Enkitec E4 2013 - Exalytics Tips and Techniques

Enkitec E4 2013 - Exalytics Tips and Techniques

As presented at Enkitec E4 2013

Mark RIttman

July 11, 2013
Tweet

More Decks by Mark RIttman

Other Decks in Technology

Transcript

  1. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Oracle Exalytics -  Tips and Experiences from the Field Mark Rittman & Stewart Bryson, Rittman Mead Enkitec Extreme Exadata Expo, Texas, August 2013 T : +44 (0) 8446 697 995 E : [email protected] W: www.rittmanmead.com
  2. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Mark Rittman •Mark Rittman, Co-Founder of Rittman Mead •Oracle ACE Director, specialising in Oracle BI&DW •14 Years Experience with Oracle Technology •Regular columnist for Oracle Magazine •Author of two Oracle Press Oracle BI books •Oracle Business Intelligence Developers Guide •Oracle Exalytics Revealed •Writer for Rittman Mead Blog :
 http://www.rittmanmead.com/blog •Email : [email protected] •Twitter : @markrittman
  3. T : +1 (888) 631-1410 E : [email protected] W: www.rittmanmead.com

    Stewart Bryson •Twitter : @StewartBryson •Oracle ACE in BI/DW •Oracle BI/DW Architect and Delivery Specialist •Community Speaker and Enthusiast •Writer for Rittman Mead Blog:
 http://www.rittmanmead.com/blog •US Conference Chair of the Rittman Mead BI Forum •Developer of Transcend Framework •Email : [email protected] •Real Time BI with Kevin & Stewart ‣ iTunes: http://bit.ly/realtimebi ‣ YouTube: http://www.youtube.com/user/realtimebi
  4. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com About Rittman Mead •Oracle BI and DW platinum partner •World leading specialist partner for technical excellence, solutions delivery and innovation in Oracle BI •Approximately 120 consultants worldwide •All expert in Oracle BI and DW •Offices in US (Atlanta), Europe, Australia and India •Skills in broad range of supporting Oracle tools: ‣ OBIEE ‣ OBIA ‣ ODIEE ‣ Essbase, Oracle OLAP ‣ GoldenGate ‣ Exadata ‣ Endeca http://www.rittmanmead.com/blog
  5. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Main Exalytics Proposition •In-Memory analytics - lightening-fast response, free-form analysis and aggregation •Rich, immersive interactive dashboards
 powered-by high-spec hardware •Extra OBIEE + other features
 only available on this platform •Enables fast development
 controlled by the business •Faster planning and budgeting
  6. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Oracle Exalytics In-Memory Machine •Engineered system, complements Oracle Exadata Database Machine (though can work standalone) •Combination of high-end hardware (Sun x86_64 architecture, 3RU rack-mountable, 1-2TB RAM)
 and optimized versions of Oracle’s BI, In-Memory Database and OLAP software •Delivers “in-memory analytics” focusing on analysis, aggregation and UI ‣ Rich, interactive dashboards with split-second response times ‣ 1-2TB of RAM, to run your analysis in-memory ‣ Infiniband connection to Exadata and Oracle Big Data Appliance ‣ 40 CPU cores to support high-levels of user concurrency ‣ Lower TCO through known configuration, combined patch sets ‣ Contains software features only licensable through
 Exalytics package
  7. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Exalytics as the Exa-Machine for OBIEE •Runs the BI layer on a high-performance, multi-core, 1-2TB server •In-memory cache used to accelerate the BI part of the stack •If Exadata addresses 80% of the query performance, Exalytics addresses
 the remaining 20% ‣ Consistent response times for queries ‣ In-memory caching of aggregates ‣ 40 cores for high concurrency ‣ Re-engineered BI and OLAP software
 that assumes 40 cores and 1TB RAM ERP/Apps DW Oracle BI In-Memory DB/Cache
  8. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Using Tom Kyte’s Car Analogy... Your database Exadata Exalytics
  9. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Exalytics history - software Oct 11 Feb 12 Aug Sep Jan 13 Apr Jul Exaly&cs announced at OOW2011 v1.0.0.0 OBI 11.1.1.5 Essbase 11.1.2.2.0 TimesTen 11.2.2.2.1 PS1 (v1.0.0.1) OBI 11.1.1.6.2 BP1 Essbase 11.1.2.2.100 TimesTen 11.2.2.3.0 Cer&fied: Golden Gate 11.1.1 ODI 11.1.1.5+ Endeca 2.3 OBIA 7.9.6.4 Exaly&cs available to license through Trusted Par22ons on OVM PS2 (v1.0.0.2) OBI 11.1.1.6.5+ Essbase 11.1.2.2.101+ TimesTen 11.2.2.4.1+ Cer&fied: Endeca 3.0 PS3 (v1.0.0.3) Essbase 11.1.2.2.200 OBIEE 11.1.1.7.0+ TimesTen 11.2.2.5 Cer&fied: Essbase 11.1.2.3 OBIA 11.1.1.7.1 Exaly&cs X2-4/ V1 becomes GA Hardware upgrade, new OBI features, support for OBIA 11g Non-core soFware such as ODI and Golden Gate now cer&fied SoFware support updates Flash PCIe added
  10. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Exalytics history - hardware Oct 11 Feb 12 Aug Sep Jan 13 Apr Jul Exaly&cs announced at OOW2011 X2-4 • 40 cores (4x E7-4800) • 1TB RAM • 3.6TB raw disk (6x SAS-2 600GB) • Two 40Gb/s InfiniBand ports • Four 10/100/1000Base-T on- board Ethernet ports Exaly&cs available to license through Trusted Par22ons on OVM X2-4 Flash Upgrade Kit Adds 2.4TB of Flash storage to exis&ng X2-4 machines, with 6x Sun F40 400GB eMLC Flash PCIe cards X3-4 • 40 cores (4x E7-4800) • 2TB RAM • 2.4TB eMLC Flash PCIe • 5.4TB raw disk (6x SAS-2 900GB) • Two 40Gb/s InfiniBand ports • Four 10/100/1000Base-T on- board Ethernet ports X2-4 Memory and Flash Upgrade Kit Adds 2.4TB Flash PCIe and addi&onal 1TB RAM to exis&ng X2-4 machines Exaly&cs X2-4/ V1 becomes GA Hardware upgrade, new OBI features, support for OBIA 11g Non-core soFware such as ODI and Golden Gate now cer&fied SoFware support updates Flash PCIe added
  11. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Rittman Mead and Oracle Exalytics •Rittman Mead were the first UK Oracle Partner to purchase an Exalytics server, back in Q1 2012 •Intention was to use it for customer PoCs, internal and external training, R&D •Had additional support from the Oracle product development team as an “early adopter” •Run several customer PoCs since then, independently & with Oracle •Developed Exalytics training material •Written “Oracle Exalytics Revealed” ebook for Oracle Press •Most importantly - springboard for several customer projects ‣ UK Retailer ‣ US Pharmaceuticals Company ‣ UK/Worldwide Broker + Financial Information Company ‣ US / US / Asia Financial Asset Management ‣ UK National Health Service Hospital ‣ etc
  12. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Findings from the Field •So what have we found, after over a year of working with, and implementing, Exalytics? •How well does it work as a query accelerator (“analysis at the speed of thought”)? •How else has it been used (in-memory data warehouse, for example)? •What role has the Essbase software played (and, Endeca?) •How have customers been deploying it?
  13. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Exalytics as the Query Performance Enhancer •In conjunction with a well-tuned source data warehouse, Exalytics adds an in-memory analysis later •Based around Oracle TimesTen for Exalytics, Oracle’s In-Memory Database •Aggregates are recommended based on query patterns, and automatically created in TimesTen •Summary Advisor makes recommendations, which adapt as queries change •Meant to be “plug-and-play” - no need for
 expensive data warehouse tuning •So how does it work in-practice? TimesTen BI Server Exalytics Aggregates Data Warehouse Detail-level
 Data
  14. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Summary Advisor for Aggregate Recommendation & Creation •Utility within Oracle BI Administrator tool that recommends aggregates •Bases recommendations on usage tracking and summary statistics data •Captured based on past activity •Runs an iterative algorithm that searches,
 each iteration, for the best aggregate
  15. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Recommendations Based on Enhanced Usage Tracking Data •Historically, usage tracking has been tracked using S_NQ_ACCT ‣ Holds basic usage tracking statistics + logical SQL query •Now supplemented by S_NQ_DB_ACCT ‣ Extra usage tracking information, includes physical SQL •Exalytics Summary Advisor uses S_NQ_SUMMARY_ADVISOR ‣ Contains summary statistics, execution time etc ‣ Gathered at same time as usage tracking when
 Exalytics is enabed ‣ Contents can be derived from usage tracking if needed
  16. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Oracle TimesTen for Exalytics •New version of TimesTen specifically for Exalytics (and only available with Exalytics) •Support for analytic functions ‣ Perform all the processing at source ‣ Combine with being in-memory = should be very fast •Column compression ‣ Whitepaper cites 5x - possible for dimension tables, usually much lower for fact tables (20% compression) ‣ Given the hardware capacity, we could seriously contemplate loading the whole Data Warehouse into memory - see techniques and limitations later on ‣ Opens up lots of interesting design potential •We can load aggregates into TimesTen, leave base data at source, and use OBIEE’s Vertical Federation capability to seamlessly report across both ‣ All hidden from the end-user, all they will know is that their reports run fast!
  17. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com TimesTen and OBIEE Architecture •Oracle BI Server communicates with TimesTen through TimesTen Client •Summary Advisor, and nqcmd use Oracle BI Server to access TimesTen •Typical single TimesTen database per Exalyics machine ‣ Max TimesTen database size around 300MB - Due to need to set aside equal
 Temp size for the Perm size selected •Clustered Exalytics boxes can be daisy-chained
 together using InfinBand connections ‣ For HA scenarios, does not increase available RAM ‣ Summary advisor scripts write to both TimesTen
 databases, replicating aggregates ‣ TimesTen databases can be “wired together”
 for failover/HA purposes TimesTen
 Memory-Resident
 Database Checkpoint
 Files Log
 Files ODBC Oracle BI
 Server nqcmd Summary
 Advisor
  18. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Example 1: Using Exalytics to Pre-Aggregate and Cache BI Apps Data •Can we use the Summary Advisor to automatically cache commonly-used aggregates in-memory? ‣ Similar to regular OBIEE caching, relies on query repeatability + use of aggregation •Could we copy all, or part, of the BI Apps data warehouse directly into TimesTen? •How would we update the RPD to point to the in-memory tables? •How fast would TimesTen be to load, and to query, vs. Oracle/SQL Server/DB2 etc? •Here’s our thoughts and R&D to date....
  19. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Using the Summary Advisor on BI Apps 7.9.6.4 Step 1 : Start Advisor •Server has to be an Exalytics server, in this example is patched-up to 11.1.1.6.9 •Workstation has the 11.1.1.6.9 BI Administration tool installed •Select Tools > Utilities, then Oracle BI Summary Advisor from utility list 1 2
  20. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Using the Summary Advisor on BI Apps 7.9.6.4 Step 2 : Scope Source Queries •By default, all queries registered in the usage tracking and summary statistics tables are in-scope •Refine the recommendations by limiting timeframe, and setting minimum accumulated time threshold •Still an opportunity later on to pick and choose from recommended aggregates •Once selected, then select the TimesTen connection pool and database as the aggregate table target 3 4
  21. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Using the Summary Advisor on BI Apps 7.9.6.4 Step 3 : Create Aggregates •Summary Advisor then recommends a set of “candidate” aggregates, which you can choose to implement •Select all, none or some of the recommended aggregates •Then run the resulting logical SQL script using the nqcmd utility •Note - may need to clean-up BI Apps DW data to remove duplicates etc before script completes OK
  22. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Using the Summary Advisor on BI Apps 7.9.6.4 Step 4 : Review RPD and Data •Aggregate Persistence process called by the “create aggregates” process also maps tables in RPD •Physical layer contains entries for the TimesTen tables •Business Model and Mapping later contains vertically-federated LTSs for the new TT tables
  23. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Summary Advisor for BI Apps : Pros and Cons •Pros ‣ Automatically analyzes query patterns and recommends aggregates to accelerate them ‣ Handles the registering of the TimesTen tables in the RPD, including mapping back into business model ‣ Supports any data source that the BI Server supports •Cons ‣ Queries have to have run before they’ll be considered for loading
 into TimesTen for Exalytics ‣ Relies on subsequent queries being able to use those aggregates ‣ Could get unwieldy if many aggregates are registered in the RPD ‣ Summary Advisor process does not automatically clear down
 tables that don’t feature in future recommendations ‣ Refresh process for aggregates is inefficient
  24. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Refreshing Summary Advisor Aggregates Within the TimesTen Data Mart •Aggregates are built in TimesTen to support sub-second response times •Summary Advisor tool suggests aggregate dimensionality and grain, generates script •BI Server’s Aggregate Persistence executes script: 1. Create TimesTen aggregate table 2. Populate TimesTen aggregate 3. Update RPD online with new aggregate metadata •Handles supporting dimensions too Base data Aggregates TimesTen OBIEE Aggregate Persistence RPD Aggregate tables created RPD updated with new aggregate mappings Aggregate tables loaded from base data
  25. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Out-of-the-Box Summary Advisor Limitations •To refresh an aggregate, Summary Advisor deletes and rebuilds from scratch •The RPD is edited directly on the BI Server each time an aggregate is created or rebuilt •Build failures can be difficult to debug, if it fails can leave the RPD in an inconsistent state with TimesTen After a failed build, the aggregates are still in the RPD, but no longer exist in TimesTen nqquery.log suggests possible errors but no clear root cause This is that the error the user sees
  26. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Alternatives to using Aggregate Persistence •However aggregates are refreshed, they must be included in the RPD ‣ Can be done manually ‣ Aggregate Persistence is useful for this •Complete refresh of aggregate data ‣ Extract the SQL that OBIEE generates in Aggregate Persistence, run this through ODI ‣ Write bespoke aggregate refresh code in ODI •Incremental refresh using GoldenGate and ODI ‣ Instead of rebuilding aggregates in their entirety each time, only update the part of the aggregate that has changed on the base data
  27. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Custom BI Server ETL Option : Incremental BI Server Refresh •Uses BI Server to do the refresh, but invokes just part of it - the data refresh part •Avoids unnecessary aggregate table drop/rebuild, and online RPD edit •Uses BI Server logical ETL SQL features
 to just refresh the TT aggregate table, using
 only the latest set of detail-level data ‣ Avoids use of additional ETL tools ‣ No additional license cost ‣ Works against any BI Server source
  28. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Custom BI Server ETL Option : Incremental BI Server Refresh •Uses a number of “undocumented” but support BI Server ETL features ‣ POPULATE command for loading data into an RPD table ‣ WHERE clause for limiting the refresh to just the incremental load ‣ INACTIVE_SCHEMAS to stop BI Server refreshing using existing RPD agg table •See http://www.rittmanmead.com/2013/04/incremental-refresh-of-exalytics- aggregates-using-native-bi-server-capabilities/ for full details including scripts etc SET VARIABLE DISABLE_CACHE_HIT=1, DISABLE_CACHE_SEED=1, DISABLE_SUMMARY_STATS_LOGGING=1, INACTIVE_SCHEMAS='"TimesTen Aggregates".."EXALYTICS"'; populate "ag_sales_month" mode ( append table connection pool "TimesTen aggregates"."TT_CP") as select_business_model "Sales"."Fact Sales"."Sale Amount" as "Sale_Amoun000000AD",
 "Sales"."Dim Times"."Month YYYYMM" as "Month_YYYY000000D0" from "Sales" where "Dim Times"."Month YYYYMM" = VALUEOF("THIS_MONTH");
  29. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com But .. What About if I want to Put My Entire Data Warehouse In-Memory •Actually a common request - many reporting datasets are under 500GB / 1TB in size •Why not put the whole dataset in-memory, rather than just expensively maintain aggregates? •Maybe put “hot data” - current month, popular products - into TT as a form of in-memory partitioning? •Use Exalytics as an analytics toolbox - independence from IT / DBAs •In-memory access to detail-level, as well as summary-level, data
  30. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Options for Analyzing Large Datasets “In-Memory” •Summary Advisor only puts aggregates, not the whole dataset, in-memory ‣ May be the only practical solution for very large datasets, and comes with automation for build/ maintainance •TimesTen could potentially hold the full dataset, but has practical limitations on scale ‣ TimesTen tables can be large, even with compression ‣ Lacks PQ, partitioning, so could possibly struggle when analyzing large amounts of table data •Essbase Aggregate Storage Option (ASO) is also a possibility, and also ships with Exalytics ‣ Stores data at detail level, uses indexing and fast aggregation to analyze large, dimensional datasets vs.
  31. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com What is Essbase Aggregate Storage Option? •Essbase is Oracle’s Exalytics OLAP server, and has two storage types for databases: BSO and ASO •BSO (“Block Storage Option”) is traditional MOLAP, and stores data in multidimensional blocks and indexes ‣ Good for fast access and write-back at all levels, needs pre-calculating, but limited in scale •ASO (“Aggregate Storage Option”) is more like relational storage, and can scale hugely ‣ 100x scaleability over BSO, 10x faster load and calc, 20x smaller databases ‣ But can only write-back to level 0, more limited calculations, aimed at DW-style sales analysis applications ‣ Uses bitmaps based on cube metadata to quickly index the whole cube, plus optional stored pre-aggs ‣ Different approach to TimesTen, more “OLAP” than relational, but is it an option?
  32. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Example Two: Storing Detail-Level DW Data in Exalytics •Examples are to establish which of TimesTen, or Essbase ASO, is best-suited to storing whole DW datasets •Two sample datasets were chosen: ‣ Sample Sales (SH) from the Oracle database - 900k rows of fact data + 5 dimensions ‣ Airline Delays from the Exalytics demo program - 130m+ rows of flight leg information + 4 dims •Looking to assess three factors: ‣ Speed to load ‣ Speed to access detail data ‣ Speed to access summary data SH.SALES 900k+ rows PERFORMANCE 130m+ rows
  33. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Initial Data Load - TimesTen for Exalytics •TimesTen tries to mirror Oracle RBDMS in terms of SQL, PL/SQL etc •Has its own optimized datatypes, plus in-memory optimized indexes ‣ Ideally you would map Oracle datatypes to the most
 optimal TT ones, not just VARCHAR, NUMBER etc •Column-based compression can also be used ‣ Creates query performance gain proportionate to
 the space saving, i.e. 20% compression, 20% faster query ‣ Benefits dimension tables most, but some gain for facts •ttimportfromOracle utility automatically creates optimal
 TT DDL, and replicates the Oracle data into TT ‣ Need to be on TimesTen 11.1.2.2.5 to be able to
 load into compressed TT tables ‣ From TT 11.1.2.2.5, can make use of parallel load into TT ‣ All tables loaded, took around 9GB space + 4GB temp c:\TEMP\tt\tt_sh>C:\TimesTen\tt1122_64_3\support \ttImportFromOracle.exe -oraConn sh/password@orcl -compression 1
 -tables sales promotions products customers channels times Beginning processing Resolving any tablename wildcards Eliminating any duplicate tables Getting metadata from source Generating database user list Assigning TimesTen datatypes Analyzing source tables (this may take some time) Analyzing table 'SH.SALES' ... Analyzing table 'SH.PROMOTIONS' ... Analyzing table 'SH.PRODUCTS' ... Analyzing table 'SH.CUSTOMERS' ... Analyzing table 'SH.CHANNELS' ... Analyzing table 'SH.TIMES' ... Estimating compression ratios Generating output files Finished processing
  34. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Initial Data Load - Essbase ASO •Had to model the data in Essbase Studio, the cube design IDE for Essbase •Prefix and transform dimension member names to
 ensure uniqueness •Can source data either from OBIEE repository,
 or direct from source •Essbase database loaded in <1 min, around 250MB in size •Modeling was only for a single star - question how practical this
 modeling in Essbase would be for a large, conformed DW ‣ Knowledge of Essbase required ‣ Dealing with data issues ‣ Not a trivial exercise
  35. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Initial Query Response Times for Large, Detail-Level Datasets •Created dashboards against the Oracle DB, TimesTen and Essbase ASO databases •Enabled for Exalytics, removed Submit and Reset buttons from prompts •Results were surprising ‣ All were fast (<1 sec/query) for Sales History ‣ Oracle RDBMS was slow for Airline Delays - 60 secs+ for individual analyses ‣ Essbase ASO was fast for Airline Delays - 5-10 secs for individual analyses - But caused a few BI Server crashes ‣ TimesTen was also slow for Airline Delays - 30 secs+ for a query - Lots of timeouts •Was this correct?
  36. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Analyzing the Slow TimesTen Query Performance with Large Datasets •Queries against Oracle’s SH.SALES table can often benefit from partition elimination •Oracle database also has potential for parallel query - TT is limited to a single CPU/query •But is the TT execution plan optimal? •No - TmpHashScan operation indicates TT’s optimizer
 has created an on-the-fly temporary index for the query ‣ Impacts on query performance ‣ Ideally, these indexes should already be there •Solution - post-load index optimization
 using the TT Index Advisor utility TmpHashScan
 indicates creation of temporary index
  37. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Optimizing the TimesTen for Exalytics Database •TT Index Advisor uses a three-stage process ‣ ttindexAdviceCaptureStart(1,0) - start capturing all queries across the database ‣ ttindexAdviceCaptureEnd(1) - stop capture of queries ‣ ttindexAdviceCaptureOutput(1) - output index DDL for queries across database •Then implement the DDL, and rinse-and-repeat •Impact - massive - query time fell to <1 sec ‣ But would need to run advisor regularly
  38. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Optimizing the Essbase ASO Database •But - there’s a similar process also available for Essbase ASO •Focuses on aggregates, rather than indexing (indexing already covered by ASO database bitmaps) •Accessed from the Essbase Administration Services Console •Fast to aggregate - can recommend, or run manually •Also brought query response time
 down to <1 sec
  39. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Refreshing the TimesTen and Essbase ASO Databases •As well as the initial load, you will need to refresh (or rebuild) the in-memory structures with new data •TimesTen tables can be refreshed using various options ‣ Create custom ODI or GoldenGate routines - same as any other target, but “fragile” - Beware table locking - TT compressed tables cannot be queried while loading - OBI also takes out full table locks when running queries - ttloadfromOracle can be used to automatically full-load TT tables, or edit script with WHERE clause - Either requires BI down-time, or use double-buffering solution •ASO has features for incremental, trickle-refresh for databases ‣ Based around concept of “slices” - sub-cubes that contain the new/updated data ‣ Database is then dynamically aggregated to include the slices ‣ Slices can be incorporated back into the main database from time-to-time ‣ Designed to support incremental load
  40. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com So Which Technology Best Suits Loading the Whole Dataset into RAM? •Remember - primary use-case for Exalytics / OBIEE / Timesten is caching of regularly-used aggregates •Permits analysis across massive source datasets, and concentrates in-memory feature where most needed •But - space permitting - TimesTen could handle the whole dataset ‣ Remember to use compression ‣ Use the Index Advisor after each load ‣ Also factor in the refreshing of TT tables - is this a 24x7 system •Essbase ASO also an interesting option ‣ Much smaller datasets - potential to load more source data ‣ Optimized for this task ‣ But requires Essbase modeling skills ‣ Features exist for Essbase ASO real-time refresh,
 but probably will need an Essbase admin on the team vs.
  41. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Deployments of Exalytics “In The Field” •Surprisingly few of our implementations have been Exadata + Exalytics ‣ Maybe Exadata provides enough of a performance boost? ‣ Maybe those customers are self-supporting? •Most have bought Exalytics as the best way to host their BI + Analytics mid-tier ‣ Typically with a non-Exadata (but Oracle) database underneath ‣ Sometimes as a way of avoiding DW query optimization •For many, these are their first Sun (and Exa-) servers •Many have bought single Exalytics servers ‣ (but what about dev, test etc?) •Some have bought 3+ (including one of our customers)
  42. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Deploying Multiple Environments •Exalytics main value proposition is around performance ‣ In-memory aggregates speeding up query performance •However many customers wish to use Exalytics for consolidation ‣ Run multiple environments (test, dev, prod) on a single server ‣ Consolidate multiple applications on a single server •Desire is usually down to cost (multiple physical servers, per-processor licensing) DEV DEV TEST PROD vs. MWHOME1 DEV MWHOME2 DEV MWHOME3 MWHOME1 MWHOME1 MWHOME1 Single Exalytics Server Exalytics Svr 1 Exalytics Svr 2 Exalytics Svr 3
  43. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Oracle “Best Practice” for Consolidation : Oracle Virtual Machine •Exalytics is now certified for use with Oracle Virtual Machine,
 Oracle’s hard-partitioning virtualization platform •OVM is installed first, on Exalytics “bare metal”, with OVM Repository
 on external DB server (as with BIPLATFORM, MDS) •Exalytics VM templates then used to create required environments
 (dev, test etc) •Also allows for licensing in smaller per-processor license blocks
 (1 processor, 2 cores) •OVM provides for resource caging, isolating environments ‣ But requires more infrastructure ‣ And has limitations around use of InfiniBand •So many customers (and us) just do multiple FMW Home installs
 on the same server, manually managing conflicts etc ‣ Supported by Oracle, now detailed in tech docs DEV MWHOME1 Single Exalytics Server OVM Hypervisor (Oracle VM Server) OVM Guest 1 DEV MWHOME1 OVM Guest 2 DEV MWHOME1 OVM Guest 3 Oracle VM
 Manager Oracle VM
 Repository
  44. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com High Availability using Clustered Exalytics Servers •Multiple Exalytics servers can be clustered for HA and performance (load balancing) ‣ Requires hardware load balancer above clustered servers •Linked together via InfiniBand (one for clustering, one for connection to Exadata) •Note: does not double available RAM
 - aggs are replicated in each TT database ‣ Note that Summary Advisor / nqcmd
 does not replicate agg tables -
 manual replication required •HA is between TT instances, and OBIEE
 managed server + system components
  45. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Summary •1 year on, we are starting to see Exalytics deployments “in the field” •Usage of the platform is much wider than just “aggregates into TimesTen” ‣ Customers want to get “full value” from their high-end hardware, esp. 1TB RAM •Recent platform refresh to 2TB RAM, SSD, plus several software + certification updates •OBIEE + Summary Advisor + TT works as a way of caching commonly-used aggs in memory ‣ Recent updates make support for BI Apps etc possible ‣ But give consideration to summary update process - default solution can be inefficient •Also possible to store whole datasets / datamarts / DW sub-sets in-memory ‣ Utilities exist for TT to automate the process - but don’t forget Index Advisor post-load ‣ Essbase ASO also an interesting solution for large, sparse datasets •Many solutions exist for HA, multiple environments etc •Speak to Rittman Mead if you’re considering Exalytics -
 experience from several real-world projects in UK, Europe, USA
  46. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Thank You for Attending! • Thank you for attending this presentation, and more information can be found at http://www.rittmanmead.com • Contact us at [email protected] or [email protected] • Look out for our book, “Oracle Business Intelligence Developers Guide” out now! • Follow-us on Twitter (@rittmanmead) or Facebook (facebook.com/rittmanmead)
  47. T : +44 (0) 8446 697 995 E : [email protected]

    W: www.rittmanmead.com Oracle Exalytics -  Tips and Experiences from the Field Mark Rittman & Stewart Bryson, Rittman Mead Enkitec Extreme Exadata Expo, Texas, August 2013 T : +44 (0) 8446 697 995 E : [email protected] W: www.rittmanmead.com
