Building multi-million document applications with scalability in mind

What does it mean to work with a huge quantity of data? We know that sharding and replication are our friends, but those are also other things that we should consider. In this session I will show you how we have used Raven with scalability in mind.

Transcript

1. Building multi-million document applications with scalability in mind a case-study Software Architect at ServiziCGN RavenDB User CTO at Managed Designs RavenDB Contributor Manuel Scapolan Mauro Servienti
2. “The Italian Guys” Software Architect at ServiziCGN RavenDB User 1nn0va community speaker Manuel Scapolan @manuelscapolan CTO at Managed Designs RavenDB Contributor Microsoft MVP - Visual C# Mauro Servienti @mauroservienti
3. Servizi CGN •  Fiscal and tax advice •  E-learning and class learning •  Dedicated software to fill tax return statements and to run the companies accounting Leader company in offering services to accountants
4. An italian strange fact… The Revenue Agency   Employees and retired people   Tax return statement
5. Fiscal Assistance Centers (CAF) The Revenue Agency   CAF (Fiscal Assistance Center)   Employees and retired people
6. Servizi CGN •  More than 1.260.000 tax return statements sent only this year •  Thanks to a network of 35.000 professionals that use its software free to fill and send the tax return statements of their clients 1° CAF in Italy as private business
7. The case-study The porting of the applications that allow the accountants to fill and send the tax return statements to the Revenue Agency
8. A tax return statement •  A huge form composed of different fields that can be filled by the user or automatically •  Some fields can be validated by rules •  Once correctly filled the statement will be sent to the Revenue Agency
9. Our first attempt •  3-layer architecture •  Data persistence on SQL Server •  EntityFramework as ORM Business Layer Presentation Layer Data Layer SQL Server
10. Good, but… JOIN  JOIN  JOIN  JOIN  JOIN  JOIN  JOIN
11. Aggregate Data Model •  An Aggregate is a cluster of associated objects that are treated as a unit for the purpose of data changes •  The document databases are the best way to save the aggregates (Aggregate = Document) “A data model is the model through which we perceive and manipulate our data.” Martin Fowler, NoSQL Distilled
12. Why RavenDB? •  All our developers are familiar with the .NET Framework and the C# language •  We operate with sensitive data so we have the need of ACID transactions •  For the technical support provided by Managed Designs
13. The architecture UI   Command   Handling   command   result   Thin  Data   Layer   DTOs   query   load,  change  and  persist   Domain   Model   Query-­‐side   Command-­‐side   Bertrand Meyer’s Command Query Separation Principle   RavenDB  2.5
14. The Command-side •  The user fills the fields of a section •  A save command will be sent to the server •  On the server the statement is loaded and through an object mapper it is filled with the data in the command •  All the rules are applied •  Finally, all the changes will be saved on the database How it works   UI   Command   Handling   command   result   Thin  Data   Layer   DTOs   query   load,  change  and  persist   Domain   Model   Query-­‐side   Command-­‐side
15. Persistence Ignorance
16. The Persistence layer •  The UnitOfWork manages business transactions •  It persists all the changes made within the transaction in an atomic operation •  If there are mistakes or exceptions no changes are saved UnitOfWork + Repository   BeginUnitOfWork()   EndUnitOfWork()   using(var tran = new TransactionScope()) { tran.Complete(); }
17. The Persistence layer •  The Repository mediates between the domain and data layer using a collection-like interface for accessing our aggregates •  Changes will be persisted on storage in a completely transparent way •  With RavenDB we don’t have to write a mapping layer UnitOfWork + Repository   BeginUnitOfWork()   EndUnitOfWork()   using(var tran = new TransactionScope()) { Repository.GetById(id)   tran.Complete(); } Repository.Update()   session.SaveChanges(); var s = session.Load<Statement>(id); // Changes occur in the aggregate root
18. The Query-side •  We make a load of the entire statement •  With an operation reverse to the saving, a view model is populated with only the data of the section to display •  The view model is then sent to the client serialized in json How it works   UI   Command   Handling   command   result   Thin  Data   Layer   DTOs   query   load,  change  and  persist   Domain   Model   Query-­‐side   Command-­‐side
19. What about the indexes? •  We didn’t use the indexes in this case because: 1.  All the data that we needed were a subset of the statement document 2.  Not to handle the asynchronous update of the indexes •  We used indexes for reports, look-up lists and summary information
20. Scalability
21. What does scalability mean? •  The ability of a system or a software solution to handle increased loads of work •  A solution that can scale out can usually grow to larger loads in a more convenient way SCALE UP SCALE OUT growing by using stronger hardware growing by adding more hardware
22. What is the worst enemy of the horizontal scalability for a database? THE DATA CONSISTENCY
23. Aggregate boundaries •  Put together the information that need to be consistent so they can be easily distributed without compromising the performance •  Obviously this “indivisible whole of consistency” is an aggregate •  So, first of all, define your aggregate boundaries
24. Data-Sharding
25. Data-Sharding •  The most effective solution to be adopted is to divide the data per accountant •  Each statement may be made only by an accountant •  So we will not need to run queries on multiple servers at the same time
26. The ShardStrategy •  We assign to every new accountant a serial number (a simple auto-increment integer) •  This number has a high cardinality and so it can be a good shard-key
27. The ShardStrategy •  Each accountant lives in its own shard •  From the support/back office POV we need cross accountants queries •  Accountant affinity requires us to keep “related” accountants as near as possible Node 0 Node 1 Node N Shard(s) DB Shard(s) DB Shard(s) DB
28. Replication
29. Master-Slave Replication MASTER   SLAVE   SLAVE   SLAVE
30. High Availability •  The life of the accountant will often be on the cutting edge •  The unavailability of the software in those moments can bring serious harm to our clients •  A master-slave replication can be crucial to ensure high availability to the application
31. High Availability •  Patch/deploy/update & rebuild on the logical-slave •  Switch –  logical-slave becomes the logical-master –  logical-master switches to logical-slave •  VIP Switch the application to use the logical-master through Master-Master Replication
32. Fault tolerance •  Write assurance to wait for data to be replicated at least to n servers in the replica set; •  Deploy RavenDB server on VMs on SAN; –  Each SAN shadow copies the VM at each change, amazingly fast; –  If HW fails, restore the SAN snapshot to a replicated SAN and move on;
33. Pros & Cons
34. The Good stuff •  Simplifies the data layer development •  Ready to run in 5 minutes •  It just works, “zero” administration •  Safe by default •  Easy scale-out
35. The Bad stuff •  Being an early adopter •  Lack of monitoring tools •  Doing query on the fly •  All about the Eventual Consistency
36. Can RavenDB be the right choice? •  Is your aggregate boundaries well defined? •  Are you looking for scalability and lack of verbosity? •  … •  RavenDB may just be the technology you are looking for!
37. Thank you @mauroservienti @manuelscapolan
