Shellac: a distributed web accelerator

Transcript

1. Shellac A distributed web accelerator. Kalan MacRow Data at Scale

   ‘13

2. Shellac. (noun) Lac bug resin melted into thin flakes, used

   for making varnish Kalan MacRow Data at Scale ‘13

3. Shellac. (verb) To defeat or beat (someone) decisively Kalan MacRow

   Data at Scale ‘13

4. 5.2% of the top 10,000 sites. Kalan MacRow Data at

   Scale ‘13

5. Kalan MacRow Data at Scale ‘13 ! Script interpreters 50+

   SQL queries Localization Personalization Template rendering …. ! 3 sec.

6. • HTTP/1.1 proxy server for Linux 2.5+ • Distributed RAM

   cache built on Memcached • Level-triggered edge-polling architecture • 1K lines of Python Kalan MacRow Data at Scale ‘13 Design

7. Kalan MacRow Data at Scale ‘13 “The key to making

   programs fast is to make them do practically nothing” — Mike Haertel, original author of GNU grep Design

8. Kalan MacRow Data at Scale ‘13 • I/O bound and

   largely avoids the GIL • Substantial function/method/syscall call overhead • Iteration with while, for expensive • Event dispatch really suffers, but… Design

9. Load Balancer Web Server Accelerator Cache Web Server Accelerator Cache

   Web Server Accelerator Cache Typical HA Kalan MacRow Data at Scale ‘13

10. Shellac HA Kalan MacRow Data at Scale ‘13 Load Balancer

    Web Server Shellac Web Server Shellac Web Server Shellac Cache Dedicated Cache

11. Kalan MacRow Data at Scale ‘13 • Interested in performance

    both • as a proxy / load balancer • as a caching proxy / accelerator • Graphs: best of Apache, Varnish and worst for Shellac over 3 runs Evaluation

12. Kalan MacRow Data at Scale ‘13 • 4 x m1.large

    instances (4 core Xeon, 8GB) • Elastic Load Balancer • Master for running benchmarks • One availability zone, one region

13. Kalan MacRow Data at Scale ‘13 Evaluation Apache Benchmark (-n

    10k -c 1000)

14. Evaluation Kalan MacRow Data at Scale ‘13 Apache Benchmark (-n

    10k -c 1000)

15. Evaluation Kalan MacRow Data at Scale ‘13 Apache Benchmark (-n

    10k -c 1000)

16. Kalan MacRow Data at Scale ‘13 Static Dynamic 1 Dynamic

    2 Requests / sec. (mean) Evaluation 10K requests, 1K clients

17. Static Dynamic 1 Dynamic 2 Transfer Rate (KB/s) Kalan MacRow

    Data at Scale ‘13 Evaluation 10K requests, 1K clients

18. Static Dynamic 1 Dynamic 2 Peak Memory Usage (MB) Kalan

    MacRow Data at Scale ‘13 Evaluation

19. Kalan MacRow Data at Scale ‘13 Conclusions • Shellac 0.1.0a

    is competitive • as a proxy / load balancer • as a caching proxy / accelerator • A C port might shellac Varnish!

20. Future • HTTP/1.1 compliance • Try with PyPy JIT’ing, eventually

    port to C • Binary format for cache entries • Tighter integration of cache node with proxy Kalan MacRow Data at Scale ‘13

21. https://github.com/kmacrow/Shellac Kalan MacRow Data at Scale ‘13
