The Ceph Distributed Storage System

The Ceph Distributed Storage System

Slides of my introduction to the Ceph Distributed Storage System for the SAGE@GUUG meetup in Hamburg, Germany - http://guug.de/lokal/hamburg/index.html

Lenz Grimmer

May 24, 2018
Tweet

More Decks by Lenz Grimmer

Other Decks in Technology

Transcript

  1. The Ceph Distributed Storage System
    Lenz Grimmer
    [email protected]

    View Slide

  2. 2
    Ceph Overview
    A distributed storage system
    Object, block, and file storage in one unified system
    Designed for performance, reliability and scalability

    View Slide

  3. 3
    Ceph Motivating Principles
    Everything must scale horizontally
    No single point of failure (SPOF)
    Commodity (off-the-shelf) hardware
    Self-manage (whenever possible)
    Client/cluster instead of client/server
    Avoid ad-hoc high-availability
    Open source (LGPL)

    View Slide

  4. 4
    Ceph Architectural Features
    Smart storage daemons
    • Centralized coordination of dumb devices does not scale
    • Peer to peer, emergent behavior
    Flexible object placement
    • “Smart” hash-based placement (CRUSH)
    • Awareness of hardware infrastructure, failure domains
    No metadata server or proxy for finding objects
    Strong consistency (CP instead of AP)

    View Slide

  5. 5
    Ceph Components

    View Slide

  6. 6
    MONs
    Tracks & Monitor the health of the cluster
    Maintains a master copy of the cluster map
    Consensus for distributed decision making
    MONs DO NOT serve data to clients

    View Slide

  7. 7
    OSDs
    Object Storage Deamon
    Store the actual data as objects on physical disks
    Serve stored data to clients
    Replication mechanism included
    Minimum of 3 OSDs recommended for data replication

    View Slide

  8. 8
    Ceph Pools
    Logical container for storage objects
    Replicated or erasure coding
    Dedicated CRUSH rules

    View Slide

  9. 9
    Placement Groups
    Helper to balance the data across the OSDs
    One PG typically spans several OSDs
    One OSD typically serves many PGs
    Recommended ~150 PGs per OSD

    View Slide

  10. 10
    CRUSH Map
    Controlled Replication Under Scalable Hashing
    MONs maintain the CRUSH map
    Topology of any environment can be modeled (row, rack, host, dc...)

    View Slide

  11. 11
    Basic Ceph Cluster (MONs and OSDs only)

    View Slide

  12. 12
    Write Data

    View Slide

  13. 13
    Read Data

    View Slide

  14. 14
    Ceph Object Store Features
    RESTful Interface
    S3- and Swift-compliant APIs
    S3-style subdomains
    Unified S3/Swift namespace
    User management
    Usage tracking
    Striped objects
    Cloud solution integration
    Multi-site deployment
    Multi-site replication

    View Slide

  15. 15
    Ceph Block Device Features
    Thin-provisioned
    Images up to 16 exabytes
    Configurable striping
    In-memory caching
    Snapshots
    Copy-on-write cloning
    Kernel driver support
    KVM/libvirt support
    Back-end for cloud solutions
    Incremental backup
    Disaster recovery (multisite asynchronous replication)

    View Slide

  16. 16
    Ceph Filesystem Features
    POSIX-compliant semantics
    Separates metadata from data
    Dynamic rebalancing
    Subdirectory snapshots
    Configurable striping
    Kernel driver support
    FUSE support
    NFS/CIFS deployable
    Use with Hadoop (replace HDFS)

    View Slide

  17. View Slide
