CloudNative時代におけるKubernetes
〜情報処理学会 コンピュータシステムシンポジウム 2018 (ComSys 2018)〜

招待講演1：「Cloud Native時代におけるKubernetes」　株式会社サイバーエージェント　青山 真也様
今日コンテナ技術は広く普及し、大規模な環境でのコンテナオーケストレーションエンジンとしてはKubernetesがデファクトスタンダードとなっています。本講演ではKubernetesが必要な理由・機能及びコンセプト・解決できる問題について、また分散システムとしてのKubernetesの仕組みについて紹介します。あわせて、コンテナを利用した開発をするにあたり切り離すことのできない「Cloud Native」や「マイクロサービス」の考え方、最近のKubernetesを取り巻く技術動向についても紹介します。
主なトピック：
Kubernetesの歴史的背景と必要な理由
Cloud Nativeとマイクロサービスとは
Kubernetesの機能やコンセプト
今後注目されているKubernetes周辺分野や技術
御略歴
株式会社サイバーエージェント アドテク本部 Strategic Infrastructure Agency 2016年入社。OpenStack?を使ったプライベートクラウドやGKE互換なコンテナプラットフォームをゼロから構築し、国内カンファレンスでのKeynoteに登壇。その後、世界で2番目にCertified Kubernetes Application Developer、138番目にCertified Kubernetes Administratorの認定資格を取得。現在はKubernetesやOpenStack?などOSSへのコントリビュート活動をはじめ、CNCF公式のCloud Native Meetup TokyoのOrganizerやJapan Container Daysの運営などコミュニティ活動にも従事。
2018年9月発刊「Kubernetes完全ガイド」（インプレス）の著者。

Transcript

1. Masaya Aoyama
   CyberAgent adtech studio
   CloudNative࣌୅ʹ͓͚ΔKubernetes
   ৘ใॲཧֶձ ίϯϐϡʔλγεςϜγϯϙδ΢Ϝ 2018
   MasayaAoyama @amsy810


   View Slide

2. Japan Container Days v18.04 Keynote
   Cloud Native Meetup Tokyo Organizer (+ KubeCon + JKD)

   for Kubernetes
   CKA #138CKAD #2
   OpenStack / Kubernetes Contributor
   Masaya Aoyama (@amsy810)
   Infrastructure Engineer


   View Slide

3. Hobby == Kubernetes


   View Slide

4. Supervisor == Hirotsu Toshio


   View Slide

5. Agenda
   page
   05
   • Cloud Native and Kubernetes
   • Container and Docker
   • Microservice and Service Mesh
   • Kubernetes
   • Kubernetes & Workloads
   • Kubernetes & Networking
   • Kubernetes is Distributed system
   • Extends Kubernetes
   • Other topics for Kubernetes


   View Slide

6. Agenda
   page
   06
   • Cloud Native and Kubernetes
   • Container and Docker
   • Microservice and Service Mesh
   • Kubernetes
   • Kubernetes & Workloads
   • Kubernetes & Networking
   • Kubernetes is Distributed system
   • Extends Kubernetes
   • Other topics for Kubernetes


   View Slide

7. Cloud Native and Kubernetes
   What is Kubernetes? What is Cloud Naitve?


   View Slide

8. CNCF and
   The Linux Foundation
   • KubernetesThe Linux Foundation

   CNCF
   •





   View Slide

9. page
   09
   CNCF

   CNCF Community Presentation, CNCF, 2018
   (https://github.com/cncf/presentations)


   View Slide

10. Graduated projects
    Graduated and Incubating Projects, CNCF, 2018-11-28 (https://www.cncf.io/projects/)


    View Slide

11. Incubating projects
    Graduated and Incubating Projects, CNCF, 2018-11-28 (https://www.cncf.io/projects/)


    View Slide

12. Sandbox projects
    Sandbox Projects, CNCF, 2018-11-28 (https://www.cncf.io/sandbox-projects/)


    View Slide

13. View Slide

14. Cloud Native
    page
    014
    Cloud native technologies empower organizations to build and run scalable
    applications in modern, dynamic environments such as public, private, and hybrid
    clouds. Containers, service meshes, microservices, immutable infrastructure, and
    declarative APIs exemplify this approach.
    These techniques enable loosely coupled systems that are resilient, manageable,
    and observable. Combined with robust automation, they allow engineers to make
    high-impact changes frequently and predictably with minimal toil.
    The Cloud Native Computing Foundation seeks to drive adoption of this paradigm by
    fostering and sustaining an ecosystem of open source, vendor-neutral projects. We
    democratize state-of-the-art patterns to make these innovations accessible for
    everyone.
    CNCF Cloud Native Defenition v1.0, CNCF, 2018-11-28
    (https://github.com/cncf/toc/blob/master/DEFINITION.md)


    View Slide

15. Cloud Native &
    page
    015
    Cloud native technologies empower organizations to build and run scalable
    applications in modern, dynamic environments such as public, private, and hybrid
    clouds. Containers, service meshes, microservices, immutable infrastructure, and
    declarative APIs exemplify this approach.
    !#Scalable
    "
    $%
    CNCF Cloud Native Defenition v1.0, CNCF, 2018-11-28
    (https://github.com/cncf/toc/blob/master/DEFINITION.md)
    • Container
    • Immutable Infrastructure
    • Service Mesh
    • Microservice
    • Declarative API



    View Slide

16. Cloud Native5
    page
    016
    These techniques enable loosely coupled systems that are resilient, manageable,
    and observable. Combined with robust automation, they allow engineers to make
    high-impact changes frequently and predictably with minimal toil.
    CNCF Cloud Native Defenition v1.0, CNCF, 2018-11-28
    (https://github.com/cncf/toc/blob/master/DEFINITION.md)
    • +-
    • $
    • ,*
    • 1(

    • )0 4. '#2
    &"3
    ! %/ note. SRE


    View Slide

17. Cloud Native-
    page
    017
    The Cloud Native Computing Foundation seeks to drive adoption of this paradigm by
    fostering and sustaining an ecosystem of open source, vendor-neutral projects. We
    democratize state-of-the-art patterns to make these innovations accessible for
    everyone.
    CNCF Cloud Native Defenition v1.0, CNCF, 2018-11-28
    (https://github.com/cncf/toc/blob/master/DEFINITION.md)
    • ! #'
    • ! !

    • ! ,%*
    ($+
    !
    )"&


    View Slide

18. Cloud Native8
    page
    018
    Cloud native technologies empower organizations to build and run scalable
    applications in modern, dynamic environments such as public, private, and hybrid
    clouds. Containers, service meshes, microservices, immutable infrastructure, and
    declarative APIs exemplify this approach.
    These techniques enable loosely coupled systems that are resilient, manageable,
    and observable. Combined with robust automation, they allow engineers to make
    high-impact changes frequently and predictably with minimal toil.
    The Cloud Native Computing Foundation seeks to drive adoption of this paradigm by
    fostering and sustaining an ecosystem of open source, vendor-neutral projects. We
    democratize state-of-the-art patterns to make these innovations accessible for
    everyone.
    CNCF Cloud Native Defenition v1.0, CNCF, 2018-11-28
    (https://github.com/cncf/toc/blob/master/DEFINITION.md)
    • .0
    • &
    • /-
    • 4*

    • +3 71 )%5
    ($6
    "!'2
    Open Scalable#,


    View Slide

19. Docker Swarm mode
    Container Orchestration Engine


    View Slide

20. Container Orchestration
    Engine (4/0
    • 3*Docker2/
    • #
    $ #
    •
    $ # / $
    $ #
    • "$ # $
    • #-.15
    • 6&+!$ #
    • $
    • "$# #
    • $,')%2/


    View Slide

21. Container Orchestration
    Engine CYOP
    • XE Docker*" SO
    • 1 $ ,2.1
    • 2.1 / 2"2.1
    • 02.1)!2"
    • 1 $ KLRZ
    • ^>F /(&2.1
    • 2'!%.
    • 02#%-11
    • !2J?D; SO
    Container Orchestration
    Engine CYOP
    • QT9 +
    • B34
    • SO
    • 8[M

    • :NW67_U IA
    \H@] 54
    =8V


    View Slide

22. Kubernetes
    06 2014
    Borg
    OSS
    Kubernetes timeline
    page
    022
    Google Borg"
    ~2015
    Google !
    $#OrchestratorBorg


    View Slide

23. page
    023
    CNCF v1.0
    07 2015
    Cloud Native Computing Foundation
    11 2014
    GCP GKE
    Google Cloud Platform
    Google Kubernetes Engine
    Kubernetes timeline


    View Slide

24. page
    024
    Amazon EKS
    11 2017
    Amazon Web Service
    Amazon Elastic Container Service for Kubernetes
    02 2017
    Azure AKS
    Microsoft Azure
    Azure Container Service
    Kubernetes timeline


    View Slide

25. future is promising
    32 Certified Kubernetes
    Platform/Distribution
    11 2017
    Kubernetes CNCF

    Platform
    Distribution
    page
    025
    09 2017
    Certified Kubernetes
    Administrator
    Kubernetes !
    Kubernetes timeline


    View Slide

26. page
    026
    KubeCon + CloudNativeCon
    KubeCon + CloudNativeCon Barcelona 2019 Call for Proposals (CFP) Is Open, CNCF, 2018-11-28
    (https://www.cncf.io/blog/2018/11/16/kubecon-barcelona-2019-call-for-proposals-cfp-is-open/)


    View Slide

27. CNCF Community Presentation, CNCF, 2018 (https://github.com/cncf/presentations)


    View Slide

28. page
    028
    Enterprise
    •
    Monzo Bank
    • Kubernetes + Linkerd (Service Mesh)
    Ref: https://monzo.com/blog/2016/09/19/building-a-modern-bank-backend/


    View Slide

29. Agenda
    page
    029
    • Cloud Native and Kubernetes
    • Container and Docker
    • Microservice and Service Mesh
    • Kubernetes
    • Kubernetes & Workloads
    • Kubernetes & Networking
    • Kubernetes is Distributed system
    • Extends Kubernetes
    • Other topics for Kubernetes


    View Slide

30. Container / Docker
    Benefit of Container / Docker
    •

    •
    •


    View Slide

31. Container
    System Container
    • KVMXen

    • init
    Application Container
    •


    •
    page
    04


    View Slide

32. Docker
    • Docker4%Application Container
    .71-+8$!
    • #DevOps/# 2: /3
    6)*5
    • 0, Moby"

    &9 # containerd

    ('
    page
    032


    View Slide

33. page
    033
    Ref: https://docs.docker.com/develop/develop-images/dockerfile_best-practices/
    Ref: https://12factor.net/
    Part of Docker Container Best Practice
    • >(1
    • "2; $0@Immutable InfrastructureA
    • ?:7+ / 397+*"
    !'8
    • #/< !&
    • 48)=-%7+,1 . 6
    • 5
    • etc


    View Slide

34. DockerfileDocker Image
    page
    034
    FROM centos:7
    RUN yum -y install epel-release
    RUN yum -y install nginx
    COPY nginx.conf /etc/nginx/
    ENTRYPOINT ["nginx", "-g", "daemon off;"]
    Build Once, Run Anywhere

    Docker Image


    View Slide

35. Docker Image
    page
    035
    5: ENTRYPOINT ["nginx", "-g", "daemon off;"]
    4: COPY nginx.conf /etc/nginx/
    3: RUN yum -y install nginx
    2: RUN yum -y install epel-release
    1: FROM centos:7


    Docker Image


    View Slide

36. page
    036
    $ docker build . -t sample-image
    Sending build context to Docker daemon 252.9kB
    Step 1/5 : FROM centos:7
    ---> 75835a67d134
    Step 2/5 : RUN yum -y install epel-release
    ---> Running in 9db248fc7b9a
    ...
    Removing intermediate container 9db248fc7b9a
    ---> 2fe5a7f8c007
    Step 3/5 : RUN yum -y install nginx
    ---> Running in 0547bd920b0a
    ...
    Removing intermediate container 0547bd920b0a
    ---> 843b47a96c5e
    Step 4/5 : COPY nginx.conf /etc/nginx/
    ---> fe63b2d4c95d
    Step 5/5 : ENTRYPOINT ["nginx", "-g", "daemon off;"]
    ---> Running in 876ee4d29339
    Removing intermediate container 876ee4d29339
    ---> b5068171c053
    Successfully built b5068171c053
    Successfully tagged sample-image:latest
    75835a67d134
    2fe5a7f8c007
    843b47a96c5e
    fe63b2d4c95d
    b5068171c053
    sample-image


    View Slide

37.
    page
    037
    $ docker history sample-image
    IMAGE CREATED BY SIZE
    b5068171c053 #(nop) ENTRYPOINT ["nginx" "-g" … 0B
    fe63b2d4c95d #(nop) COPY file:6edadf5af999cacd… 3.51kB
    843b47a96c5e yum -y install nginx 214MB
    2fe5a7f8c007 yum -y install epel-release 99.5MB
    75835a67d134 #(nop) CMD ["/bin/bash"] 0B
    #(nop) LABEL org.label-schema.sc… 0B
    #(nop) ADD file:fbe9badfd2790f074… 200MB
    75835a67d134
    2fe5a7f8c007
    843b47a96c5e
    fe63b2d4c95d
    b5068171c053
    sample-image


    View Slide

38. Docker
    page
    038
    •

    • Read Write
    • Read Only


    View Slide

39.

    page
    039
    5: ENTRYPOINT [”/usr/sbin/nginx", "-g",
    "daemon off;"]
    4: COPY nginx.conf /etc/nginx/
    3: RUN yum -y install nginx
    2: RUN yum -y install epel-release
    1: FROM centos:7



    View Slide

40.

    page
    040
    5: ENTRYPOINT [”/usr/sbin/nginx",
    "-g", "daemon off;"]
    5: ENTRYPOINT [”nginx",
    "-g", "daemon off;"]





    View Slide

41. moby/buildkit – =+/ “docker build”
    page
    041
    • DAG;I1-KDGLLB?,37B
    • "') '4?9,37B
    • (&
    $%4?.A
    • JFE!'624?.A
    • root• :53007BH8
    • NTT SIC M@>5#(
    • Nmoby/moby, containerd/containerd#(O
    Ref: https://www.slideshare.net/AkihiroSuda/buildkit


    View Slide

42. DockerfileDocker Image
    page
    042
    FROM sample-image:latest
    RUN yum –y install telnet
    •
    !"
    • )(#' &%!!$


    View Slide

43. Container

    page
    043
    • . #
    740 %/.
    • . #+/&-"8 B35@
    • 7/$/(" DC B35@
    • 12 factor app)!',
    =:A
    • 6 *
    • 912
    • >;


    View Slide

44. Agenda
    page
    044
    • Cloud Native and Kubernetes
    • Container and Docker
    • Microservice and Service Mesh
    • Kubernetes
    • Kubernetes & Workloads
    • Kubernetes & Networking
    • Kubernetes is Distributed system
    • Extends Kubernetes
    • Other topics for Kubernetes


    View Slide

45. Microservice and Service Mesh
    Benefit of Microservice and Service Mesh
    •

    •
    •
    •
    •


    View Slide

46. Microservice Architecture
    page
    046


    ProductPage Reviews
    Details
    Ratings
    HTTP/gRPC
    HTTP/gRPC
    HTTP/gRPC


    View Slide

47. page
    047
    500+ microservices
    The Case of Chaos, Bruce Wong, 2014-12-19, (https://www.slideshare.net/BruceWong3/the-case-for-chaos)
    The History of the Service Mesh, The New Stack, 2018-2-13, (https://thenewstack.io/history-service-mesh/)


    View Slide

48. %' )#!D@X_71T
    gRPC, REST N%' )#!cS
    2 )#!@X_7UJ<f
    "$'9A
    : CT/*"$'1T
    f^=eO4;
    6YBbK-^
    2`aG7%' )#!bK,+?M
    CT\-E[L

    !)&(9A
    G7CT!)&( .IV
    d8,+F0

    G7CTd8Z 53
    R]
    H> )#!PQW
    Benefit of
    Microservice
    Golang
    Java
    Scala
    gRPC
    REST


    View Slide

49. %' )#!D@X_71T
    gRPC, REST N%' )#!cS
    2 )#!@X_7UJ<f
    "$'9A
    : CT/*"$'1T
    f^=eO4;
    6YBbK-^
    2`aG7%' )#!bK,+?M
    CT\-E[L

    !)&(9A
    G7CT!)&( .IV
    d8,+F0

    G7CTd8Z 53
    R]
    H> )#!PQW
    Developer
    Benefit of
    Microservice


    View Slide

50. %' )#!D@X_71T
    gRPC, REST N%' )#!cS
    2 )#!@X_7UJ<f
    "$'9A
    : CT/*"$'1T
    f^=eO4;
    6YBbK-^
    2`aG7%' )#!bK,+?M
    CT\-E[L

    !)&(9A
    G7CT!)&( .IV
    d8,+F0

    G7CTd8Z 53
    R]
    H> )#!PQW
    Benefit of
    Microservice


    View Slide

51. %' )#!D@X_71T
    gRPC, REST N%' )#!cS
    2 )#!@X_7UJ<f
    "$'9A
    : CT/*"$'1T
    f^=eO4;
    6YBbK-^
    2`aG7%' )#!bK,+?M
    CT\-E[L

    !)&(9A
    G7CT!)&( .IV
    d8,+F0

    G7CTd8Z 53
    R]
    H> )#!PQW
    Benefit of
    Microservice


    View Slide

52. %' )#!D@X_71T
    gRPC, REST N%' )#!cS
    2 )#!@X_7UJ<f
    "$'9A
    : CT/*"$'1T
    f^=eO4;
    6YBbK-^
    2`aG7%' )#!bK,+?M
    CT\-E[L

    !)&(9A
    G7CT!)&( .IV
    d8,+F0

    G7CTd8Z 53
    R]
    H> )#!PQW
    Benefit of
    Microservice


    View Slide

53. page
    053
    Can we get Observability?
    The Case of Chaos, Bruce Wong, 2014-12-19, (https://www.slideshare.net/BruceWong3/the-case-for-chaos)
    The History of the Service Mesh, The New Stack, 2018-2-13, (https://thenewstack.io/history-service-mesh/)


    View Slide

54. Service Mesh Architecture (generally)
    page
    054
    • Microservice
    • Microservice with Service Mesh (for Observability)


    View Slide

55. Service Mesh
    page
    055
    • Microservice

    • Traffic Shifting (ex, Canary release)
    • Circuit Break
    • Fault Injection
    • Rate Limit
    • Retry
    • mTLS


    View Slide

56. Canary Release
    page
    056


    View Slide

57. Microservice / Service Mesh

    page
    057
    • Microservice
    2J=:OC*@0$
    • 5R49,-HS#!"Q3T
    • MicroserviceP-K>8D%
    • MicroserviceP• mTLS
    N&FL;.,
    • BG/
    • 7')
    • EA
    • -K>
    • 1? I+,


    View Slide

58. Agenda
    page
    058
    • Cloud Native and Kubernetes
    • Container and Docker
    • Microservice and Service Mesh
    • Kubernetes
    • Kubernetes & Workloads
    • Kubernetes & Networking
    • Kubernetes is Distributed system
    • Extends Kubernetes
    • Other topics for Kubernetes


    View Slide

59. Kubernetes Overview
    Promote Cloud Native
    •

    •
    •
    •
    •


    View Slide

60. Kubernetes


    page
    060
    Design Principles, Kubernetes Community, 2017-11-04
    (https://github.com/kubernetes/community/blob/master/contributors/design-proposals/architecture/principles.md)
    01 Declarative Code & API
    Manifests API
    Infrastructure as Code


    View Slide

61. Declarative Code & API
    page
    061
    Master
    Worker Worker Worker
    Register
    Declarative Manifest
    to API Server
    client


    View Slide

62. Kubernetes
    page
    062
    Design Principles, Kubernetes Community, 2017-11-04
    (https://github.com/kubernetes/community/blob/master/contributors/design-proposals/architecture/principles.md)
    02
    03
    01
    Self Healing

    ) #"

    Automation & Immutable Infrastructure
    Immutable Infrastructure& #
    Declarative Code & API
    Manifests$"
    %'API
    !(
    Infrastructure as Code


    View Slide

63. Agenda
    page
    063
    • Cloud Native and Kubernetes
    • Container and Docker
    • Microservice and Service Mesh
    • Kubernetes
    • Kubernetes & Workloads
    • Kubernetes & Networking
    • Kubernetes is Distributed system
    • Extends Kubernetes
    • Other topics for Kubernetes


    View Slide

64. Kubernetes & Workloads
    Running Container


    View Slide

65. Workloads
    page
    065
    •
    Workloads
    Deployment
    ReplicaSet ReplicaSet
    Pod Pod Pod Pod Pod
    Deployment
    ReplicaSet
    Pod


    View Slide

66. Pod
    page
    066
    • Kubernetes "
    • 1 #! $ Node
    Scheduling%
    • PodIP Address $PortBind%
    Deployment
    ReplicaSet
    Pod


    View Slide

67. Pod Linux Namespace
    page
    067
    • PodLinux Namespace Container
    • PID
    K8s 1.12

    net
    user
    ipc
    pid
    mnt
    uts


    View Slide

68. Container Design Pattern
    page
    068
    Design patterns for container-based distributed systems
    Brendan Burns, David Oppenheimer (Google)
    8th USENIX Workshop on Hot Topics in Cloud Computing (HotCloud '16)
    (https://www.usenix.org/system/files/conference/hotcloud16/hotcloud16_burns.pdf)
    • Pod

    • Sidecar pattern
    • Ambassador pattern
    • Adaptor pattern


    View Slide

69. Sidecar pattern
    page
    069
    •




    View Slide

70. Ambassador Pattern
    page
    070
    • "
    #
    !


    View Slide

71. Adaptor pattern
    page
    071
    • !$
    "
    #


    View Slide

72. ReplicaSet
    page
    072
    • Pod
    Pod
    Deployment
    ReplicaSet
    Pod


    View Slide

73. PodReplicaSet

    • Pod



    View Slide

74. Replica


    View Slide

75. ReplicaSet Self-Healing
    page
    075
    • ReplicaSet PodReplica

    • = NodePod Node


    View Slide

76. SchedulingPod

    page
    076
    •
    1. Node Affinity / Node Anti-affinity
    2. Pod Affinity / Pod Anti-affinity
    3. Taints / Tolerations


    View Slide

77. Node Affinnity / Node Anti-affinity
    page
    077
    • Node



    View Slide

78. Inter-pod Affinity / Inter-pod Anti-Affinity
    page
    078
    • Pod Pod



    View Slide

79. Taints / Tolerations
    page
    079
    • PodNode
    Node PodReject



    View Slide

80. Deployment
    • ReplicaSet

    page
    080
    Deployment
    ReplicaSet
    Pod


    View Slide

81. Deployment Rolling Update
    page
    081


    View Slide

82. Deployment Rollback
    page
    082


    View Slide

83. ReplicaSet
    page
    083


    View Slide

84.
    Workloads"(
    page
    084
    DaemonSet:
    StatefulSet:
    Job:
    CronJob:
    Node
    1Pod'
    !%* Pod'
    #$&Pod'
    )Pod'


    View Slide

85. Cloud Native
    '
    %

    page
    085
    !$()Persistent Volume*
    / &#")Secret / ConfigMap*

    #"


    View Slide

86. Agenda
    page
    086
    • Cloud Native and Kubernetes
    • Container and Docker
    • Microservice and Service Mesh
    • Kubernetes
    • Kubernetes & Workloads
    • Kubernetes & Networking
    • Kubernetes is Distributed system
    • Extends Kubernetes
    • Other topics for Kubernetes


    View Slide

87. Kubernetes & Networking
    Connect to container


    View Slide

88. Kubernetes Network
    page
    088
    • External Network Pod

    • Internal Network
    NodePod CNI


    View Slide

89. Service
    page
    089
    Service



    Load Balancing
    Service Discovery


    View Slide

90. Load Balancingtype: ClusterIP
    page
    090


    View Slide

91. Load Balancingtype: LoadBalancer
    page
    091


    View Slide

92. Load Balancing
    page
    092


    View Slide

93. Balancingkube-proxyproxy-mode
    page
    093
    1. userspace
    • Userspace kube-proxy

    2. iptables
    • iptables

    • kube-proxyiptables
    3. ipvs
    • ipvs

    • kube-proxyipvs


    View Slide

94. page
    094
    Service Discovery
    • Service Discovery
    IP



    View Slide

95. page
    095
    Service Discovery
    • Kubernetes DNS
    Service Object DNS "
    resolv.conf#search$
    !
    SERVICE.NAMESPACE.svc.cluster.local


    View Slide

96. Ingress
    page
    096
    •
    Service L4 LoadBalancing
    • Ingress L7 LoadBalancing
    •


    View Slide

97. Pod Native Network
    page
    097
    • 2LoadBalancing


    View Slide

98. Pod Network Policy
    page
    098
    •
    Pod

    • Network Policy Node iptables


    View Slide

99. Kubernetes Network )96%&
    page
    099
    *14#/!Kubernetes 3 -5
    ".2+(
    • Rolling Update0NodeLB,1'Rolling Update
    7

    • 8$0LB8$


    View Slide

100.
     page
     0100
     •



     View Slide

101. Agenda
     page
     0101
     • Cloud Native and Kubernetes
     • Container and Docker
     • Microservice and Service Mesh
     • Kubernetes
     • Kubernetes & Workloads
     • Kubernetes & Networking
     • Kubernetes is Distributed system
     • Extends Kubernetes
     • Other topics for Kubernetes


     View Slide

102. Kubernetes is Distributed System
     Kubernetes architecture deep dive


     View Slide

103. Manifest (Declarative Code)
     • '$(*YAML

     • KubernetesAPI Object%"#
     • ! &
     nginx 3)


     View Slide

104. Overview of Kubernetes Architecture
     page
     0104
     kube-apiserver
     kubelet kubelet kubelet
     etcd
     client
     Manifest API Object
     Register API Object
     via REST API
     Store API Object
     kube-scheduler
     kube-controller-
     manager
     kube-proxy kube-proxy kube-proxy


     View Slide

105. API Object (also Declarative)
     page
     0105
     curl https://kubernetes/apis/extensions/v1beta1/namespaces/default
     /replicasets/sample-rs
     --cacert /var/run/secrets/kubernetes.io/serviceaccount/ca.crt
     -H "Authorization: Bearer $(cat /var/run/secrets/kubernetes.io/serviceaccount/token)”
     {
     "kind": ”RepicaSets",
     "apiVersion": "extensions/v1beta1",
     "metadata": {
     "name": "sample-rs",
     "namespace": "default",
     "selfLink": "/apis/extensions/v1beta1/namespaces/default/replicasets/sample-rs",
     "uid": "f10cdd9e-f249-11e8-9dde-42010a92013a",
     "resourceVersion": "5004593",
     ...


     View Slide

106. Flow of ReplicaSet
     page
     0106
     kube-apiserver
     apiVersion: apps/v1
     kind: ReplicaSet
     metadata:
     name: sample-rs
     spec:
     replicas: 3
     …
     etcd
     apiVersion: apps/v1
     kind: ReplicaSet
     metadata:
     name: sample-rs
     spec:
     replicas: 3
     …
     client
     Manifest
     Register
     ReplicaSet Object


     View Slide

107. Flow of ReplicaSet
     page
     0107
     kube-apiserver
     kube-controller-
     manager
     Detect
     ReplicaSet Object
     Observe
     Diff
     Act
     control
     loop
     apiVersion: apps/v1
     kind: ReplicaSet
     metadata:
     name: sample-rs
     spec:
     replicas: 3
     …
     etcd


     View Slide

108. Flow of ReplicaSet
     page
     0108
     kube-apiserver
     kube-controller-
     manager
     Register
     3 Pod Object
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     …
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     …
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     …
     Observe
     Diff
     Act
     control
     loop
     apiVersion: apps/v1
     kind: ReplicaSet
     metadata:
     name: sample-rs
     spec:
     replicas: 3
     …
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “”
     …
     status:
     phase: “Pending”
     etcd


     View Slide

109. Flow of ReplicaSet
     page
     0109
     kube-apiserver
     apiVersion: apps/v1
     kind: ReplicaSet
     metadata:
     name: sample-rs
     spec:
     replicas: 3
     …
     Detect
     Pod Object
     kube-scheduler
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “”
     …
     status:
     phase: “Pending”
     etcd


     View Slide

110. Flow of ReplicaSet
     page
     0110
     kube-apiserver
     apiVersion: apps/v1
     kind: ReplicaSet
     metadata:
     name: sample-rs
     spec:
     replicas: 3
     …
     Scheduling Pod
     to some Node
     kube-scheduler
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     etcd


     View Slide

111. Flow of ReplicaSet
     page
     0111
     kube-apiserver
     apiVersion: apps/v1
     kind: ReplicaSet
     metadata:
     name: sample-rs
     spec:
     replicas: 3
     …
     Detect
     Not running Pod
     kubelet
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     etcd


     View Slide

112. Flow of ReplicaSet
     page
     0112
     kube-apiserver
     apiVersion: apps/v1
     kind: ReplicaSet
     metadata:
     name: sample-rs
     spec:
     replicas: 3
     …
     kubelet
     Container
     Runtime
     (Docker)
     Create pod
     (container)
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     etcd


     View Slide

113. Flow of ReplicaSet
     page
     0113
     kube-apiserver
     apiVersion: apps/v1
     kind: ReplicaSet
     metadata:
     name: sample-rs
     spec:
     replicas: 3
     …
     Update
     status.phase
     Pending > Running
     kubelet
     Container
     Runtime
     (Docker)
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Pending”
     apiVersion: apps/v1
     kind: Pod
     metadata:
     name: sample-rs-xxxxx
     spec:
     nodeName: “nodeA”
     …
     status:
     phase: “Running”
     etcd


     View Slide

114. Agenda
     page
     0114
     • Cloud Native and Kubernetes
     • Container and Docker
     • Microservice and Service Mesh
     • Kubernetes
     • Kubernetes & Workloads
     • Kubernetes & Networking
     • Kubernetes is Distributed system
     • Extends Kubernetes
     • Other topics for Kubernetes


     View Slide

115. Extends Kubernetes
     Kubernetes is becoming the framework


     View Slide

116. XaaS on Kubernetes
     page
     0116
     (Ceph) as a Service
     Rook
     MySQL as a Service
     Vitess
     Queue as a Service
     NATS
     ML as a Service
     Kubeflow
     • NTT SIC

     kubeflow/katib
     • docker/infrakit


     View Slide

117. Queue as a Service
     Developer
     Kubernetes
     Register
     NatsCluster Object
     NATS
     Operator
     Detect Object
     Deploy Queue cluster
     Change
     Management
     Watch objects
     Kubernetes

     Kubernetes
     Observe
     Diff
     Act
     control
     loop


     View Slide

118. CustomResourceDefinition Operator
     page
     0118
     CustomResourceDefinition
     '+$
     "!! "#*
     Operator
     " "!
     )(
     ! "
     apiVersion: db.io/v1
     kind: MyDB
     metadata:
     name: sample-db
     spec:
     size: 10G
     type: mysql
     version: 5.6
     …
     DB%&)(
     Observe
     Diff
     Act
     control
     loop


     View Slide

119. Service Catalog
     page
     0119
     Service Broker
     Open Service Broker API
     Create Managed
     Service Instance


     View Slide

120.
     page
     0120
     Model and Operate Datacenter by Kubernetes at eBay - Xiaogang Xin
     & Tommy Mei, eBay, 2018-11-15, (https://sched.co/FuKD)
     • Datacenter Kubernetes Kubernetes



     View Slide

121. Agenda
     page
     0121
     • Cloud Native and Kubernetes
     • Container and Docker
     • Microservice and Service Mesh
     • Kubernetes
     • Kubernetes & Workloads
     • Kubernetes & Networking
     • Kubernetes is Distributed system
     • Extends Kubernetes
     • Other topics for Kubernetes


     View Slide

122. Other topics for Kubernetes
     Kubernetes is widespread in the world


     View Slide

123. page
     0123
     CNCFStandardization
     01.





     " (!)
     OCI v1.0 02.


     #

     CRI 03.

     #

     CSI 04.

     #

     CNI


     View Slide

124. Serverless Cloud Native Landscape by CNCF
     page
     0124


     View Slide

125. Conclusion
     page
     0122
     Cloud Native
     Container / Microservice / Service Mesh'1Cloud Native
     4+2
     &(
     Kubernetes-$0Cloud Native4+


     Kubernetes Google 3# /.4+ )
     !*, Platform 5"%


     View Slide

126. Kubernetes


     View Slide

127. 3 I H uNs P
     /D 6 IBK c a io sy P
     0 C 1 DD 3 I H
     W3 I HS M
     3 I H
     & 72 uNs C ID
     9 CD H uNs
     0BH K L 4 uNs
     / B 8I uNs
     /D HI uNs 5 I I uNs
     uNs N snN
     s h l o y f fl
     y s N
     snr N
     tk ye
     & hs c N uNsu ghd
     v
     o y
     /2 /0
     fl N s 8 KB 5 HA
     3 I H dNkyl
     3 I H b


     View Slide

128. Thank you for your attention
     follow me: @amsy810


     View Slide
