Security@Scale: Invariant Detector

A Facebook London project with Chad Parry, Ben Matthews, Ioannis Papagiannis and Marjori Pomarole.

Video: https://www.youtube.com/watch?v=a-GyrDBWppU

Transcript

3. Software Engineer - Security Infrastructure in London Marjori Pomarole Improving Code Health with Invariant Detector
4. The Problem
5. Endpoints everywhere, bugs will appear eventually Facebook App POST requests facebook.com/update/cover_photo m.facebook.com/update/page_preference facebook.com/graphql/photos .... Mobile Apps (Android, iPhone, etc) facebook.com m.facebook.com
6. Malicious actors taking advantage of bugs Exploiting endpoints POST requests facebook.com/update/cover_photo m.facebook.com/update/page_preference facebook.com/graphql/photos .... Mobile Apps (Android, iPhone, etc) facebook.com m.facebook.com
7. Building tools and frameworks so developers don't have to think about security Security Infrastructure POST requests facebook.com/update/cover_photo m.facebook.com/update/page_preference facebook.com/graphql/photos .... Mobile Apps (Android, iPhone, etc) facebook.com m.facebook.com
8. What a typical request looks like Good Request and Good Code endpoint facebook.com/update/cover_photo uri params ?user_id=1234&photo_id=4321 Logger in user: 1234 class UpdateCoverPhotoController { ... public async genResponse( ): Awaitable<xhp> { $request = $this->getRequest(); $user_id = $request->getInt('user_id'); $photo_id = $request->getInt('photo_id'); $actor = $request->getUserID(); $can_edit = Photos::checkPermission($actor, $photo_id); // code to update cover photo for $user_id } }
9. Malicious actor can use Curl to fabricate a request Evil request and Good code endpoint facebook.com/update/cover_photo uri params ?user_id=9876&photo_id=2345 Logger in user: 1234 class UpdateCoverPhotoController { ... public async genResponse( ): Awaitable<xhp> { $request = $this->getRequest(); $user_id = $request->getInt('user_id'); $photo_id = $request->getInt('photo_id'); $actor = $request->getUserID(); $can_edit = Photos::checkPermission($actor, $photo_id); // cannot edit, so fail the request } }
10. This is where we fail Evil Request and Bad code class UpdateCoverPhotoController { ... public async genResponse( ): Awaitable<xhp> { $request = $this->getRequest(); $user_id = $request->getInt('user_id'); $photo_id = $request->getInt('photo_id'); // code to update cover photo for $user_id } } endpoint facebook.com/update/cover_photo uri params ?user_id=9876&photo_id=2345 Logger in user: 1234
11. How can we spot the vulnerabilities before they go live?
12. You shall not pass Code Review
13. Adding a layer of security before product code access objects in data store Privacy Framework Privacy Rules AllowIfOwner DenyIfNotCreator AllowIfViewerCanSeePageRule .... Product Code Data Store
14. We still have to have all the correct policies in place Privacy Framework Privacy Rules AllowIfOwner DenyIfNotCreator AllowIfViewerCanSeePageRule .... Product Code Data Store
15. Tons of legacy code though, hard to migrate everything over night Privacy Framework Product Code Data Store Privacy Rules AllowIfOwner DenyIfNotCreator AllowIfViewerCanSeePageRule ....
16. How can we find the vulnerabilities after they have gone live?
17. Facebook's bug bounty program Whitehats
18. The automatic approach, this is what you are all here for System that automatically finds and blocks anomalies in write requests before we update our data stores. Invariant Detector
19. 100.000 feet view of how it works
20. 1. log sample 2. data pipeline creates rules 3. evaluate rules 6. enforce rules 7. Block Set of Invariants 5. data pipeline ratifies rules 4. log evaluation results Hive actor uri equivalent fields 1234 /photo/save photo.owner_id === actor 2432 /user/update user.id == actor
21. Web Servers
22. 1. log sample Hive actor uri equivalent fields 1234 /photo/save photo.owner_id === actor 2432 /user/update user.id == actor
23. 1. log sample 2. data pipeline creates rules Set of Invariants Hive actor uri equivalent fields 1234 /photo/save photo.owner_id === actor 2432 /user/update user.id == actor
24. 1. log sample 2. data pipeline creates rules Set of Invariants Hive actor uri equivalent fields 1234 /photo/save photo.owner_id === actor 2432 /user/update user.id == actor 3. evaluate rules
25. 1. log sample 2. data pipeline creates rules 3. evaluate rules Set of Invariants 4. log evaluation results Hive actor uri equivalent fields 1234 /photo/save photo.owner_id === actor 2432 /user/update user.id == actor
26. 1. log sample 2. data pipeline creates rules 3. evaluate rules Set of Invariants 5. data pipeline ratifies rules 4. log evaluation results Hive actor uri equivalent fields 1234 /photo/save photo.owner_id === actor 2432 /user/update user.id == actor
27. 1. log sample 2. data pipeline creates rules 3. evaluate rules Set of Invariants 5. data pipeline ratifies rules 4. log evaluation results Hive actor uri equivalent fields 1234 /photo/save photo.owner_id === actor 2432 /user/update user.id == actor 6. enforce rules
28. 1. log sample 2. data pipeline creates rules 3. evaluate rules 6. enforce rules 7. Block Set of Invariants 5. data pipeline ratifies rules 4. log evaluation results Hive actor uri equivalent fields 1234 /photo/save photo.owner_id === actor 2432 /user/update user.id == actor
29. Deep Dive
30. What exactly are we logging here? Equivalent Fields { "11111111111111":[["id1","owner_id"],["actors","[]"]], "22222222222222":[["id1","owner_id"],["id1","oid"]], "19283912830192":[["id1","time_updated"],["id2","time_updated"]], }
31. Read-optimised graph data store built at Facebook TAO Bronson, Nathan, et al. "TAO: Facebook's Distributed Data Store for the Social Graph." USENIX Annual Technical Conference. 2013. User Privacy Settings Photo User like (asymmetric) liked by (asymmetric) privacy (unique) friends (symmetric)
32. Objects and associations TAO FBObj FBObj Associations assoc TAO id1 id2
33. How it looks before it is saved to TAO Example request PHOTO USER USER_TO_COVER_PHOTO { "22222222222222":[["id1","id"],["id2","owner_id"]], "19283912830192":[["id1","time_updated"],["id2","time_updated"]], } id owner_id size type ... id name dob username ... id1 id2
34. We can look at the environment as well Example request PHOTO USER USER_TO_COVER_PHOTO { "11111111111111":[["actors","[]"], ["id2","owner_id"]], "22222222222222":[["id1","id"],["id2","owner_id"]], "19283912830192":[["id1","time_updated"],["id2","time_updated"]], } id owner_id size type ... id name dob username ... id1 id2 logged in user (actors) actor's friends pages the actor admins groups the actor has membership groups the actor admins
35. Reading logs in Hive and creating rules Data pipeline Logs Logs Logs Logs DATE DATE-1 DATE-N ... Data Pipeline HiveQL Set of invariants PHOTO -> COVER_PHOTO_TO_USER -> USER 1. logged in user always needs to be equal to the owner_id of the photo 2. field owner_id always needs to be equal to id of user FBOBj.
36. With negligible overhead in 100% of the requests Evaluate the rules Set of invariants PHOTO -> COVER_PHOTO_TO_USER -> USER 1. logged in user always needs to be equal to the owner_id of the photo 2. field owner_id always needs to be equal to id of user FBOBj. /update/cover_photo
37. Updating these rules on web servers Distribution Set of invariants PHOTO -> COVER_PHOTO_TO_USER -> USER 1. logged in user always needs to be equal to the owner_id of the photo 2. field owner_id always needs to be equal to id of user FBOBj.
38. Configerator Tang, Chunqiang, et al. "Holistic configuration management at Facebook." Proceedings of the 25th Symposium on Operating Systems Principles. ACM, 2015.
39. Configerator can take care of it Distribution Set of invariants Configerator PHOTO -> COVER_PHOTO_TO_USER -> USER 1. logged in user always needs to be equal to the owner_id of the photo 2. field owner_id always needs to be equal to id of user FBOBj.
40. Configerator is immediate though, block disaster can occur Distribution Set of invariants PHOTO -> COVER_PHOTO_TO_USER -> USER 1. field size in photo is equal to 10x10 Configerator
41. Canary roll out Distribution Take 2 Set of invariants Cache Archive blob
42. Canary roll out Distribution Take 2 Set of invariants Cache Archive blob
43. Canary roll out Distribution Take 2 Set of invariants Cache Archive blob
44. Negligible overhead Evaluate and enforce invariants Product code Data fetching Privacy Layer TAO Invariant Detector
45. Investigating what code has the vulnerability Violations violations actor uri stack_trace post_data event_time 1234 /photo/ save .... photo_id.... 1231239122 blocked request Product teams to investigate
46. Reducing impact of false positives Whitelist read whitelist before blocking Whitelist (in Configerator) PHOTO -> COVER_PHOTO_TO_USER -> USER logged in user always needs to be equal to the owner_id of the photo
47. Whitelist Whitelist PHOTO -> COVER_PHOTO_TO_USER -> USER logged in user always needs to be equal to the owner_id of the photo Whitelist (in Configerator) PHOTO -> COVER_PHOTO_TO_USER -> USER logged in user always needs to be equal to the owner_id of the photo
48. Final thoughts
49. And blocked from exploiting people's data • A request that was trying to upload pending photos to any album in an specific endpoint in mobile • Whitehat trying to exploit scheduling of draft posts in pages in our graphql api • Requests that were allowing personal photos of a page admin to be used on the page. Leaked the identity of the admin • Endpoint to update location preferences of page was not checking that the person logged in was admin of the page Cool stuff it found
50. What can we do to make the system even more powerful • False Positives • Better tools for investigation • Better graph relationships support What's next
51. With Facebook scale and negligible overhead we can use dynamic code analysis on our live production traffic to automatically infer invariants to find and block malicious actors from manipulating people's data. Invariant Detector Questions? Come find me afterwards or email me at mpomarole@fb.com A Facebook London project with Chad Parry, Ioannis Papagiannis, Marjori Pomarole and SecInfra team.
