Implementing safe and secure LINE Login

Implementing safe and secure LINE Login

Eebedc2ee7ff95ffb9d9102c6d4a065c?s=128

LINE DevDay 2020

November 27, 2020
Tweet

Transcript

  1. None
  2. Agenda › Introduction to LINE Login › Case Study of

    Actual Security Incidents
  3. • Social Login Service • OAuth2 compliant • OpenID Connect

    certified What's LINE Login
  4. • Social Login Service • OAuth2 compliant • OpenID Connect

    certified What's LINE Login • and many useful features • Password-less Login • QR Code Login on PC • Auto Login on Smart phone/PC
  5. • Social Login Service • OAuth2 compliant • OpenID Connect

    certified What's LINE Login • and many useful features • Password-less Login • QR Code Login on PC • Auto Login on Smart phone/PC • Bot link • Profile+ • etc.
  6. What's QR Code Login?

  7. › All LINE app users can login without ID/password What's

    Auto Login
  8. › All LINE app users can login without ID/password What's

    Auto Login › You need not to add additional implementation
  9. › All LINE app users can login without ID/password What's

    Auto Login › Authentication information is passed from LINE client app and server to your web site or native application securely. › PKCE like mechanism is used › You need not to add additional implementation
  10. Agenda › Introduction to LINE Login › Case Study of

    Actual Security Incidents › Target of This Presentation › case 1 › case 2 › case 3 › case 4
  11. Case Study of Actual Security Incidents › Vulnerability caused by

    wrong implementation of user services › Vulnerability in LINE Login / LIFF Platform itself
  12. Case Study of Actual Security Incidents › Vulnerability caused by

    wrong implementation of user services › Even if LINE Login platform has no vulnerability, wrong implementation by user service will lead to vulnerability, such as information leak, identity theft. › Vulnerability of LINE Login Platform itself › LINE Login platform developers fix them with the highest priority. 5BSHFUPGUIJTQSFTFOUBUJPO
  13. Social Login LINE Login yoursite.com 1. login request end user

  14. Social Login LINE Login yoursite.com 1. login request 2. redirected

    to LINE Login server end user
  15. Social Login LINE Login yoursite.com 1. login request 2. redirected

    to LINE Login server 3. ID/password input etc. end user
  16. Social Login LINE Login yoursite.com 1. login request 2. redirected

    to LINE Login server 3. ID/password input etc. 4. allow data access by yousite.com end user
  17. Social Login LINE Login yoursite.com 1. login request 2. redirected

    to LINE Login server 3. ID/password input etc. 5. redirected to yoursite.com with access right to the login user's data 4. allow data access by yousite.com end user
  18. Social Login LINE Login yoursite.com 1. login request 2. redirected

    to LINE Login server 3. ID/password input etc. 5. redirected to yoursite.com with access right to the login user's data 4. allow data access by yousite.com end user 6. access the user's data
  19. Case 1

  20. Case 1 - Access Token in Query Parameter BDDFTT@UPLFO

  21. Case 1 - Access Token in Query Parameter BDDFTT@UPLFO ›

    Query parameter value can be exposed easily. › Evil attacker can get user information with the access token.
  22. Case 1 - Access Token in Query Parameter LINE Login

    server
  23. Case 1 - Access Token in Query Parameter 1. An

    attacker posts a link to evil.com LINE Login server
  24. Case 1 - Access Token in Query Parameter 1. An

    attacker posts a link to evil.com 2. A victim clicks the link LINE Login server
  25. Case 1 - Access Token in Query Parameter 1. An

    attacker posts a link to evil.com 2. A victim clicks the link 3. The access_token is sent to the attacker's web server in Referrer header LINE Login server
  26. Case 1 - Access Token in Query Parameter 1. An

    attacker posts a link to evil.com 2. A victim clicks the link 3. The access_token is sent to the attacker's web server in Referrer header 4. The Attacker can get user information by the access token LINE Login server
  27. Case 1 - Access Token in Query Parameter Solution ›

    Do not expose access token. Instead use, for example, › Server storage › Browser storage with same origin policy, like session storage › Native app storage
  28. Case 2 https://access.line.me/oauth2/v2.1/authorize ?client_id=987654321 &scope=profile &response_type=code &redirect_uri=https%3A%2F%2Fexample.com%2Flogin%2Fcallback &state=GsdtJnrabFMWcHsq2Od8

  29. Case 2 https://access.line.me/oauth2/v2.1/authorize ?client_id=987654321 &scope=profile &response_type=code &redirect_uri=https%3A%2F%2Fexample.com%2Flogin%2Fcallback &state=GsdtJnrabFMWcHsq2Od8 https://access.line.me/oauth2/v2.1/authorize ?client_id=987654321

    &scope=profile &response_type=code &redirect_uri=https%3A%2F%2Fexample.com%2Flogin%2Fcallback &state=GsdtJnrabFMWcHsq2Od8 Another login attempts
  30. Case 2 - Fixed State Value https://access.line.me/oauth2/v2.1/authorize ?client_id=987654321 &scope=profile &response_type=code

    &redirect_uri=https%3A%2F%2Fexample.com%2Flogin%2Fcallback &state=GsdtJnrabFMWcHsq2Od8 https://access.line.me/oauth2/v2.1/authorize ?client_id=987654321 &scope=profile &response_type=code &redirect_uri=https%3A%2F%2Fexample.com%2Flogin%2Fcallback &state=GsdtJnrabFMWcHsq2Od8 Another login attempts
  31. Case 2 - Fixed State Value LINE Login yoursite.com How

    'state' works
  32. Case 2 - Fixed State Value LINE Login yoursite.com 1.

    yoursite.com issues a state for an user and redirects a request to LINE Login How 'state' works
  33. Case 2 - Fixed State Value 2. The user do

    'LINE Login' LINE Login yoursite.com 1. yoursite.com issues a state for an user and redirects a request to LINE Login How 'state' works
  34. Case 2 - Fixed State Value 2. The user do

    'LINE Login' LINE Login yoursite.com 1. yoursite.com issues a state for an user and redirects a request to LINE Login How 'state' works 3. LINE Login redirects the request to yoursite.com w/ the state value
  35. Case 2 - Fixed State Value 2. The user do

    'LINE Login' LINE Login yoursite.com 1. yoursite.com issues a state for an user and redirects a request to LINE Login 4. The user is redirected to yoursite.com How 'state' works 3. LINE Login redirects the request to yoursite.com w/ the state value
  36. Case 2 - Fixed State Value 2. The user do

    'LINE Login' LINE Login yoursite.com 1. yoursite.com issues a state for an user and redirects a request to LINE Login 4. The user is redirected to yoursite.com 5. yoursite.com can reject the request if state value is different from the one issued for the user How 'state' works 3. LINE Login redirects the request to yoursite.com w/ the state value
  37. Case 2 - Fixed State Value LINE Login yoursite.com If

    'state' is fixed value, CSRF attack can be possible.
  38. Case 2 - Fixed State Value 1. An attacker try

    LINE Login for yoursite.com LINE Login yoursite.com If 'state' is fixed value, CSRF attack can be possible.
  39. Case 2 - Fixed State Value 1. An attacker try

    LINE Login for yoursite.com LINE Login 2. The attacker stops to redirect to yoursite.com yoursite.com If 'state' is fixed value, CSRF attack can be possible.
  40. Case 2 - Fixed State Value 1. An attacker try

    LINE Login for yoursite.com LINE Login 2. The attacker stops to redirect to yoursite.com yoursite.com 3. The attacker sends a victim the redirect link in some website or e-mail etc. If 'state' is fixed value, CSRF attack can be possible.
  41. Case 2 - Fixed State Value 1. An attacker try

    LINE Login for yoursite.com LINE Login 2. The attacker stops to redirect to yoursite.com yoursite.com 3. The attacker sends a victim the redirect link in some website or e-mail etc. 4. The victim clicks the link and login to yoursite.com as the attacker If 'state' is fixed value, CSRF attack can be possible.
  42. Case 2 - Fixed State Value 1. An attacker try

    LINE Login for yoursite.com LINE Login 2. The attacker stops to redirect to yoursite.com yoursite.com 5. The victim uploads sensitive data. The date is stored as the attacker's data since the victim is logging in as the attacker. 3. The attacker sends a victim the redirect link in some website or e-mail etc. 4. The victim clicks the link and login to yoursite.com as the attacker If 'state' is fixed value, CSRF attack can be possible.
  43. Case 2 - Fixed State Value Solution Summary What yoursite.com

    should do is 1. Issue a random value as state for each login attempts. 2. Store it securely, for example, as browser cookie. 3. Redirect the login request to LINE Login authorization endpoint with the state parameter. 4. Reject if a state value returned from LINE Login is different from the value issued at step 1.
  44. Case 3 LINE Login yoursite.com 1. do 'LINE Login' &

    get the user ID
  45. Case 3 LINE Login yoursite.com 1. do 'LINE Login' &

    get the user ID 2. call some server API
  46. Case 3 - User ID as Credential 2. call some

    server API LINE Login 1. do 'LINE Login' for a native app or SPA & get the user ID yoursite.com
  47. Case 3 - User ID as Credential LINE Login yoursite.com

  48. Case 3 - User ID as Credential 1. An attacker

    does 'LINE Login' & get the attacker's user ID LINE Login yoursite.com
  49. Case 3 - User ID as Credential 1. An attacker

    does 'LINE Login' & get the attacker's user ID LINE Login yoursite.com 2. call some server API w/ another user ID AAAAAAA
  50. Case 3 - User ID as Credential 1. An attacker

    does 'LINE Login' & get the attacker's user ID 3. The attacker can get/update a victim's data LINE Login yoursite.com 2. call some server API w/ another user ID AAAAAAA
  51. Case 3 - User ID as Credential Actually it's difficult

    for an attacker to find a valid LINE user ID. 1. LINE User ID is random value generated by cryptographically secure way. 2. LINE User ID is PPID. The ID value for service provider A is different from the ID value for service provider B even if the IDs are for same user.
  52. Case 3 - User ID as Credential Actually it's difficult

    for an attacker to find a valid LINE user ID. 1. LINE User ID is random value generated by cryptographically secure way. 2. LINE User ID is PPID. The ID value for service provider A is different from the ID value for service provider B even if the IDs are for same user. But this does not mean no risk.
  53. Case 3 - User ID as Credential Solution * Stop

    using user ID as credential * Use ID Token / Access Token instead
  54. Case 3 - User ID as Credential Solution * Stop

    using user ID as credential * Use ID Token / Access Token instead NOT enough!!!
  55. Case 4 2. call some server API 1. do 'LINE

    Login' & get an access token LINE Login yoursite.com
  56. Case 4 - No Token validation 2. call some server

    API 1. do 'LINE Login' & get an access token Validate the token received! LINE Login yoursite.com
  57. Case 4 - No Token validation seems.safe.but.evil.com LINE Login yoursite.com

  58. Case 4 - No Token validation 1. A victim does

    'LINE Login' & get an access token for an attacker's service seems.safe.but.evil.com LINE Login yoursite.com
  59. Case 4 - No Token validation 1. A victim does

    'LINE Login' & get an access token for an attacker's service seems.safe.but.evil.com 2. The attacker's service get the token LINE Login yoursite.com
  60. Case 4 - No Token validation 1. A victim does

    'LINE Login' & get an access token for an attacker's service seems.safe.but.evil.com 2. The attacker's service get the token 3. The attacker calls yoursite.com with the access token LINE Login yoursite.com
  61. Case 4 - No Token validation 1. A victim does

    'LINE Login' & get an access token for an attacker's service seems.safe.but.evil.com 2. The attacker's service get the token 3. The attacker calls yoursite.com with the access token LINE Login yoursite.com 4. LINE API is called as the victim & the victim's user ID is returned
  62. Case 4 - No Token validation 2. The attacker's service

    get the token 1. A victim does 'LINE Login' & get an access token for an attacker's service 3. The attacker calls yoursite.com with the access token 4. Call Token Validation API before other API call Solution seems.safe.but.evil.com LINE Login yoursite.com
  63. Case 4 - No Token validation Call Verify Access Token

    API and confirm that returned client_id is your service's client ID curl -v -X GET \ 'https://api.line.me/oauth2/v2.1/verify?access_token=eyJhbGciOiJIUzI1NiJ9.UnQ_o-GP0VtnwDjbK0C8E_NvK...' { "scope":"profile", "client_id":"1440057261", "expires_in":2591659 } https://developers.line.biz/en/reference/social-api/#verify-access-token
  64. Case 4 - No Token validation If you use ID

    Token, you can validate it by yourself. https://developers.line.biz/en/docs/line-login/integrate-line-login/#write-original-code
  65. Case 4 - No Token validation If you use ID

    Token, you can validate it by yourself. https://developers.line.biz/en/docs/line-login/integrate-line-login/#write-original-code LINE Login provides a utility API and you can use it to verify ID Token. https://developers.line.biz/en/reference/social-api/#verify-id-token curl -v -X POST 'https://api.line.me/oauth2/v2.1/verify' \ -d 'id_token=eyJraWQiOiIxNmUwNGQ0ZTU2NzgzYTc5MmRjYjQ2ODRkOD...&client_id=1440057261' { "iss": "https://access.line.me", "sub": "U1234567890abcdef1234567890abcdef", "aud": "1234567890", "exp": 1504169092, "iat": 1504263657, "nonce": "0987654asdf", "amr": [ "pwd", "linesso", "lineqr" ], "name": "Taro Line", "picture": "https://sample_line.me/aBcdefg123456", "email": "taro.line@example.com" }
  66. Make useful and secure internet services together with us Thank

    you!
