Click Modular Router merupakan suatu router berbasis PC. Karena sifatnya yang flexible dan configurable, router ini biasanya digunakan untuk riset mengenai jaringan komputer ataupun riset mengenai fungsionalitas router sendiri. Tech talk kali ini membahas tentang bagaimana mengkonfigurasi dan menambah fitur pada Click Modular Router.

Transcript

1. Click Modular Router: Introduction Junita Sinambela
2. Click Modular Router PC based Router in C++ by Eddie Kohler Flexible and configurable Assembled by packet processing modules called elements Run the router using configuration file
3. Elements Process incoming packet through the router Can change and route the packet Written in a C++ class (with cc and hh format file)
4. How to Write Your Element const char *class_name() const; // return your element's name void push(int i, Packet *); // process push request on input i Packet *pull(int i); // process pull request on output i Packet *simple_action(Packet *); // for agnostic elements const char *port_count() const; // return port count code const char *processing() const; // return processing code int configure(Vector<String> &, ErrorHandler *); // process configuration string void add_handlers(); // set up element handlers int initialize(ErrorHandler *); // initialize element void cleanup(CleanupStage); // clean up element state
5. Configuration File
6. How to add new feature in Click Modular Router Add the element by hh, cc file in CLICKDIR/elements/ ./configure make elemlist Compile it (gmake or make install)
7. Run The Router Add .click file as configuration file click PATH_TO_CONF_FILE
