  1. あなたの知らない
    MeasurementsとUnitsの世界
    2018/09/01 iOSDC LT
    @ken0nek

    View Slide

  2. Measurements & Units ??

    View Slide

  3. Measurements & Unitsとは
    iOS10からFoundation.frameworkに追加された、
    数量と単位を扱う仕組み
    ● 数量の単位変換
    ● 数量の表示形式
    8 km 5 mile
    Value
    Measurement
    Unit

    View Slide

  4. https://www.apple.com/ios/health/

    View Slide

  5. Measurement

    View Slide

  6. Measurementの定義
    /// A `Measurement` is a model type that holds a `Double` value associated with a `Unit`.
    /// Measurements support a large set of operators, including `+`, `-`, `*`, `/`, and a full set of
    comparison operators.
    public struct Measurement where UnitType : Unit {
    /// The unit component of the `Measurement`.
    public let unit: UnitType
    /// The value component of the `Measurement`.
    public var value: Double
    /// Create a `Measurement` given a specified value and unit.
    public init(value: Double, unit: UnitType)
    }
    (一部略)

    View Slide

  7. Measurementの使い方
    8 km
    Value
    Measurement
    Unit
    let _8km: Measurement
    = Measurement(value: 8, unit: UnitLength.kilometers)
    // 8.0 km

    View Slide

  8. Measurementの特徴 <単位変換>
    let _8km: Measurement
    = Measurement(value: 8, unit: UnitLength.kilometers)
    // 8.0 km
    let _5mi = _8km.converted(to: UnitLength.miles)
    // 5.0 mi
    8 km 5 mile
    (正確には 4.97098189319845 mi)

    View Slide

  9. Measurementの特徴 <加減乗除>
    let _4km = Measurement(value: 4, unit: .kilometers)
    let _1km = Measurement(value: 1, unit: .kilometers)
    _4km + _1km // 5.0 km
    _4km - _1km // 3.0 km
    _4km * 2 // 8.0 km
    _4km / 2 // 2.0 km
    let _3mi = Measurement(value: 3, unit: .miles)
    _4km + _3mi // 8828.02 m

    View Slide

  10. Unit & Dimension

    View Slide

  11. Unit

    View Slide

  12. UnitとDimensionについて
    open class Unit {
    open var symbol: String { get }
    public init(symbol: String)
    }
    open class Dimension : Unit {
    @NSCopying open var converter: UnitConverter { get }
    public init(symbol: String, converter: UnitConverter)
    open class func baseUnit() -> Self
    }
    (一部略)

    View Slide

  13. Unitの定義
    open class Unit {
    open var symbol: String { get }
    public init(symbol: String)
    }
    (一部略)

    View Slide

  14. Unitの特徴
    記号 “km”
    次元 長さ
    基本単位との変換 1 km = 1000 m
    例: UnitLength.kilometers

    View Slide

  15. Dimension

    View Slide

  16. Dimensionの定義
    open class Dimension : Unit {
    @NSCopying open var converter: UnitConverter { get }
    public init(symbol: String, converter: UnitConverter)
    open class func baseUnit() -> Self
    }
    (一部略)

    View Slide

  17. Dimensionの特徴
    ● 単位の種類を表す(長さ、重さ、速さなど)
    ● 異なる単位で表すことができる
    UnitLength: m, km, mi, ft, yd, etc.
    ● 基本単位を必ず持つ
    UnitLength: m(メートル)
    ● 同一次元内で単位変換できる
    km ⇄ m, mi ⇄ ft

    View Slide

  18. Dimensionについて <定義の豊富さ>
    UnitLength UnitArea UnitAngle
    UnitDuration UnitMass UnitSpeed
    UnitPressure UnitTemprature UnitAcceleration
    国際単位系に準拠した単位が
    170個以上

    View Slide

  19. まとめ
    ● Measurements&UnitsはiOS10から導入された
    数量と単位を扱う仕組み
    ● 単位変換やローカライズが簡単に実現できる
    発展編...
    ● UnitConverter
    ● MeasurementFormatter
    ● カスタム単位の実装方法
    ● カスタム次元の実装方法

    View Slide

  20. Reference
    ● Measurements and Units - WWDC 2016 - Videos - Apple Developer
    ● Units and Measurement | Apple Developer Documentation
    ● Measurement - Foundation | Apple Developer Documentation
    ● Unit - Foundation | Apple Developer Documentation
    ● Dimension - Foundation | Apple Developer Documentation
