ○ CAP_SETUID
    ○ CAP_NET_RAW
    ○ CAP_SYS_ADMIN


    View Slide

24. WhoamI


    View Slide

25. WhoamI


    View Slide

26. WhoamI


    View Slide

27. WhoamI


    View Slide

28. WhoamI


    View Slide

29. WhoamI
    Docker security is about
    limiting and controlling
    the attack surface on the
    kernel.


    View Slide

30. WhoamI
    Run filesystems as
    read-only so that attackers
    can not overwrite data or
    save malicious scripts to the
    image.


    View Slide

31. WhoamI
    ● Do not run processes in a container as root to avoid
    root access from attackers.
    ● Enable User-namespace (disabled by default.)
    ● Run filesystems as read-only so that attackers can
    not overwrite data or save malicious scripts to file.
    ● Cut down the kernel calls that a container can make
    to reduce the potential attack surface.
    ● Limit the resources that a container can use
    (SELinux/AppArmor)


    View Slide

32. WhoamI
    ● Set a specific user.
    ● Don’t run your applications as root in
    containers.


    View Slide

33. WhoamI


    View Slide

34. WhoamI


    View Slide

35. WhoamI
    ● AppArmor is a Mandatory Access Control (MAC) system
    which is a kernel (LSM) enhancement to confine
    programs to a limited set of resources. AppArmor's
    security model is to bind access control attributes to
    programs rather than to users.
    ● Security-Enhanced Linux (SELinux) is a Linux kernel
    security module that provides a mechanism for supporting
    access control security policies, including United States
    Department of Defense


    View Slide

36. WhoamI
    ● Restricts system calls based on a policy
    ● Block things like
    ○ Kernel manipulation (init_module,
    finit_module, delete_module)
    ○ Executing mount options
    ○ Change permissions
    ○ Change owner and groups


    View Slide

37. WhoamI


    View Slide

38. WhoamI


    View Slide

39. WhoamI


    View Slide

40. WhoamI


    View Slide

41. WhoamI


    View Slide

42. WhoamI
    Auditing Docker Host


    View Slide

43. WhoamI
    ● Auditing docker environment and containers
    ● Open-source tool for running automated tests
    ● Inspired by the CIS Docker 1.11 benchmark
    ● Runs against containers currently running on same host
    ● Checks for AppArmor, read-only volumes, etc...
    ● https://github.com/docker/docker-bench-security


    View Slide

44. WhoamI


    View Slide

45. WhoamI
    ● The host configuration
    ● The Docker daemon configuration
    ● The Docker daemon configuration
    files
    ● Container images and build files
    ● Container runtime
    ● Docker security operations


    View Slide

46. WhoamI
    ● The Docker daemon configuration
    ● [WARN] 2.1- Restrict network traffic between containers
    ● [WARN] 4.1 - Create a user for the container
    ● [WARN] * Running as root:
    ● [WARN] 5.4 - Restrict Linux Kernel Capabilities within
    containers
    ● [WARN] * Capabilities added: CapAdd=[audit_control]
    ● [WARN] 5.13 - Mount container's root filesystem as
    readonly
    ● [WARN] * Container running with root FS mounted R/W:


    View Slide

47. WhoamI


    View Slide

48. WhoamI


    View Slide

49. WhoamI


    View Slide

50. WhoamI
    ● https://github.com/CISOfy/lynis-docker
    ● Lynis is a Linux, Mac and Unix security
    auditing and system hardening tool that
    includes a module to audit Dockerfiles.
    ● lynis audit system
    ● lynis audit dockerfile


    View Slide

51. WhoamI


    View Slide

52. WhoamI


    View Slide

53. WhoamI


    View Slide

54. WhoamI


    View Slide

55. WhoamI
    https://github.com/CISOfy/lynis/blob/master/include/helper_audit_dockerfile


    View Slide

56. WhoamI


    View Slide

57. WhoamI


    View Slide

58. WhoamI


    View Slide

59. WhoamI
    Demo time


    View Slide

60. WhoamI
    Auditing Docker Images


    View Slide

61. WhoamI
    ● You can scan your images for known
    vulnerabilities
    ● Find known vulnerable binaries
    ● Docker Security Scanning
    ● OWASP Dependency checker
    ● Anchore Cloud
    ● Tenable.io Container Security
    ● Dagda


    View Slide

62. WhoamI


    View Slide

63. WhoamI


    View Slide

64. WhoamI


    View Slide

65. WhoamI


    View Slide

66. WhoamI
    https://hub.docker.com/r/deepfenceio/deepfence_depcheck/


    View Slide

67. WhoamI


    View Slide

68. WhoamI


    View Slide

69. WhoamI


    View Slide

70. WhoamI


    View Slide

71. WhoamI


    View Slide

72. WhoamI


    View Slide

73. WhoamI
    https://github.com/eliasgranderubio/dagda


    View Slide

74. WhoamI
    Python 3
    MongoDB
    PyMongo
    Requests
    Python-dateutil
    Joblib
    Docker-py
    Flask
    Flask-cors
    PyYAML


    View Slide

75. WhoamI


    View Slide

76. WhoamI


    View Slide

77. WhoamI


    View Slide

78. WhoamI


    View Slide

79. WhoamI
    Docker Images for Malware Analysis


    View Slide

80. WhoamI
    Demo time


    View Slide

81. WhoamI
    Signing ● Secure & sign your source
    Dependences ● Pin & verify your dependencies
    Content Trust
    ● Sign your artifacts with Docker
    Content Trust
    Privileges ● Least Privilege configurations


    View Slide

82. WhoamI
    ● https://docs.docker.com/engine/security
    ● http://www.oreilly.com/webops-perf/free/files/docker-securit
    y.pdf
    ● http://container-solutions.com/content/uploads/2015/06/15.
    06.15_DockerCheatSheet_A2.pdf
    ● Docker Content Trust
    https://docs.docker.com/engine/security/trust/content_trust
    ● Docker Security Scanning
    https://docs.docker.com/docker-cloud/builds/image-scan
    https://blog.docker.com/2016/04/docker-security
    http://softwaretester.info/docker-audit


    View Slide

83. WhoamI


    View Slide

84. WhoamI jmortega.github.io
    @jmortegac


    View Slide
