1. General Pigeonhole Principle
   Shunsuke Kanda (proper string beginner)
   1
   StringBeginners#1


   View Slide

2. Literature
   2
   } IEEE International Conference on Data Engineering
   (ICDE), 2018


   View Slide

3. Background
   3
   } Finding similar objects of high-dimensional vectorial data is a
   fundamental task in recent data analysis
   Original space (high dimension)
   q
   xi
   Hamming space (low dimension)
   q’
   x’i
   similarity-preserving
   hashing
   } e.g., near duplication detection in Web pages [Manku et al., WWW07]
   } Web pages are converted into 64-bit vectors using SimHash
   } Jaccard similarity between Web pages is approximated by Hamming
   distance between 64-bit vectors
   costly lightweight


   View Slide

4. Problem definition
   } We have n binary strings x1
   , …, xn
   of length m each
   } Given a query string q and threshold t, the goal is to
   report all string ids i such that Ham(q, xi
   ) ≤ t
   } where Ham(·, ·) is the Hamming distance between two strings
   4
   Dataset
   x1
   0000 0000
   x2
   0000 0111
   x3
   0000 1111
   x4
   1001 1111
   Given q = 0000 0111 and t = 2 Ham(0000 0111,
   0000 0000) = 3 > t
   Ham(0000 0111,
   0000 0111) = 0 ≤ t
   Ham(0000 0111,
   0000 1111) = 1 ≤ t
   Ham(0000 0111,
   1001 1111) = 3 > t
   2
   3


   View Slide

5. How to solve?
   5
   } Brute-force linear scan: O(n) time
   } Ham(x, y) can be computed by popcnt(x xor y) in O(1) when a
   string is within a machine word
   } Modern solutions use inverted-index-based approaches
   Dataset
   x1
   0000 0000
   x2
   0000 0111
   x3
   0000 1111
   x4
   1001 1111
   O(n)
   Ham(0000 0111,
   1001 1111) = 3
   0000 0111
   xor
   1001 1111
   =
   1001 1000 popcnt(1001 1000) = 3


   View Slide

6. Inverted-index-based solution
   6
   } Approach
   } Build an inverted index from the strings
   } Generate a set of strings whose Hamming distance for query q is no
   more than t, Q = {q’ ∈ {0,1}m: Ham(q, q’) ≤ t}, called signatures
   } Find a set of string ids whose key is in Q by retrieving the index
   } Problem
   } |Q| becomes too large for long strings and large thresholds
   Index id
   0000 0000 1
   0000 0111 2
   0000 1111 3
   1001 1111 4
   |Q| =
   t
   X
   k=0
   ✓
   m
   k
   ◆
   Dataset
   x1
   0000 0000
   x2
   0000 0111
   x3
   0000 1111
   x4
   1001 1111
   Given q = 0000 0111 and t = 1,
   Generate Q = { 0000 0111,
   1000 0111,
   0100 0111,
   0010 0111,
   0001 0111,
   0000 1111,
   0000 0011,
   0000 0101,
   0000 0110 }
   Results = {2, 3}


   View Slide

7. Multi-index approach
   7
   } Aim
   } To leverage the index approach also for large parameters
   } Preprocessing
   } Partition string xi
   into b disjoint blocks
   } Build inverted indexes for each block
   1st 2nd
   x1
   0000 0000
   x2
   0000 0111
   x3
   0000 1111
   x4
   1001 1111
   1st id
   0000 1, 2, 3
   1001 4
   2nd id
   0000 1
   0111 2
   1111 3, 4
   When b = 2,


   View Slide

8. Multi-index approach
   8
   } Query processing: filter-and-verification strategy
   } Partition q into b disjoint blocks q1
   , q2
   , …, qb
   } (Filter phase): Obtain candidates by retrieving each index with Qj
   =
   {q’ ∈ {0,1}m/b: Ham(qj
   , q’) ≤ ⌊t/b⌋} for each block j
   } ⌊t/b⌋ is based on the pigeonhole principle
   1st id
   0000 1, 2, 3
   1001 4
   2nd id
   0000 1
   0111 2
   1111 3, 4
   1st block: q1
   = 0000, ⌊t/b⌋ = ⌊1/2⌋ = 0
   Q1
   = {0000}
   2nd block: q2
   = 0111, ⌊t/b⌋ = 0
   Q2
   = {0111}
   Given q = 0000 0111 and t = 1
   Candidates = {1, 2, 3}


   View Slide

9. Multi-index approach
   9
   } Query processing: filter-and-verification strategy
   } Partition q into b disjoint blocks q1
   , q2
   , …, qb
   } (Filter phase): Obtain candidates by retrieving each index with Qj
   =
   {q’ ∈ {0,1}m/b: Ham(qj
   , q’) ≤ ⌊t/b⌋} for each block j
   } ⌊t/b⌋ is based on the pigeonhole principle
   } (Verification phase): Verify those candidates with the original strings
   x1
   , …, xn
   by computing the Hamming distance
   Dataset
   x1
   0000 0000
   x2
   0000 0111
   x3
   0000 1111
   x4
   1001 1111
   Candidates = {1, 2, 3}
   Ham(q, x1
   ) = 3 > t
   Ham(q, x2
   ) = 0 ≤ t
   Ham(q, x3
   ) = 1 ≤ t
   verification!
   Results = {2, 3}
   Does the threshold ⌊t/b⌋
   never allow false negatives?
   Question
   Given q = 0000 0111 and t = 1


   View Slide

10. Pigeonhole principle ()
    10
    } If n items are contained in m boxes, then at least one box
    has no more than ⌊n/m⌋ items
    4 boxes
    7 items


    View Slide

11. Pigeonhole principle ()
    11
    } If n items are contained in m boxes, then at least one box
    has no more than ⌊n/m⌋ items
    4 boxes
    7 items
    ⌊n/m⌋ = ⌊7/4⌋ = 1


    View Slide

12. Pigeonhole principle ()
    12
    } If n items are contained in m boxes, then at least one box
    has no more than ⌊n/m⌋ items
    } Many existing solutions based on the principle
    } Google (WWW2007), HEngine (ICDE2013), HmSearch
    (SSDBM2013), MIH (CVPR2012), PartAlloc (VLDB2015), multi-
    index* (SIGIR2016) and so on…
    q = 0000 1111 0000 1111
    x = 0011 0011 0011 1011
    4 boxes and 7 items
    Ham(q4
    , x4
    ) ≤ ⌊7/4⌋ = 1


    View Slide

13. Qin’s claim in ICDE18
    13
    } Is the threshold assignment based on the (basic) pigeonhole
    principle tight?
    } The tightness means that
    } (correctness) false negative never occurs with the threshold
    assignment, and
    } (minimality) there does not exist another threshold assignment
    whose values are smaller (simplified)
    } Smaller thresholds can reduce filter and verification costs
    } Unfortunately, the existing assignment is not tight
    } The general pigeonhole principle offers such tight assignment


    View Slide

14. Flexible pigeonhole principle
    14
    } Lemma (integer)
    } Given strings q = q1
    , q2
    , …, qb
    and x = x1
    , x2
    , …, xb
    , and threshold t
    } Consider thresholds t1
    , t2
    , …, tb
    such that tj
    are integers and ∑ tj
    = t
    } If Ham(q, x) ≤ t, there exists at least one block j such that Ham(qj
    , xj
    ) ≤ tj
    } Proof
    } Assume there is no block j such that Ham(qj
    , xj
    ) ≤ tj
    } Ham(q, x) = ∑ Ham(qj
    , xj
    ) > ∑ tj
    = t contradicts Ham(q, x) ≤ t
    1st 2nd 3rd 4th
    qj
    0000 1111 0000 1111
    xj
    0001 0011 0011 1111
    tj
    1 1 1 1
    When t = 4,
    ∑ tj
    = t = 4


    View Slide

15. Flexible pigeonhole principle
    15
    } Lemma (real)
    } Given strings q = q1
    , q2
    , …, qb
    and x = x1
    , x2
    , …, xb
    , and threshold t
    } Consider thresholds t1
    , t2
    , …, tb
    such that tj
    are real numbers and ∑ tj
    = t
    } If Ham(q, x) ≤ t, there exists at least one block j such that Ham(qj
    , xj
    ) ≤ ⌊tj
    ⌋
    } Proof
    } Assume there is no block j such that Ham(qj
    , xj
    ) ≤ ⌊tj
    ⌋
    } Ham(q, x) = ∑ Ham(qj
    , xj
    ) > ∑ tj
    = t contradicts Ham(q, x) ≤ t
    1st 2nd 3rd 4th
    qj
    0000 1111 0000 1111
    xj
    0001 0011 0011 1111
    tj
    0.8 0.8 0.8 1.6 ∑ tj
    = t = 4
    When t = 4,


    View Slide

16. Flexible pigeonhole principle
    16
    } Lemma (real)
    } Given strings q = q1
    , q2
    , …, qb
    and x = x1
    , x2
    , …, xb
    , and threshold t
    } Consider thresholds t1
    , t2
    , …, tb
    such that tj
    are real numbers and ∑ tj
    = t
    } If Ham(q, x) ≤ t, there exists at least one block j such that Ham(qj
    , xj
    ) ≤ ⌊tj
    ⌋
    } Proof
    } Assume there is no block j such that Ham(qj
    , xj
    ) ≤ ⌊tj
    ⌋
    } Ham(q, x) = ∑ Ham(qj
    , xj
    ) > ∑ tj
    = t contradicts Ham(q, x) ≤ t
    1st 2nd 3rd 4th
    qj
    0000 1111 0000 1111
    xj
    0001 0011 0011 1111
    tj
    0.8 0.8 0.8 1.6
    ⌊tj
    ⌋ 0 0 0 1
    Integer reduction
    ⌊t/b⌋ 1 1 1 1
    When t = 4,


    View Slide

17. General pigeonhole principle
    17
    } Theorem
    } Given strings q = q1
    , q2
    , …, qb
    and x = x1
    , x2
    , …, xb
    , and threshold t
    } Consider thresholds t1
    , t2
    , …, tb
    such that tj
    are integers and ∑ tj
    = t–b+1
    } If Ham(q, x) ≤ t, there exists at least one block j such that Ham(qj
    , xj
    ) ≤ tj
    } Proof
    1st 2nd … b–1th bth
    tj
    t1
    t2
    … tb-1
    tb
    ∑ tj
    = t–b+1


    View Slide

18. General pigeonhole principle
    18
    } Theorem
    } Given strings q = q1
    , q2
    , …, qb
    and x = x1
    , x2
    , …, xb
    , and threshold t
    } Consider thresholds t1
    , t2
    , …, tb
    such that tj
    are integers and ∑ tj
    = t–b+1
    } If Ham(q, x) ≤ t, there exists at least one block j such that Ham(qj
    , xj
    ) ≤ tj
    } Proof
    1st 2nd … b–1th bth
    tj
    t1
    t2
    … tb-1
    tb
    +1 +1 +1 +0
    t’j
    t1
    +1 t2
    +1 … tb-1
    +1 tb
    ∑ tj
    = t–b+1
    ∑ t’j
    = t (Lemma integer)


    View Slide

19. General pigeonhole principle
    19
    } Theorem
    } Given strings q = q1
    , q2
    , …, qb
    and x = x1
    , x2
    , …, xb
    , and threshold t
    } Consider thresholds t1
    , t2
    , …, tb
    such that tj
    are integers and ∑ tj
    = t–b+1
    } If Ham(q, x) ≤ t, there exists at least one block j such that Ham(qj
    , xj
    ) ≤ tj
    } Proof
    1st 2nd … b–1th bth
    tj
    t1
    t2
    … tb-1
    tb
    +1 +1 +1 +0
    t’j
    t1
    +1 t2
    +1 … tb-1
    +1 tb
    –ε –ε –ε +(b–1)ε
    t’’j
    t1
    +1–ε t2
    +1–ε … tb-1
    +1–ε tb
    +(b–1)ε
    ∑ tj
    = t–b+1
    ∑ t’j
    = t (Lemma integer)
    ∑ t’’j
    = t (Lemma real)
    ε: small positive real number


    View Slide

20. General pigeonhole principle
    20
    } Theorem
    } Given strings q = q1
    , q2
    , …, qb
    and x = x1
    , x2
    , …, xb
    , and threshold t
    } Consider thresholds t1
    , t2
    , …, tb
    such that tj
    are integers and ∑ tj
    = t–b+1
    } If Ham(q, x) ≤ t, there exists at least one block j such that Ham(qj
    , xj
    ) ≤ tj
    } Proof
    ⌊t’’j
    ⌋ t1
    t2
    … tb-1
    tb
    ∑ tj
    = t–b+1
    ∑ t’j
    = t (Lemma integer)
    ∑ t’’j
    = t (Lemma real)
    Integer reduction
    1st 2nd … b–1th bth
    tj
    t1
    t2
    … tb-1
    tb
    +1 +1 +1 +0
    t’j
    t1
    +1 t2
    +1 … tb-1
    +1 tb
    –ε –ε –ε +(b–1)ε
    t’’j
    t1
    +1–ε t2
    +1–ε … tb-1
    +1–ε tb
    +(b–1)ε
    ε: small positive real number


    View Slide

21. General pigeonhole principle
    21
    } Theorem
    } Given strings q = q1
    , q2
    , …, qb
    and x = x1
    , x2
    , …, xb
    , and threshold t
    } Consider thresholds t1
    , t2
    , …, tb
    such that tj
    are integers and ∑ tj
    = t–b+1
    } If Ham(q, x) ≤ t, there exists at least one block j such that Ham(qj
    , xj
    ) ≤ tj
    1st 2nd 3rd 4th
    qj
    0000 1111 0000 1111
    xj
    0001 0011 0011 1111
    tj
    0 0 0 1
    When t = 4 and b = 4
    ∑ tj
    = t–b+1=1
    ⌊t/b⌋ 1 1 1 1


    View Slide

22. Results
    22
    } Method
    } GPH: Multi-index based on the general principle
    } MIH: Multi-index based on the basic principle
    } Dataset
    } SIFT: a billion binary strings of length 128


    View Slide

23. Next stage
    23
    } Utilizing data skewness
    } Varying block lengths depending on the data skewness
    } Qin et al., “GPH: Similarity Search in Hamming Space,” ICDE,
    2018
    } Utilizing adjacent thresholds
    } To shorten the verification time with stronger constraints
    } Qin and Xiao, “Pigeonring: A Principle for Faster Thresholded
    Similarity Search,” VLDB, 2018
