Ignition Illustrated: The CoreOS node provisioner

BayLISA meetup, Groupon, Inc: http://www.meetup.com/BayLISA/events/231269769/

Transcript

1. Josh Wood - DocOps - CoreOS @joshixisjosh9 | j@coreos.com | coreos.com/docs Ignition Illustrated: The CoreOS provisioner
3. We’re hiring in all departments! Email: careers@coreos.com Positions: coreos.com/ careers 90+ Projects on GitHub, 1,000+ Contributors OPEN SOURCE CoreOS.com - @coreoslinux - github/coreos Secure solutions, support plans, training + more ENTERPRISE sales@coreos.com - tectonic.com - quay.io CoreOS Runs the World’s Containers
4. Branding: A cautionary tale ;-)
11. Early-boot provisioning utility - for clusters at scale Set up machine given a configuration Atomic: Boot or die! Infrastructure must be dynamic; immutable by version CoreOS Ignition
12. Runs during the first boot only The clear distinction: Ignition is not config management Static configuration Written in Go - self-contained; community; CoreOS fit Configuration specification and JSON How is it different than CloudInit?
13. CloudInit runs before networkd... ...so it can’t start services that depend on the network Ignition runs early configures networkd with the unit interface… ...and services with systemd units, then pivots “Let systemd do it.” How is it different than CloudInit (2)?
14. systemd dependency tree, knowledge, tools, community… systemd is CoreOS service management Atomic provisioning (“Don’t reconfigure. Reprovision.”) Static config - no “2-stage cloud-config” invoking a sh script Same semantics across environments Why use Ignition?
15. Relatively easy to read (well, ok…) Machine oriented, machine legible, machine generated Difficult to write - let’s generate and validate it Easy to generate - wide language and library support But why JSON?!?
16. What can Ignition do?
17. Storage - disks, partitions, md (RAID), file systems systemd & networkd units - services and networks - configure etcd, kubelet Users and groups - ssh and keys Remote configs - HTTP, validate a sha for the target What can Ignition do?
18. Illustrated Ignition boot process How does this work?
19. Userspace Bootload Early Userspace Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
20. Early Userspace Userspace Bootload Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
21. Early Userspace Userspace Bootload Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
22. Early Userspace Userspace Bootload Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
23. Userspace Bootload Early Userspace Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
24. Userspace Bootload Early Userspace Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
25. Userspace Bootload Early Userspace Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
26. Userspace Bootload Early Userspace Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
27. Userspace Bootload Early Userspace Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
28. Early Userspace Userspace Bootload Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
29. Early Userspace Userspace Bootload Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
30. Early Userspace Userspace Bootload Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
31. Early Userspace Userspace Bootload Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
32. Early Userspace Userspace Bootload Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
33. Early Userspace Userspace Bootload Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
34. Early Userspace Userspace Bootload Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
35. Userspace Bootload Early Userspace Boot Process Ignition coreos-m etadata m ulti-user journald netw orkd GRUB etcd pivot netw orkd
36. Cici n’est pas un demo
37. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT ext4
38. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT ext4 /dev/vdb
39. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT ext4 /dev/vdb /dev/vdc
40. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT ext4 /dev/vdb /dev/vdc
41. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT btrfs /dev/vdb /dev/vdc
42. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT btrfs /dev/vdb /dev/vdc
43. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT btrfs /dev/vdb /dev/vdc
44. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT btrfs /dev/vdb /dev/vdc
45. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT btrfs /dev/vdb /dev/vdc
46. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT btrfs /dev/vdb /dev/vdc DATA ext4 (RAID 0)
47. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT btrfs /dev/vdb /dev/vdc DATA ext4 (RAID 0)
48. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT btrfs /dev/vdb /dev/vdc DATA ext4 (RAID 0) /config.json
49. Demo /dev/vda USR-A ext4 USR-B ext4 ROOT btrfs /dev/vdb /dev/vdc DATA ext4 (RAID 0) /config.json
50. Demo - Ignition config JSON
51. "ignition": { "version": "2.0.0" } Demo
52. "ignition": { "version": "2.0.0" } Demo
53. "disks": [ { "device": "/dev/vdb", "wipeTable": true, "partitions": [{ "label": "raid.1.1" }] }, { "device": "/dev/vdc", "wipeTable": true, "partitions": [{ "label": "raid.1.2" }] } ] Demo
54. "disks": [ { "device": "/dev/vdb", "wipeTable": true, "partitions": [{ "label": "raid.1.1" }] }, { "device": "/dev/vdc", "wipeTable": true, "partitions": [{ "label": "raid.1.2" }] } ] Demo
55. "disks": [ { "device": "/dev/vdb", "wipeTable": true, "partitions": [{ "label": "raid.1.1" }] }, { "device": "/dev/vdc", "wipeTable": true, "partitions": [{ "label": "raid.1.2" }] } ] Demo
56. "disks": [ { "device": "/dev/vdb", "wipeTable": true, "partitions": [{ "label": "raid.1.1" }] }, { "device": "/dev/vdc", "wipeTable": true, "partitions": [{ "label": "raid.1.2" }] } ] Demo
57. "disks": [ { "device": "/dev/vdb", "wipeTable": true, "partitions": [{ "label": "raid.1.1" }] }, { "device": "/dev/vdc", "wipeTable": true, "partitions": [{ "label": "raid.1.2" }] } ] Demo
58. "disks": [ { "device": "/dev/vdb", "wipeTable": true, "partitions": [{ "label": "raid.1.1" }] }, { "device": "/dev/vdc", "wipeTable": true, "partitions": [{ "label": "raid.1.2" }] } ] Demo
59. "disks": [ { "device": "/dev/vdb", "wipeTable": true, "partitions": [{ "label": "raid.1.1" }] }, { "device": "/dev/vdc", "wipeTable": true, "partitions": [{ "label": "raid.1.2" }] } ] Demo
60. "disks": [ { "device": "/dev/vdb", "wipeTable": true, "partitions": [{ "label": "raid.1.1" }] }, { "device": "/dev/vdc", "wipeTable": true, "partitions": [{ "label": "raid.1.2" }] } ] Demo
61. "raid": [{ "devices": [ "/dev/disk/by-partlabel/raid.1.1", "/dev/disk/by-partlabel/raid.1.2" ], "level": "stripe", "name": "data" }] Demo
62. "raid": [{ "devices": [ "/dev/disk/by-partlabel/raid.1.1", "/dev/disk/by-partlabel/raid.1.2" ], "level": "stripe", "name": "data" }] Demo
63. "raid": [{ "devices": [ "/dev/disk/by-partlabel/raid.1.1", "/dev/disk/by-partlabel/raid.1.2" ], "level": "stripe", "name": "data" }] Demo
64. "raid": [{ "devices": [ "/dev/disk/by-partlabel/raid.1.1", "/dev/disk/by-partlabel/raid.1.2" ], "level": "stripe", "name": "data" }] Demo
65. "raid": [{ "devices": [ "/dev/disk/by-partlabel/raid.1.1", "/dev/disk/by-partlabel/raid.1.2" ], "level": "stripe", "name": "data" }] Demo
66. "filesystems": [ { "mount": { "device": "/dev/md/data", "format": "ext4", "create": { "force": true } }, "name": "our filesystem" } ] Demo
67. "filesystems": [ { "mount": { "device": "/dev/md/data", "format": "ext4", "create": { "force": true } }, "name": "our filesystem" } ] Demo
68. "filesystems": [ { "mount": { "device": "/dev/md/data", "format": "ext4", "create": { "force": true } }, "name": "our filesystem" } ] Demo
69. "filesystems": [ { "mount": { "device": "/dev/md/data", "format": "ext4", "create": { "force": true } }, "name": "our filesystem" } ] Demo
70. "filesystems": [ { "mount": { "device": "/dev/md/data", "format": "ext4", "create": { "force": true } }, "name": "our filesystem" } ] Demo
71. "filesystems": [ { "mount": { "device": "/dev/md/data", "format": "ext4", "create": { "force": true } }, "name": "our filesystem" } ] Demo
72. "files": [{ "filesystem": "our filesystem", "path": "/config.json", "mode": 292, "contents": { "source": "http://192.168.179.1/demo.ignition" } }] Demo
73. "files": [{ "filesystem": "our filesystem", "path": "/config.json", "mode": 292, "contents": { "source": "http://192.168.179.1/demo.ignition" } }] Demo
74. "files": [{ "filesystem": "our filesystem", "path": "/config.json", "mode": 292, "contents": { "source": "http://192.168.179.1/demo.ignition" } }] Demo
75. "files": [{ "filesystem": "our filesystem", "path": "/config.json", "mode": 292, "contents": { "source": "http://192.168.179.1/demo.ignition" } }] Demo
76. "files": [{ "filesystem": "our filesystem", "path": "/config.json", "mode": 292, "contents": { "source": "http://192.168.179.1/demo.ignition" } }] Demo
77. "files": [{ "filesystem": "our filesystem", "path": "/config.json", "mode": 292, "contents": { "source": "http://192.168.179.1/demo.ignition" } }] Demo
78. { "ignition": { "version": "2.0.0", "config": { "replace": { "source": "http://192.168.179.1/demo.ign", "verification": { "hash": "sha512-98d…" } } } } } Demo
79. • Bare metal and PXE • EC2 • Azure • Google GCP GCE • VMware • coreos.com/ignition/docs/latest/supported-platforms. html Where? - Platforms and providers
80. Config verification/encryption/transport sec (HTTPS) Config generation tooling (YAML → Ignition.json) More supported platforms Your ingenious contributions! What’s next?
81. See also: • coreos.com/ignition • github.com/coreos/ignition • github.com/coreos/fuze (EXPERIMENTAL) • https://youtu.be/rYZ4Lb_n5i4
82. Thank you! Josh Wood @joshixisjosh9 | j@coreos.com | github.com/joshix We’re hiring in all departments! Email: careers@coreos.com Positions: coreos.com/ careers
