1. REVERSE ENGINEERING, PENTESTING
   AND HARDENING OF ANDROID APPS
   Droidcon IT Torino 2014
   !
   Marco Grassi

   @marcograss

   -

   Mobile Security Analyst @ viaForensics


   View Slide

2. $ whoami
   • R&D Team Member @ viaForensics

   • Developer background (both Android
   and iOS)

   • Part of my job is to attack and break
   mobile apps


   View Slide

3. View Slide

4. AGENDA
   • Reverse Engineering and Obfuscation

   • Tampering Detection

   • Logging

   • File Storage

   • Secure Network Communications

   • IPC Attack Surface

   • RAM memory attacks

   • More Advanced Material : Runtime Manipulation

   • Extra: Creating Cheats for Android Games : )


   View Slide

5. SANTOKU LINUX
   https://santoku-linux.com/


   View Slide

6. PULLING THE APK FROM THE DEVICE


   View Slide

7. REVERSE ENGINEERING

   FREE TOOLS
   • apktool and smali/baksmali
   It will provide us a disassembled
   representation of the Dalvik bytecode,
   so sort “low level”, with registers, but
   very understandable because of
   bytecode metadata. Very useful to disable
   tampering protections, the code can be
   modified and the application can be
   recompiled and resigned.


   View Slide

8. DISASSEMBLED SMALI CODE


   View Slide

9. REVERSE ENGINEERING

   FREE TOOLS
   • dex2jar + Java decompiler (jd-gui, jad …)
   dex2jar will convert the .dex file to a .jar
   containing Java code

   We can then use the freely available Java
   decompilers and obtain back a Java
   representation of the code.

   Very readable if no obfuscation is in
   place.


   View Slide

10. DECOMPILED JAVA CODE


    View Slide

11. REVERSE ENGINEERING

    PRO TOOLS
    • JEB Decompiler
    Renaming feature, very handy with
    obfuscated applications

    Python APIs

    Native Dalvik decompiler, it does not
    pass through Java byte code,
    decompilation is usually much better


    View Slide

12. REVERSE ENGINEERING

    PRO TOOLS
    • IDA + Hex Rays Decompiler
    De facto the best interactive disassembler
    and decompiler on the market.

    Impressive set of APIs, you can write
    modules or scripts for everything.


    View Slide

13. REVERSE ENGINEERING

    PRO TOOLS
    • Hopper Disassembler
    Very nice disassembler and decompiler
    with a killer price.


    View Slide

14. OBFUSCATION

    PROGUARD
    • Free

    • Integrated into the build environment

    • NOT Android specific

    • http://developer.android.com/tools/
    help/proguard.html


    View Slide

15. DECOMPILED CODE WITH PROGUARD


    View Slide

16. OBFUSCATION

    DEXGUARD
    • Commercial product from ProGuard
    author.

    • Android specific
    • Native support to string and code
    encryption and tamper detection
    • Very easy to use, with a config file like
    ProGuard


    View Slide

17. DECOMPILED CODE WITH DEXGUARD


    View Slide

18. TAMPERING DETECTION


    View Slide

19. DEFEATING TAMPERING DETECTION

    WHY OBFUSCATION IS FUNDAMENTAL


    View Slide

20. LOGGING
    • Remove Logcat logging from your production builds.
    • It can be done with few lines in Proguard and Dexguard, they
    remove all the calls to Log.d, Log.e etc in the build process

    • It’s very easy for third party malware or an attacker to access the
    Logs on Android.


    View Slide

21. FILE STORAGE

    EXTERNAL STORAGE
    • Try to avoid storing your
    data in the shared storage,
    almost any application can
    read it. (In 4.4 a small protection at
    permission level was added
    android.permission.READ_EXTERNAL
    _STORAGE, usually users does not check
    permissions too much anyway… Don’t rely
    on this.)


    View Slide

22. FILE STORAGE

    PRIVATE APP FOLDER
    • Encrypt your preferences/files
    • With root access they can be modified, avoid store sensitive data at all if possible

    • With a backup, they can be retrieved from the device usually

    • The private folder can be found on the device at path /data/data/yourpackage


    View Slide

23. FILE STORAGE

    SQLITE DATABASES


    View Slide

24. SQLCIPHER


    View Slide

25. #1 RULE: YOU DO
    NOT IMPLEMENT
    YOUR OWN
    CRYPTOGRAPHY
    #2 Rule: You do NOT implement your
    own Cryptography


    View Slide

26. SECURE NETWORK COMMUNICATIONS
    • It’s your responsibility to protect data in transit!
    • Don’t transmit sensitive information without SSL/TLS
    • Implement if possibile Certificate Pinning, in this way your
    communications will be more resistant to MITM attacks, for example
    if a malicious certificate is pushed into the device, or if an attacker
    can impersonate your web service with a trusted certificate.


    View Slide

27. IPC ATTACK SURFACE

    THE ANDROID MANIFEST


    View Slide

28. IPC ATTACK SURFACE

    EXAMPLE: SCREEN BYPASS


    View Slide

29. 1PASSWORD READER
    • Password wallet application for Android, a
    companion application of the Mac/Windows
    client, to be able to share our passwords
    between our PC and the mobile device,
    leveraging Dropbox or the Shared Storage.


    View Slide

30. BE CAREFUL WITH BROADCASTED
    INTENTS


    View Slide

31. LET’S INSTALL SOME MALWARE


    View Slide

32. RESULTS


    View Slide

33. RAM MEMORY ATTACKS
    • An attacker can retrieve and
    inspect the ram memory used
    by our application and search for
    sensitive informations.

    • Avoid storing such sensitive
    informations inside instance or
    static variables.


    View Slide

34. RAM MEMORY ATTACKS
    • An easiest way to get an incomplete
    (VM only) chunk of live memory from
    our application is to use the “Dump
    HPROF” functionality in the monitor
    tool, with a debuggable application or
    a device with the flag
    ro.debuggable=1


    View Slide

35. APPENDIX
    Extras with more advanced material


    View Slide

36. RUNTIME MANIPULATION
    Why modify the code of the application
    recompiling it when we can modify the
    code at runtime, without alerting the
    basic tampering detection?


    View Slide

37. RUNTIME MANIPULATION


    View Slide

38. MOST POPULAR FRAMEWORKS
    • Cydia Substrate

    • Xposed Framework


    View Slide

39. HOW CAN WE DEVELOP A PLUGIN AND
    WHAT WE CAN DO WITH IT?


    View Slide

40. 1PASSWORD READER
    • Password wallet application for Android, a
    companion application of the Mac/Windows
    client, to be able to share our passwords
    between our PC and the mobile device,
    leveraging Dropbox or the Shared Storage.


    View Slide

41. 1PASSWORD: WHY SHARED STORAGE
    AND DROPBOX?
    • This choices are forced for technical limitation in the sharing process
    between the PC and the device.

    • Without root permissions, the user can only write in the shared
    folder, or the application can use third party services, such file sharing
    API by Dropbox, to share the wallet file.


    View Slide

42. FIRST LOOK
    • The 1Password wallet is totally unobfuscated, so an attacker can
    easily understand the logic of the application and the weak points.

    • First weak spot: LOGS, the application disabled in productions the
    logging of the user credentials and other internal information to the
    Logcat, but the logs are only disabled, the code that logs at the critical
    points (even the user password) it’s in there.


    View Slide

43. HELLO WORLD: WHAT CODE CHANGE?
    LET’S ENABLE LOGGING


    View Slide

44. REPLACED METHODS


    View Slide

45. RESULTS


    View Slide

46. CANDY!
    Reverse Engineering it’s fun!


    View Slide

47. LET’S USE RUNTIME MANIPULATION
    TO CHEAT IN ANDROID GAMES!


    View Slide

48. AGIMAT
    • Simple cheat engine/app for Android
    using runtime manipulation

    • When more games are supported and
    if there is interest, it will be open
    sourced (no time)


    View Slide

49. SUPER HEXAGON
    Addictive but difficult game for Android


    View Slide

50. View Slide

51. VIDEO DEMO


    View Slide

52. SECURITY IS A PROCESS.


    View Slide

53. View Slide

54. SECURE MOBILE DEVELOPMENT BEST PRACTICES
    AVOIDING COMMON PROBLEMS AND CREATING MORE SECURE
    APPS FOR IOS AND ANDROID



    View Slide

55. View Slide

56. Great book to start with Secure Android Development, written by my
    friend @scottyab


    View Slide

57. GET CERTIFIED
    bit.ly/1lwIGjl


    View Slide

58. WE ARE HIRING!


    View Slide

59. View Slide

60. @marcograss
    MGrassi@viaforensics.com


    View Slide
