Add the security layer to your REST API and serve a distributed web application

In the past editions of the PhpDay we have assisted to several talks about REST APIs and we learned how to implement a proper REST API service. In this talk I want to present how, at Capturator S.r.l., we have added a security layer to our private REST API (based on Symfony 2) adding authentication token and the support for CORS.

I will start with some theoretical and historical facts on Same Origin Policy and I will present the different solutions to deal with it, dwelling on CORS and its W3C recommendation document. CORS is the solution for a web app that needs to communicate with a REST API able to manage all the CRUD verbs in a distributed architecture (different domain or subdomain).
In the second part I will illustrate the actual implementation of the RESTfull API able to manage distributed and authenticated clients. The backend relies on a couple of Symfony 2 useful bundles and a customization of the security layer.
Presentation given at phpDay 2014 (http://2014.phpday.it)

Transcript

1. Add the security layer to your
   (RESTfull) API and serve a
   distributed web application
   Marco Loche
   PHPDay 2014


   View Slide

2. PHP is the language Community gives value


   View Slide

3. 1. Introduction


   View Slide

4. Who am I ?


   View Slide

5. About  my  company


   View Slide

6. eLearning
   •  Learning Management System
   – Content management system dedicated to
   learning management



   View Slide

7. eLearning
   Sharable Content Object Reference Model
   – SCORM compliant content must be
   transferable on LMS server
   – SCORM compliant content can
   comunicate with LMS
   – SCORM compliant conten must be
   agnostic about server technology



   View Slide

8. How to serve content remotly and on
   different domains keeping control of
   whoever is using it ?


   View Slide

9. 2. Context


   View Slide

10. An open system for
    browsing, sharing and
    including resources


    View Slide

11. API era is now


    View Slide

12. REST is the best


    View Slide

13. A matter of consuming resources


    View Slide

14. Uniform  interface
    Uniform interface


    View Slide

15. Richardson Model
    Access through HTTP
    (RMM level 0)
    Endpoints of the api are resource representations
    (RMM level 1)
    Interact with resources with HTTP Verbs and Content
    negotiation
    (RMM level 2)
    … Hypermedia and the glory
    (RMM level 3)


    View Slide

16.

    Be fluent and
    transitional


    View Slide

17. REST in Symfony
    jms/serializer-bundle
    friendsofsymfony/rest-bundle
    willdurand/hateoas-bundle
    nelmio/api-doc-bundle


    View Slide

18. Lesson learned


    View Slide

19. 3. Managing origin of
    distributed client


    View Slide

20. Protecting personal data and identity integrity




    View Slide

21.  Same Origin Policy


    View Slide

22. Pages of the same origin can manipulate
    each other's DOM


    View Slide

23. Content loaded from one domain can not
    interact with content coming from another


    View Slide

24. Extended to other aspects :
    HTTP Cookies, XMLHttpRequest


    View Slide

25. Defining origin
    http://tools.ietf.org/html/rfc6454
    trusted === {scheme, host, port}
    not trusted !== {scheme, host, port}


    View Slide

26. So what’s trustworthy?
    http://www.example.com/index.html
    http://www.example.com/content/page2.html
    http://user:pwd@www.example.com/api/resource


    View Slide

27. And what’s not?
    http://www.example.com/index.html
    http://www.example.com:81/content/page2.html
    https://www.example.com/content/page2.html
    http://example.com/content/page2.html
    http://api.example.com/content/page2.html


    View Slide

28. We need to relax


    View Slide

29. Techniques for relaxing

    •  document.domain property
    •  Cross-document messaging
    •  JSONP
    •  CORS



    View Slide

30. document.domain property
    http://www.example.com/
    <br/>document.domain = 'example.com';<br/>
    http://store.example.com/
    <br/>document.domain = 'example.com';<br/>


    View Slide

31. Cross-document messaging
    http://www.example.com/
    http://store.example.net/
    http://example.com/
    <br/>otherWindow.postMessage("hello there!", "http://example.net");<br/>
    http://example.net/
    <br/>window.addEventListener("message",receiveMessage,false);<br/>function receiveMessage(event) {<br/>if (event.origin !== "http://example.com")<br/>// DO STUFF HERE WITH event.data<br/>}<br/>


    View Slide

32. JSONP
    <br/>


    View Slide

33. JSONP


    View Slide

34. Ok, but we want more!
    Previous solutions are valid only if you want to be
    in RMM1
    No Verbs
    No Content Negotiation
    No Headers for security


    View Slide

35. Cross-Origin Resource Sharing
    •  W3C Recomandation (16 january 2014)
    •  Enable true cross domain communication
    for JavaScript application
    •  Build on top of the XHR


    View Slide

36. Simple Cross-Origin Request
    JavaScript Code Browser API Server
    xhr.send()
    Actual request
    Actual response
    onload / onerror


    View Slide

37. Simple Request Method
    HEAD
    GET
    POST



    View Slide

38. Simple request header
    Accept
    Accept-Language
    Content-Type
    Content-Language


    View Slide

39. Simple response header
    Cache-Control
    Content-Language
    Content-Type
    Expires
    Last-Modified
    Pragma


    View Slide

40. GET /resource HTTP/1.1
    Origin: http://www.example.com
    Host: api.example.com
    ...
    HTTP/1.1 200 OK
    Access-Control-Allow-Origin: http://www.example.com
    ...


    View Slide

41. Cross-Origin Request with Prefilght
    JavaScript Code Browser API Server
    xhr.send()
    Actual request
    Actual response
    onload / onerror
    Prefligth request
    Preflight response


    View Slide

42. •  CORS with preflight request are originated by :
    –  Other HTTP verbs (PUT PATCH DELETE)
    –  Other Content-Type (Application/Json)
    –  Custom Headers (Allow-Header : X-AUTH)
    –  Non simple header expose (Expose-Header)
    •  Preflight request + actual request


    View Slide

43. OPTIONS /resource HTTP/1.1
    Origin: http://www.example.com
    Access-Control-Request-Method: PUT
    Access-Control-Request-Headers: X-Custom-Header
    Host: api.example.com
    HTTP/1.1 200 OK
    Access-Control-Allow-Origin: http://www.example.com
    Access-Control-Allow-Methods: GET, POST, PUT, PATCH,
    DELETE
    Access-Control-Allow-Headers: X-Custom-Header
    Access-Control-Max-Age: 3600
    ...


    View Slide

44. PUT /cors HTTP/1.1
    Origin: http://www.example.com
    Host: api.example.com
    X-Custom-Header: value

    HTTP/1.1 200 OK
    Access-Control-Allow-Origin: http://www.example.com
    Content-Type: text/html; charset=utf-8


    View Slide

45. Implementation
    Client side:
    •  Nicolas Zakas’s Request Object Wrapper
    •  jQuery
    Server side:
    •  NelmioCorsBundle


    View Slide

46. composer.json
    "require": {
    "nelmio/cors-bundle": "~1.0"},
    }


    View Slide

47. app/config/config.yml
    nelmio_cors:
    defaults:
    allow_credentials: false
    allow_origin: [*]
    allow_methods: ['GET','PUT','POST']
    expose_headers: []
    max_age: 3600
    hosts: []


    View Slide

48. app/config/config.yml
    nelmio_cors:
    defaults:
    allow_credentials: false
    allow_origin: [*]
    allow_methods: ['GET','PUT','POST']
    expose_headers: []
    max_age: 3600
    hosts: []


    View Slide

49. app/config/config.yml
    nelmio_cors:
    defaults:
    allow_credentials: false
    allow_origin: [*]
    allow_methods: ['GET','PUT','POST']
    expose_headers: []
    max_age: 3600
    hosts: []


    View Slide

50. app/config/config.yml
    nelmio_cors:
    defaults:
    allow_credentials: false
    allow_origin: [*]
    allow_methods: ['GET','PUT','POST']
    expose_headers: []
    max_age: 3600
    hosts: []


    View Slide

51. […]
    paths:
    '^/api/':
    allow_origin: ['*']
    allow_methods: ['GET','PUT','POST']
    '^/api/sensitiveResource':
    allow_origin:['https://trusted.io']


    View Slide

52. Lesson learned
    If you want to be RESTfull you have to go with CORS


    View Slide

53. 4. Managing  security  of  your
    resources


    View Slide

54. Authentication
    •  Basic authentication
    •  Digest authentication
    •  Token authentication
    •  API Key
    •  WSSE
    •  OpenID


    View Slide

55. Authorization
    •  Authorization token
    •  OAuth 1.0a
    •  OAuth 2


    View Slide

56. API Security in Symfony
    hwi/HWIOAuthBundle
    friendsofsymfony/oauth-server-bundle
    escapestudios/EscapeWSSEAuthenticationBundle


    View Slide

57. HANDS ON


    View Slide

58. https://www.university.edu
    0. authentication
    Web Application Client
    LMS
    SCORM
    1. API Key
    https://auth.example.com
    2 request
    authorization
    https://content.example.com
    3 3 send token
    4 access resources


    View Slide

59. Custom Authentication Provider


    View Slide

60. app/configu/security.yml
    security:
    providers:
    [...]
    capturator:
    id: capturator.security.tokenAuth
    in_memory:
    memory:
    users:
    authentication-authority:
    - password: %auth_authority_pwd%
    - roles: ROLE_AUTH'


    View Slide

61. app/configu/security.yml
    security:
    providers:
    [...]
    capturator:
    id: capturator.security.tokenAuth
    in_memory:
    memory:
    users:
    authentication-authority:
    - password: %auth_authority_pwd%
    - roles: 'ROLE_AUTHENTICATION_AUTHORITY'


    View Slide

62. firewalls:
    capturator_api_licenser:
    pattern: ^/api/token(.*)
    anonymous: ~
    http_basic:
    realm: "Secured Authentication Authority Realm"
    provider: in_memory
    capturator_api:
    pattern: ^/api/(.*)
    capturator: true
    stateless: true
    [...]
    access_control:
    [...]
    - { path: ^/api/token(.*), roles: ROLE_AUTH, ip: 192.168.0.1, requires_channel: https }


    View Slide

63. Capturator/CoreBundle/Resources/config/services.xml



    Capturator\CoreBundle\Security\User\CapturatorUserProvider

    Capturator\CoreBundle\Security\Service\TokenRetriever
    [...]


    class="%capturator.security.userProvider.class%">


    [...]



    View Slide

64. Capturator/CoreBundle/Resources/config/services.xml



    Capturator\CoreBundle\Security\User\CapturatorUserProvider

    Capturator\CoreBundle\Security\Service\TokenRetriever
    [...]


    class="%capturator.security.userProvider.class%">


    [...]



    View Slide

65. class CapturatorListener implements ListenerInterface
    {
    protected $securityContext;
    protected $authenticationManager;
    protected $tokeRetriever;
    […]
    public function handle(GetResponseEvent $event)
    {
    $request = $event->getRequest();
    $requestTokenString = $this->tokeRetriever->retrieve($request);
    $token = new CapturatorToken();
    $token->setUser($requestTokenString);
    $authToken = $this->authenticationManager->authenticate($token);
    $this->securityContext->setToken($authToken);
    }
    }


    View Slide

66. class CapturatorListener implements ListenerInterface
    {
    protected $securityContext;
    protected $authenticationManager;
    protected $tokeRetriever;
    […]
    public function handle(GetResponseEvent $event)
    {
    $request = $event->getRequest();
    $requestTokenString = $this->tokeRetriever->retrieve($request);
    $token = new CapturatorToken();
    $token->setUser($requestTokenString);
    $authToken = $this->authenticationManager->authenticate($token);
    $this->securityContext->setToken($authToken);
    }
    }


    View Slide

67. namespace Capturator\CoreBundle\Security\Service;
    use Symfony\Component\HttpFoundation\Request;
    use Capturator\CoreBundle\Exception\AuthenticationException;
    class TokenRetriever implements TokenRetrieverInterface
    {
    public function retrieve(Request $request)
    {
    if (!$request->query->has('token') && !$request->headers->has('x-cassys-auth')) {
    throw new AuthenticationException(
    ‘Missing required authentication parameter',
    __CLASS__);
    }
    $requestTokenString = $request->query->has('token') ?
    $request->query->get('token') :
    $request->headers->get('x-cassys-auth');
    return $requestTokenString;
    }
    }


    View Slide

68. class CapturatorListener implements ListenerInterface
    {
    protected $securityContext;
    protected $authenticationManager;
    protected $tokeRetriever;
    […]
    public function handle(GetResponseEvent $event)
    {
    $request = $event->getRequest();
    $requestTokenString = $this->tokeRetriever->retrieve($request);
    $token = new CapturatorToken();
    $token->setUser($requestTokenString);
    $authToken = $this->authenticationManager->authenticate($token);
    $this->securityContext->setToken($authToken);
    }
    }


    View Slide

69. Capturator/CoreBundle/Security/User/CapturatorUserProvider.php
    class CapturatorUserProvider implements UserProviderInterface
    {
    protected $em;
    public function __construct(EntityManager $em)
    {
    $this->em = $em;
    }
    public function loadUserByUsername( $token) [...]
    public function refreshUser(UserInterface $user ) [...]
    public function supportsClass($class)
    {
    return ($class == "Capturator\CoreBundle\Security\User\CapturatorUser");
    }
    }


    View Slide

70. The SimplePreAuthenticatorInterface
    interface was introduced in Symfony 2.4.


    View Slide

71. Extendig NelmioCorsBundle
    Associating Origin and Authorization


    View Slide

72. /Users/marco/Progetti/Cassys-Server/app/config/config.yml
    capturator_cors:
    allow_origin_entity: CapturatorCoreBundle:CustomerDomainName
    defaults:
    allow_credentials: false
    expose_headers: []
    max_age: 0
    hosts: []
    paths:
    '^/api/3/':
    allow_headers: ['X-Cassys-Auth', 'X-Requested-With', 'Content-Type']
    allow_methods: ['POST', 'PUT', 'GET']


    View Slide

73. /Users/marco/Progetti/Cassys-Server/app/config/config.yml
    capturator_cors:
    allow_origin_entity: CapturatorCoreBundle:CustomerDomainName
    defaults:
    allow_credentials: false
    expose_headers: []
    max_age: 0
    hosts: []
    paths:
    '^/api/3/':
    allow_headers: ['X-Cassys-Auth', 'X-Requested-With', 'Content-Type']
    allow_methods: ['POST', 'PUT', 'GET']


    View Slide

74. Capturator/CoreBundle/Resources/config/services.xml



    Capturator\CorsBundle\Options\CustomerDomainProvider


    class="%capturator_cors.customer_origin_provider%">
    %capturator_cors.map%
    %capturator_cors.defaults%
    %capturator_cors.allow_origin_entity%







    View Slide

75. Capturator/CoreBundle/Resources/config/services.xml



    Capturator\CorsBundle\Options\CustomerDomainProvider


    class="%capturator_cors.customer_origin_provider%">
    %capturator_cors.map%
    %capturator_cors.defaults%
    %capturator_cors.allow_origin_entity%







    View Slide

76. Capturator/CorsBundle/Options/CustomerDomainRepositoryInterface.php
    namespace Capturator\CorsBundle\Options;
    interface CustomerDomainRepositoryInterface {
    /**
    * @param $origin
    * @return mixed
    */
    public function findOneByOriginDomain( $origin, $token);}


    View Slide

77. CorsBundle/Options/CustomerDomainProvider.php
    [...]use Nelmio\CorsBundle\Options\ProviderInterface;
    class CustomerDomainProvider implements ProviderInterface
    {
    [...]
    public function getOptions(Request $request)
    {
    [...]
    $origin = $request->headers->get('Origin');
    $token= $request->headers->get('X-CUSTOM-AUTH');
    if (!is_null($this->repository->findOneByOriginDomain($origin, $token))) {
    $options['allow_origin'] = array($origin);
    $options= array_merge($this->defaults, $options);
    return $options;
    }
    }
    }


    View Slide

78. CorsBundle/Options/CustomerDomainProvider.php
    [...]use Nelmio\CorsBundle\Options\ProviderInterface;
    class CustomerDomainProvider implements ProviderInterface
    {
    [...]
    public function getOptions(Request $request)
    {
    [...]
    $origin = $request->headers->get('Origin');
    $token= $request->headers->get('X-CUSTOM-AUTH');
    if (!is_null($this->repository->findOneByOriginDomain($origin, $token))) {
    $options['allow_origin'] = array($origin);
    $options= array_merge($this->defaults, $options);
    return $options;
    }
    }
    }


    View Slide

79. 5. Conclusion


    View Slide

80. Work done


    View Slide

81. Prefer open protocol


    View Slide

82. Access control


    View Slide

83. References
    h7p://www.ics.uci.edu/~fielding/pubs/disserta@on/top.htm
    h7ps://www.owasp.org/index.php/REST_Security_Cheat_Sheet#Introduc@on
    h7p://www.w3.org/TR/cors/
    h7p://www.iana.org/assignments/link-­‐rela@ons/
    h7ps://www.oasis-­‐open.org/commi7ees/wss/documents/WSS-­‐Username-­‐02-­‐0223-­‐merged.pdf
    h7p://oauth.net/
    h7p://www.ieP.org/rfc/rfc2617.txt
    h7p://www.ieP.org/rfc/rfc5849.txt  (OAuth  1.0a)
    h7p://www.ieP.org/rfc/rfc6749.txt  (OAutn  2.0)
    h7p://tools.ieP.org/html/dra[-­‐kelly-­‐json-­‐hal-­‐06
    h7p://www.w3.org/TR/json-­‐ld/


    View Slide

84. Readings
    h7p://en.wikipedia.org/wiki/Cross-­‐origin_resource_sharing
    h7ps://code.google.com/p/browsersec/wiki/Part2#Standard_browser_security_features
    h7p://www.html5rocks.com/en/tutorials/cors/
    h7p://enable-­‐cors.org/
    h7p://williamdurand.fr/2012/08/02/rest-­‐apis-­‐with-­‐symfony2-­‐the-­‐right-­‐way/
    h7p://welcometothebundle.com/symfony2-­‐rest-­‐api-­‐the-­‐best-­‐2013-­‐way/
    h7p://2012.phpday.it/talk/designing-­‐h7p-­‐interfaces-­‐and-­‐resPul-­‐web-­‐services/
    h7p://2013.phpday.it/talk/rest-­‐apis-­‐made-­‐easy-­‐with-­‐symfony2/
    h7p://www.slideshare.net/dlondero/rest-­‐in-­‐prac@ce-­‐27335543
    h7p://edu.williamdurand.fr/web-­‐security-­‐101-­‐slides/#/
    h7p://edu.williamdurand.fr/security-­‐slides/#slide1
    h7p://friendsofsymfony.github.io/slides/res@ng-­‐with-­‐symfony2.html#/
    h7p://symfony.com/doc/current/cookbook/security/custom_authen@ca@on_provider.html
    h7p://symfony.com/doc/current/cookbook/security/api_key_authen@ca@on.html


    View Slide

85. Thanks
    http://joind.in/11303
    @netamorfose
    www.marcoloche.com
    marco@marcoloche.com
    All pictures are mine


    View Slide

86. Q & A
    http://joind.in/11303
    @netamorfose
    www.marcoloche.com
    marco@marcoloche.com
    All pictures are mine


    View Slide
