BIWA2016 - Enrich Transform and Analyse Big Data using Oracle Big Data Discovery and Oracle Visual Analyzer

Many organizations are implementing data lakes or data reservoirs to add new sources and types of data to their existing analytic platform, but are struggling to get full use of out of these new platforms as the data in them needs digesting, cataloging, transforming and then curating before it can be used properly with tools such as OBIEE12c and Visual Analyzer. In this session we'll see how Oracle Big Data Discovery can fill this need by proving a graphical environment to load and process data coming into the data reservoir, enrich and transform the data to make it more suitable for analysis by end users, and then publish this data in conbination with other data reservoir datasets into a format more suited to tools such as OBIEE12c and Visual Analyzer. We'll see how Big Data Discovery is more suited to the initial phases of a big data project due to its support of flexible-schema datasets and it's more freeform analysis tools, how it can be used to make sense of the typically hundreds of distinct datasets in a Hadoop environment, and then use simple user-driven tools to enrich, transform and then prepare data for analysis. We'll then see the additional requirements that tools such as OBIEE place on datasets they they use and how Big Data Discovery along wih other Oracle tools can help shape the dimensions, fact tables and hierarchies OBIEE requires, all within the Hadoop environment and without writing any code.

Transcript

1. info@rittmanmead.com www.rittmanmead.com @rittmanmead Enrich, Transform and Analyse Big Data using
 Oracle Big Data Discovery and Oracle Visual Analyzer Mark Rittman, CTO, Rittman Mead BIWA Summit 2016, San Francisco, January 2016
2. info@rittmanmead.com www.rittmanmead.com @rittmanmead 2 •Mark Rittman, Co-Founder of Rittman Mead ‣Oracle ACE Director, specialising in Oracle BI&DW ‣14 Years Experience with Oracle Technology ‣Regular columnist for Oracle Magazine •Author of two Oracle Press Oracle BI books ‣Oracle Business Intelligence Developers Guide ‣Oracle Exalytics Revealed ‣Writer for Rittman Mead Blog :
 http://www.rittmanmead.com/blog •Email : mark.rittman@rittmanmead.com •Twitter : @markrittman About the Speaker
3. info@rittmanmead.com www.rittmanmead.com @rittmanmead 3 •Many Rittman Mead customers have asked us whether they need both Visual Analyzer, and Oracle Big Data Discovery, for data discovery against big data ‣They both provide “data discovery” ‣OBIEE can access Hadoop + NoSQL datasets ‣BDD is just Endeca, and we didn’t need that •Why don’t we just use Visual Analyzer for this work? •Can we just give Big Data Discovery to all our users? •Well let’s find out… I’m Analysing Oracle Big Data - Which Tool to Use? Mr. Visual Analyzer Mr. Big Data Discovery
4. info@rittmanmead.com www.rittmanmead.com @rittmanmead 4 Business Scenario •Rittman Mead want to understand drivers and audience for their website ‣What is our most popular content? Who are the most in-demand blog authors? •Three data sources in scope ‣Mixture of event-based data (website page view), Social Media (Twitter) and Textual (blog) RM Website Logs Twitter Stream Website Posts, Comments etc
5. info@rittmanmead.com www.rittmanmead.com @rittmanmead 5 •Apache Flume is the standard way to transport log files from source through to target •Initial use-case was webserver log files, but can transport any file from A>B •Does not do data transformation, but can send to multiple targets / target types •Mechanisms and checks to ensure successful transport of entries •Has a concept of “agents”, “sinks” and “channels” •Agents collect and forward log data •Sinks store it in final destination •Channels store log data en-route •Simple configuration through INI files •Handled outside of ODI12c Apache Flume : Distributed Transport for Log Activity
6. info@rittmanmead.com www.rittmanmead.com @rittmanmead 6 •Twitter provides an API for developers to use to
 consume the Twitter “firehose” •Can specify keywords to limit the tweets consumed •Free service, but some limitations on actions
 (number of requests etc) •Install additional Flume source JAR (pre-built available,
 but best to compile from source) ‣https://github.com/cloudera/cdh-twitter-example •Specify Twitter developer API key and keyword
 filters in the Flume conf settings Accessing the Twitter “Firehose”
7. info@rittmanmead.com www.rittmanmead.com @rittmanmead •Capture page view + Twitter activity using Apache Flume, land in HDFS •Analyse using Big Data SQL and OBIEE Overall Project Architecture - Phase 1 Spark Hive HDFS Spark Hive HDFS Spark Hive HDFS Cloudera CDH5.3 BDA Hadoop Cluster Big Data SQL Exadata Exalytics Flume Flume Dim
 Attributes SQL for
 BDA Exec Filtered &
 Projected
 Rows /
 Columns OBIEE TimesTen 12c In-Mem Flume
8. info@rittmanmead.com www.rittmanmead.com @rittmanmead 8 •Data landed into Hadoop is considered “raw” ‣At best, semi-structured ‣No data quality checks ‣Typically in non-tabular format ‣Isolated datasets, no joins ‣No data dictionary ‣Real-time and immediate, but raw Raw Data Landed into Hadoop Data Reservoir
9. info@rittmanmead.com www.rittmanmead.com @rittmanmead •Data integration tools such as Oracle Data Integrator can load and process Hadoop data •BI tools such as Oracle Business Intelligence 12c can report on Hadoop data •Visual Analyzer fantastic tool for data discovery •Can’t we use these for accessing and processing
 our raw incoming datasets? Data Integration and BI Tools can Access Hadoop? Access direct Hive or extract using ODI12c for structured OBIEE dashboard analysis What pages are people visiting? Who is referring to us on Twitter? What content has the most reach?
10. info@rittmanmead.com www.rittmanmead.com @rittmanmead 10 •Visual Analyzer and Answers both require a BI Repository (RPD) as their main datasource ‣Provides a structured, curated baseline for reporting, can be supplemented by mashups •But is this the right time to be curating data? ‣Do we understand it well enough yet? Understand the Work Involved in Creating an RPD
11. info@rittmanmead.com www.rittmanmead.com @rittmanmead 11 •Data in the data reservoir typically is raw, hasn’t been organised into facts, dimensions yet •Often you don’t want to it to be - “data scientists like it raw” •Later on though, users will benefit from structure and hierarchies being added to data •So how do we initially understand raw data, enrich and make is suitable for Visual Analyzer? Hadoop Data is Typically “Schema-on-Read”
12. info@rittmanmead.com www.rittmanmead.com @rittmanmead 12 Where Can We Find This Type of Developer…? + =
13. info@rittmanmead.com www.rittmanmead.com @rittmanmead 13 •Specialist skills typically needed to ingest and understand data coming into Hadoop •Data loaded into the reservoir needs preparation and curation before presenting to users •But we’ve heard a similar story before, a few years ago… Turning Raw Data into Information and Value is Hard 6 Tool Complexity • Early Hadoop tools only for experts • Existing BI tools not designed for Hadoop • Emerging solutions lack broad capabilities 80% effort typically spent on evaluating and preparing data Data Uncertainty • Not familiar and overwhelming • Potential value not obvious • Requires significant manipulation Overly dependent on scarce and highly skilled resources
14. info@rittmanmead.com www.rittmanmead.com @rittmanmead 14 Back to 2012…
15. info@rittmanmead.com www.rittmanmead.com @rittmanmead 15 •Part of the acquisition of Endeca back in 2012 by Oracle Corporation •Based on search technology and concept of “faceted search” •Data stored in flexible NoSQL-style in-memory database called “Endeca Server” •Added aggregation, text analytics and text enrichment features for “data discovery” ‣Explore data in raw form, loose connections, navigate via search rather than hierarchies ‣Useful to find out what is relevant and valuable in a dataset before formal modeling What Was Oracle Endeca Information Discovery?
16. info@rittmanmead.com www.rittmanmead.com @rittmanmead 16 •Proprietary database engine focused on search and analytics •Data organized as records, made up of attributes stored as key/value pairs •No over-arching schema,
 no tables, self-describing attributes •Endeca Server hallmarks: ‣Minimal upfront design ‣Support for “jagged” data ‣Administered via web service calls ‣“No data left behind” ‣“Load and Go” •But … limited in scale (>1m records) ‣… what if it could be rebuilt on Hadoop? Endeca Server Technology Combined Search + Analytics
17. info@rittmanmead.com www.rittmanmead.com @rittmanmead 17 •A visual front-end to the Hadoop data reservoir, providing end-user access to datasets •Catalog, profile, analyse and combine schema-on-read datasets across the Hadoop cluster •Visualize and search datasets to gain insights, potentially load in summary form into DW Oracle Big Data Discovery
18. info@rittmanmead.com www.rittmanmead.com @rittmanmead 18 •Initial catalog view of the raw datasets in Hadoop •Lightweight, user-driven data transformations (“data wrangling”) •Enrichment of raw data to add sentiment scores, extract nouns etc •User-driven addition of file and RDBMS datasets for reference data •Understand potential columns for joins, and for hierarchies to go into RPD Where Oracle Big Data Discovery Can Add Value
19. info@rittmanmead.com www.rittmanmead.com @rittmanmead 19 •Relies on datasets in Hadoop being registered with Hive Catalog •Presents semi-structured and other datasets as tables, columns •Hive SerDe and Storage Handler technologies allow Hive to run over most datasets •Hive tables need to be defined before dataset can be used by BDD Enabling Raw Data for Access by Big Data Discovery CREATE external TABLE apachelog_parsed( host STRING, identity STRING, … agent STRING) ROW FORMAT SERDE 'org.apache.hadoop.hive.serde2.RegexSerDe' WITH SERDEPROPERTIES ( "input.regex" = "([^]*) ([^]*) ([^]*) (-|\\[^\\]*\\])
 ([^ \”]*|\"[^\"]*\")(-|[0-9]*) (-|[0-9]*)(?: ([^ \"]
 *|\".*\") ([^ \"]*|\".*\"))?" ) STORED AS TEXTFILE LOCATION '/user/flume/rm_website_logs;
20. info@rittmanmead.com www.rittmanmead.com @rittmanmead 20 •Tweets and Website Log Activity stored already in data reservoir as Hive tables •Upload triggered by manual call to BDD Data Processing CLI ‣Runs Oozie job in the background to profile,
 enrich and then ingest data into DGraph Ingesting Logs and Tweet Data Samples into DGraph [oracle@bddnode1 ~]$ cd /home/oracle/Middleware/BDD1.0/dataprocessing/edp_cli [oracle@bddnode1 edp_cli]$ ./data_processing_CLI -t access_per_post_cat_author [oracle@bddnode1 edp_cli]$ ./data_processing_CLI -t rm_linked_tweets Hive Apache Spark pageviews X rows pageviews >1m rows Profiling pageviews >1m rows Enrichment pageviews >1m rows BDD pageviews >1m rows { "@class" : "com.oracle.endeca.pdi.client.config.workflow.
 ProvisionDataSetFromHiveConfig", "hiveTableName" : "rm_linked_tweets", "hiveDatabaseName" : "default", "newCollectionName" : “edp_cli_edp_a5dbdb38-b065…”, "runEnrichment" : true, "maxRecordsForNewDataSet" : 1000000, "languageOverride" : "unknown" } 1 2 3
21. info@rittmanmead.com www.rittmanmead.com @rittmanmead 21 •Ingested datasets are now visible in Big Data Discovery Studio •Create new project from first dataset, then add second View Ingested Datasets, Create New Project
22. info@rittmanmead.com www.rittmanmead.com @rittmanmead 22 •Ingestion process has automatically geo-coded host IP addresses •Other automatic enrichments run after initial discovery step, based on datatypes, content Automatic Enrichment of Ingested Datasets
23. info@rittmanmead.com www.rittmanmead.com @rittmanmead 23 •For the ACCESS_PER_POST_CAT_AUTHORS dataset, 18 attributes now available •Combination of original attributes, and derived attributes added by enrichment process Initial Data Exploration On Uploaded Dataset Attributes
24. info@rittmanmead.com www.rittmanmead.com @rittmanmead 24 •Click on individual attributes to view more details about them •Add to scratchpad, automatically selects most relevant data visualisation Explore Attribute Values, Distribution using Scratchpad 1 2
25. info@rittmanmead.com www.rittmanmead.com @rittmanmead 25 •Data ingest process automatically applies some enrichments - geocoding etc •Can apply others from Transformation page - simple transformations & Groovy expressions Data Transformation & Enrichment
26. info@rittmanmead.com www.rittmanmead.com @rittmanmead 26 •Uses Salience text engine under the covers •Extract terms, sentiment, noun groups, positive / negative words etc Transformations using Text Enrichment / Parsing
27. info@rittmanmead.com www.rittmanmead.com @rittmanmead 27 •Choose option to Create New Attribute, to add derived attribute to dataset •Preview changes, then save to transformation script Create New Attribute using Derived (Transformed) Values 1 2 3
28. info@rittmanmead.com www.rittmanmead.com @rittmanmead 28 •Transformation changes have to be committed to DGraph sample of dataset ‣Project transformations kept separate from other project copies of dataset •Transformations can also be applied to full dataset, using Apache Spark ‣Creates new Hive table of complete dataset Commit Transforms to DGraph, or Create New Hive Table
29. info@rittmanmead.com www.rittmanmead.com @rittmanmead 29 •Users can upload their own datasets into BDD, from MS Excel or CSV file •Uploaded data is first loaded into Hive table, then sampled/ingested as normal Combine with User-Uploaded Reference Data 1 2 3
30. info@rittmanmead.com www.rittmanmead.com @rittmanmead 30 •Used to create a dataset based on the intersection (typically) of two datasets •Not required to just view two or more datasets together - think of this as a JOIN and SELECT Join Datasets On Common Attributes
31. info@rittmanmead.com www.rittmanmead.com @rittmanmead 31 •BDD Studio dashboards support faceted search across all attributes, refinements •Auto-filter dashboard contents on selected attribute values - for data discovery •Fast analysis and summarisation through Endeca Server technology Search and Analyse Schema-on-Read Data using BDD Studio Further refinement on
 “OBIEE” in post keywords 3 Results now filtered
 on two refinements 4
32. info@rittmanmead.com www.rittmanmead.com @rittmanmead 32 •Can’t we now just use Oracle Big Data Discovery to do our data discovery & dashboarding? •Basic BI-type reporting against datasets, joined together, filtered, transformed etc •But … lack of structure, hierarchies, free form joins etc will cause issues for non-tech users •They need structure, hierarchies, measures •They need … Dan Can’t We Keep Using BDD for End-User Reporting?
33. info@rittmanmead.com www.rittmanmead.com @rittmanmead 33 •Transformations within BDD Studio can then be used to create curated fact + dim Hive tables •Can be used then as a more suitable dataset for use with OBIEE RPD + Visual Analyzer •Or exported then in to Exadata or Exalytics to combine with main DW datasets Export Onboard Datasets Back to Hive, for OBIEE + VA
34. info@rittmanmead.com www.rittmanmead.com @rittmanmead 34 •Now is the time to invest time into creating the RPD •We understand the data, have added enrichments, discovered the hierarchies •The next set of users will benefit from time taken to curate the data into an RPD Create the RPD Against Curated, Enriched Hive Tables
35. info@rittmanmead.com www.rittmanmead.com @rittmanmead 35 •Users in Visual Analyzer then have
 a more structured dataset to use •Data organised into dimensions,
 facts, hierarchies and attributes •Can still access Hadoop directly
 through Impala or Big Data SQL •Big Data Discovery though was
 key to initial understanding of data Further Analyse in Visual Analyzer for Managed Dataset
36. info@rittmanmead.com www.rittmanmead.com @rittmanmead 36 •If customer is still on OBIEE11g, another
 option is to use BICS instead •Export Hive data to file using ODI or Hue •Upload to BICS using Data Sync •Model exported Hive tables using TCM •Analyse in the Cloud Or … Use Data Sync to Upload into BICS
37. info@rittmanmead.com www.rittmanmead.com @rittmanmead 37 •Both tools play a key role in analysing Hadoop data •Big Data Discovery adds significant value for data on boarding ‣Initial catalog view of data ‣Data Wrangling and Enrichment ‣Discover hierarchies, measures and attributes •But BDD isn’t a sensible BI tool for non-analyst users ‣OBIEE’s RPD provides much needed structure ‣Visual Analyzer enables “managed data discovery” ‣But only make this investment when it’s needed, and
 once the data is understood and ready for curation So Who Will it Be? VA or Big Data Discovery? Mr. Visual Analyzer Mr. Big Data Discovery
38. info@rittmanmead.com www.rittmanmead.com @rittmanmead Oracle Big Data Spatial & Graph
 Social Media Analysis - Case Study Mark Rittman, CTO, Rittman Mead BIWA Summit 2016, San Francisco, January 2016
