  1. MQTT
    for sysadmins and for fun
    Jan-Piet Mens
    April 2014
    @jpmens

    View Slide

  2. @jpmens: consultant,
    author, architect, part-time
    admin, small-scale fiddler,
    loves LDAP, DNS,
    plain text, and things
    that work.

    View Slide

  3. MQTT is a standard,
    a transport,
    PUB/SUB messaging,
    designed for
    unreliable networks

    View Slide

  4. transport protocol
    binary payload, 256MB, (+2 bytes)
    ,
    fast,
    lightweight, ideal for low-
    bandwith, high-latency networks

    View Slide

  5. security
    TLS
    authentication
    ACLs
    TLS-PSK
    (payload encryption)

    View Slide

  6. Quality of Service
    0 At most once
    1 Assured delivery
    2 Once only

    View Slide

  7. more features
    keepalive
    last will & testament

    View Slide

  8. compare HTTP ?
    request/response, verbose,
    push, poll, nobody hears clients
    die

    View Slide

  9. PUB/SUB
    decoupled senders recipients: flexibility
    one producer to many (changing) consumers
    no queueing
    broker can hold messages until subscriber reconnects
    durable (retain)
    Last Will and Testament
    single TCP port (easy on firewalls)

    View Slide

  10. topic names
    UTF-8, hierarchical, wildcards
    temperature/room/living
    devices/#
    finance/+/eur/rate

    View Slide

  11. PUB/SUB cauldron

    View Slide

  12. MQTT brokers
    the server bit of MQTT

    View Slide

  13. Mosquitto
    C, fast, lightweight, ACLs (plugin), TLS, TLS-PSK, bridge,
    logging via $SYS
    http://mosquitto.org

    View Slide

  14. HiveMQ
    Java, plugins, Websockets, clustering, modules
    http://hivemq.com

    View Slide

  15. more brokers
    RSMB, Mosca, Apollo, RabbitMQ

    View Slide

  16. MQTT brokers
    $SYS topic
    $SYS/broker/clients/total 1771
    $SYS/broker/messages/received 36597465
    $SYS/broker/messages/sent 39714120
    $SYS/broker/messages/stored 2941
    $SYS/broker/bytes/received 2830787008
    $SYS/broker/bytes/sent 3810653433
    $SYS/broker/version mosquitto version 1.2
    $SYS/broker/publish/messages/received 19798673
    $SYS/broker/publish/messages/sent 30622855
    $SYS/broker/publish/bytes/received 1868229299
    $SYS/broker/publish/bytes/sent 3185942282

    View Slide

  17. bridging

    View Slide

  18. CLI utilities
    mosquitto_sub -v
    [-h localhost] [-p 1883]
    [--cafile file]
    [--cert file --key file]
    [-u username [-P password]]
    [ --tls-version tlsv1.2 ]
    -t 'topic/#'
    subscribe
    publish
    mosquitto_pub
    ...
    [-r]
    -m payload

    View Slide

  19. languages
    Lua, Python, C, JavaScript, Perl, Ruby, Java, ...

    View Slide

  20. Python API: PUB
    #!/usr/bin/env python
    import paho.mqtt.publish as mqtt
    mqtt.single('conf/hello', 'Hello MQTT')
    $ mosquitto_sub -h localhost -v -t 'conf/#'
    conf/hello Hello MQTT
    payload
    topic

    View Slide

  21. Python API: SUB
    #!/usr/bin/env python
    import paho.mqtt.client as paho
    def on_connect(mosq, userdata, rc):
    mqttc.subscribe("conf/+", 0)
    def on_message(mosq, userdata, msg):
    print "%s %s" % (msg.topic, str(msg.payload))
    mqttc = paho.Client()
    mqttc.on_connect = on_connect
    mqttc.on_message = on_message
    mqttc.connect("localhost", 1883, 60)
    mqttc.loop_forever()
    callbacks

    View Slide

  22. Python API: SUB
    $ mosquitto_pub -t 'conf/thirsty' -m 'Beertime?'
    $ mosquitto_pub -t 'conf/catering' -m 'Coffee is ready'
    $ ./sub.py
    conf/thirsty Beertime?
    conf/catering Coffee is ready

    View Slide

  23. devices

    View Slide

  24. devices

    View Slide

  25. practical solutions
    alerting, metering, logging, location awareness, tracking,
    automation, and controlling

    View Slide

  26. MQTT out there
    Github (notifications), power metering, trains, FaceBook
    messenger, connected cars, temperature monitoring, host
    monitoring (load)

    View Slide

  27. system utilities
    Ansible (notifications), Fluentd (logging), Diamond (system
    metrics), mqtt-watchdir, Jenkins, (build logs),

    View Slide

  28. database persistence
    SUB and store in any SQL or
    NoSQL database

    View Slide

  29. alerting: mqttwarn
    https://github.com/jpmens/mqttwarn

    View Slide

  30. job control, reporting
    https://gist.github.com/jpmens/7101170
    $ mosquitto_sub -v -t 'processes/#'
    processes/run.sh Starting
    processes/run.sh Still running
    processes/monitor/spec1 Starting
    processes/run.sh Still going strong at Tue Oct 22 15:49:07 CEST 2013
    processes/run.sh That's it, folks!

    View Slide

  31. WebSockets
    HiveMQ, WSS, lighttpd mod_websocket

    View Slide

  32. WebSockets
    http://www.hivemq.com/demos/websocket-client/

    View Slide

  33. View Slide

  34. View Slide

  35. Node-RED
    http://nodered.org

    View Slide

  36. mqtt.org
    @mqttorg

    View Slide
