Orchestrating and monitoring Fedora CoreOS auto-updates

Fedora CoreOS follows the “auto-updates by design” model. It sports a modern architecture which has been designed based on learnings from past experiences, and built with safety in mind.

This talk describes Fedora CoreOS approach to orchestrating and monitoring auto-updates for a cluster of Linux machines. In particular it covers the auto-updates protocol (Cincinnati), the OS agent and client-side logic (Zincati), cluster-wide orchestration (Airlock), and overall observability from a single-pane of glass (with Prometheus metrics).

Transcript

1. Luca BRUNO @lucabruno | lucab@redhat.com | github.com/lucab Orchestrating and monitoring auto-updates on Fedora CoreOS
2. “OS engineer, Rust & Go developer, enthusiast FLOSS supporter” • ex-CoreOS, Software Engineer • Red Hat, Berlin office • Previously: security researcher/engineer $ whoami
3. • Fedora CoreOS (FCOS) ◦ Auto-updates as first-class OS feature • Cincinnati ◦ Graphs and update-hints • Zincati ◦ Safety and observability • Airlock ◦ Fleet-wide reboot orchestration Overview
4. • local_exporter ◦ Bridging host-local services & cluster monitoring • Demo ◦ Prometheus & Grafana in action Overview (cont.)
5. Fedora CoreOS: auto-updates
6. Overall goals • Port Container Linux model to Fedora CoreOS • Continuous auto-updates as first-class OS feature • Atomic OS updates/rollbacks • Phased rollouts with multiple update channels • Cluster-orchestrated reboots • Observability, single pane of glass • Safety across the board (Go & Rust)
7. Phased rollouts • Release artifacts are uploaded to public Web ◦ But not immediately announced for auto-updates • Release engineers define a timeframe for rollouts ◦ 0% -> 100% over a time window (pausable) • Updates are gradually exposed to nodes 0% 100% t
8. Observability Single panel of glass for all auto-updates machinery: • Prometheus for metrics collection • Thanos for history recording • AlertManager for whitebox alerting • Grafana for visualization
9. Auto-updates Cincinnati fedoraproject.org infra OSTree repo Zincati airlock (or other) etcd3 (or other) Local cluster FCOS Host rpm-ostree Our focus for today Monitoring Our focus for today
10. Cincinnati: DAG applied to updates
11. Cincinnati JSON-based protocol for FCOS updates (OpenShift too!) • Provides update-hints as a DAG • Backend on fedora-infra (on k8s, Rust) • Scrapes FCOS metadata, builds a graph (per stream) • Serve the graph to clients, with specific mutations: ◦ Barriers ◦ Dead-ends ◦ Phased Rollouts
12. Update barrier Forced choke-points, before further auto-updates v0 v1 v2 v3 v4 v5 Barrier: v3
13. Update dead-end Explicit releases which cannot further auto-updates v0 v1 v2 v3 v4 v5 Dead-end: v4
14. Phased rollouts Node identity and time influence the (client-observed) graph v0 v1 v0 v1 v0 v1 v0 v1 Time 0+x Time 0 Node A Node B
15. Checklist-based Release-Engineering flow • Handled via git+review process (on Github) • Metadata for parallel rollouts, pauses/resumes, update barriers, dead-ends signaling • Automatable • Fully public • Auditable • No sprawling of private DBs Less eye-catching, more devops-friendly GitOps applied to Release Eng
16. GitOps applied to Release Eng
17. Zincati: client-side update logic
18. Zincati Update agent • Long-running service (on-host, Rust) • Actor-based architecture • Checks for auto-updates, triggers reboots • TOML configuration, with systemd-style dropins • Internal state-machine with few possible states (<10) • Exposes metrics in Prometheus format Written from scratch, but in practice an evolution of update-engine and locksmith
19. Zincati - noteworthy Metrics: • Metrics exposed over node-local IPC (Unix-domain socket). • Progress of the state-machine exposed as state changes and refresh timestamp Errors: • Rust enum (sum types) allows strongly typed, exhaustive error encapsulation • Error variant kinds tracked as label in error metrics
20. Airlock: fleet-wide reboot manager
21. Airlock Reboot coordination • Go service (containerized) • Counting semaphore with recursive locking • Simple HTTPS operations for locking/unlocking • etcd3 as backend DB • Exposes metrics in Prometheus format Decoupled from OS, we expect communities to adapt it for their preferred non-etcd3 backends
22. Airlock Airlock etcd3 etcd3 etcd3 Database Reboot manager Workers nodes Master nodes
23. Airlock
24. local-exporter: fan-out to local services
25. local_exporter • Go application (containerized) • Web service, bind to a TCP port on container network • Fan-out to local targets • TOML configuration, single file • Allow defining multiple selectors/endpoints It may have rough edges (I’m happy if it finds a new owner)
26. local_exporter - design Heavily inspired by node-exporter, however: • Configuration via file only (TOML) • Keep different endpoint metrics separate • Can pick up single files from different directories • Does not contain content-translation logic • Only bridges across “transports” • No internal caches
27. local_exporter - backend selectors Local IPC Regular file local_exporter Targets: • A • B • C TCP (HTTP) Unix socket DBus endpoint Selectors config: • A • B • C A B C
28. Example with Zincati [bridge.selectors] "zincati" = { kind = "uds", path = "/host/run/zincati/private/metrics.promsock" } - job_name: 'os_updates' metrics_path: '/bridge' params: selector : [ 'zincati' ] prometheus.yml local_exporter.toml Host bind-mount Selector
29. Demo (recorded) Single pane of glass for all auto-updates machinery: • Prometheus for metrics collection • Grafana for visualization Recorded demo with subtitles: https://youtu.be/_gU1mHKlmQw (equivalent screenshots in backup slides)
30. References • Fedora CoreOS docs https://docs.fedoraproject.org/en-US/fedora-coreos/ • Airlock https://github.com/coreos/airlock • Cincinnati https://github.com/openshift/cincinnati • Zincati https://github.com/coreos/zincati • Local_exporter https://github.com/lucab/local_exporter
31. Questions?
32. [Backup] Dashboard Lock-manager status and incoming requests:
33. [Backup] Dashboard Auto-updates propagating through the cluster:
34. [Backup] Dashboard
35. [Backup] Dashboard Client state-machine changes:
36. [Backup] Dashboard Client error-rate, bucketed by error kind:
