From 0 to 60 with Kubernetes and Istio

Hands on presentation to get started with your Kubernetes cluster on AWS (using kops), set up Istio and deploy and manage your multi tiered microservice application.

Transcript

1. FROM 0 TO 60 WITH KUBERNETES AND ISTIO J o o n a t h a n M ä g i
2. KUBERNETES & ISTIO § It’s not scary to get started § Kubernetes is production ready § Istio builds on Envoy but many components are early in their life and require testing for your use case § Not only for “microservices” § Complementary to Kubernetes
3. KUBERNETES § End to end system to automate management of containerized applications § Portable § Open source, started at Google, now governed by CNCF § Supports range of container tools, including Docker
4. KUBERNETES BUILDING BLOCKS § Pods § ReplicationControllers § Services § Labels § Ingress
5. WHERE CAN YOU RUN K8S § Minikube § Docker for Mac & Windows (beta signup) § Google Kubernetes Engine (previously known as Container Engine or GKE) § Azure Container Service (AKS) § Kubernetes Operations (kops) § kubeadm
6. KOPS § De facto way to provision Kubernetes on AWS § Fully automated installation § Self-healing § High-Availability support § Not only for setup but also for maintenance, upgrades, cluster cleanups
7. INSTALL KOPS AND AWS CLI Install kubectl: brew update && brew install kubernetes-cli Install kops: brew update && brew install kops Install AWS CLI Tools: brew update && brew install awscli
8. LAUNCHING A KUBERNETES CLUSTER HOSTED ON AWS You need an AWS user with the following simplified permissions for: AmazonEC2FullAccess AmazonRoute53FullAccess AmazonS3FullAccess IAMFullAccess AmazonVPCFullAccess
9. LAUNCHING A KUBERNETES CLUSTER HOSTED ON AWS S3 bucket for cluster state storage: aws s3api create-bucket \ --bucket kubernetes-example-co-uk-state-store-2 \ --region eu-central-1 \ --create-bucket-configuration LocationConstraint=eu-central-1 aws s3api put-bucket-versioning \ --bucket kubernetes-example-co-uk-state-store-2 \ --versioning-configuration Status=Enabled
10. LAUNCHING A KUBERNETES CLUSTER HOSTED ON AWS Prepare your local environment: export NAME=presentationcluster.kubernetes-example.co.uk export KOPS_STATE_STORE=s3://kubernetes-example-co-uk-state-store-2 You don’t have to use environmental variables here. You can always define the values using the --name and --state flags.
11. LAUNCHING A KUBERNETES CLUSTER HOSTED ON AWS Let’s create a cluster configuration: kops create cluster \ --zones "eu-central-1a,eu-central-1b,eu-central-1c" \ --master-zones "eu-central-1a,eu-central-1b,eu-central-1c" \ --master-count 3 \ --node-count 4 \ --topology private \ --networking kopeio-vxlan \ --bastion \ --name presentationcluster.kubernetes-example.co.uk \ --state s3://kubernetes-example-co-uk-state-store-2
12. LAUNCHING A KUBERNETES CLUSTER HOSTED ON AWS Let’s build the cluster: kops update cluster \ --name presentationcluster.kubernetes-example.co.uk \ --yes This will take a while. Once it finishes you'll have to wait while the started instances finish downloading and setting up Kubernetes components and reach a "ready" state.
13. LAUNCHING A KUBERNETES CLUSTER HOSTED ON AWS Let’s take a look at the cluster we just built: kubectl get nodes kops validate cluster kubectl get pods --namespace kube-system
14. ISTIO § Platform to connect, manage, and secure microservices § Addresses many of the challenges as we transition towards a distributed microservice architecture § Wide protocol support from TCP to higher level HTTP, gRPC, Websocket, Redis etc. § Tackles traffic management, observability, identity and security § Brings resilience and fault-injection features to the table § Builds on proven Envoy proxy from Lyft
15. INSTALL ISTIO Let’s get Istio installed: curl -L https://git.io/getLatestIstio | sh - cd istio-0.2.12 export PATH=$PWD/bin:$PATH # deploy istio kubectl apply -f install/kubernetes/istio.yaml # validate the installation kubectl get svc -n istio-system kubectl get pods -n istio-system
16. ISTIO ADDONS # let’s install some Isito addons kubectl apply -f install/kubernetes/addons/prometheus.yaml kubectl apply -f install/kubernetes/addons/grafana.yaml kubectl apply -f install/kubernetes/addons/servicegraph.yaml kubectl apply -n istio-system -f https://raw.githubusercontent.com/jaegertracing/jaeger- kubernetes/master/all-in-one/jaeger-all-in-one-template.yml
17. APPLICATION DEPLOYMENT Deploying our first application on our Istio enabled Kubernetes cluster: kubectl apply -f <(istioctl kube-inject -f samples/bookinfo/kube/bookinfo.yaml)
18. APPLICATION ON ISTIO
19. APPLICATION DEPLOYMENT kubectl get services kubectl get pods # let’s see how to access our deployed application (/productpage) kubectl get ingress -o wide http://books.kubernetes-example.co.uk/productpage
20. INTELLIGENT ROUTING # route all traffic to review v1 istioctl create -f route-rule-all-v1.yaml # route for test user “joonathan” to v3 istioctl create -f route-rule-reviews-test-v3.yaml istioctl get routerule reviews-test-v3 -o yaml # route everyones traffic to v3 istioctl replace -f route-rule-reviews-v3.yaml
21. GRAFANA # let’s look at some metrics in grafana coming in kubectl -n istio-system port-forward $(kubectl -n istio-system get pod -l app=grafana -o jsonpath='{.items[0].metadata.name}') 3000:3000 http://localhost:3000/dashboard/db/istio-dashboard
22. DOTVIZ # how are our services connected? kubectl -n istio-system port-forward $(kubectl -n istio-system get pod -l app=servicegraph -o jsonpath='{.items[0].metadata.name}') 8088:8088 http://localhost:8088/dotviz
23. JAEGER # distributed tracing using Jaeger kubectl port-forward -n istio-system $(kubectl get pod -n istio-system -l app=jaeger -o jsonpath='{.items[0].metadata.name}') 16686:16686 http://localhost:16686
24. NEXT STEPS… We covered only a small subset of what Kubernetes and Istio have to offer. Continue learning at kubernetes.io and istio.io. Come and solve interesting microservices challenges with me at MOVE Guides.
25. THANKS! http://moveguides.com/careers
