1. SPIRAL PATCH EXEMPLAR-BASED INPAINTING OF 3D COLORED MESHES Olivier L´ ezoray and S´ ebastien Bougleux Normandie Univ, UNICAEN, ENSICAEN, CNRS, GREYC, Caen, FRANCE olivier.lezoray@unicaen.fr https://lezoray.users.greyc.fr
2. Outline 1. Introduction 2. Local spiral hop descriptors 3. Proposed 3D Mesh Inpainting algorithm 4. Results 5. Conclusion O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 2 / 33
3. Outline 1. Introduction 2. Local spiral hop descriptors 3. Proposed 3D Mesh Inpainting algorithm 4. Results 5. Conclusion O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 3 / 33
4. Introduction ▶ Recent technological advances have led to the generation of huge amounts of 3D data ▶ Even with cheap hardware and software, one can easily generate 3D data: ▶ 3D data acquisition with common smartphone (e.g., Photogrammetry) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 4 / 33
5. New applications Fields ▶ With this proliferation of such 3D Data, new application fields have appeared ▶ Digital Forensics, Cultural Heritage, Body Scanning ▶ The scanned data will often need to be consolidated (to fix scan problems or remove unwanted elements) → Inpainting O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 5 / 33
6. What is inpainting ? O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 6 / 33
7. What is inpainting ? O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 6 / 33
8. What is inpainting ? O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 6 / 33
9. What is inpainting ? O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 6 / 33
10. What is inpainting ? O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 6 / 33
11. What is inpainting ? O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 6 / 33
12. What is inpainting ? O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 6 / 33
13. What is inpainting ? M. Daisy, P. Buyssens, D. Tschumperl´ e, O. L´ ezoray, A smarter exemplar-based inpainting algorithm using local and global heuristics for more geometric coherence, International Conference on Image Processing (ICIP - IEEE), pp. 4622-4626, 2014.. O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 6 / 33
14. Examplar-based image inpainting approaches Criminisi et al. 2004, ”Region Filling and Object Removal by Exemplar-Based Image Inpainting” C: Confidence term (reliable information for each patch) D: Data term (local structure estimation) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 7 / 33
15. Examplar-based image inpainting approaches Criminisi et al. 2004, ”Region Filling and Object Removal by Exemplar-Based Image Inpainting” C: Confidence term (reliable information for each patch) D: Data term (local structure estimation) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 7 / 33
16. Examplar-based image inpainting approaches Criminisi et al. 2004, ”Region Filling and Object Removal by Exemplar-Based Image Inpainting” C: Confidence term (reliable information for each patch) D: Data term (local structure estimation) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 7 / 33
17. Examplar-based image inpainting approaches Criminisi et al. 2004, ”Region Filling and Object Removal by Exemplar-Based Image Inpainting” C: Confidence term (reliable information for each patch) D: Data term (local structure estimation) How can we do this on 3D colored meshes ? → 3D mesh patches, priority ? O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 7 / 33
18. Outline 1. Introduction 2. Local spiral hop descriptors 3. Proposed 3D Mesh Inpainting algorithm 4. Results 5. Conclusion O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 8 / 33
19. Outline 1. Introduction 2. Local spiral hop descriptors 3. Proposed 3D Mesh Inpainting algorithm 4. Results 5. Conclusion O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 9 / 33
20. Local spiral hop descriptors Notations ▶ A mesh M is represented by a graph G = (V,E) with V = {v1,...,vm} and E ⊂ V×V ▶ vi ∼ vj is used to denote two adjacent vertices ▶ N (vi) = {vj,vj ∼ vi} gives the set of all the adjacent vertices to vi within a 1-hop (vertices that can be reached in one walk). ▶ Lim et al. have proposed local spiral hop descriptors: the surrounding vertices of one vertex can be enumerated by following a spiral Graph signal F : V → Rd. 1. S : V → R3 for coordinates 2. N : V → R3 for normals 3. C : V → R3 for colors O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 10 / 33
21. Local spiral hop descriptors Definitions ▶ Rk(vi) = k-ring(vi) is an ordered set of vertices whose shortest path to vi is exactly k-hops long vi R1 7 R1 1 R1 2 R1 3 R1 4 R1 5 R1 6 R2 1 R2 2 R2 3 R2 4 R2 5 R2 6 R2 7 R2 8 R2 9 R2 10 R2 11 R2 12 R2 13 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 11 / 33
22. Local spiral hop descriptors Definitions ▶ Rk(vi) = k-ring(vi) is an ordered set of vertices whose shortest path to vi is exactly k-hops long ⇒ R0(vi) = {vi} vi R1 7 R1 1 R1 2 R1 3 R1 4 R1 5 R1 6 R2 1 R2 2 R2 3 R2 4 R2 5 R2 6 R2 7 R2 8 R2 9 R2 10 R2 11 R2 12 R2 13 0-ring(vi) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 11 / 33
23. Local spiral hop descriptors Definitions ▶ Rk(vi) = k-ring(vi) is an ordered set of vertices whose shortest path to vi is exactly k-hops long ⇒ R0(vi) = {vi} and R1(vi) = N (vi) vi R1 7 R1 1 R1 2 R1 3 R1 4 R1 5 R1 6 R2 1 R2 2 R2 3 R2 4 R2 5 R2 6 R2 7 R2 8 R2 9 R2 10 R2 11 R2 12 R2 13 1-ring(vi) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 11 / 33
24. Local spiral hop descriptors Definitions ▶ Rk(vi) = k-ring(vi) is an ordered set of vertices whose shortest path to vi is exactly k-hops long ⇒ R0(vi) = {vi} and R1(vi) = N (vi) ▶ k-disk(vi) = l=0,...,k Rl(vi) is the set of vertices that can be reached from vi in 0 to k walks. vi R1 7 R1 1 R1 2 R1 3 R1 4 R1 5 R1 6 R2 1 R2 2 R2 3 R2 4 R2 5 R2 6 R2 7 R2 8 R2 9 R2 10 R2 11 R2 12 R2 13 1-disk(vi) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 11 / 33
25. Local spiral hop descriptors Definitions ▶ Rk(vi) = k-ring(vi) is an ordered set of vertices whose shortest path to vi is exactly k-hops long ⇒ R0(vi) = {vi} and R1(vi) = N (vi) ▶ k-disk(vi) = l=0,...,k Rl(vi) is the set of vertices that can be reached from vi in 0 to k walks. ▶ R(k+1)(vi) = N (R(k)(vi))\k-disk(vi) is the set of vertices that can be reached in 1 walk from Rk(vi) without going through its k-disk (that contains vertices that can be reached from vi in 0 to k walks) vi R1 7 R1 1 R1 2 R1 3 R1 4 R1 5 R1 6 R2 1 R2 2 R2 3 R2 4 R2 5 R2 6 R2 7 R2 8 R2 9 R2 10 R2 11 R2 12 R2 13 2-ring(vi) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 11 / 33
26. Local spiral hop descriptors Definitions ▶ The local spiral hop operator Sp(vi,k) is an ordered sequence from the concatenation of the ordered rings Sp(vi,k) = (vi,1-ring(vi),...,k-ring(vi)) = R0 1 (vi),R1 1 (vi),R1 2 (vi),...,Rk |Rk| (vi) ▶ It has 2 degrees of freedom: the direction (clockwise or counterclockwise) of the rings and the first chosen vertex R1 1 (vi) ▶ We fix : ▶ the orientation clockwise ▶ the initial vertex R1 1 (vi) is the one in the direction of the shortest geodesic path to vi: R1 1 (vi) = arg min vj∈N (vi) dG(vi,vj) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 12 / 33
27. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
28. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
29. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
30. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
31. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
32. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
33. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
34. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
35. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
36. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
37. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
38. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
39. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
40. Local spiral hop descriptors Comparison ▶ The size of the operator Sp(vi,k) varies for the vertices ▶ Lim et al. either truncate or zero-pad each spiral depending on its size to compare two local spiral hop descriptors ▶ We propose a more accurate hierarchical comparison d(Sp(vi,k),Sp(vj,k)) = k ∑ l=0 d(Rl(vi),Rl(vj)) Two k-rings are compared by mapping the vertices of the largest ring to the smallest one: d(Rl(vi),Rl(vj)) = |Rl (vi)| ∑ n=0 d(Rl n (vi),Rl n′ (vj)) with n′ = n·|Rl (vj)| |Rl (vi)| and |Rl(vi)| > |Rl(vj)| First vertex descriptor Second vertex descriptor 0-hop 1-hop 2-hop The distance between two vertices is then the distance between their graph signal vectors: d(Rl n (vi),Rl m (vj)) = ∥F(Rl n (vi))−F(Rl m (vj))∥2 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 13 / 33
41. Outline 1. Introduction 2. Local spiral hop descriptors 3. Proposed 3D Mesh Inpainting algorithm 4. Results 5. Conclusion O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 14 / 33
42. Outline 1. Introduction 2. Local spiral hop descriptors 3. Proposed 3D Mesh Inpainting algorithm 4. Results 5. Conclusion O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 15 / 33
43. Area to be inpainted Given a Mesh M and its associated graph G = (V,E), the area to be inpainted is denoted as Ω ⊂ V and its boundary is ∂Ω ⊂ Ω. We mark the vertices to be inpainted by the following function: Marked(vi) = 1 if vi ∈ Ω 0 if vi / ∈ Ω For vertices vi in Ω, their color is considered as unknown and set to C(vi) = (0,0,0)T . The objective of the inpainting is to recover the color of these vertices by pasting the color of vertices from surrounding spiral patches. O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 16 / 33
44. Our examplar-based 3D colored Mesh inpainting: Algorithm Input: Mesh M and associated graph G = (V,E), inpainting area Ω ⊂ V Set the size k of spiral patches and γ the ring search size Compute Spiral patches Sp(vi,k) of size k, ∀vi ∈ V Mark vertices to be inpainted : Marked(vi) = 1, ∀vi ∈ Ω while ∂Ω ̸= / 0 do 1) Compute Priority(vi), ∀vi ∈ ∂Ω 2) Find the spiral patch Sp(vtarget,k) with the maximum priority i.e., vtarget = arg max vi∈∂Ω Priority(vi) 3) Find the fully-defined exemplar Sp(vbest,k) (with vbest ∈ V\Ω) that minimizes d(Sp(vtarget,k),Sp(vbest,k)) with Confidence(vbest) = 1 in γ-ring(vtarget) 4) Copy colors from the spiral patch Sp(vbest,k) to Sp(vtarget,k), ∀vi ∈ Sp(vtarget,k) with Marked(vi) = 1 6) Update Marked(vi) and ∂Ω for all inpainted vertices end while O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 17 / 33
45. Priority computation We want to favor the inpainting of spiral patches that: ▶ have few missing information (Confidence term), ▶ have a small spatial range (Density term), ▶ are located at strong geometric features (Variance term), ▶ are located at strong color structures (Continuity term). Our priority is defined as Priority(vi) = Confidence(vi)·Density(vi)·Variance(vi)·Continuity(vi) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 18 / 33
46. Confidence term The confidence term is similar to the one used for images. Its objective is to fill first the spiral patches that have most of their vertices’ colors already known. The confidence is defined as Confidence(vi) = ∑ vj∈ k-disk(vi) (1−Marked(vj)) |k-disk(vi)| This measures the proportion of known vertices’ colors within the spiral patch Sp(vi,k). It is close to 1 if most of the vertices’ colors of the spiral patch are known, and close to 0 for spiral patches that contain few known vertices’ colors O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 19 / 33
47. Density term The density term aims at favoring dense spiral patches to be filled first. Indeed, in meshes, the spatial coverage of a patch can be very different from one part of the mesh to another. It is preferable to inpaint first small spiral patches. The density is defined as Density(vi) = |k-ring(vi)| ∑ vj∈ k-ring(vi) ∥S(vi)−S(vj)∥2 This measures the average spatial dispersion of the vertices of the spiral patch Sp(vi,k) with respect to its center vi. It is high if the spiral patch is small and low otherwise O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 20 / 33
48. Variance term The variance term aims at favoring the filling of spiral patches that exhibit strong geometrical variations. We measure the latter by the total variance of the vertices’ normals of a spiral patch Sp(vi,k). If its value is high this means that there are variations in the surface of the spiral patch. The variance term is defined as Variance(vi) = 3 ∑ j=1 σ2 j (N(vi,k)) where N(vi,k) is the set of vertices’ normals for vertices in Sp(vi,k). O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 21 / 33
49. Continuity term The continuity term is similar to the data term used for images. Its aim is to encourage the inpainting of spiral patches where a strong variation in color is present. It is based on the Structure Tensor J(vi) = ∇T f(vi)·∇f(vi) Total Variation . ∇f(vi) = [d(Sp(vi,k),Sp(vj,k)),vj ∈ k-ring(vi)]T In the spiral comparison, the graph signal is the vertices’ color vectors: F(vi) = C(vi) We have J(vi) = UΛUT with U its eigenvectors and Λ its eigenvalues. Continuity(vi) = |k-ring(vi)| ∑ j=1 λ2 j with λj = Λ(j, j). If its value is high this means that there are color variations in the surface of the spiral patch O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 22 / 33
50. Priority computation (a) Original (b) Zone to (c) Confidence (d) Density Mesh colors C inpaint Ω (e) Variance (f) Continuity (g) Priority (h) Target and best matching patches O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 23 / 33
51. Outline 1. Introduction 2. Local spiral hop descriptors 3. Proposed 3D Mesh Inpainting algorithm 4. Results 5. Conclusion O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 24 / 33
52. Outline 1. Introduction 2. Local spiral hop descriptors 3. Proposed 3D Mesh Inpainting algorithm 4. Results 5. Conclusion O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 25 / 33
53. First example O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 26 / 33
54. First example O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 26 / 33
55. First example PSNR between original and inpainted mesh : 33.24db O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 26 / 33
56. Results on real scanned meshes O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 27 / 33
57. Results on real scanned meshes O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 27 / 33
58. Comparison with SOTA Figure: Inpainting comparison with the approach of Maggiordomo et al. with from left to rigth, (a) Elephant Mesh, (b) Texture defect 90.26, (c) Inpainting area, (d) Result of Maggiordomo et al. 96.33, (e) Ours (k = 1, γ = 15) 69.11, (f) Ours (k = 2, γ = 15) 68.40. Bolded values : BRISQUE IQA (↓). O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 28 / 33
59. Virtual avatar editing 77.42 74.34 60.81 60.72 O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 29 / 33
60. Outline 1. Introduction 2. Local spiral hop descriptors 3. Proposed 3D Mesh Inpainting algorithm 4. Results 5. Conclusion O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 30 / 33
61. Outline 1. Introduction 2. Local spiral hop descriptors 3. Proposed 3D Mesh Inpainting algorithm 4. Results 5. Conclusion O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 31 / 33
62. Conclusion Our contributions We have proposed a 3D Colored mesh inpainting approach ▶ Defines spiral patch as examplar to be pasted ▶ Defines how to compare spiral patches ▶ Defines a priority term from Confidence, Density, Variance and Continuity terms. ▶ Provides good visual results (quantitative results in the paper) Future works ▶ Limitations due to similar patch search: define a more efficient patch search strategy (adapt patchMatch for meshes) O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 32 / 33
63. The End Publications available at : https://lezoray.users.greyc.fr This work was funded by the Normandy Region Council and the European Union (COSURIA project). O. L´ ezoray & S. Bougleux Spiral patch exemplar-based inpainting of 3D colored meshes 33 / 33
