1. MindCamp 6 May 23-25, 2014 MindCamp 6 May 23-25, 2014
2. Copy protection & cracking history By @Kartones
3. Agenda • Storage of data • Techniques of copy protection • Cheating (bonus section)
4. Storage Filesystem • Recommended encrypted – Even in consoles & mobile • Easy to detect – Process Monitor – Obfuscation useless
5. Storage System Registry (Windows) • Recommended encrypted • Easy to detect – Process Monitor – Not very safe
6. Storage Remote Server • Depends on server security • Depends on connection QoS
7. Storage Paper! • Code Wheels • Instructions manual words
8. Storage Cassetes • Cheap
9. Storage Cassetes • Easy & cheap to copy
10. Storage Cartidges • Hardware bound • Really hard to copy
11. Storage Cartidges • Always possible to dump • Once hacked, multi-game cartidges
12. Storage NES Floppy Disks
13. Storage NES Floppy Disks
14. Storage Floppy Disks • Special “unreadable” sectors • Custom partition formats
15. Storage Floppy Disks • Always a way to copy or convert
16. Storage Custom Optical Drives • Hard or impossible to duplicate • Propietary formats • Physical modifications
17. Storage Custom Optical Drives • Console mod to accept other format (e.g. GD-ROM -> CD-ROM) • ISO dump & ISO loader • Can be faster than original!
18. Storage A/V Streaming • Emerging technology • Usually subscription-based
19. Storage A/V Streaming • Classic cracking impossible • Probably fake accounts • Still not widely used
20. Techniques Undocummented Hardware/Firmware • Modified motherboards / CPU / firmwares – E.g. XBox 360 DVD drive special firmware
21. Techniques Undocummented Hardware/Firmware • Hidden backdoors – 360 DVDdrive debug mode • Engineers with time – Firmware “diffs” • Documentation leaks • CPU exceptions • Firmware glitches
22. Techniques ROM & Flash based storage • ROM OS Bootstrap – Cannot be modified – Can be encrypted (Xbox 360 onwards) • Main OS data on Flash • Can get more complex – Boot mini-ROM -> decrypt ROM -> check Flash hash -> boot flash
23. Techniques ROM & Flash based storage • “Chips” w/secondary ROM – Boot original -> redirect to 2nd ROM • Satellite software can have bugs – PSP: Tiff buffer overflow – Xbox: Unsigned Dashboard font files – Savegame buffer vulnerabilities Great paper: 17 Mistakes Microsoft Made in the Xbox Security System
24. Techniques Time/Uses based Trial • Stops working after X days/uses • Usually allows full version – Exception: 3DS demos
25. Techniques Time/Uses based Trial • System clock == trivial “crack” • Encrypt value – 1st launch date, # remaining uses… • Only obfuscation? BAD – Process Monitor
26. Techniques CD-Check • CD must be in drive • Unreadable sectors • Special formatted partitions • Usually combined (like CD-Key) • Made game load slower • DEPRECATED
27. Techniques CD-Check • Clone CD, Blindwrite… – able to read most CDs • CD-Drive emulators + ISOs – DaemonTools • Cracks – Disable or fake check • Special FAIL mention: PS2 Game Swap Trick
28. Techniques Game CD-Key • Permanent, unbinded • Reusable – Local validity check – Online check • install and/or play time – Online activation with # max activations
29. Techniques Game CD-Key • Extract validation algorithm – Create a Keygen • Patch validation algorithm – Allow to accept anything as valid – Crack • Distribute CD-Keys in .NFO – Blacklisting + online checks rendered this obsolete
30. Techniques Registration CD-Key • Binds upon registering • User/Email + Password • As safe as user password • Validation at install time • Usually online validation at play time • Binds IAPs to a certain account • Commercial services available – Microsoft SLP – Steam – Apple Store, Play Store…
31. Techniques Registration CD-Key • Patch validation algorithm • Create fake validation server app
32. Techniques PC Hardware binded • Network MAC, HDD Serial, CPU ID… • Severe restrictions – Any change needs reactivation
33. Techniques PC Hardware binded • Device ID emulators • Bypassing checks
34. Techniques USB Dongle • Needs plugged at launch time • Uncommon for videogames • Copy-protected – HDD special partitions – HDD sectors with special data – Custom Hardware – Custom Firmware
35. Techniques USB Dongle • Dongle emulator • Patch validation algorithm • Extract validation binaries, distribute them
36. Techniques Online play • Remote servers • Sometimes game data online only
37. Techniques Online play • Dump & decrypt received game data – Singleplayer games • Server emulator – Multiplayer games – Hard to keep up with updates
38. Techniques CD-Key/Serial Generation • Assymetric encryption • Partial Key Verification
39. Techniques CD-Key/Serial Generation • Crypto expert can always detect encryption pattern in dissasembled code
40. Techniques Code/Data Obfuscation • Binaries obfuscation – Headers manipulation – Packing… • Custom/obfuscated data formats
41. Techniques Code/Data Obfuscation • Java/.NET/ASM dissassemblers • Reflection tools – Managed languages • Patient cracker will discover any “hidden” format – e.g. Game File Format Central website
42. Techniques Binaries Encryption • Many tools available for PC • Consoles now do it – Even for the ROM
43. Techniques Binaries Encryption • IDA (cross-platform dissasembler & debugger) • Memory dumpers • Emulation systems – If you can’t crack it, emulate a legit scenario – Slower than a real crack
44. Techniques Binaries Signing • Binary comes “clean” -> can’t run • “Something” signs -> can run – Usually per-user signature – System-wide signature • e.g. system updates • Consoles • Some mobile platforms
45. Techniques Binaries Signing • If gets broken, SPOF – XBox360 JTAG: Auto self-signing
46. Techniques Gaming SDKs • Steam, Games For Windows Live * • Memory & binaries protection – Unsafe memory modification -> crash to desktop – Anti-debugging measures – Disallows game modding • Except if game has solid modding SDK
47. Techniques Gaming SDKs • Generic SDK == Generic crack Tool – SteamEmu, rev-emu, rev-launcher – XLiveLess • Always ends up cracked/emulated
48. Cheating Hardware
49. Cheating Software
50. Final Advice Crackers have more time and more determination than you Focus on quality content, not anti-piracy measures
51. The End Slides will be at http://slides.kartones.net
