Computer Architecture, C++, and High Performance (CppCon 2016)

With the increase in the available computational power, the Nathan Myhrvold's Laws of Software continue to apply: New opportunities enable new applications with increased needs, which subsequently become constrained by the hardware that used to be "modern" at adoption time. C++ itself opens the access to high-quality optimizing compilers and a wide ecosystem of high-performance tooling and libraries. At the same time, simply turning on the highest optimization flags and hoping for the best is not going to automagically yield the highest performance -- i.e., the lowest execution time. The reasons are twofold: Algorithms' performance can differ in theory -- and that of their implementations can differ even more so in practice.

Modern CPU architecture has continued to yield increases in performance through the advances in microarchitecture, such as pipelining, multiple issue (superscalar) out-of-order execution, branch prediction, SIMD-within-a-register (SWAR) vector units, and chip multi-processor (CMP, also known as multi-core) architecture. All of these developments have provided us with the opportunities associated with a higher peak performance -- while at the same time raising new optimization challenges when actually trying to reach that peak.

In this talk we'll consider the properties of code which can make it either friendly -- or hostile -- to a modern microprocessor. We will offer advice on achieving higher performance, from the ways of analyzing it beyond algorithmic complexity, recognizing the aspects we can entrust to the compiler, to practical optimization of the existing code. Instead of stopping at the "you should measure it" advice (which is correct, but incomplete), the talk will be focused on providing practical, hands-on examples on _how_ to actually perform the measurements (presenting tools -- including perf and likwid -- simplifying the access to CPU performance monitoring counters) and how to reason about the resulting measurements (informed by the understanding of the modern CPU architecture, generated assembly code, as well as an in-depth look at how the CPU cycles are spent using modern microarchitectural simulation tools) to improve the performance of C++ applications.

Transcript

1. Computer Architecture, C++, and High Performance Matt P. Dziubinski CppCon 2016 matt@math.aau.dk // @matt_dz Department of Mathematical Sciences, Aalborg University CREATES (Center for Research in Econometric Analysis of Time Series)
2. Outline • Performance • Why do we care? • What is it? • How to • measure it - reason about it - improve it? 2
3. Why? 3
4. Costs and Curves Moore, Gordon E. (1965). "Cramming more components onto integrated circuits". Electronics Magazine. 4
5. Cramming more components onto integrated circuits Moore, Gordon E. (1965). "Cramming more components onto integrated circuits". Electronics Magazine. 5
6. Spending Moore’s Dividend "Spending Moore's Dividend," James Larus, Microsoft Research Technical Report MSR-TR-2008-69, May 2008. 6
7. Transformation Hierarchy Yale N. Patt, Microprocessor Performance, Phase 2: Can We Harness the Transformation Hierarchy https://youtube.com/watch?v=0fLlDkC625Q 7
8. Phase I & The Walls Yale N. Patt, Microprocessor Performance, Phase 2: Can We Harness the Transformation Hierarchy https://youtube.com/watch?v=0fLlDkC625Q 8
9. CPU Performance Trends 1 5 9 13 18 24 51 80 117 183 280 481 649 993 1,267 1,779 3,016 4,195 6,043 6,681 7,108 11,865 14,387 19,484 21,871 24,129 1 10 100 1000 10,000 100,000 1978 1980 1982 1984 1986 1988 1990 1992 1994 1996 1998 2000 2002 2004 2006 2008 2010 2012 Performance (vs. VAX-11/780) 25%/year 52%/year 22%/year IBM POWERstation 100, 150 MHz Digital Alphastation 4/266, 266 MHz Digital Alphastation 5/300, 300 MHz Digital Alphastation 5/500, 500 MHz AlphaServer 4000 5/600, 600 MHz 21164 Digital AlphaServer 8400 6/575, 575 MHz 21264 Professional Workstation XP1000, 667 MHz 21264A Intel VC820 motherboard, 1.0 GHz Pentium III processor IBM Power4, 1.3 GHz Intel Xeon EE 3.2 GHz AMD Athlon, 2.6 GHz Intel Core 2 Extreme 2 cores, 2.9 GHz Intel Core Duo Extreme 2 cores, 3.0 GHz Intel Core i7 Extreme 4 cores 3.2 GHz (boost to 3.5 GHz) Intel Xeon 4 cores, 3.3 GHz (boost to 3.6 GHz) Intel Xeon 6 cores, 3.3 GHz (boost to 3.6 GHz) Intel D850EMVR motherboard (3.06 GHz, Pentium 4 processor with Hyper-Threading Technology) 1.5, VAX-11/785 AMD Athlon 64, 2.8 GHz Digital 3000 AXP/500, 150 MHz HP 9000/750, 66 MHz IBM RS6000/540, 30 MHz MIPS M2000, 25 MHz MIPS M/120, 16.7 MHz Sun-4/260, 16.7 MHz VAX 8700, 22 MHz AX-11/780, 5 MHz Hennessy, John L.; Patterson, David A., 2011, "Computer Architecture: A Quantitative Approach," Morgan Kaufmann. 9
10. 40 Years of Microprocessor Trend Data https://www.karlrupp.net/2015/06/40-years-of-microprocessor-trend- data/ 10
11. Processor-Memory Performance Gap 1 100 10 1000 Performance 10,000 100,000 1980 2010 2005 2000 1995 Year Processor Memory 1990 1985 The difference in the time between processor memory requests (for a single processor or core) and the latency of a DRAM access. Hennessy, John L.; Patterson, David A., 2011, "Computer Architecture: A Quantitative Approach," Morgan Kaufmann. Computer Architecture is Back: Parallel Computing Landscape https://www.youtube.com/watch?v=On-k-E5HpcQ 11
12. DRAM Performance Trends D. Lee: "Reducing DRAM Latency at Low Cost by Exploiting Heterogeneity." http://arxiv.org/abs/1604.08041 (2016) D. Lee et al., "Tiered-latency DRAM: A low latency and low cost DRAM architecture," in HPCA, 2013. 12
13. Emerging Memory Technologies - Further Down The Hierarchy Qureshi et al., “Scalable high performance main memory system using phase-change memory technology,” ISCA 2009. 13
14. NVMs as Storage Class Memories - Bottlenecks: New & Old Justin Meza, Yixin Luo, Samira Khan, Jishen Zhao, Yuan Xie, and Onur Mutlu, "A Case for Efficient Hardware-Software Cooperative Management of Storage and Memory" Proceedings of the 5th Workshop on Energy-Efficient Design (WEED), Tel-Aviv, Israel, 2013. 14
15. DBs Execution Cycles: Useful Computation vs. Stall Cycles R. Panda, C. Erb, M. LeBeane, J. H. Ryoo and L. K. John, "Performance Characterization of Modern Databases on Out-of-Order CPUs," Computer Architecture and High Performance Computing (SBAC-PAD), 2015 27th International Symposium on, Florianopolis, 2015, pp. 114-121. 15
16. System Calls - Performance Impact Livio Soares and Michael Stumm. 2010. "FlexSC: flexible system call scheduling with exception-less system calls." In Proceedings of the 9th USENIX conference on Operating systems design and implementation (OSDI'10). USENIX Association, Berkeley, CA, USA, 33-46. 16
17. System Calls, Interrupts, and Asynchronous I/O Jisoo Yang, Dave B. Minturn, and Frank Hady. 2012. "When poll is better than interrupt." In Proceedings of the 10th USENIX conference on File and Storage Technologies (FAST'12). USENIX Association, Berkeley, CA, USA. 17
18. System Calls as CPU Exceptions Craig B. Zilles, Joel S. Emer, and Gurindar S. Sohi. 1999. "The use of multithreading for exception handling." In Proceedings of the 32nd annual ACM/IEEE international symposium on Microarchitecture (MICRO 32). IEEE Computer Society, Washington, DC, USA, 219-229. 18
19. Pollution & Context Switch Misses Replaced Miss (D) & Reordered Miss (C) F. Liu, F. Guo, Y. Solihin, S. Kim and A. Eker, "Characterizing and modeling the behavior of context switch misses", Intl. Conf. on Parallel Architectures and Compilation Techniques, 2008. 19
20. Beyond Mode Switch Time: Footprint & Pollution Livio Soares and Michael Stumm. 2010. "FlexSC: flexible system call scheduling with exception-less system calls." In Proceedings of the 9th USENIX conference on Operating systems design and implementation (OSDI'10). USENIX Association, Berkeley, CA, USA, 33-46. 20
21. Beyond Mode Switch Time: Direct & Indirect Costs Livio Soares and Michael Stumm. 2010. "FlexSC: flexible system call scheduling with exception-less system calls." In Proceedings of the 9th USENIX conference on Operating systems design and implementation (OSDI'10). USENIX Association, Berkeley, CA, USA, 33-46. 21
22. Feature Scaling Trends Lee, Yunsup, "Decoupled Vector-Fetch Architecture with a Scalarizing Compiler," EECS Department, University of California, Berkeley. 2016. http://www.eecs.berkeley.edu/Pubs/TechRpts/2016/EECS-2016-82.html 22
23. Process-Architecture-Optimization Intel's Annual Report on Form 10-K for the fiscal year ended December 26, 2015, filed with the SEC on February 12, 2016. https://www.sec.gov/Archives/edgar/data/50863/000005086316000105/a10kdocument12262015q4.htm 23
24. Make it fast Butler W. Lampson. 1983. "Hints for computer system design." In Proceedings of the ninth ACM symposium on Operating systems principles (SOSP '83). ACM, New York, NY, USA, 33-48. 24
25. What? 25
26. Performance: The Early Days A. Greenbaum and T. Chartier. "Numerical Methods: Design, analysis, and computer implementation of algorithms." 2010. Course Notes for Short Course on Numerical Analysis. 26
27. Algorithms Classification Problem Hartmanis, J.; Stearns, R. E. (1965), "On the computational complexity of algorithms", Transactions of the American Mathematical Society 117: 285–306. 27
28. Algorithms Classification Problem Hartmanis, J.; Stearns, R. E. (1965), "On the computational complexity of algorithms", Transactions of the American Mathematical Society 117: 285–306. 28
29. Complexity: Algorithms & Data Structures O(N) http://en.cppreference.com/w/cpp/algorithm/find O(N·log(N)) http://en.cppreference.com/w/cpp/algorithm/sort http://en.cppreference.com/w/cpp/algorithm/lower_bound log(N) http://en.cppreference.com/w/cpp/container/set/find 29
30. Analysis of Algorithms - Scientific Method Robert Sedgewick and Kevin Wayne, "Algorithms," 4th Edition, Addison-Wesley Professional, 2011. 30
31. Analysis of Algorithms - Problem Size N vs. Running Time T(N) Robert Sedgewick and Kevin Wayne, "Algorithms," 4th Edition, Addison-Wesley Professional, 2011. 31
32. Analysis of Algorithms - Tilde Notation & Tilde Approximations Robert Sedgewick and Kevin Wayne, "Algorithms," 4th Edition, Addison-Wesley Professional, 2011. 32
33. Analysis of Algorithms - Doubling Ratio Experiments Robert Sedgewick and Kevin Wayne, "Algorithms," 4th Edition, Addison-Wesley Professional, 2011. 33
34. Find Example C++ Code I #include <algorithm> #include <chrono> #include <cstddef> #include <cstdint> #include <cstdio> #include <iterator> #include <random> #include <set> #include <vector> #include <boost/container/flat_set.hpp> #include <EASTL/vector_set.h> // EASTL // https://wuyingren.github.io/howto/2016/02/11/Using-EASTL-in-your-project void* operator new[](size_t size, const char* pName, int flags, unsigned debugFlags, const char* file, int line) { return malloc(size); } 34
35. Find Example C++ Code II void* operator new[](size_t size, size_t alignment, size_t alignmentOffset, const char* pName, int flags, unsigned debugFlags, const char* file, int line) { return malloc(size); } using T = std::uint32_t; std::vector<T> odd_numbers(std::size_t count) { std::vector<T> result; result.reserve(count); for (std::size_t i = 0; i != count; i++) result.push_back(2 * i + 1); return result; } 35
36. Find Example C++ Code III template <typename container_type> void ctor_and_find(const char * type_name, const std::vector<T> & v, std::size_t q) { printf("%s\n", type_name); std::mt19937 prng(1); const std::size_t n = v.size(); std::uniform_int_distribution<T> uniform(0, 2 * n + 2); printf("ctor\t"); auto time_start = std::chrono::steady_clock::now(); const container_type s(begin(v), end(v)); auto time_end = std::chrono::steady_clock::now(); std::chrono::duration<double> duration = time_end - time_start; printf("duration: %g \n", duration.count()); printf("search\t"); time_start = std::chrono::steady_clock::now(); T sum = 0; for (std::size_t i = 0; i != q; ++i) { 36
37. Find Example C++ Code IV const auto it = s.find(uniform(prng)); sum += (it != end(s)) ? *it : 0; } time_end = std::chrono::steady_clock::now(); duration = time_end - time_start; printf("duration: %g \t", duration.count()); printf("sum: %zu \n\n", sum); } void ctor_and_find(const char * type_name, const std::vector<T> & v_src, std::size_t q) { printf("%s\n", type_name); std::mt19937 prng(1); const std::size_t n = v_src.size(); std::uniform_int_distribution<T> uniform(0, 2*n + 2); printf("prep\t"); auto time_start = std::chrono::steady_clock::now(); auto v = v_src; 37
38. Find Example C++ Code V std::sort(begin(v), end(v)); auto time_end = std::chrono::steady_clock::now(); std::chrono::duration<double> duration = time_end - time_start; printf("duration: %g \n", duration.count()); printf("search\t"); time_start = std::chrono::steady_clock::now(); T sum = 0; for (std::size_t i = 0; i != q; ++i) { const auto k = uniform(prng); const auto it = std::lower_bound(begin(v), end(v), k); sum += (it != end(v)) ? (*it == k ? k : 0) : 0; } time_end = std::chrono::steady_clock::now(); duration = time_end - time_start; printf("duration: %g \t", duration.count()); printf("sum: %zu \n\n", sum); } 38
39. Find Example C++ Code VI int main(int argc, char * argv[]) { // `n`: elements count (size) const std::size_t n = (argc > 1) ? std::atoll(argv[1]) : 100; printf("size: %zu \n", n); // `q`: queries count const std::size_t q = (argc > 2) ? std::atoll(argv[2]) : 10; printf("queries: %zu \n", q); const auto v = odd_numbers(n); printf("\n"); ctor_and_find<std::set<T>>("std::set", v, q); ctor_and_find("std::vector: copy & sort", v, q); ctor_and_find<boost::container::flat_set<T>>("boost::container::flat_set" ctor_and_find<eastl::vector_set<T>>("eastl::vector_set", v, q); } 39
40. Find Example - Benchmark (Nonius) Code I #include <algorithm> #include <cstddef> #include <cstdint> #include <cstdio> #include <iterator> #include <random> #include <set> #include <vector> #include <boost/container/flat_set.hpp> #include <EASTL/vector_set.h> #include <nonius/nonius.h++> #include <nonius/main.h++> NONIUS_PARAM(size, std::size_t{100u}) NONIUS_PARAM(queries, std::size_t{10u}) 40
41. Find Example - Benchmark (Nonius) Code II // EASTL // https://wuyingren.github.io/howto/2016/02/11/Using-EASTL-in-your-project void* operator new[](size_t size, const char* pName, int flags, unsigned de return malloc(size); } void* operator new[](size_t size, size_t alignment, size_t alignmentOffset, return malloc(size); } using T = std::uint32_t; std::vector<T> odd_numbers(std::size_t count) { std::vector<T> result; result.reserve(count); for (std::size_t i = 0; i != count; i++) result.push_back(2 * i + 1); return result; } 41
42. Find Example - Benchmark (Nonius) Code III template <typename container_type> T ctor_and_find(const char * type_name, const std::vector<T> & v, std::size_t q) { std::mt19937 prng(1); const std::size_t n = v.size(); std::uniform_int_distribution<T> uniform(0, 2 * n + 2); const container_type s(begin(v), end(v)); T sum = 0; for (std::size_t i = 0; i != q; ++i) { const auto it = s.find(uniform(prng)); sum += (it != end(s)) ? *it : 0; } return sum; } 42
43. Find Example - Benchmark (Nonius) Code IV T ctor_and_find(const char * type_name, const std::vector<T> & v_src, std::size_t q) { std::mt19937 prng(1); const std::size_t n = v_src.size(); std::uniform_int_distribution<T> uniform(0, 2*n + 2); auto v = v_src; std::sort(begin(v), end(v)); T sum = 0; for (std::size_t i = 0; i != q; ++i) { const auto k = uniform(prng); const auto it = std::lower_bound(begin(v), end(v), k); sum += (it != end(v)) ? (*it == k ? k : 0) : 0; } return sum; } 43
44. Find Example - Benchmark (Nonius) Code V NONIUS_BENCHMARK("std::set", [](nonius::chronometer meter) { const auto n = meter.param<size>(); const auto q = meter.param<queries>(); const auto v = odd_numbers(n); meter.measure([q, &v] { ctor_and_find<std::set<T>>("std::set", v, q); }); }); NONIUS_BENCHMARK("std::vector: copy & sort", [](nonius::chronometer meter) const auto n = meter.param<size>(); const auto q = meter.param<queries>(); const auto v = odd_numbers(n); meter.measure([q, &v] { ctor_and_find("std::vector: copy & sort", v, q); }); }); 44
45. Find Example - Benchmark (Nonius) Code VI NONIUS_BENCHMARK("boost::container::flat_set", [](nonius::chronometer meter const auto n = meter.param<size>(); const auto q = meter.param<queries>(); const auto v = odd_numbers(n); meter.measure([q, &v] { ctor_and_find<boost::container::flat_set<T>>("boost::container::flat_se }); }); NONIUS_BENCHMARK("eastl::vector_set", [](nonius::chronometer meter) { const auto n = meter.param<size>(); const auto q = meter.param<queries>(); const auto v = odd_numbers(n); meter.measure([q, &v] { ctor_and_find<eastl::vector_set<T>>("eastl::vector_set", v, q); }); }); int main(int argc, char * argv[]) { nonius::main(argc, argv); } 45
46. Find Example - Benchmark (Nonius) Code I Nonius: statistics-powered micro-benchmarking framework: https://nonius.io/ https://github.com/libnonius/nonius Running: BNSIZE=10000; BNQUERIES=1000 ./find --param=size:$BNSIZE --param=queries:$BNQUERIES > results.size=$BNSIZE.queries=$BNQUERIES.txt ./find --param=size:$BNSIZE --param=queries:$BNQUERIES --reporter=html --output=results.size=$BNSIZE.queries=$BNQUERIES.html 46
47. Find Example - Results: size=10,000 queries=1,000 47
48. Find Example - Results: size=10,000,000 queries=1,000,000 48
49. How? 49
50. Asymptotic growth & "random access machines"? Tomasz Jurkiewicz and Kurt Mehlhorn. 2015. "On a Model of Virtual Address Translation." J. Exp. Algorithmics 19. http://arxiv.org/abs/1212.0703 & https://people.mpi-inf.mpg.de/~mehlhorn/ftp/KMvat.pdf 50
51. Asymptotic growth & "random access machines"? Asymptotic - growing problem size • for large data need to take into account the costs of actually bringing it in • communication complexity vs. computation complexity • including overlapping computation-communication latencies 51
52. "Operation"? Jack Dongarra. 2016. "With Extreme Scale Computing the Rules Have Changed." In Proceedings of the 25th ACM International Symposium on High-Performance Parallel and Distributed Computing (HPDC '16). 52
53. "Operation"? Jack Dongarra. 2016. "With Extreme Scale Computing the Rules Have Changed." In Proceedings of the 25th ACM International Symposium on High-Performance Parallel and Distributed Computing (HPDC '16). 53
54. Complexity - constants, microarchitecture? "Array Layouts for Comparison-Based Searching" Paul-Virak Khuong, Pat Morin http://cglab.ca/~morin/misc/arraylayout-v2/ • "With this understanding, we are able to choose layouts and design search algorithms that perform searches in 1/2 to 2/3 (depending on the array length) the time of the C++ std::lower_bound() implementation of binary search 54
55. Complexity - constants, microarchitecture? "Array Layouts for Comparison-Based Searching" Paul-Virak Khuong, Pat Morin http://cglab.ca/~morin/misc/arraylayout-v2/ • "With this understanding, we are able to choose layouts and design search algorithms that perform searches in 1/2 to 2/3 (depending on the array length) the time of the C++ std::lower_bound() implementation of binary search • (which itself performs searches in 1/3 the time of searching in the std::set implemementation of red-black trees). 54
56. Complexity - constants, microarchitecture? "Array Layouts for Comparison-Based Searching" Paul-Virak Khuong, Pat Morin http://cglab.ca/~morin/misc/arraylayout-v2/ • "With this understanding, we are able to choose layouts and design search algorithms that perform searches in 1/2 to 2/3 (depending on the array length) the time of the C++ std::lower_bound() implementation of binary search • (which itself performs searches in 1/3 the time of searching in the std::set implemementation of red-black trees). • It was only through careful and controlled experimentation with different implementations of each of the search algorithms that we are able to understand how the interactions between processor features such as pipelining, prefetching, speculative execution, and conditional moves affect the running times of the search algorithms." 54
57. Reasoning about Performance: The Scientific Method Requires - enabled by - the knowledge of microachitectural details. Mark D. Hill, Norman P. Jouppi, and Gurindar S. Sohi, Chapter 2 "Methods" from "Readings in Computer Architecture," Morgan Kaufmann, 2000. Prefetching benefits evaluation: Disable/enable prefetchers using likwid-features: https://github.com/RRZE-HPC/likwid/wiki/likwid-features Example: https://gist.github.com/MattPD/06e293fb935eaf67ee9c301e70db6975 55
58. Microarchitecture Intel® 64 and IA-32 Architectures Optimization Reference Manual https://www-ssl.intel.com/content/www/us/en/architecture-and- technology/64-ia-32-architectures-optimization-manual.html 56
59. Pervasive CPU Parallelism pipeline-level parallelism (PLP) instruction-level parallelism (ILP) memory-level parallelism (MLP) data-level parallelism (DLP) thread-level parallelism (TLP) 57
60. Pipelining & Temporal Parallelism D. Sima, "Decisive aspects in the evolution of microprocessors", Proceedings of the IEEE, vol. 92, pp. 1896-1926, 2004 58
61. Pipelining: Base N. P. Jouppi and D. W. Wall. 1989. "Available instruction-level parallelism for superscalar and superpipelined machines." In Proceedings of the third international conference on Architectural support for programming languages and operating systems (ASPLOS III). ACM, New York, NY, USA, 272-282. 59
62. Pipelining: Superscalar N. P. Jouppi and D. W. Wall. 1989. "Available instruction-level parallelism for superscalar and superpipelined machines." In Proceedings of the third international conference on Architectural support for programming languages and operating systems (ASPLOS III). ACM, New York, NY, USA, 272-282. 60
63. The Cache Liptay, J. S. (1968) "Structural Aspects of the System/360 Model 85, Part II: The Cache," IBM System Journal, 7(1). 61
64. The Cache: Processor-Memory Performance Gap Liptay, J. S. (1968) "Structural Aspects of the System/360 Model 85, Part II: The Cache," IBM System Journal, 7(1). 62
65. The Cache: Assumptions & Effectiveness Liptay, J. S. (1968) "Structural Aspects of the System/360 Model 85, Part II: The Cache," IBM System Journal, 7(1). 63
66. Out-of-Order Execution R.M. Tomasulo, “An Efficient Algorithm for Exploiting Multiple Arithmetic Units,” IBM Journal of R&D, Jan. 1967. 64
67. Out-of-Order Execution: Overlap R.M. Tomasulo, “An Efficient Algorithm for Exploiting Multiple Arithmetic Units,” IBM Journal of R&D, Jan. 1967. 65
68. Out-of-Order Execution: Reservation Stations R.M. Tomasulo, “An Efficient Algorithm for Exploiting Multiple Arithmetic Units,” IBM Journal of R&D, Jan. 1967. 66
69. Out-of-Order Execution: Dependencies vs. Overlap R.M. Tomasulo, “An Efficient Algorithm for Exploiting Multiple Arithmetic Units,” IBM Journal of R&D, Jan. 1967. 67
70. Out-of-Order Execution: Dependencies vs. Overlap R.M. Tomasulo, “An Efficient Algorithm for Exploiting Multiple Arithmetic Units,” IBM Journal of R&D, Jan. 1967. 68
71. Out-of-Order Execution of Simple Micro-Operations Y.N. Patt, W.M. Hwu, and M. Shebanow, “HPS, A New Microarchitecture: Rationale and Introduction,” Proc. 18th Ann. Workshop Microprogramming, 1985, pp. 103–108. 69
72. Out-of-Order Execution: Restricted Dataflow Y.N. Patt, W.M. Hwu, and M. Shebanow, “HPS, A New Microarchitecture: Rationale and Introduction,” Proc. 18th Ann. Workshop Microprogramming, 1985, pp. 103–108. 70
73. Out-of-Order Execution: Results Buffer Y.N. Patt, W.M. Hwu, and M. Shebanow, “HPS, A New Microarchitecture: Rationale and Introduction,” Proc. 18th Ann. Workshop Microprogramming, 1985, pp. 103–108. 71
74. Pipelining & Precise Exceptions: Reorder Buffer (ROB) J.E. Smith and A.R. Pleszkun, “Implementation of Precise Interrupts in Pipelined Processors,” Proc. 12th Ann. IEEE/ACM Int’l Symp. Computer Architecture, 1985, pp. 36–44. 72
75. Execution: Superscalar & Out-Of-Order J.E. Smith and G.S. Sohi, "The Microarchitecture of Superscalar Processors," Proc. IEEE, vol. 83, pp. 1609-1624, Dec. 1995. 73
76. Superscalar CPU Organization J.E. Smith and G.S. Sohi, "The Microarchitecture of Superscalar Processors," Proc. IEEE, vol. 83, pp. 1609-1624, Dec. 1995. 74
77. Superscalar CPU: ROB J.E. Smith and G.S. Sohi, "The Microarchitecture of Superscalar Processors," Proc. IEEE, vol. 83, pp. 1609-1624, Dec. 1995. 75
78. Computer Architecture: A Science of Tradeoffs "My tongue in cheek phrase to emphasize the importance of tradeoffs to the discipline of computer architecture. Clearly, computer architecture is more art than science. Science, we like to think, involves a coherent body of knowledge, even though we have yet to figure out all the connections. Art, on the other hand, is the result of individual expressions of the various artists. Since each computer architecture is the result of the individual(s) who specified it, there is no such completely coherent structure. So, I opined if computer architecture is a science at all, it is a science of tradeoffs. In class, we keep coming up with design choices that involve tradeoffs. In my view, "tradeoffs" is at the heart of computer architecture." — Yale N. Patt 76
79. Design Points: Dictated the Application Space The design of a microprocessor is about making relevant tradeoffs. We refer to the set of considerations, along with the relevant importance of each, as the “design point” for the microprocessor—that is, the characteristics that are most important to the use of the microprocessor, such that one is willing to be less concerned about other characteristics. In each case, it is usually the problem we are addressing . . . which dictates the design point for the microprocessor, and the resulting tradeoffs that must be made. Patt, Y., & Cockrell, E. (2001). "Requirements, bottlenecks, and good fortune: Agents for microprocessor evolution." Proceedings of the IEEE, 89(11), 1553-1559. 77
80. A Science of Tradeoffs Software Performance Optimization - Analogous! The multiplicity of tradeoffs: • Multidimensional • Multiple levels • Costs and benefits 78
81. Trade-offs - Latency & Bandwidth I Intel(R) Memory Latency Checker - v3.1a Measuring idle latencies (in ns)... Memory node Socket 0 0 60.4 Measuring Peak Memory Bandwidths for the system Bandwidths are in MB/sec (1 MB/sec = 1,000,000 Bytes/sec) Using traffic with the following read-write ratios ALL Reads : 24152.0 3:1 Reads-Writes : 22313.2 2:1 Reads-Writes : 22050.5 1:1 Reads-Writes : 21130.4 Stream-triad like: 21559.4 79
82. Trade-offs - Latency & Bandwidth II Measuring Memory Bandwidths between nodes within system Using Read-only traffic type Memory node Socket 0 0 24155.0 Measuring Loaded Latencies for the system Using Read-only traffic type Inject Latency Bandwidth Delay (ns) MB/sec ========================== 00000 122.27 24109.6 00002 121.99 24082.7 00008 120.60 23952.1 00015 119.28 23837.6 00050 70.87 17408.7 00100 64.59 12496.6 80
83. Trade-offs - Latency & Bandwidth III Inject Latency Bandwidth Delay (ns) MB/sec ========================== 00200 61.76 8129.1 00300 60.75 6194.8 00400 60.63 5085.6 00500 60.12 4377.0 00700 60.51 3505.2 01000 60.60 2812.6 01300 60.66 2425.3 01700 60.51 2117.0 02500 60.36 1789.5 03500 60.33 1585.4 05000 60.29 1430.9 09000 60.31 1267.9 20000 60.32 1154.7 81
84. Trade-offs - Latency & Size I Intel i3-2120 (Sandy Bridge), 3.3 GHz, 32 nm. RAM: 16 GB (4 x 4GB), PC3-10700 (667 MHz) 9-9-9-24-2T. http://www.7-cpu.com/cpu/SandyBridge.html Size Latency Increase Description 32 K 4 64 K 8 4 + 8 (L2) 128 K 10 2 256 K 11 1 512 K 20 9 + 16 (L3) 1 M 24 4 2 M 26 2 4 M 27 + 18 ns 1 + 18 ns + 56 ns (RAM) 8 M 28 + 38 ns 1 + 20 ns 16 M 28 + 47 ns 9 ns 32 M 28 + 52 ns 5 ns 64 M 28 + 54 ns 2 ns 128 M 36 + 55 ns 8 + 1 ns + 16 (TLB miss) 82
85. Trade-offs - Latency & Size II Size Latency Increase Description 256 M 40 + 56 ns 4 + 1 ns 512 M 42 + 56 ns 2 1024 M 43 + 56 ns 1 2048 M 44 + 56 ns 1 4096 M 44 + 56 ns 0 8192 M 53 + 56 ns 9 + 18 (PDPTE cache miss) Intel i3-2120 (Sandy Bridge), 3.3 GHz, 32 nm. RAM: 16 GB (4 x 4GB), PC3-10700 (667 MHz) 9-9-9-24-2T. http://www.7-cpu.com/cpu/SandyBridge.html 83
86. Trade-offs - Least Squares Golub & Van Loan (2013) "Matrix Computations" Trade-offs: FLOPs (FLoating-point OPerations) vs. Applicability / Numerical Stability / Speed / Accuracy Example: Catalogue of dense decompositions: http://eigen.tuxfamily.org/dox/group__TopicLinearAlgebraDecompositions.html 84
87. Trade-offs - Multidimensional - Numerical Optimization Ben Recht, Feng Niu, Christopher Ré, Stephen Wright. "Lock-Free Approaches to Parallelizing Stochastic Gradient Descent" OPT 2011: 4th International Workshop on Optimization for Machine Learning http://opt.kyb.tuebingen.mpg.de/slides/opt2011-recht.pdf 85
88. Trade-offs - Multiple levels - Numerical Optimization Gradient computation - accuracy vs. function evaluations f : Rd → RN • Finite differencing: • forward-difference: O( √ ϵM) error, d O(Cost(f)) evaluations • central-difference: O(ϵ2/3 M ) error, 2d O(Cost(f)) evaluations w/ the machine epsilon ϵM := inf{ϵ > 0 : 1.0 + ϵ ̸= 1.0} • Algorithmic differentiation (AD): precision - as in hand-coded analytical gradient • rough forward-mode cost d O(Cost(f)) • rough reverse-mode cost N O(Cost(f)) 86
89. Trade-offs: Costs and Benefits Gabriel, Richard P. (1985). "Performance and Evaluation of Lisp Systems." Cambridge, Mass: MIT Press; Computer Systems Series. 87
90. Costs and Benefits: Implications • Important to know what to focus on • Optimize the optimization: so that it doesn't always take hours or days or weeks or months... 88
91. Superscalar CPU Model Stijn Eyerman, Lieven Eeckhout, Tejas Karkhanis, and James E. Smith. 2009. "A mechanistic performance model for superscalar out-of-order processors." ACM Trans. Comput. Syst. 27, 2, Article 3. 89
92. Instruction Level Parallelism & Loop Unrolling - Code I #include <cstddef> #include <cstdint> #include <cstdlib> #include <iostream> #include <vector> #include <boost/timer/timer.hpp> 90
93. Instruction Level Parallelism & Loop Unrolling - Code II using T = double; T sum_1(const std::vector<T> & input) { T sum = 0.0; for (std::size_t i = 0, n = input.size(); i != n; ++i) sum += input[i]; return sum; } T sum_2(const std::vector<T> & input) { T sum1 = 0.0, sum2 = 0.0; for (std::size_t i = 0, n = input.size(); i != n; i += 2) { sum1 += input[i]; sum2 += input[i + 1]; } return sum1 + sum2; } 91
94. Instruction Level Parallelism & Loop Unrolling - Code III int main(int argc, char * argv[]) { const std::size_t n = (argc > 1) ? std::atoll(argv[1]) : 10000000; const std::size_t f = (argc > 2) ? std::atoll(argv[2]) : 1; std::cout << "n = " << n << '\n'; // iterations count std::cout << "f = " << f << '\n'; // unroll factor const std::vector<T> a(n, T(1)); boost::timer::auto_cpu_timer timer; const T sum = (f == 1) ? sum_1(a) : (f == 2) ? sum_2(a) : 0; std::cout << sum << '\n'; } 92
95. Instruction Level Parallelism & Loop Unrolling - Results make vector_sums CXXFLAGS="-std=c++14 -O2 -march=native" LDLIBS=-lboost_timer $ ./vector_sums 1000000000 2 n = 1000000000 f = 2 1e+09 0.466293s wall, 0.460000s user + 0.000000s system = 0.460000s CPU (98.7%) $ ./vector_sums 1000000000 1 n = 1000000000 f = 1 1e+09 0.841269s wall, 0.840000s user + 0.010000s system = 0.850000s CPU (101.0%) 93
96. perf • https://perf.wiki.kernel.org/ • http://www.brendangregg.com/perf.html 94
97. perf Results - sum_1 Performance counter stats for './vector_sums 1000000000 1': 1675.812457 task-clock (msec) # 0.850 CPUs utilized 34 context-switches # 0.020 K/sec 5 cpu-migrations # 0.003 K/sec 8,953 page-faults # 0.005 M/sec 5,760,418,457 cycles # 3.437 GHz 3,456,046,515 stalled-cycles-frontend # 60.00% frontend cycles id 8,225,763,566 instructions # 1.43 insns per cycle # 0.42 stalled cycles per 2,050,710,005 branches # 1223.711 M/sec 104,331 branch-misses # 0.01% of all branches 1.970909249 seconds time elapsed 95
98. perf Results - sum_2 Performance counter stats for './vector_sums 1000000000 2': 1283.910371 task-clock (msec) # 0.835 CPUs utilized 38 context-switches # 0.030 K/sec 3 cpu-migrations # 0.002 K/sec 9,466 page-faults # 0.007 M/sec 4,458,594,733 cycles # 3.473 GHz 2,149,690,303 stalled-cycles-frontend # 48.21% frontend cycles id 6,734,925,029 instructions # 1.51 insns per cycle # 0.32 stalled cycles per 1,552,029,608 branches # 1208.830 M/sec 119,358 branch-misses # 0.01% of all branches 1.537971058 seconds time elapsed 96
99. GCC Explorer: sum_1 (C++) http://gcc.godbolt.org/ 97
100. GCC Explorer: sum_1 (x86-64 Assembly) http://gcc.godbolt.org/ 98
101. GCC Explorer: sum_2 (C++) http://gcc.godbolt.org/ 99
102. GCC Explorer: sum_2 (x86-64 Assembly) http://gcc.godbolt.org/ 100
103. Intel Architecture Code Analyzer (IACA) #include <iacaMarks.h> T sum_2(const std::vector<T> & input) { T sum1 = 0.0, sum2 = 0.0; for (std::size_t i = 0, n = input.size(); i != n; i += 2) { IACA_START sum1 += input[i]; sum2 += input[i + 1]; } IACA_END return sum1 + sum2; } $ g++ -std=c++14 -O2 -march=native vector_sums_2i.cpp -o vector_sums_2i $ iaca -64 -arch IVB -graph ./vector_sums_2i • https://software.intel.com/en-us/articles/intel-architecture-code-analyzer • https://stackoverflow.com/questions/26021337/what-is-iaca-and-how-do-i- use-it • http://kylehegeman.com/blog/2013/12/28/introduction-to-iaca/ 101
104. IACA Results - sum_1 $ iaca -64 -arch IVB -graph ./vector_sums_1i Intel(R) Architecture Code Analyzer Version - 2.1 Analyzed File - ./vector_sums_1i Binary Format - 64Bit Architecture - IVB Analysis Type - Throughput Throughput Analysis Report -------------------------- Block Throughput: 3.00 Cycles Throughput Bottleneck: InterIteration Port Binding In Cycles Per Iteration: ------------------------------------------------------------------------- | Port | 0 - DV | 1 | 2 - D | 3 - D | 4 | 5 | ------------------------------------------------------------------------- | Cycles | 1.0 0.0 | 1.0 | 1.0 1.0 | 1.0 1.0 | 0.0 | 1.0 | ------------------------------------------------------------------------- N - port number or number of cycles resource conflict caused delay, DV - Divider pipe (on port 0) D - Data fetch pipe (on ports 2 and 3), CP - on a critical path F - Macro Fusion with the previous instruction occurred * - instruction micro-ops not bound to a port ^ - Micro Fusion happened # - ESP Tracking sync uop was issued @ - SSE instruction followed an AVX256 instruction, dozens of cycles penalty is expected ! - instruction not supported, was not accounted in Analysis | Num Of | Ports pressure in cycles | | | Uops | 0 - DV | 1 | 2 - D | 3 - D | 4 | 5 | | --------------------------------------------------------------------- | 1 | | | 1.0 1.0 | | | | | mov rdx, qword ptr [rdi] | 2 | | 1.0 | | 1.0 1.0 | | | CP | vaddsd xmm0, xmm0, qword ptr [rdx+rax*8] | 1 | 1.0 | | | | | | | add rax, 0x1 | 1 | | | | | | 1.0 | | cmp rax, rcx | 0F | | | | | | | | jnz 0xffffffffffffffe7 Total Num Of Uops: 5 102
105. IACA Results - sum_2 $ iaca -64 -arch IVB -graph ./vector_sums_2i Intel(R) Architecture Code Analyzer Version - 2.1 Analyzed File - ./vector_sums_2i Binary Format - 64Bit Architecture - IVB Analysis Type - Throughput Throughput Analysis Report -------------------------- Block Throughput: 6.00 Cycles Throughput Bottleneck: InterIteration Port Binding In Cycles Per Iteration: ------------------------------------------------------------------------- | Port | 0 - DV | 1 | 2 - D | 3 - D | 4 | 5 | ------------------------------------------------------------------------- | Cycles | 1.5 0.0 | 3.0 | 1.5 1.5 | 1.5 1.5 | 0.0 | 1.5 | ------------------------------------------------------------------------- N - port number or number of cycles resource conflict caused delay, DV - Divider pipe (on port 0) D - Data fetch pipe (on ports 2 and 3), CP - on a critical path F - Macro Fusion with the previous instruction occurred * - instruction micro-ops not bound to a port ^ - Micro Fusion happened # - ESP Tracking sync uop was issued @ - SSE instruction followed an AVX256 instruction, dozens of cycles penalty is expected ! - instruction not supported, was not accounted in Analysis | Num Of | Ports pressure in cycles | | | Uops | 0 - DV | 1 | 2 - D | 3 - D | 4 | 5 | | --------------------------------------------------------------------- | 1 | | | 0.5 0.5 | 0.5 0.5 | | | | mov rcx, qword ptr [rdi] | 2 | | 1.0 | 0.5 0.5 | 0.5 0.5 | | | CP | vaddsd xmm0, xmm0, qword ptr [rcx+rax*8] | 1 | 1.0 | | | | | | | add rax, 0x2 | 2 | | 1.0 | 0.5 0.5 | 0.5 0.5 | | | | vaddsd xmm1, xmm1, qword ptr [rcx+rdx*1] | 1 | 0.5 | | | | | 0.5 | | add rdx, 0x10 | 1 | | | | | | 1.0 | | cmp rax, rsi | 0F | | | | | | | | jnz 0xffffffffffffffde | 1 | | 1.0 | | | | | CP | vaddsd xmm0, xmm0, xmm1 Total Num Of Uops: 9 103
106. IACA Data Dependency Graph - sum_1 104
107. IACA Data Dependency Graph - sum_2 105
108. Work, Depth, and Parallelism Guy E. Blelloch, "Programming parallel algorithms", Communications of the ACM, 1996. 106
109. ILP & Data (In)dependence G. S. Tjaden and M. J. Flynn, ‘‘Detection and Parallel Execution of Independent Instructions,’’ IEEE Transactions on Computers, vol. C-19, pp. 889-895, October 1970. 107
110. ILP vs. Dependencies D. W. Wall, “Limits of instruction-level parallelism,” Digital Western. Research Laboratory, Tech. Rep. 93/6, Nov. 1993. 108
111. ILP, Criticality & Latency Hiding D. W. Wall, “Limits of instruction-level parallelism,” Digital Western. Research Laboratory, Tech. Rep. 93/6, Nov. 1993. 109
112. Empty Issue Slots: Horizontal Waste & Vertical Waste D. M. Tullsen, S. J. Eggers and H. M. Levy, "Simultaneous multithreading: Maximizing on-chip parallelism," Proceedings, 22nd Annual International Symposium on Computer Architecture, 1995. 110
113. Wasted Slots: Causes D. M. Tullsen, S. J. Eggers and H. M. Levy, "Simultaneous multithreading: Maximizing on-chip parallelism," Computer Architecture, 1995. Proceedings., 22nd Annual International Symposium on, Santa Margherita Ligure, Italy, 1995, pp. 392-403. 111
114. Wasted Slots: Miss Events Stijn Eyerman, Lieven Eeckhout, Tejas Karkhanis, and James E. Smith. 2006. "A performance counter architecture for computing accurate CPI components." SIGOPS Oper. Syst. Rev. 40, 5 (October 2006), 175-184. 112
115. likwid • https://github.com/RRZE-HPC/likwid • https://github.com/RRZE-HPC/likwid/wiki • https://github.com/RRZE-HPC/likwid/wiki/likwid-perfctr 113
116. likwid Results - sum_1: 489 Scalar MUOPS/s $ likwid-perfctr -C S0:0 -g FLOPS_DP -f ./vector_sums 1000000000 1 -------------------------------------------------------------------------------- CPU name: Intel(R) Core(TM) i7-3720QM CPU @ 2.60GHz CPU type: Intel Core IvyBridge processor CPU clock: 2.59 GHz -------------------------------------------------------------------------------- n = 1000000000 f = 1 1e+09 1.090122s wall, 0.880000s user + 0.000000s system = 0.880000s CPU (80.7%) -------------------------------------------------------------------------------- Group 1: FLOPS_DP +--------------------------------------+---------+------------+ | Event | Counter | Core 0 | +--------------------------------------+---------+------------+ | INSTR_RETIRED_ANY | FIXC0 | 8002493499 | | CPU_CLK_UNHALTED_CORE | FIXC1 | 4285189526 | | CPU_CLK_UNHALTED_REF | FIXC2 | 3258346806 | | FP_COMP_OPS_EXE_SSE_FP_PACKED_DOUBLE | PMC0 | 0 | | FP_COMP_OPS_EXE_SSE_FP_SCALAR_DOUBLE | PMC1 | 1000155741 | | SIMD_FP_256_PACKED_DOUBLE | PMC2 | 0 | +--------------------------------------+---------+------------+ +----------------------+-----------+ | Metric | Core 0 | +----------------------+-----------+ | Runtime (RDTSC) [s] | 2.0456 | | Runtime unhalted [s] | 1.6536 | | Clock [MHz] | 3408.2011 | | CPI | 0.5355 | | MFLOP/s | 488.9303 | | AVX MFLOP/s | 0 | | Packed MUOPS/s | 0 | | Scalar MUOPS/s | 488.9303 | +----------------------+-----------+ 114
117. likwid Results - sum_2: 595 Scalar MUOPS/s $ likwid-perfctr -C S0:0 -g FLOPS_DP -f ./vector_sums 1000000000 2 -------------------------------------------------------------------------------- CPU name: Intel(R) Core(TM) i7-3720QM CPU @ 2.60GHz CPU type: Intel Core IvyBridge processor CPU clock: 2.59 GHz -------------------------------------------------------------------------------- n = 1000000000 f = 2 1e+09 0.620421s wall, 0.470000s user + 0.000000s system = 0.470000s CPU (75.8%) -------------------------------------------------------------------------------- Group 1: FLOPS_DP +--------------------------------------+---------+------------+ | Event | Counter | Core 0 | +--------------------------------------+---------+------------+ | INSTR_RETIRED_ANY | FIXC0 | 6502566958 | | CPU_CLK_UNHALTED_CORE | FIXC1 | 2948446599 | | CPU_CLK_UNHALTED_REF | FIXC2 | 2223894218 | | FP_COMP_OPS_EXE_SSE_FP_PACKED_DOUBLE | PMC0 | 0 | | FP_COMP_OPS_EXE_SSE_FP_SCALAR_DOUBLE | PMC1 | 1000328727 | | SIMD_FP_256_PACKED_DOUBLE | PMC2 | 0 | +--------------------------------------+---------+------------+ +----------------------+-----------+ | Metric | Core 0 | +----------------------+-----------+ | Runtime (RDTSC) [s] | 1.6809 | | Runtime unhalted [s] | 1.1377 | | Clock [MHz] | 3435.8987 | | CPI | 0.4534 | | MFLOP/s | 595.1079 | | AVX MFLOP/s | 0 | | Packed MUOPS/s | 0 | | Scalar MUOPS/s | 595.1079 | +----------------------+-----------+ 115
118. likwid Results: sum_vectorized: 676 AVX MFLOP/s g++ -std=c++14 -O2 -ftree-vectorize -ffast-math -march=native -lboost_timer vector_sums.cpp -o vector_sums_vf $ likwid-perfctr -C S0:0 -g FLOPS_DP -f ./vector_sums_vf 1000000000 1 -------------------------------------------------------------------------------- CPU name: Intel(R) Core(TM) i7-3720QM CPU @ 2.60GHz CPU type: Intel Core IvyBridge processor CPU clock: 2.59 GHz -------------------------------------------------------------------------------- n = 1000000000 f = 1 1e+09 0.561288s wall, 0.390000s user + 0.000000s system = 0.390000s CPU (69.5%) -------------------------------------------------------------------------------- Group 1: FLOPS_DP +--------------------------------------+---------+------------+ | Event | Counter | Core 0 | +--------------------------------------+---------+------------+ | INSTR_RETIRED_ANY | FIXC0 | 3002491149 | | CPU_CLK_UNHALTED_CORE | FIXC1 | 2709364345 | | CPU_CLK_UNHALTED_REF | FIXC2 | 2043804906 | | FP_COMP_OPS_EXE_SSE_FP_PACKED_DOUBLE | PMC0 | 0 | | FP_COMP_OPS_EXE_SSE_FP_SCALAR_DOUBLE | PMC1 | 91 | | SIMD_FP_256_PACKED_DOUBLE | PMC2 | 260258099 | +--------------------------------------+---------+------------+ +----------------------+-----------+ | Metric | Core 0 | +----------------------+-----------+ | Runtime (RDTSC) [s] | 1.5390 | | Runtime unhalted [s] | 1.0454 | | Clock [MHz] | 3435.5297 | | CPI | 0.9024 | | MFLOP/s | 676.4420 | | AVX MFLOP/s | 676.4420 | | Packed MUOPS/s | 169.1105 | | Scalar MUOPS/s | 0.0001 | +----------------------+-----------+ 116
119. Performance: CPI Steven K. Przybylski, "Cache and Memory Hierarchy Design – A Performance-Directed Approach," San Fransisco, Morgan-Kaufmann, 1990. 117
120. Performance: [YMMV]PI - Power Grochowski, E., Ronen, R., Shen, J., & Wang, H. (2004). "Best of Both Latency and Throughput." Proceedings of the IEEE International Conference on Computer Design. 118
121. Performance: [YMMV]PI - Graphs Scott Beamer, Krste Asanović, and David A. Patterson. "GAIL: The Graph Algorithm Iron Law." Workshop on Irregular Applications: Architectures and Algorithms (IAˆ3), at the International Conference for High Performance Computing, Networking, Storage and Analysis (SC), 2015. 119
122. Performance: [YMMV]PI - Packets packet_processing_times = seconds/packet = instructions/packet * clock_cycles/instruction * seconds/clock_cycle = clock_cycles/packet * seconds/clock_cycle = CPP / core_frequency cycles per packet (CPP) http://blogs.cisco.com/sp/a-bigger-helping-of-internet-please 120
123. Performance: separable components of a CPI CPI = (Infinite-cache CPI) + finite-cache effect (FCE) Infinite-cache CPI = execute busy (EBusy) + execute idle (EIdle) FCE = (cycles per miss) × (misses per instruction) = (miss penalty) × (miss rate) P. G. Emma. "Understanding some simple processor-performance limits." IBM Journal of Research and Development, 41(3):215–232, May 1997. 121
124. Pipelining & Branches P. Emma and E. Davidson, "Characterization of Branch and Data Dependencies in Programs for Evaluating Pipeline Performance," IEEE Trans. Computers C-36, No. 7, 859-875 (July 1987) 122
125. Branch Misprediction Penalty Stijn Eyerman, Lieven Eeckhout, Tejas Karkhanis, and James E. Smith. 2009. "A mechanistic performance model for superscalar out-of-order processors." ACM Trans. Comput. Syst. 27, 2, Article 3. 123
126. Branch Misprediction Penalty Stijn Eyerman, Lieven Eeckhout, Tejas Karkhanis and James E. Smith, "A Performance Counter Architecture for Computing Accurate CPI Components", ASPLOS 2006, pp. 175-184. 124
127. Branch (Mis)Prediction Example I #include <cmath> #include <cstddef> #include <cstdlib> #include <future> #include <iostream> #include <random> #include <vector> #include <boost/timer/timer.hpp> double sum1(const std::vector<double> & x, const std::vector<bool> & which) { double sum = 0.0; for (std::size_t i = 0, n = which.size(); i != n; ++i) { sum += which[i] ? std::cos(x[i]) : std::sin(x[i]); } return sum; } 125
128. Branch (Mis)Prediction Example II double sum2(const std::vector<double> & x, const std::vector<bool> & which) { double sum = 0.0; for (std::size_t i = 0, n = which.size(); i != n; ++i) { sum += which[i] ? std::sin(x[i]) : std::cos(x[i]); } return sum; } std::vector<bool> inclusion_random(std::size_t n, double p) { std::vector<bool> which; which.reserve(n); static std::mt19937 g(1); std::bernoulli_distribution decision(p); for (std::size_t i = 0; i != n; ++i) which.push_back(decision(g)); 126
129. Branch (Mis)Prediction Example III return which; } int main(int argc, char * argv[]) { const std::size_t n = (argc > 1) ? std::atoll(argv[1]) : 1000; std::cout << "n = " << n << '\n'; // branch takenness / predictability type // 0: never; 1: always; 2: random const std::size_t type = (argc > 2) ? std::atoll(argv[2]) : 0; std::cout << "type = " << type << '\n'; // takenness probability // 0.0: never; 1.0: always const double p = (argc > 3) ? std::atof(argv[3]) : 0.5; std::cout << "p = " << p << '\n'; 127
130. Branch (Mis)Prediction Example IV std::vector<bool> which; if (type == 0) which.resize(n, false); else if (type == 1) which.resize(n, true); else if (type == 2) which = inclusion_random(n, p); const std::vector<double> x(n, 1.1); boost::timer::auto_cpu_timer timer; std::cout << sum1(x, which) + sum2(x, which) << '\n'; } 128
131. Timing: Branch (Mis)Prediction Example $ make BP CXXFLAGS="-std=c++14 -O3 -march=native" LDLIBS=-lboost_timer-mt $ ./BP 10000000 0 n = 10000000 type = 0 1.3448e+007 1.190391s wall, 1.187500s user + 0.000000s system = 1.187500s CPU (99.8%) $ ./BP 10000000 1 n = 10000000 type = 1 1.3448e+007 1.172734s wall, 1.156250s user + 0.000000s system = 1.156250s CPU (98.6%) $ ./BP 10000000 2 n = 10000000 type = 2 1.3448e+007 1.296455s wall, 1.296875s user + 0.000000s system = 1.296875s CPU (100.0%) 129
132. Likwid: Branch (Mis)Prediction Example $ likwid-perfctr -C S0:1 -g BRANCH -f ./BP 10000000 0 -------------------------------------------------------------------------------- CPU name: Intel(R) Core(TM) i7-3720QM CPU @ 2.60GHz CPU type: Intel Core IvyBridge processor CPU clock: 2.59 GHz -------------------------------------------------------------------------------- n = 10000000 type = 0 1.3448e+07 0.445464s wall, 0.440000s user + 0.000000s system = 0.440000s CPU (98.8%) -------------------------------------------------------------------------------- Group 1: BRANCH +------------------------------+---------+------------+ | Event | Counter | Core 1 | +------------------------------+---------+------------+ | INSTR_RETIRED_ANY | FIXC0 | 2495177597 | | CPU_CLK_UNHALTED_CORE | FIXC1 | 1167613066 | | CPU_CLK_UNHALTED_REF | FIXC2 | 1167632206 | | BR_INST_RETIRED_ALL_BRANCHES | PMC0 | 372952380 | | BR_MISP_RETIRED_ALL_BRANCHES | PMC1 | 14796 | +------------------------------+---------+------------+ +----------------------------+--------------+ | Metric | Core 1 | +----------------------------+--------------+ | Runtime (RDTSC) [s] | 0.4586 | | Runtime unhalted [s] | 0.4505 | | Clock [MHz] | 2591.5373 | | CPI | 0.4679 | | Branch rate | 0.1495 | | Branch misprediction rate | 5.929838e-06 | | Branch misprediction ratio | 3.967263e-05 | | Instructions per branch | 6.6903 | +----------------------------+--------------+ 130
133. Likwid: Branch (Mis)Prediction Example $ likwid-perfctr -C S0:1 -g BRANCH -f ./BP 10000000 1 -------------------------------------------------------------------------------- CPU name: Intel(R) Core(TM) i7-3720QM CPU @ 2.60GHz CPU type: Intel Core IvyBridge processor CPU clock: 2.59 GHz -------------------------------------------------------------------------------- n = 10000000 type = 1 1.3448e+07 0.445354s wall, 0.440000s user + 0.000000s system = 0.440000s CPU (98.8%) -------------------------------------------------------------------------------- Group 1: BRANCH +------------------------------+---------+------------+ | Event | Counter | Core 1 | +------------------------------+---------+------------+ | INSTR_RETIRED_ANY | FIXC0 | 2495177490 | | CPU_CLK_UNHALTED_CORE | FIXC1 | 1167125701 | | CPU_CLK_UNHALTED_REF | FIXC2 | 1167146162 | | BR_INST_RETIRED_ALL_BRANCHES | PMC0 | 372952366 | | BR_MISP_RETIRED_ALL_BRANCHES | PMC1 | 14720 | +------------------------------+---------+------------+ +----------------------------+--------------+ | Metric | Core 1 | +----------------------------+--------------+ | Runtime (RDTSC) [s] | 0.4584 | | Runtime unhalted [s] | 0.4504 | | Clock [MHz] | 2591.5345 | | CPI | 0.4678 | | Branch rate | 0.1495 | | Branch misprediction rate | 5.899380e-06 | | Branch misprediction ratio | 3.946885e-05 | | Instructions per branch | 6.6903 | +----------------------------+--------------+ 131
134. Likwid: Branch (Mis)Prediction Example $ likwid-perfctr -C S0:1 -g BRANCH -f ./BP 10000000 2 -------------------------------------------------------------------------------- CPU name: Intel(R) Core(TM) i7-3720QM CPU @ 2.60GHz CPU type: Intel Core IvyBridge processor CPU clock: 2.59 GHz -------------------------------------------------------------------------------- n = 10000000 type = 2 1.3448e+07 0.509917s wall, 0.510000s user + 0.000000s system = 0.510000s CPU (100.0%) -------------------------------------------------------------------------------- Group 1: BRANCH +------------------------------+---------+------------+ | Event | Counter | Core 1 | +------------------------------+---------+------------+ | INSTR_RETIRED_ANY | FIXC0 | 3191479747 | | CPU_CLK_UNHALTED_CORE | FIXC1 | 2264945099 | | CPU_CLK_UNHALTED_REF | FIXC2 | 2264967068 | | BR_INST_RETIRED_ALL_BRANCHES | PMC0 | 468135649 | | BR_MISP_RETIRED_ALL_BRANCHES | PMC1 | 15326586 | +------------------------------+---------+------------+ +----------------------------+-----------+ | Metric | Core 1 | +----------------------------+-----------+ | Runtime (RDTSC) [s] | 0.8822 | | Runtime unhalted [s] | 0.8740 | | Clock [MHz] | 2591.5589 | | CPI | 0.7097 | | Branch rate | 0.1467 | | Branch misprediction rate | 0.0048 | | Branch misprediction ratio | 0.0327 | | Instructions per branch | 6.8174 | +----------------------------+-----------+ 132
135. Perf: Branch (Mis)Prediction Example $ perf stat -e branches,branch-misses -r 10 ./BP 10000000 0 Performance counter stats for './BP 10000000 0' (10 runs): 374,121,213 branches ( +- 0.02% ) 23,260 branch-misses # 0.01% of all branches ( +- 0.35% ) 0.460392835 seconds time elapsed ( +- 0.50% ) $ perf stat -e branches,branch-misses -r 10 ./BP 10000000 1 Performance counter stats for './BP 10000000 1' (10 runs): 374,040,282 branches ( +- 0.01% ) 23,124 branch-misses # 0.01% of all branches ( +- 0.45% ) 0.457583418 seconds time elapsed ( +- 0.04% ) $ perf stat -e branches,branch-misses -r 10 ./BP 10000000 2 Performance counter stats for './BP 10000000 2' (10 runs): 469,331,762 branches ( +- 0.01% ) 15,326,501 branch-misses # 3.27% of all branches ( +- 0.01% ) 0.884858777 seconds time elapsed ( +- 0.30% ) 133
136. Sniper The Sniper Multi-Core Simulator http://snipersim.org/ 134
137. Sniper: Branch (Mis)Prediction Example CPI stack: never taken 135
138. Sniper: Branch (Mis)Prediction Example CPI stack: always taken 136
139. Sniper: Branch (Mis)Prediction Example CPI stack: randomly taken 137
140. Sniper: Branch (Mis)Prediction Example CPI graph: never taken 138
141. Sniper: Branch (Mis)Prediction Example CPI graph: always taken 139
142. Sniper: Branch (Mis)Prediction Example CPI graph: randomly taken 140
143. Sniper: Branch (Mis)Prediction Example CPI graph (detailed): always taken 141
144. Sniper: Branch (Mis)Prediction Example CPI graph (detailed): randomly taken 142
145. Branch Prediction & Speculative Execution D. Sima, "Decisive aspects in the evolution of microprocessors", Proceedings of the IEEE, vol. 92, pp. 1896-1926, 2004 143
146. Block Enlargement Fisher, J. A. (1983). "Very Long Instruction Word architectures and the ELI-512." Proceedings of the 10th Annual International Symposium on Computer Architecture. 144
147. Block Enlargement Joseph A. Fisher and John J. O'Donnell, "VLIW Machines: Multiprocessors We Can Actually Program," CompCon 84 Proceedings, pp. 299-305, IEEE, 1984. 145
148. Branch Predictability • takenness rate? 146
149. Branch Predictability • takenness rate? • transition rate? 146
150. Branch Predictability • takenness rate? • transition rate? • compare: 146
151. Branch Predictability • takenness rate? • transition rate? • compare: • 01010101 (i % 2) 146
152. Branch Predictability • takenness rate? • transition rate? • compare: • 01010101 (i % 2) • 01101101 (i % 3) 146
153. Branch Predictability • takenness rate? • transition rate? • compare: • 01010101 (i % 2) • 01101101 (i % 3) • 10101010 !(i % 2) 146
154. Branch Predictability • takenness rate? • transition rate? • compare: • 01010101 (i % 2) • 01101101 (i % 3) • 10101010 !(i % 2) • 10010010 !(i % 3) 146
155. Branch Predictability • takenness rate? • transition rate? • compare: • 01010101 (i % 2) • 01101101 (i % 3) • 10101010 !(i % 2) • 10010010 !(i % 3) • 00110011 (i / 2) % 2 146
156. Branch Predictability • takenness rate? • transition rate? • compare: • 01010101 (i % 2) • 01101101 (i % 3) • 10101010 !(i % 2) • 10010010 !(i % 3) • 00110011 (i / 2) % 2 • 00011100 (i / 3) % 2 146
157. Branch Predictability • takenness rate? • transition rate? • compare: • 01010101 (i % 2) • 01101101 (i % 3) • 10101010 !(i % 2) • 10010010 !(i % 3) • 00110011 (i / 2) % 2 • 00011100 (i / 3) % 2 • what they have in common: 146
158. Branch Predictability • takenness rate? • transition rate? • compare: • 01010101 (i % 2) • 01101101 (i % 3) • 10101010 !(i % 2) • 10010010 !(i % 3) • 00110011 (i / 2) % 2 • 00011100 (i / 3) % 2 • what they have in common: • all predictable! 146
159. Branch Predictability & Marker API https://github.com/RRZE-HPC/likwid/wiki/likwid-perfctr#using- the-marker-api https://github.com/RRZE-HPC/likwid/wiki/TutorialMarkerC g++ -Ofast -march=native source.cpp -o application -std=c++14 -DLIKWID_PERFMON -lpthread -llikwid likwid-perfctr -f -C 0-3 -g BRANCH -m ./application #include <likwid.h> // . . . LIKWID_MARKER_START("branch"); // branch code LIKWID_MARKER_STOP("branch"); 147
160. Branch Entropy linear entropy: EL(p) = 2 × min(p, 1 − p) intuition: miss rate proportional to the probability of the least frequent outcome 148
161. Branch Takenness Probability Sander De Pestel, Stijn Eyerman and Lieven Eeckhout, "Micro-Architecture Independent Branch Behavior Characterization", IEEE International Symposium on Performance Analysis of Systems and Software (ISPASS), Philadelphia, March 2015. 149
162. Branch Entropy & Miss Rate: Linear Relationship Sander De Pestel, Stijn Eyerman and Lieven Eeckhout, "Micro-Architecture Independent Branch Behavior Characterization", IEEE International Symposium on Performance Analysis of Systems and Software (ISPASS), Philadelphia, March 2015. 150
163. Branches & Expectations: Code I #include <chrono> #include <cmath> #include <cstdint> #include <cstdlib> #include <iostream> #include <iterator> #include <numeric> #include <random> #include <string> #include <vector> #define likely(x) (__builtin_expect(!!(x), 1)) #define unlikely(x) (__builtin_expect(!!(x), 0)) #define unpredictable(x) (__builtin_unpredictable((x))) 151
164. Branches & Expectations: Code II using T = int; void f(T z, T & x, T & y) { ((z < 0) ? x : y) = 5; } void generate_never(std::size_t n, std::vector<T> & zs) { zs.reserve(n); static std::mt19937 g(1); std::uniform_int_distribution<T> z(10, 19); for (std::size_t i = 0; i != n; ++i) zs.push_back(z(g)); return; } 152
165. Branches & Expectations: Code III void generate_always(std::size_t n, std::vector<T> & zs) { zs.reserve(n); static std::mt19937 g(1); std::uniform_int_distribution<T> z(-19, -10); for (std::size_t i = 0; i != n; ++i) zs.push_back(z(g)); return; } void generate_random(std::size_t n, std::vector<T> & zs) { zs.reserve(n); static std::mt19937 g(1); std::uniform_int_distribution<T> z(-5, 4); for (std::size_t i = 0; i != n; ++i) zs.push_back(z(g)); return; } 153
166. Branches & Expectations: Code IV int main(int argc, char * argv[]) { // sample size const std::size_t n = (argc > 1) ? std::atoll(argv[1]) : 1000; std::cout << "n = " << n << '\n'; // takenness predictability type // 0: never; 1: always; 2: random const std::size_t type = (argc > 2) ? std::atoll(argv[2]) : 0; std::cout << "type = " << type << '\t'; std::vector<T> xs(n), ys(n), zs; if (type == 0) { std::cout << "never"; generate_never(n, zs); } else if (type == 1) { std::cout << "always"; generate_always(n, zs); } else if (type == 2) { std::cout << "random"; generate_random(n, zs); } endl(std::cout); 154
167. Branches & Expectations: Code V const auto time_start = std::chrono::steady_clock::now(); T sum = 0; for (std::size_t i = 0; i != n; ++i) { f(zs[i], xs[i], ys[i]); } const auto time_end = std::chrono::steady_clock::now(); std::chrono::duration<double> duration = time_end - time_start; std::cout << "duration: " << duration.count() << '\n'; endl(std::cout); std::cout << "sum(xs): " << accumulate(begin(xs), end(xs), T{}) << '\n'; std::cout << "sum(ys): " << accumulate(begin(ys), end(ys), T{}) << '\n'; } 155
168. Branches & Expectations: Compiling & Timing g++ -ggdb -std=c++14 -march=native -Ofast ./branches.cpp -o branches_g clang++ -ggdb -std=c++14 -march=native -Ofast ./branches.cpp -o branches_c time ./branches_g 1000000 0 time ./branches_g 1000000 1 time ./branches_g 1000000 2 time ./branches_c 1000000 0 time ./branches_c 1000000 1 time ./branches_c 1000000 2 156
169. Branches & Expectations: Timings (GCC) $ time ./branches_g 1000000 0 n = 1000000 type = 0 never duration: 0.00082991 sum(xs): 0 sum(ys): 5000000 real 0m0.034s user 0m0.033s sys 0m0.003s $ time ./branches_g 1000000 1 n = 1000000 type = 1 always duration: 0.000839488 sum(xs): 5000000 sum(ys): 0 real 0m0.031s user 0m0.030s sys 0m0.000s $ time ./branches_g 1000000 2 n = 1000000 type = 2 random duration: 0.0052968 sum(xs): 2498105 sum(ys): 2501895 real 0m0.038s user 0m0.033s sys 0m0.003s 157
170. Branches & Expectations: Timings (Clang) $ time ./branches_c 1000000 0 n = 1000000 type = 0 never duration: 0.00091161 sum(xs): 0 sum(ys): 5000000 real 0m0.036s user 0m0.033s sys 0m0.000s $ time ./branches_c 1000000 1 n = 1000000 type = 1 always duration: 0.000765925 sum(xs): 5000000 sum(ys): 0 real 0m0.036s user 0m0.033s sys 0m0.000s $ time ./branches_c 1000000 2 n = 1000000 type = 2 random duration: 0.00554585 sum(xs): 2498105 sum(ys): 2501895 real 0m0.041s user 0m0.040s sys 0m0.000s 158
171. So many performance events, so little time "So many performance events, so little time," Gerd Zellweger, Denny Lin, Timothy Roscoe. Proceedings of the 7th Asia-Pacific Workshop on Systems (APSys, Hong Kong, China, August 2016). 159
172. Hierarchical cycle accounting Andrzej Nowak, David Levinthal, Willy Zwaenepoel: "Hierarchical cycle accounting: a new method for application performance tuning." ISPASS 2015. https://github.com/David-Levinthal/gooda 160
173. Top-down Microarchitecture Analysis Method (TMAM) https://github.com/andikleen/pmu-tools/wiki/toplev-manual https://sites.google.com/site/analysismethods/yasin-pubs "A Top-Down Method for Performance Analysis and Counters Architecture," Ahmad Yasin. In IEEE International Symposium on Performance Analysis of Systems and Software, ISPASS 2014. 161
174. TMAM: Bottlenecks "A Top-Down Method for Performance Analysis and Counters Architecture," Ahmad Yasin. In IEEE International Symposium on Performance Analysis of Systems and Software, ISPASS 2014. 162
175. TMAM: Breakdown "A Top-Down Method for Performance Analysis and Counters Architecture," Ahmad Yasin. In IEEE International Symposium on Performance Analysis of Systems and Software, ISPASS 2014. 163
176. TMAM: Meaning Updates: https://download.01.org/perfmon/ "A Top-Down Method for Performance Analysis and Counters Architecture," Ahmad Yasin. In IEEE International Symposium on Performance Analysis of Systems and Software, ISPASS 2014. 164
177. Branches & Expectations: TMAM, Level 1 (GCC) $ ~/builds/pmu-tools/toplev.py -l1 --long-desc --no-multiplex --show-sample --single-thread --user ./branches_g 1000000 2 Using level 1. RUN #1 of 1 perf stat -x\; -e '{cpu/event=0xc2,umask=0x2/u,cpu/event=0xe,umask=0x1/u,cpu/event=0xd,umask=0x3,cmask=1/u,cpu/ n = 1000000 type = 2 random duration: 0.00523105 sum(xs): 2498105 sum(ys): 2501895 FE Frontend_Bound: 53.92 % [100.00%] This category represents slots fraction where the processor's Frontend undersupplies its Backend. Frontend denotes the first part of the processor core responsible to fetch operations that are executed later on by the Backend part. Within the Frontend, a branch predictor predicts the next address to fetch, cache-lines are fetched from the memory subsystem, parsed into instructions, and lastly decoded into micro-ops (uops). Ideally the Frontend can issue 4 uops every cycle to the Backend. Frontend Bound denotes unutilized issue-slots when there is no Backend stall; i.e. bubbles where Frontend delivered no uops while Backend could have accepted them. For example, stalls due to instruction-cache misses would be categorized under Frontend Bound. Sampling: perf record -g -e cycles:pp:u -o perf.data ./branches_g 1000000 2 165
178. Branches & Expectations: TMAM, Level 2 (GCC) $ ~/builds/pmu-tools/toplev.py -l2 --long-desc --no-multiplex --show-sample --single-thread --user ./branches_g 1000000 2 Using level 2. RUN #1 of 2 perf stat -x\; -e '{cpu/event=0x9c,umask=0x1/u,cpu/event=0xc3,umask=0x1,edge=1,cmask=1/u,cpu/event=0xc2,umask=0x2/u,cpu/event=0xe,umask=0x1/u,cycles:u,cpu/event=0x79,umask=0x30/u,cpu/event=0x9c,umask=0x1 n = 1000000 type = 2 random duration: 0.00528841 sum(xs): 2498105 sum(ys): 2501895 RUN #2 of 2 perf stat -x\; -e '{cpu/event=0xb1,umask=0x1,cmask=2/u,cpu/event=0xa2,umask=0x8/u,cpu/event=0xb1,umask=0x1,cmask=1/u,cpu/event=0xa3,umask=0x6,cmask=6/u,cpu/event=0x9c,umask=0x1,cmask=4/u,instructions:u,c n = 1000000 type = 2 random duration: 0.00550316 sum(xs): 2498105 sum(ys): 2501895 FE Frontend_Bound: 53.94 % [100.00%] This category represents slots fraction where the processor's Frontend undersupplies its Backend. Frontend denotes the first part of the processor core responsible to fetch operations that are executed later on by the Backend part. Within the Frontend, a branch predictor predicts the next address to fetch, cache-lines are fetched from the memory subsystem, parsed into instructions, and lastly decoded into micro-ops (uops). Ideally the Frontend can issue 4 uops every cycle to the Backend. Frontend Bound denotes unutilized issue-slots when there is no Backend stall; i.e. bubbles where Frontend delivered no uops while Backend could have accepted them. For example, stalls due to instruction-cache misses would be categorized under Frontend Bound. FE Frontend_Bound.Frontend_Latency: 47.54 % [100.00%] This metric represents slots fraction the CPU was stalled due to Frontend latency issues. For example, instruction- cache misses, iTLB misses or fetch stalls after a branch misprediction are categorized under Frontend Latency. In such cases, the Frontend eventually delivers no uops for some period. Sampling events: rs_events.empty_end:u RET Retiring.Microcode_Sequencer: 16.41 % [100.00%] This metric represents slots fraction the CPU was retiring uops fetched by the Microcode Sequencer (MS) unit. The MS is used for CISC instructions not supported by the default decoders (like repeat move strings, or CPUID), or by microcode assists used to address some operation modes (like in Floating Point assists). These cases can often be avoided.. Sampling events: idq.ms_uops:u Sampling: perf record -g -e cycles:pp:u,cpu/event=0x5e,umask=0x1,edge=1,inv=1,cmask=1,name=Frontend_Latency_RS_EVENTS_EMPTY_END,period=200003/u, cpu/event=0x79,umask=0x30,name=Microcode_Sequencer_IDQ_MS_UOPS,period=2000003/u -o perf.data ./branches_g 1000000 2 166
179. Branches & Expectations: TMAM, Level 2, perf (GCC) perf record -g -e cycles:pp, cpu/event=0x5e,umask=0x1,edge=1,inv=1,cmask=1,name=Frontend_Latency_RS_EVENTS_EMPTY_END,period -o perf.data ./branches_g 1000000 2 perf report -Mintel 167
180. Branches & Expectations: TMAM, Level 1 (Clang) $ ~/builds/pmu-tools/toplev.py -l1 --long-desc --no-multiplex --show-sample --single-thread --user ./branches_c 1000000 2 Using level 1. RUN #1 of 1 perf stat -x\; -e '{cpu/event=0xc2,umask=0x2/u,cpu/event=0xe,umask=0x1/u,cpu/event=0xd,umask=0x3,cmask=1/u,cpu/ n = 1000000 type = 2 random duration: 0.00555177 sum(xs): 2498105 sum(ys): 2501895 FE Frontend_Bound: 45.53 % [100.00%] This category represents slots fraction where the processor's Frontend undersupplies its Backend. Frontend denotes the first part of the processor core responsible to fetch operations that are executed later on by the Backend part. Within the Frontend, a branch predictor predicts the next address to fetch, cache-lines are fetched from the memory subsystem, parsed into instructions, and lastly decoded into micro-ops (uops). Ideally the Frontend can issue 4 uops every cycle to the Backend. Frontend Bound denotes unutilized issue-slots when there is no Backend stall; i.e. bubbles where Frontend delivered no uops while Backend could have accepted them. For example, stalls due to instruction-cache misses would be categorized under Frontend Bound. Sampling: perf record -g -e cycles:pp:u -o perf.data ./branches_c 1000000 2 168
181. Branches & Expectations: TMAM, Level 2 (Clang) $ ~/builds/pmu-tools/toplev.py -l2 --long-desc --no-multiplex --show-sample --single-thread --user ./branches_c 1000000 2 Using level 2. RUN #1 of 2 perf stat -x\; -e '{cpu/event=0x9c,umask=0x1/u,cpu/event=0xc3,umask=0x1,edge=1,cmask=1/u,cpu/event=0xc2,umask=0x2/u,cpu/event=0xe,umask=0x1/u,cycles:u,cpu/event=0x79,umask=0x30/u,cpu/event=0x9c,umask n = 1000000 type = 2 random duration: 0.0055571 sum(xs): 2498105 sum(ys): 2501895 RUN #2 of 2 perf stat -x\; -e '{cpu/event=0xb1,umask=0x1,cmask=2/u,cpu/event=0xa2,umask=0x8/u,cpu/event=0xb1,umask=0x1,cmask=1/u,cpu/event=0xa3,umask=0x6,cmask=6/u,cpu/event=0x9c,umask=0x1,cmask=4/u,instructions n = 1000000 type = 2 random duration: 0.00556777 sum(xs): 2498105 sum(ys): 2501895 FE Frontend_Bound: 45.54 % [100.00%] This category represents slots fraction where the processor's Frontend undersupplies its Backend. Frontend denotes the first part of the processor core responsible to fetch operations that are executed later on by the Backend part. Within the Frontend, a branch predictor predicts the next address to fetch, cache-lines are fetched from the memory subsystem, parsed into instructions, and lastly decoded into micro-ops (uops). Ideally the Frontend can issue 4 uops every cycle to the Backend. Frontend Bound denotes unutilized issue-slots when there is no Backend stall; i.e. bubbles where Frontend delivered no uops while Backend could have accepted them. For example, stalls due to instruction-cache misses would be categorized under Frontend Bound. FE Frontend_Bound.Frontend_Latency: 39.20 % [100.00%] This metric represents slots fraction the CPU was stalled due to Frontend latency issues. For example, instruction- cache misses, iTLB misses or fetch stalls after a branch misprediction are categorized under Frontend Latency. In such cases, the Frontend eventually delivers no uops for some period. Sampling events: rs_events.empty_end:u RET Retiring.Microcode_Sequencer: 15.18 % [100.00%] This metric represents slots fraction the CPU was retiring uops fetched by the Microcode Sequencer (MS) unit. The MS is used for CISC instructions not supported by the default decoders (like repeat move strings, or CPUID), or by microcode assists used to address some operation modes (like in Floating Point assists). These cases can often be avoided.. Sampling events: idq.ms_uops:u Sampling: perf record -g -e cycles:pp:u,cpu/event=0x5e,umask=0x1,edge=1,inv=1,cmask=1,name=Frontend_Latency_RS_EVENTS_EMPTY_END,period=200003/u,cpu/event=0x79,umask=0x30,name=Microcode_Sequencer_IDQ_MS_UOPS,pe 169
182. Branches & Expectations: TMAM, Level 2, perf (Clang) perf record -g -e cycles:pp, cpu/event=0x5e,umask=0x1,edge=1,inv=1,cmask=1,name=Frontend_Latency_RS_EVENTS_EMPTY_END,period=200003/u -o perf.data ./branches_c 1000000 2 perf report -Mintel 170
183. Virtual Functions & Indirect Branches: Code I #include <chrono> #include <cmath> #include <cstdint> #include <cstdlib> #include <iostream> #include <iterator> #include <memory> #include <numeric> #include <random> #include <string> #include <vector> #define str(s) #s #define likely(x) (__builtin_expect(!!(x), 1)) #define unlikely(x) (__builtin_expect(!!(x), 0)) #define unpredictable(x) (__builtin_unpredictable(!!(x))) 171
184. Virtual Functions & Indirect Branches: Code II using T = int; struct base { virtual T f() const { return 0; } }; struct derived_taken : base { T f() const override { return -1; } }; struct derived_untaken : base { T f() const override { return 1; } }; void f(const base & b, T & x, T & y) { ((b.f() < 0) ? x : y) = 119; } void generate_never(std::size_t n, std::vector<std::unique_ptr<base>> & zs) { zs.reserve(n); for (std::size_t i = 0; i != n; ++i) zs.push_back(std::make_unique<derived_untaken>()); return; 172
185. Virtual Functions & Indirect Branches: Code III } void generate_always(std::size_t n, std::vector<std::unique_ptr<base>> & zs { zs.reserve(n); for (std::size_t i = 0; i != n; ++i) zs.push_back(std::make_unique<derived_taken>()); return; } void generate_random(std::size_t n, std::vector<std::unique_ptr<base>> & zs { zs.reserve(n); static std::mt19937 g(1); std::bernoulli_distribution z(0.5); for (std::size_t i = 0; i != n; ++i) { if (z(g)) zs.emplace_back(std::make_unique<derived_taken>()); else zs.emplace_back(std::make_unique<derived_untaken>()); 173
186. Virtual Functions & Indirect Branches: Code IV } return; } int main(int argc, char * argv[]) { // sample size const std::size_t n = (argc > 1) ? std::atoll(argv[1]) : 1000; std::cout << "n = " << n << '\n'; // takenness predictability type // 0: never; 1: always; 2: random std::size_t type = (argc > 2) ? std::atoll(argv[2]) : 0; std::cout << "type = " << type << '\t'; std::vector<T> xs(n), ys(n); std::vector<std::unique_ptr<base>> zs; if (type == 0) { std::cout << "never"; generate_never(n, zs); } else if (type == 1) { std::cout << "always"; generate_always(n, zs); } 174
187. Virtual Functions & Indirect Branches: Code V else if (type == 2) { std::cout << "random"; generate_random(n, zs); } endl(std::cout); auto time_start = std::chrono::steady_clock::now(); T sum = 0; for (std::size_t i = 0; i != n; ++i) { f(*zs[i], xs[i], ys[i]); } auto time_end = std::chrono::steady_clock::now(); std::chrono::duration<double> duration = time_end - time_start; std::cout << "duration: " << duration.count() << '\n'; endl(std::cout); std::cout << "sum(xs): " << accumulate(begin(xs), end(xs), T{}) << '\n'; std::cout << "sum(ys): " << accumulate(begin(ys), end(ys), T{}) << '\n'; } 175
188. Virtual Functions & Indirect Branches: Compiling & Timing g++ -ggdb -std=c++14 -march=native -Ofast ./vbranches.cpp -o vbranches_g clang++ -ggdb -std=c++14 -march=native -Ofast ./vbranches.cpp -o vbranches_c time ./vbranches_g 10000000 0 time ./vbranches_g 10000000 1 time ./vbranches_g 10000000 2 time ./vbranches_c 10000000 0 time ./vbranches_c 10000000 1 time ./vbranches_c 10000000 2 176
189. Virtual Functions & Indirect Branches: Timings (GCC) $ time ./vbranches_g 10000000 0 n = 10000000 type = 0 never duration: 0.0338749 sum(xs): 0 sum(ys): 1190000000 real 0m0.645s user 0m0.573s sys 0m0.070s $ time ./vbranches_g 10000000 1 n = 10000000 type = 1 always duration: 0.0406144 sum(xs): 1190000000 sum(ys): 0 real 0m0.648s user 0m0.563s sys 0m0.083s $ time ./vbranches_g 10000000 2 n = 10000000 type = 2 random duration: 0.131803 sum(xs): 595154105 sum(ys): 594845895 real 0m0.956s user 0m0.863s sys 0m0.090s 177
190. Branches & Expectations: Timings (Clang) $ time ./vbranches_c 10000000 0 n = 10000000 type = 0 never duration: 0.0314749 sum(xs): 0 sum(ys): 1190000000 real 0m0.623s user 0m0.530s sys 0m0.090s $ time ./vbranches_c 10000000 1 n = 10000000 type = 1 always duration: 0.0314727 sum(xs): 1190000000 sum(ys): 0 real 0m0.623s user 0m0.557s sys 0m0.063s $ time ./vbranches_c 10000000 2 n = 10000000 type = 2 random duration: 0.0854935 sum(xs): 595154105 sum(ys): 594845895 real 0m1.863s user 0m1.800s sys 0m0.063s 178
191. Virtual Functions & Indirect Branches: TMAM, Level 1 (GCC) $ ~/builds/pmu-tools/toplev.py -l1 --long-desc --no-multiplex --show-sample --single-thread --user ./vbranches_g 10000000 2 Using level 1. RUN #1 of 1 perf stat -x\; -e '{cpu/event=0xc2,umask=0x2/u,cpu/event=0xe,umask=0x1/u,cpu/event=0xd,umask=0x3,cmask=1/u,cpu/event=0x9c,umask=0x1/u,cycles:u}' n = 10000000 type = 2 random duration: 0.131386 sum(xs): 595154105 sum(ys): 594845895 FE Frontend_Bound: 35.96 % [100.00%] This category represents slots fraction where the processor's Frontend undersupplies its Backend. Frontend denotes the first part of the processor core responsible to fetch operations that are executed later on by the Backend part. Within the Frontend, a branch predictor predicts the next address to fetch, cache-lines are fetched from the memory subsystem, parsed into instructions, and lastly decoded into micro-ops (uops). Ideally the Frontend can issue 4 uops every cycle to the Backend. Frontend Bound denotes unutilized issue-slots when there is no Backend stall; i.e. bubbles where Frontend delivered no uops while Backend could have accepted them. For example, stalls due to instruction-cache misses would be categorized under Frontend Bound. BAD Bad_Speculation: 12.98 % [100.00%] This category represents slots fraction wasted due to incorrect speculations. This include slots used to issue uops that do not eventually get retired and slots for which the issue-pipeline was blocked due to recovery from earlier incorrect speculation. For example, wasted work due to miss- predicted branches are categorized under Bad Speculation category. Incorrect data speculation followed by Memory Ordering Nukes is another example. Sampling: perf record -g -e cycles:pp:u -o perf.data ./vbranches_g 10000000 2 179
192. Virtual Functions & Indirect Branches: TMAM, Level 2 (GCC) $ ~/builds/pmu-tools/toplev.py -l2 --long-desc --no-multiplex --show-sample --single-thread --user ./vbranches_g 10000000 2 Using level 2. RUN #1 of 2 perf stat -x\; -e '{cpu/event=0x9c,umask=0x1/u,cpu/event=0xc3,umask=0x1,edge=1,cmask=1/u,cpu/event=0xc2,umask=0x2/u,cpu/event=0xe,umask=0x1/u,cycles:u,cpu/event=0x79,umask=0x30/u,cpu/event=0x9c,umask=0x1,cmask=4/u,cpu/event=0xc5,umask=0x0/u,cp n = 10000000 type = 2 random duration: 0.131247 sum(xs): 595154105 sum(ys): 594845895 RUN #2 of 2 perf stat -x\; -e '{cpu/event=0xb1,umask=0x1,cmask=2/u,cpu/event=0xa2,umask=0x8/u,cpu/event=0xb1,umask=0x1,cmask=1/u,cpu/event=0xa3,umask=0x6,cmask=6/u,cpu/event=0x9c,umask=0x1,cmask=4/u,instructions:u,cycles:u,cpu/event=0xa3,umask=0x4,cmask=4 n = 10000000 type = 2 random duration: 0.131361 sum(xs): 595154105 sum(ys): 594845895 FE Frontend_Bound: 36.02 % [100.00%] This category represents slots fraction where the processor's Frontend undersupplies its Backend. Frontend denotes the first part of the processor core responsible to fetch operations that are executed later on by the Backend part. Within the Frontend, a branch predictor predicts the next address to fetch, cache-lines are fetched from the memory subsystem, parsed into instructions, and lastly decoded into micro-ops (uops). Ideally the Frontend can issue 4 uops every cycle to the Backend. Frontend Bound denotes unutilized issue-slots when there is no Backend stall; i.e. bubbles where Frontend delivered no uops while Backend could have accepted them. For example, stalls due to instruction-cache misses would be categorized under Frontend Bound. FE Frontend_Bound.Frontend_Latency: 17.41 % [100.00%] This metric represents slots fraction the CPU was stalled due to Frontend latency issues. For example, instruction- cache misses, iTLB misses or fetch stalls after a branch misprediction are categorized under Frontend Latency. In such cases, the Frontend eventually delivers no uops for some period. Sampling events: rs_events.empty_end:u BAD Bad_Speculation: 12.92 % [100.00%] This category represents slots fraction wasted due to incorrect speculations. This include slots used to issue uops that do not eventually get retired and slots for which the issue-pipeline was blocked due to recovery from earlier incorrect speculation. For example, wasted work due to miss- predicted branches are categorized under Bad Speculation category. Incorrect data speculation followed by Memory Ordering Nukes is another example. BAD Bad_Speculation.Branch_Mispredicts: 12.75 % [100.00%] This metric represents slots fraction the CPU has wasted due to Branch Misprediction. These slots are either wasted by uops fetched from an incorrectly speculated program path, or stalls when the out-of-order part of the machine needs to recover its state from a speculative path.. Using profile feedback in the compiler may help. Please see the optimization manual for general strategies for addressing branch misprediction issues.. http://www.intel.com/content/www/us/en/architecture-and- technology/64-ia-32-architectures-optimization-manual.html Sampling events: br_misp_retired.all_branches:u Sampling: perf record -g -e cycles:pp:u,cpu/event=0xc5,umask=0x0,name=Branch_Mispredicts_BR_MISP_RETIRED_ALL_BRANCHES,period=400009/ppu,cpu/event=0x5e,umask=0x1,edge=1,inv=1,cmask=1,name=Frontend_Latency_RS_EVENTS_EMPTY_END,period=200003/u -o perf.data . 180
193. Virtual Functions & Indirect Branches: TMAM, Level 3 (GCC) $ ~/builds/pmu-tools/toplev.py -l3 --long-desc --no-multiplex --show-sample --single-thread --user ./vbranches_g 10000000 2 n = 10000000 type = 2 random duration: 0.13145 sum(xs): 595154105 sum(ys): 594845895 FE Frontend_Bound: 35.96 % [100.00%] This category represents slots fraction where the processor's Frontend undersupplies its Backend. Frontend denotes the first part of the processor core responsible to fetch operations that are executed later on by the Backend part. Within the Frontend, a branch predictor predicts the next address to fetch, cache-lines are fetched from the memory subsystem, parsed into instructions, and lastly decoded into micro-ops (uops). Ideally the Frontend can issue 4 uops every cycle to the Backend. Frontend Bound denotes unutilized issue-slots when there is no Backend stall; i.e. bubbles where Frontend delivered no uops while Backend could have accepted them. For example, stalls due to instruction-cache misses would be categorized under Frontend Bound. FE Frontend_Bound.Frontend_Latency: 17.44 % [100.00%] This metric represents slots fraction the CPU was stalled due to Frontend latency issues. For example, instruction- cache misses, iTLB misses or fetch stalls after a branch misprediction are categorized under Frontend Latency. In such cases, the Frontend eventually delivers no uops for some period. Sampling events: rs_events.empty_end:u FE Frontend_Bound.Frontend_Latency.Branch_Resteers: 5.69 % [100.00%] This metric represents cycles fraction the CPU was stalled due to Branch Resteers. Branch Resteers estimates the Frontend delay in fetching operations from corrected path, following all sorts of miss-predicted branches. For example, branchy code with lots of miss-predictions might get categorized under Branch Resteers. Note the value of this node may overlap with its siblings. Sampling events: br_misp_retired.all_branches:u BAD Bad_Speculation: 12.97 % [100.00%] This category represents slots fraction wasted due to incorrect speculations. This include slots used to issue uops that do not eventually get retired and slots for which the issue-pipeline was blocked due to recovery from earlier incorrect speculation. For example, wasted work due to miss- predicted branches are categorized under Bad Speculation category. Incorrect data speculation followed by Memory Ordering Nukes is another example. BAD Bad_Speculation.Branch_Mispredicts: 12.82 % [100.00%] This metric represents slots fraction the CPU has wasted due to Branch Misprediction. These slots are either wasted by uops fetched from an incorrectly speculated program path, or stalls when the out-of-order part of the machine needs to recover its state from a speculative path.. Using profile feedback in the compiler may help. Please see the optimization manual for general strategies for addressing branch misprediction issues.. http://www.intel.com/content/www/us/en/architecture-and- technology/64-ia-32-architectures-optimization-manual.html Sampling events: br_misp_retired.all_branches:u Sampling: perf record -g -e cycles:pp, cpu/event=0xc5,umask=0x0,name=Branch_Resteers_BR_MISP_RETIRED_ALL_BRANCHES,period=400009/ppu, cpu/event=0xc5,umask=0x0,name=Branch_Mispredicts_BR_MISP_RETIRED_ALL_BRANCHES,period=400009/ppu, cpu/event=0x5e,umask=0x1,edge=1,inv=1,cmask=1,name=Frontend_Latency_RS_EVENTS_EMPTY_END,period=200003/u -o perf.data ./vbranches_g 10000000 2 181
194. Virtual Functions: TMAM, Level 3, perf (GCC) perf record -g -e cycles:pp, cpu/event=0xc5,umask=0x0,name=Branch_Resteers_BR_MISP_RETIRED_ALL_BRANCHES,period=400009/ppu, cpu/event=0xc5,umask=0x0,name=Branch_Mispredicts_BR_MISP_RETIRED_ALL_BRANCHES,period=400009/ppu, cpu/event=0x5e,umask=0x1,edge=1,inv=1,cmask=1,name=Frontend_Latency_RS_EVENTS_EMPTY_END,period=2 -o perf.data ./vbranches_cmov_xy_g 10000000 2 perf report -Mintel 182
195. Virtual Functions & Indirect Branches: TMAM, Level 1 (Clang) $ ~/builds/pmu-tools/toplev.py -l1 --long-desc --no-multiplex --show-sample --single-thread --user ./vbranches_c 10000000 2 Using level 1. RUN #1 of 1 perf stat -x\; -e '{cpu/event=0xc2,umask=0x2/u,cpu/event=0xe,umask=0x1/u,cpu/event=0xd,umask=0x3,cmask=1/u,cpu/ n = 10000000 type = 2 random duration: 0.0858722 sum(xs): 595154105 sum(ys): 594845895 FE Frontend_Bound: 37.66 % [100.00%] This category represents slots fraction where the processor's Frontend undersupplies its Backend. Frontend denotes the first part of the processor core responsible to fetch operations that are executed later on by the Backend part. Within the Frontend, a branch predictor predicts the next address to fetch, cache-lines are fetched from the memory subsystem, parsed into instructions, and lastly decoded into micro-ops (uops). Ideally the Frontend can issue 4 uops every cycle to the Backend. Frontend Bound denotes unutilized issue-slots when there is no Backend stall; i.e. bubbles where Frontend delivered no uops while Backend could have accepted them. For example, stalls due to instruction-cache misses would be categorized under Frontend Bound. Sampling: perf record -g -e cycles:pp:u -o perf.data ./vbranches_c 10000000 2 183
196. Virtual Functions & Indirect Branches: TMAM, Level 2 (Clang) $ ~/builds/pmu-tools/toplev.py -l2 --long-desc --no-multiplex --show-sample --single-thread --user ./vbranches_c 10000000 2 Using level 2. RUN #1 of 2 perf stat -x\; -e '{cpu/event=0x9c,umask=0x1/u,cpu/event=0xc3,umask=0x1,edge=1,cmask=1/u,cpu/event=0xc2,umask=0x2/u,cpu/event=0xe,umask=0x1/u,cycles:u,cpu/event=0x79,umask=0x30/u,cpu/event=0x9c,umask n = 10000000 type = 2 random duration: 0.0859943 sum(xs): 595154105 sum(ys): 594845895 RUN #2 of 2 perf stat -x\; -e '{cpu/event=0xb1,umask=0x1,cmask=2/u,cpu/event=0xa2,umask=0x8/u,cpu/event=0xb1,umask=0x1,cmask=1/u,cpu/event=0xa3,umask=0x6,cmask=6/u,cpu/event=0x9c,umask=0x1,cmask=4/u,instructions n = 10000000 type = 2 random duration: 0.0861661 sum(xs): 595154105 sum(ys): 594845895 FE Frontend_Bound: 37.61 % [100.00%] This category represents slots fraction where the processor's Frontend undersupplies its Backend. Frontend denotes the first part of the processor core responsible to fetch operations that are executed later on by the Backend part. Within the Frontend, a branch predictor predicts the next address to fetch, cache-lines are fetched from the memory subsystem, parsed into instructions, and lastly decoded into micro-ops (uops). Ideally the Frontend can issue 4 uops every cycle to the Backend. Frontend Bound denotes unutilized issue-slots when there is no Backend stall; i.e. bubbles where Frontend delivered no uops while Backend could have accepted them. For example, stalls due to instruction-cache misses would be categorized under Frontend Bound. FE Frontend_Bound.Frontend_Latency: 26.64 % [100.00%] This metric represents slots fraction the CPU was stalled due to Frontend latency issues. For example, instruction- cache misses, iTLB misses or fetch stalls after a branch misprediction are categorized under Frontend Latency. In such cases, the Frontend eventually delivers no uops for some period. Sampling events: rs_events.empty_end:u RET Retiring.Microcode_Sequencer: 9.04 % [100.00%] This metric represents slots fraction the CPU was retiring uops fetched by the Microcode Sequencer (MS) unit. The MS is used for CISC instructions not supported by the default decoders (like repeat move strings, or CPUID), or by microcode assists used to address some operation modes (like in Floating Point assists). These cases can often be avoided.. Sampling events: idq.ms_uops:u Sampling: perf record -g -e cycles:pp:u,cpu/event=0x5e,umask=0x1,edge=1,inv=1,cmask=1,name=Frontend_Latency_RS_EVENTS_EMPTY_END,period=200003/u,cpu/event=0x79,umask=0x30,name=Microcode_Sequencer_IDQ_MS_UOPS,pe 184
197. Virtual Functions & Indirect Branches: TMAM, Level 3 (Clang) ~/builds/pmu-tools/toplev.py -l3 --long-desc --no-multiplex --show-sample --single-thread --user ./vbranches_c 10000000 2 sum(xs): 595154105 sum(ys): 594845895 FE Frontend_Bound: 37.65 % [100.00%] This category represents slots fraction where the processor's Frontend undersupplies its Backend. Frontend denotes the first part of the processor core responsible to fetch operations that are executed later on by the Backend part. Within the Frontend, a branch predictor predicts the next address to fetch, cache-lines are fetched from the memory subsystem, parsed into instructions, and lastly decoded into micro-ops (uops). Ideally the Frontend can issue 4 uops every cycle to the Backend. Frontend Bound denotes unutilized issue-slots when there is no Backend stall; i.e. bubbles where Frontend delivered no uops while Backend could have accepted them. For example, stalls due to instruction-cache misses would be categorized under Frontend Bound. FE Frontend_Bound.Frontend_Latency: 26.63 % [100.00%] This metric represents slots fraction the CPU was stalled due to Frontend latency issues. For example, instruction- cache misses, iTLB misses or fetch stalls after a branch misprediction are categorized under Frontend Latency. In such cases, the Frontend eventually delivers no uops for some period. Sampling events: rs_events.empty_end:u FE Frontend_Bound.Frontend_Latency.MS_Switches: 8.40 % [100.00%] This metric estimates the fraction of cycles when the CPU was stalled due to switches of uop delivery to the Microcode Sequencer (MS). Commonly used instructions are optimized for delivery by the DSB or MITE pipelines. Certain operations cannot be handled natively by the execution pipeline, and must be performed by microcode (small programs injected into the execution stream). Switching to the MS too often can negatively impact performance. The MS is designated to deliver long uop flows required by CISC instructions like CPUID, or uncommon conditions like Floating Point Assists when dealing with Denormals. Sampling events: idq.ms_switches:u RET Retiring.Microcode_Sequencer: 9.04 % [100.00%] This metric represents slots fraction the CPU was retiring uops fetched by the Microcode Sequencer (MS) unit. The MS is used for CISC instructions not supported by the default decoders (like repeat move strings, or CPUID), or by microcode assists used to address some operation modes (like in Floating Point assists). These cases can often be avoided.. Sampling events: idq.ms_uops:u Sampling: perf record -g -e cycles:pp:u, cpu/event=0x5e,umask=0x1,edge=1,inv=1,cmask=1,name=Frontend_Latency_RS_EVENTS_EMPTY_END,period=200003/u, cpu/event=0x79,umask=0x30,edge=1,cmask=1,name=MS_Switches_IDQ_MS_SWITCHES,period=2000003/u, cpu/event=0x79,umask=0x30,name=Microcode_Sequencer_IDQ_MS_UOPS,period=2000003/u -o perf.data ./vbranches_c 10000000 2 185
198. Virtual Functions: TMAM, Level 3, perf (Clang) perf record -g -e cycles:pp, cpu/event=0x5e,umask=0x1,edge=1,inv=1,cmask=1,name=Frontend_Latency_RS_EVENTS_EMPTY_END,period=2 -o perf.data ./vbranches_cmov_xy_c 10000000 2 perf report -Mintel 186
199. Branches vs. Predicated Execution https://github.com/mongodb-labs/disasm Interactive Disassembler GUI with optional Intel Architecture Code Analyzer (IACA) integration 187
200. Branches vs. Predicated Execution https://github.com/mongodb-labs/disasm Interactive Disassembler GUI with optional Intel Architecture Code Analyzer (IACA) integration 188
201. Compiler-Specific Built-in Functions GCC & Clang: __builtin_expect http://llvm.org/docs/BranchWeightMetadata.html#built-in- expect-instructions https://gcc.gnu.org/onlinedocs/gcc/Other-Builtins.html likely & unlikely https://kernelnewbies.org/FAQ/LikelyUnlikely Clang: __builtin_unpredictable http://clang.llvm.org/docs/LanguageExtensions.html#builtin- unpredictable 189
202. Branch Misprediction, Speculation, and Wrong-Path Execution J. Reineke et al., “A Definition and Classification of Timing Anomalies,” Proc. Int'l Workshop Worst Case Execution Time (WCET), 2006. 190
203. Branch Misprediction Penalty & Wrong-Path Execution Tejas S. Karkhanis and James E. Smith. 2004. "A First-Order Superscalar Processor Model." In Proceedings of the 31st annual international symposium on Computer architecture (ISCA '04). 191
204. The Curse of Multiple Granularities Seshadri, V. (2016). "Simple DRAM and Virtual Memory Abstractions to Enable Highly Efficient Memory Systems." CoRR, abs/1605.06483. 192
205. Word Granularity != Cache Line Granularity Seshadri, V. (2016). "Simple DRAM and Virtual Memory Abstractions to Enable Highly Efficient Memory Systems." CoRR, abs/1605.06483. 193
206. Shortcomings of Strided Access Patterns Seshadri, V. (2016). "Simple DRAM and Virtual Memory Abstractions to Enable Highly Efficient Memory Systems." CoRR, abs/1605.06483. 194
207. Pointer Chasing Example - Vector http://pythontutor.com/cpp.html https://github.com/pgbovine/opt-cpp-backend 195
208. Pointer Chasing Example - (Singly) Linked List 196
209. Pointer Chasing Example - Doubly Linked List 197
210. Pointer Chasing Example - Linked List - C++ #include <algorithm> #include <forward_list> #include <iterator> bool found(const std::forward_list<int> & list, int value) { return find(begin(list), end(list), value) != end(list); } int main() { std::forward_list<int> list {11, 22, 33, 44, 55}; return found(list, 42); } 198
211. Pointer Chasing Example - Linked List - ASM https://godbolt.org/g/rkzQ90 199
212. Pointer Chasing Example - Linked List - ASM (r2) http://rada.re/ 200
213. Pointer Chasing Example - Linked List - CFG (r2) 201
214. Pointer Chasing Example - Linked List - CFG (r2) radiff2 -g sym.found forward_list_app forward_list_app > forward_list_found.dot xdot forward_list_found.dot dot -Tpng -o forward_list_found.png forward_list_found.dot 202
215. Isolated & Clustered Cache Misses Miquel Moreto, Francisco J. Cazorla, Alex Ramirez, and Mateo Valero. 2008. "MLP-aware dynamic cache partitioning." In Proceedings of the 3rd international conference on High performance embedded architectures and compilers (HiPEAC'08). 203
216. Cache Miss Cost & Miss Clustering Thomas R. Puzak, A. Hartstein, P. G. Emma, V. Srinivasan, and Jim Mitchell. 2007. "An analysis of the effects of miss clustering on the cost of a cache miss." In Proceedings of the 4th international conference on Computing frontiers (CF '07). ACM, New York, NY, USA, 3-12.204
217. Cache Miss Penalty: Different STC due to different MLP MLP (memory-level parallelism) & STC (stall-time criticality) R. Das, O. Mutlu, T. Moscibroda and C. R. Das, "Application-aware prioritization mechanisms for on-chip networks," 2009 42nd Annual IEEE/ACM International Symposium on Microarchitecture (MICRO), New York, NY, 2009, pp. 280-291. 205
218. Skip Lists William Pugh. 1990. "Skip lists: a probabilistic alternative to balanced trees." Commun. ACM 33, 6, 668-676. 206
219. Jump Pointers S. Chen, P. B. Gibbons, and T. C. Mowry. “Improving Index Performance through Prefetching.” In Proc. of the 20th Annual ACM SIGMOD International Conference on Management of Data, 2001. 207
220. Prefetching Aggressiveness: Distance & Degree Sparsh Mittal. 2016. "A Survey of Recent Prefetching Techniques for Processor Caches." ACM Comput. Surv. 49, 2, Article 35. 208
221. Prefetching Timeliness Jaekyu Lee, Hyesoon Kim, and Richard Vuduc. 2012. "When Prefetching Works, When It Doesn’t, and Why." ACM Trans. Archit. Code Optim. 9, 1, Article 2. 209
222. Prefetches Classification Huaiyu Zhu, Yong Chen, and Xian-He Sun. 2010. "Timing local streams: improving timeliness in data prefetching." In Proceedings of the 24th ACM International Conference on Supercomputing (ICS '10). ACM, New York, NY, USA, 169-178. 210
223. Prefetching I #include <algorithm> #include <chrono> #include <cinttypes> #include <cstddef> #include <cstdio> #include <cstdlib> #include <future> #include <iterator> #include <memory> #include <random> struct point { double x, y, z; }; using T = point; 211
224. Prefetching II struct timing_result { double duration_initial; double duration_non_prefetched; double duration_degree; double sum_initial; double sum_non_prefetched; double sum_degree; }; timing_result chase(std::size_t n, bool shuffle, std::size_t d, bool prefet timing_result chase_result; std::vector<std::unique_ptr<T>> v; for (std::size_t i = 0; i != n; ++i) { v.emplace_back(new point{1. * i, 2. * i, 5.* i}); } if (shuffle) { std::mt19937 g(1); 212
225. Prefetching III std::shuffle(begin(v), end(v), g); } double sum = 0.0; auto time_start = std::chrono::steady_clock::now(); if (prefetch) { for (std::size_t i = 0; i != n; ++i) { __builtin_prefetch(v[i + d].get()); sum += std::exp(-v[i]->y); } } else { for (std::size_t i = 0; i != n; ++i) { sum += std::exp(-v[i]->y); } } auto time_end = std::chrono::steady_clock::now(); std::chrono::duration<double> duration = time_end - time_start; chase_result.duration_initial = duration.count(); chase_result.sum_initial = sum; 213
226. Prefetching IV sum = 0.0; time_start = std::chrono::steady_clock::now(); for (std::size_t i = 0; i != n; ++i) { sum += std::exp(-v[i]->y); } time_end = std::chrono::steady_clock::now(); duration = time_end - time_start; chase_result.duration_non_prefetched = duration.count(); chase_result.sum_non_prefetched = sum; sum = 0.0; time_start = std::chrono::steady_clock::now(); for (std::size_t i = 0; i != n; ++i) { __builtin_prefetch(v[i + d].get()); __builtin_prefetch(v[i + 2*d].get()); sum += std::exp(-v[i]->y); } time_end = std::chrono::steady_clock::now(); 214
227. Prefetching V duration = time_end - time_start; chase_result.duration_degree = duration.count(); chase_result.sum_degree = sum; return chase_result; } int main(int argc, char * argv[]) { // sample size const std::size_t n = (argc > 1) ? std::atoll(argv[1]) : 100; const bool shuffle = (argc > 2) ? std::atoi(argv[2]) : false; const std::size_t d = (argc > 3) ? std::atoll(argv[3]) : 3; const bool prefetch = (argc > 4) ? std::atoi(argv[4]) : false; const std::size_t threads_count = (argc > 5) ? std::atoll(argv[5]) : 4; printf("size: %zu \n", n); printf("shuffle: %d \n", shuffle); printf("distance: %zu \n", d); printf("prefetch: %d \n", prefetch); 215
228. Prefetching VI printf("threads_count: %d \n", threads_count); const auto thread_work = [n, shuffle, d, prefetch]() { return chase(n, shuffle, d, prefetch); }; std::vector<std::future<timing_result>> results; for (std::size_t thread = 0; thread != threads_count; ++thread) results.emplace_back(std::async(std::launch::async, thread_work)); for (auto && future_result : results) if (future_result.valid()) future_result.wait(); std::vector<double> timings_initial, timings_non_prefetched, timings_degree; for (auto && future_result : results) { timing_result chase_result = future_result.get(); timings_initial.push_back(chase_result.duration_initial); 216
229. Prefetching VII timings_non_prefetched.push_back(chase_result.duration_non_prefetched); timings_degree.push_back(chase_result.duration_degree); } const auto timings_initial_minmax = std::minmax_element(begin(timings_initial), end(timings_initial)); const auto timings_non_prefetched_minmax = std::minmax_element(begin(timings_non_prefetched), end(timings_non_pref const auto timings_degree_minmax = std::minmax_element(begin(timings_degree), end(timings_degree)); printf(prefetch ? "prefetched" : "non-prefetched"); printf(" initial duration: [%g, %g] \n", *timings_initial_minmax.first, *timings_initial_minmax.second); printf("non-prefetched duration: [%g, %g] \n", *timings_non_prefetched_mi *timings_non_prefetched_minmax.second); printf("degree-two prefetching duration: [%g, %g] \n", *timings_degree_mi *timings_degree_minmax.second); } 217
230. Prefetch Overhead S. Van der Wiel and D. Lilja, "A Survey of Data Prefetching Techniques," Technical Report No. HPPC 96-05, University of Minnesota, October 1996. 218
231. Prefetching Timings: No Prefetch $ likwid-perfctr -f -C 0-3 -g L3 -m ./prefetch 100000 1 0 0 4 distance: 0 prefetch: 0 non-prefetched initial duration: [0.00280393, 0.00289815] non-prefetched duration: [0.00254968, 0.00257311] degree-two prefetching duration: [0.00290615, 0.00296243] Region chase_initial, Group 1: L3 | CPI STAT | 5.8641 | 1.4529 | 1.4744 | 1.4660 | | L3 bandwidth [MBytes/s] STAT | 10733.6308 | 2666.0364 | 2710.9325 | 2683.4077 | Region chase_initial, Group 1: L3CACHE | Metric | Sum | Min | Max | Avg | | L3 miss rate STAT | 0.0584 | 0.0145 | 0.0148 | 0.0146 | | L3 miss ratio STAT | 3.7723 | 0.9117 | 0.9789 | 0.9431 | $ likwid-perfctr -f -C 0-3 -g CYCLE_ACTIVITY -m ./prefetch 100000 1 0 0 4 | Cycles without execution [%] STAT | 228.2316 | 56.8136 | 57.4443 | 57.0579 | | Cycles without execution [%] STAT | 227.0385 | 56.5980 | 57.0024 | 56.7596 | 219
232. Prefetching Timings: useless 0-distance prefetch (overhead) $ likwid-perfctr -f -C 0-3 -g L3 -m ./prefetch 100000 1 0 1 4 distance: 0 prefetch: 1 prefetched initial duration: [0.00288751, 0.00295978] non-prefetched duration: [0.0025575, 0.00258342] degree-two prefetching duration: [0.00285772, 0.00287839] Region chase_initial, Group 1: L3 | CPI STAT | 5.7454 | 1.4345 | 1.4387 | 1.4364 | | L3 bandwidth [MBytes/s] STAT | 10518.6383 | 2618.5405 | 2645.6096 | 2629.6596 | 220
233. Prefetching Timings: 1-distance prefetch (mostly overhead) $ likwid-perfctr -f -C 0-3 -g L3CACHE -m ./prefetch 100000 1 1 1 4 prefetched initial duration: [0.00250957, 0.00257662] non-prefetched duration: [0.00255286, 0.00258417] degree-two prefetching duration: [0.00230482, 0.00235828] Region chase_initial, Group 1: L3CACHE | Metric | Sum | Min | Max | Avg | | CPI STAT | 4.9595 | 1.2343 | 1.2433 | 1.2399 | | L3 miss rate STAT | 0.0004 | 0.0001 | 0.0001 | 0.0001 | | L3 miss ratio STAT | 2.0889 | 0.4381 | 0.6454 | 0.5222 | $ likwid-perfctr -f -C 0-3 -g CYCLE_ACTIVITY -m ./prefetch 100000 1 1 1 4 | Cycles without execution [%] STAT | 214.1614 | 53.4628 | 53.6716 | 53.5404 | | Cycles without execution [%] STAT | 200.4785 | 50.0405 | 50.1857 | 50.1196 | Formulas: L3 request rate = MEM_LOAD_UOPS_RETIRED_L3_ALL/UOPS_RETIRED_ALL L3 miss rate = MEM_LOAD_UOPS_RETIRED_L3_MISS/UOPS_RETIRED_ALL L3 miss ratio = MEM_LOAD_UOPS_RETIRED_L3_MISS/MEM_LOAD_UOPS_RETIRED_L3_ALL https://github.com/RRZE-HPC/likwid/blob/master/groups/ivybridge/L3CACHE.txt 221
234. Prefetching Timings: 2-distance prefetch $ likwid-perfctr -f -C 0-3 -g L3CACHE -m ./prefetch 100000 1 2 1 4 size: 100000 shuffle: 1 distance: 2 prefetch: 1 threads_count: 4 prefetched initial duration: [0.0023392, 0.00241287] non-prefetched duration: [0.00257006, 0.00260938] degree-two prefetching duration: [0.00199431, 0.00203528] Region chase_initial, Group 1: L3CACHE | Metric | Sum | Min | Max | Avg | | CPI STAT | 4.5557 | 1.1331 | 1.1423 | 1.1389 | | L3 request rate STAT | 0.0006 | 0.0001 | 0.0002 | 0.0002 | | L3 miss rate STAT | 0.0004 | 0.0001 | 0.0001 | 0.0001 | | L3 miss ratio STAT | 2.2317 | 0.3138 | 0.6791 | 0.5579 | Region chase_degree, Group 1: L3CACHE | CPI STAT | 3.6990 | 0.9243 | 0.9253 | 0.9248 | | L3 request rate STAT | 0.0005 | 0.0001 | 0.0002 | 0.0001 | | L3 miss rate STAT | 0.0004 | 0.0001 | 0.0001 | 0.0001 | | L3 miss ratio STAT | 2.0145 | 0.3597 | 0.6550 | 0.5036 | 222
235. Prefetching Timings: 8-distance prefetch $ likwid-perfctr -f -C 0-3 -g L3CACHE -m ./prefetch 100000 1 8 1 4 size: 100000 shuffle: 1 distance: 8 prefetch: 1 threads_count: 4 prefetched initial duration: [0.00181161, 0.00188783] non-prefetched duration: [0.00257601, 0.0026076] degree-two prefetching duration: [0.00152468, 0.00156814] Region chase_initial, Group 1: L3CACHE | Metric | Sum | Min | Max | Avg | | Runtime (RDTSC) [s] STAT | 0.0065 | 0.0016 | 0.0017 | 0.0016 | | CPI STAT | 3.4808 | 0.8650 | 0.8788 | 0.8702 | | L3 miss rate STAT | 0.0004 | 0.0001 | 0.0001 | 0.0001 | | L3 miss ratio STAT | 2.2431 | 0.4694 | 0.6640 | 0.5608 | Region chase_degree, Group 1: L3CACHE | Metric | Sum | Min | Max | Avg | | Runtime (RDTSC) [s] STAT | 0.0053 | 0.0013 | 0.0014 | 0.0013 | | CPI STAT | 2.7450 | 0.6832 | 0.6882 | 0.6863 | | L3 miss rate STAT | 0.0016 | 0.0004 | 0.0004 | 0.0004 | | L3 miss ratio STAT | 3.4045 | 0.7778 | 0.9346 | 0.8511 | 223
236. Prefetching Timings: 8-distance prefetch $ likwid-perfctr -f -C 0-3 -g L3 -m ./prefetch 100000 1 8 1 4 size: 100000 shuffle: 1 distance: 8 prefetch: 1 threads_count: 4 prefetched initial duration: [0.00180738, 0.00189831] non-prefetched duration: [0.00254486, 0.00258013] degree-two prefetching duration: [0.00154542, 0.00158065] Region chase_initial, Group 1: L3 | CPI STAT | 3.5027 | 0.8668 | 0.8835 | 0.8757 | | L3 bandwidth [MBytes/s] STAT | 17384.8731 | 4296.5905 | 4381.7164 | 4346.2183 | Region chase_degree, Group 1: L3 | Metric | Sum | Min | Max | Avg | | CPI STAT | 2.7626 | 0.6894 | 0.6919 | 0.6906 | | L3 bandwidth [MBytes/s] STAT | 21505.6670 | 5333.6653 | 5396.4473 | 5376.4168 $ likwid-perfctr -f -C 0-3 -g CYCLE_ACTIVITY -m ./prefetch 100000 1 8 1 4 | Cycles without execution [%] STAT | 187.6689 | 46.3938 | 47.3055 | 46.9172 | | Cycles without execution [%] STAT | 151.5095 | 37.6872 | 38.0656 | 37.8774 | 224
237. Prefetching Timings: suboptimal (untimely) prefetch $ likwid-perfctr -f -C 0-3 -g L3 -m ./prefetch 100000 1 512 1 4 size: 100000 shuffle: 1 distance: 512 prefetch: 1 threads_count: 4 prefetched initial duration: [0.00177956, 0.00186644] non-prefetched duration: [0.00257188, 0.0026064] degree-two prefetching duration: [0.00173249, 0.00178712] Region chase_initial, Group 1: L3 | CPI STAT | 3.4343 | 0.8523 | 0.8683 | 0.8586 | | L3 data volume [GBytes] STAT | 0.0293 | 0.0073 | 0.0074 | 0.0073 | Region chase_degree, Group 1: L3 | Metric | Sum | Min | Max | Avg | | CPI STAT | 3.1891 | 0.7903 | 0.8034 | 0.7973 | | L3 bandwidth [MBytes/s] STAT | 19902.4764 | 4954.4107 | 5013.4006 | 4975.6191 | 225
238. Gem5 http://www.gem5.org/ 226
239. Gem5 - std::vector & std::list I Filling with numbers - std::vector vs. std::list Machine code & assembly (std::vector) Micro-ops execution breakdown (std::vector) Assembly is Too High Level: http://xlogicx.net/?p=369 227
240. Gem5 - std::vector & std::list II Micro-ops pipeline stages (std::vector) 228
241. Gem5 - std::vector & std::list III Pipeline diagram - one iteration (std::vector) Pipeline diagram - three iterations (std::vector) 229
242. Gem5 - std::vector & std::list IV Machine code & assembly (std::list) heap allocation in the loop @ 400d85 what could possibly go wrong? 230
243. std::list - one iteration
244. std::list - one iteration (continued...)
245. std::list - one iteration (...continued still)
246. std::list - one iteration (...done!)
247. (The GNU C library's) malloc https://sourceware.org/glibc/wiki/MallocInternals Arena A structure that is shared among one or more threads which contains references to one or more heaps, as well as linked lists of chunks within those heaps which are "free". Threads assigned to each arena will allocate memory from that arena's free lists. Glibc Heap Analysis in Linux Systems with Radare2 https://youtube.com/watch?v=Svm5V4leEho r2con-2016 - rada.re/con/ 235
248. malloc & free - new, new[], delete, delete[] int main() { double * a = new double[8]; double * b = new double[8]; delete[] b; delete[] a; double * c = new double[8]; delete[] c; } 236
249. new[] & delete[] - dmhg 1/6 237
250. new[] & delete[] - dmhg 2/6 238
251. new[] & delete[] - dmhg 3/6 239
252. new[] & delete[] - dmhg 4/6 240
253. new[] & delete[] - dmhg 5/6 241
254. new[] & delete[] - dmhg 6/6 242
255. Memory Access Patterns: Temporal & Spatial Locality horizontal axis - time vertical axis - address D. J. Hatfield and J. Gerald. "Program restructuring for virtual memory." IBM Systems Journal, 10(3):168–192, 1971. 243
256. Loop Fusion 0.429504s (unfused) down to 0.287501s (fused) g++ -Ofast -march=native (5.2.0) void unfused(double * a, double * b, double * c, double * d, size_t N) { for (size_t i = 0; i != N; ++i) a[i] = b[i] * c[i]; for (size_t i = 0; i != N; ++i) d[i] = a[i] * c[i]; } void fused(double * a, double * b, double * c, double * d, size_t N) { for (size_t i = 0; i != N; ++i) { a[i] = b[i] * c[i]; d[i] = a[i] * c[i]; } } 244
257. Pin - A Dynamic Binary Instrumentation Tool http://www.intel.com/software/pintool pin -t $PIN_ROOT/source/tools/ManualExamples/obj-intel64/pinatrace.so -- ./loop_fusion . . . 0x400e43,R,0x401c48 0x400e59,R,0x401d40 0x400e65,W,0x1c789c0 0x400e65,W,0x1c789e0 . . . r-project.org rstudio.com ggplot2.org rcpp.org 245
258. Loop Fusion: unfused over time PC: Program Counter (instruction pointer) 246
259. Loop Fusion: unfused space-time PC: Program Counter (instruction pointer) MA: Memory Address (array element pointer) 247
260. Loop Fusion: unfused space over time MA: Memory Address (array element pointer) 248
261. Loop Fusion: fused over time PC: Program Counter (instruction pointer) 249
262. Loop Fusion: fused space-time PC: Program Counter (instruction pointer) MA: Memory Address (array element pointer) 250
263. Loop Fusion: fused space over time MA: Memory Address (array element pointer) 251
264. Takeaway: Overlapping Latencies as a General Principle Overlapping latencies also works on a "macro" scale • load as "get the data from the Internet" • compute as "process the data" Another example: Communication Avoiding and Overlapping for Numerical Linear Algebra • https://www.eecs.berkeley.edu/Pubs/TechRpts/2012/EECS-2012-65.html • http://www.cs.berkeley.edu/~egeor/sc12_slides_final.pdf 252
265. Non-Overlapped Timings id,symbol,count,time 1,AAPL,565449,1.59043 2,AXP,731366,3.43745 3,BA,867366,5.40218 4,CAT,830327,7.08103 5,CSCO,400440,8.49192 6,CVX,687198,9.98761 7,DD,910932,12.2254 8,DIS,910430,14.058 9,GE,871676,15.8333 10,GS,280604,17.059 11,HD,556611,18.2738 12,IBM,860071,20.3876 13,INTC,559127,21.9856 14,JNJ,724724,25.5534 15,JPM,500473,26.576 16,KO,864903,28.5405 17,MCD,717021,30.087 18,MMM,698996,31.749 19,MRK,733948,33.2642 20,MSFT,475451,34.3134 21,NKE,556344,36.4545 253
266. Overlapped Timings id,symbol,count,time 1,AAPL,565449,2.00713 2,AXP,731366,2.09158 3,BA,867366,2.13468 4,CAT,830327,2.19194 5,CSCO,400440,2.19197 6,CVX,687198,2.19198 7,DD,910932,2.51895 8,DIS,910430,2.51898 9,GE,871676,2.51899 10,GS,280604,2.519 11,HD,556611,2.51901 12,IBM,860071,2.51902 13,INTC,559127,2.51902 14,JNJ,724724,2.51903 15,JPM,500473,2.51904 16,KO,864903,2.51905 17,MCD,717021,2.51906 18,MMM,698996,2.51907 19,MRK,733948,2.51908 20,MSFT,475451,2.51908 21,NKE,556344,2.51909 254
267. Visualizing & Monitoring Performance https://github.com/Celtoys/Remotery 255
268. Timeline: Without Overlapping 256
269. Timeline: With Overlapping 257
270. Cache Misses, MLP, and STC: Slack R. Das et al., "Aérgia: Exploiting Packet Latency Slack in On-Chip Networks," Proc. 37th Ann. Int’l Symp. Computer Architecture (ISCA 10), ACM Press, 2010. 258
271. Dependent Cache Misses - Non-Overlapped - Serialized A Day in the Life of a Cache Miss Stijn Eyerman, Lieven Eeckhout, Tejas Karkhanis and James E. Smith, "A Performance Counter Architecture for Computing Accurate CPI Components", ASPLOS 2006, pp. 175-184. 1. load instruction enters the window (ROB) 2. the load issues from the instruction buffer (RS) 3. the load blocks the ROB head 4. ROB eventually fills 5. dispatch stops, instruction window drains 6. eventually issue and commit stop
272. Independent Cache Misses in ROB - Overlapped Stijn Eyerman, Lieven Eeckhout, Tejas Karkhanis, and James E. Smith, "A Top-Down Approach to Architecting CPI Component Performance Counters", IEEE Micro, Special Issue on Top Picks from 2006 Microarchitecture Conferences, Vol 27, No 1, pp. 84-93. 260
273. Miss-Dependent Mispredicted Branch - Penalties Serialization S. Eyerman, J.E. Smith and L. Eeckhout, "Characterizing the branch misprediction penalty", Performance Analysis of Systems and Software 2006 IEEE International Symposium on 2006, pp. 48-58. 261
274. Dependent Cache Misses - Non-Overlapped - Serialized Milad Hashemi, Khubaib, Eiman Ebrahimi, Onur Mutlu, and Yale N. Patt. "Accelerating Dependent Cache Misses with an Enhanced Memory Controller." In ISCA, 2016. 262
275. Independent Misses Connected by a Pending Cache Hit • MLP - supported by non-blocking caches, out-of-order execution • multiple outstanding cache-misses - Miss Status Holding Registers (MSHRs) / Line Fill Buffers (LFBs) • MSHR file entries - merging redundant (same cache line) memory requests Xi E. Chen and Tor M. Aamodt. 2008. "Hybrid analytical modeling of pending cache hits, data prefetching, and MSHRs." In Proceedings of the 41st annual IEEE/ACM International Symposium on Microarchitecture (MICRO 41). 263
276. Independent Misses Connected by a Pending Cache Hit Xi E. Chen and Tor M. Aamodt. 2011. "Hybrid analytical modeling of pending cache hits, data prefetching, and MSHRs." ACM Transactions on Architecture and Code Optimization (TACO) 8, 3, Article 10. 264
277. Finite MSHRs => Finite MLP Xi E. Chen and Tor M. Aamodt. 2011. "Hybrid analytical modeling of pending cache hits, data prefetching, and MSHRs." ACM Transactions on Architecture and Code Optimization (TACO) 8, 3, Article 10. 265
278. Cache Miss Penalty: Leading Edge & Trailing Edge "The End of Scaling? Revolutions in Technology and Microarchitecture as we pass the 90 Nanometer Node," Philip Emma, IBM T. J. Watson Research Center, 33rd International Symposium on Computer Architecture (ISCA 2006) Keynote Address http://www.hpcaconf.org/hpca12/Phil_HPCA_06.pdf 266
279. Cache Miss Penalty: Bandwidth Utilization Impact "The End of Scaling? Revolutions in Technology and Microarchitecture as we pass the 90 Nanometer Node," Philip Emma, IBM T. J. Watson Research Center, 33rd International Symposium on Computer Architecture (ISCA 2006) Keynote Address http://www.hpcaconf.org/hpca12/Phil_HPCA_06.pdf 267
280. Memory Capacity & Multicore Processors Memory utilization even more important - contention for capacity & bandwidth! "Disaggregated Memory Architectures for Blade Servers," Kevin Te-Ming Lim, Ph.D. Thesis, The University of Michigan, 2010. 268
281. Multicore: Sequential / Parallel Execution Model L. Yavits, A. Morad, R. Ginosar, The effect of communication and synchronization on Amdahl's law in multicore systems, Parallel Computing, v. 40 n. 1, p. 1-16, January, 2014 269
282. Multicore: Amdahl's Law, Strong Scaling "Reevaluating Amdahl's Law," John L. Gustafson, Communications of the ACM 31(5), 1988. pp. 532-533. 270
283. Multicore: Gustafson's Law, Weak Scaling "Reevaluating Amdahl's Law," John L. Gustafson, Communications of the ACM 31(5), 1988. pp. 532-533. 271
284. Amdahl's Law Optimistic Assumes perfect parallelism of the parallel portion: Only Serial Bottlenecks, No Parallel Bottlenecks Counterpoint: https://blogs.msdn.microsoft.com/ddperf/2009/04/29/parallel-scalability-isnt-childs-play-part-2-amdahls-law-vs- gunthers-law/ 272
285. Multicore: Synchronization, Actual Scaling M. A. Suleman, M. K. Qureshi, and Y. N. Patt, “Feedback-driven threading: Power-efficient and high-performance execution of multi-threaded workloads on CMPs,” in Proc. 13th Archit. Support Program. Lang. Oper. Syst., 2008, pp. 277–286. 273
286. Multicore: Communication, Actual Scaling M. A. Suleman, M. K. Qureshi, and Y. N. Patt, “Feedback-driven threading: Power-efficient and high-performance execution of multi-threaded workloads on CMPs,” in Proc. 13th Archit. Support Program. Lang. Oper. Syst., 2008, pp. 277–286. 274
287. Multicore & DRAM: AoS I #include <cstddef> #include <cstdlib> #include <future> #include <iostream> #include <random> #include <vector> #include <boost/timer/timer.hpp> struct contract { double K; double T; double P; }; using element = contract; using container = std::vector<element>; 275
288. Multicore & DRAM: AoS II double sum_if(const container & a, const container & b, const std::vector<std::size_t> & index) { double sum = 0.0; for (std::size_t i = 0, n = index.size(); i != n; ++i) { std::size_t j = index[i]; if (a[j].K == b[j].K) sum += a[j].K; } return sum; } template <typename F> double average(F f, std::size_t m) { double average = 0.0; for (std::size_t i = 0; i != m; ++i) average += f() / m; return average; } 276
289. Multicore & DRAM: AoS III std::vector<std::size_t> index_stream(std::size_t n) { std::vector<std::size_t> index; index.reserve(n); for (std::size_t i = 0; i != n; ++i) index.push_back(i); return index; } std::vector<std::size_t> index_random(std::size_t n) { std::vector<std::size_t> index; index.reserve(n); std::random_device rd; static std::mt19937 g(rd()); std::uniform_int_distribution<std::size_t> u(0, n - 1); for (std::size_t i = 0; i != n; ++i) index.push_back(u(g)); return index; } 277
290. Multicore & DRAM: AoS IV int main(int argc, char * argv[]) { const std::size_t n = (argc > 1) ? std::atoll(argv[1]) : 1000; const std::size_t m = (argc > 2) ? std::atoll(argv[2]) : 10; std::cout << "n = " << n << '\n'; std::cout << "m = " << m << '\n'; const std::size_t threads_count = 4; // thread access locality type // 0: none (default); 1: stream; 2: random std::vector<std::size_t> thread_type(threads_count); for (std::size_t thread = 0; thread != threads_count; ++thread) { thread_type[thread] = (argc > 3 + thread) ? std::atoll(argv[3 + thread]) : 0; std::cout << "thread_type[" << thread << "] = " << thread_type[thread] << '\n'; } 278
291. Multicore & DRAM: AoS V endl(std::cout); std::vector<std::vector<std::size_t>> index(threads_count); for (std::size_t thread = 0; thread != threads_count; ++thread) { index[thread].resize(n); if (thread_type[thread] == 1) index[thread] = index_stream(n); else if (thread_type[thread] == 2) index[thread] = index_random(n); } const container v1(n, {1.0, 0.5, 3.0}); const container v2(n, {1.0, 2.0, 1.0}); const auto thread_work = [m, &v1, &v2](const auto & thread_index) { const auto f = [&v1, &v2, &thread_index] { return sum_if(v1, v2, thread_index); }; return average(f, m); }; 279
292. Multicore & DRAM: AoS VI boost::timer::auto_cpu_timer timer; std::vector<std::future<double>> results; results.reserve(threads_count); for (std::size_t thread = 0; thread != threads_count; ++thread) { results.emplace_back(std::async(std::launch::async, [thread, &thread_work, &index] { return thread_work(index[thread]); ); } for (auto && result : results) if (result.valid()) result.wait(); for (auto && result : results) std::cout << result.get() << '\n'; } 280
293. Multicore & DRAM: AoS Timings 1 thread, sequential access $ ./DRAM_CMP 10000000 10 1 n = 10000000 m = 10 thread_type[0] = 1 1e+007 0.395408s wall, 0.406250s user + 0.000000s system = 0.406250s CPU (102.7%) 281
294. Multicore & DRAM: AoS Timings 1 thread, random access $ ./DRAM_CMP 10000000 10 2 n = 10000000 m = 10 thread_type[0] = 2 1e+007 5.348314s wall, 5.343750s user + 0.000000s system = 5.343750s CPU (99.9%) 282
295. Multicore & DRAM: AoS Timings 4 threads, sequential access $ ./DRAM_CMP 10000000 10 1 1 1 1 n = 10000000 m = 10 thread_type[0] = 1 thread_type[1] = 1 thread_type[2] = 1 thread_type[3] = 1 1e+007 1e+007 1e+007 1e+007 0.508894s wall, 2.000000s user + 0.000000s system = 2.000000s CPU (393.0%) 283
296. Multicore & DRAM: AoS Timings 4 threads: 3 sequential access + 1 random access $ ./DRAM_CMP 10000000 10 1 1 1 2 n = 10000000 m = 10 thread_type[0] = 1 thread_type[1] = 1 thread_type[2] = 1 thread_type[3] = 2 1e+007 1e+007 1e+007 1e+007 5.666049s wall, 7.265625s user + 0.000000s system = 7.265625s CPU (128.2%) 284
297. Multicore & DRAM: AoS Timings Memory Access Patterns & Multicore: Interactions Matter Inter-thread Interference Sharing - Contention - Interference - Slowdown Threads using a shared resource (like on-chip/off-chip interconnects and memory) contend for it, interfering with each other's progress, resulting in slowdown (and thus negative returns to increased threads count). cf. Thomas Moscibroda and Onur Mutlu, "Memory Performance Attacks: Denial of Memory Service in Multi-Core Systems," Microsoft Research Technical Report, MSR-TR-2007-15, February 2007. 285
298. Multicore & DRAM: SoA I #include <cstddef> #include <cstdlib> #include <future> #include <iostream> #include <random> #include <vector> #include <boost/timer/timer.hpp> // SoA (structure-of-arrays) struct data { std::vector<double> K; std::vector<double> T; std::vector<double> P; }; 286
299. Multicore & DRAM: SoA II double sum_if(const data & a, const data & b, const std::vector<std::size_t { double sum = 0.0; for (std::size_t i = 0, n = index.size(); i != n; ++i) { std::size_t j = index[i]; if (a.K[j] == b.K[j]) sum += a.K[j]; } return sum; } template <typename F> double average(F f, std::size_t m) { double average = 0.0; for (std::size_t i = 0; i != m; ++i) { average += f() / m; } 287
300. Multicore & DRAM: SoA III return average; } std::vector<std::size_t> index_stream(std::size_t n) { std::vector<std::size_t> index; index.reserve(n); for (std::size_t i = 0; i != n; ++i) index.push_back(i); return index; } std::vector<std::size_t> index_random(std::size_t n) { std::vector<std::size_t> index; index.reserve(n); std::random_device rd; static std::mt19937 g(rd()); std::uniform_int_distribution<std::size_t> u(0, n - 1); 288
301. Multicore & DRAM: SoA IV for (std::size_t i = 0; i != n; ++i) index.push_back(u(g)); return index; } int main(int argc, char * argv[]) { const std::size_t n = (argc > 1) ? std::atoll(argv[1]) : 1000; const std::size_t m = (argc > 2) ? std::atoll(argv[2]) : 10; std::cout << "n = " << n << '\n'; std::cout << "m = " << m << '\n'; const std::size_t threads_count = 4; // thread access locality type // 0: none (default); 1: stream; 2: random std::vector<std::size_t> thread_type(threads_count); for (std::size_t thread = 0; thread != threads_count; ++thread) { 289
302. Multicore & DRAM: SoA V thread_type[thread] = (argc > 3 + thread) ? std::atoll(argv[3 + thr std::cout << "thread_type[" << thread << "] = " << thread_type[thre } endl(std::cout); std::vector<std::vector<std::size_t>> index(threads_count); for (std::size_t thread = 0; thread != threads_count; ++thread) { index[thread].resize(n); if (thread_type[thread] == 1) index[thread] = index_stream(n); else if (thread_type[thread] == 2) index[thread] = index_random(n); } data v1; v1.K.resize(n, 1.0); v1.T.resize(n, 0.5); v1.P.resize(n, 3.0); 290
303. Multicore & DRAM: SoA VI data v2; v2.K.resize(n, 1.0); v2.T.resize(n, 2.0); v2.P.resize(n, 1.0); const auto thread_work = [m, &v1, &v2](const auto & thread_index) { const auto f = [&v1, &v2, &thread_index] { return sum_if(v1, v2, thread_index); }; return average(f, m); }; 291
304. Multicore & DRAM: SoA VII boost::timer::auto_cpu_timer timer; std::vector<std::future<double>> results; results.reserve(threads_count); for (std::size_t thread = 0; thread != threads_count; ++thread) { results.emplace_back(std::async(std::launch::async, [thread, &thread_work, &index] { return thread_work(index[thread]); ); } for (auto && result : results) if (result.valid()) result.wait(); for (auto && result : results) std::cout << result.get() << '\n'; } 292
305. Multicore & DRAM: SoA Timings 1 thread, sequential access $ ./DRAM_CMP.SoA 10000000 10 1 1 1 1 n = 10000000 m = 10 thread_type[0] = 1 1e+007 0.211877s wall, 0.203125s user + 0.000000s system = 0.203125s CPU (95.9%) 293
306. Multicore & DRAM: SoA Timings 1 thread, random access $ ./DRAM_CMP.SoA 10000000 10 2 n = 10000000 m = 10 thread_type[0] = 2 1e+007 4.534646s wall, 4.546875s user + 0.000000s system = 4.546875s CPU (100.3%) 294
307. Multicore & DRAM: SoA Timings 4 threads, sequential access $ ./DRAM_CMP.SoA 10000000 10 1 1 1 1 n = 10000000 m = 10 thread_type[0] = 1 thread_type[1] = 1 thread_type[2] = 1 thread_type[3] = 1 1e+007 1e+007 1e+007 1e+007 0.256391s wall, 1.031250s user + 0.000000s system = 1.031250s CPU (402.2%) 295
308. Multicore & DRAM: SoA Timings 4 threads: 3 sequential access + 1 random access $ ./DRAM_CMP.SoA 10000000 10 1 1 1 2 n = 10000000 m = 10 thread_type[0] = 1 thread_type[1] = 1 thread_type[2] = 1 thread_type[3] = 2 1e+007 1e+007 1e+007 1e+007 4.581033s wall, 5.265625s user + 0.000000s system = 5.265625s CPU (114.9%) 296
309. Multicore & DRAM: SoA Timings Better Access Patterns yield Better Single-core Performance but also Reduced Interference and thus Better Multi-core Performance 297
310. Multicore: Arithmetic Intensity L. Yavits, A. Morad, R. Ginosar, The effect of communication and synchronization on Amdahl's law in multicore systems, Parallel Computing, v. 40 n. 1, p. 1-16, January, 2014 298
311. Multicore: Synchronization & Connectivity Intensity L. Yavits, A. Morad, R. Ginosar, The effect of communication and synchronization on Amdahl's law in multicore systems, Parallel Computing, v. 40 n. 1, p. 1-16, January, 2014 299
312. Speedup: Synchronization and Connectivity Bottlenecks f: parallelizable fraction f1 : connectivity intensity f2 : synchronization intensity L. Yavits, A. Morad, R. Ginosar, The effect of communication and synchronization on Amdahl's law in multicore systems, Parallel Computing, v. 40 n. 1, p. 1-16, January, 2014 300
313. Speedup: Synchronization & Connectivity Bottlenecks Speedup - affected by sequential-to-parallel data synchronization and inter-core communication. L. Yavits, A. Morad, R. Ginosar, The effect of communication and synchronization on Amdahl's law in multicore systems, Parallel Computing, v. 40 n. 1, p. 1-16, January, 2014 301
314. Partitioning-Sharing Tradeoffs Butler W. Lampson. 1983. "Hints for computer system design." In Proceedings of the ninth ACM symposium on Operating systems principles (SOSP '83). ACM, New York, NY, USA, 33-48. 302
315. Shared Resource: DRAM Heechul Yun, Renato, Zheng-Pei Wu, Rodolfo Pellizzoni. "PALLOC: DRAM Bank-Aware Memory Allocator for Performance Isolation on Multicore Platforms," IEEE Intl. Conference on Real-Time and Embedded Technology and Applications Symposium (RTAS), 2014. https://github.com/heechul/palloc 303
316. Shared Resource: MSHRs Heechul Yun, Rodolfo Pellizzon, and Prathap Kumar Valsan. 2015. "Parallelism-Aware Memory Interference Delay Analysis for COTS Multicore Systems." In Proceedings of the 2015 27th Euromicro Conference on Real-Time Systems (ECRTS '15). 304
317. Partitioning Multithreading • Thread affinity • POSIX: sched_getcpu, pthread_setaffinity_np • http://eli.thegreenplace.net/2016/c11-threads-affinity-and- hyperthreading/ • https://github.com/RRZE- HPC/likwid/blob/master/groups/skylake/FALSE_SHARE.txt • Local LLC false sharing rate = MEM_LOAD_L3_HIT_RETIRED_XSNP_HITM / MEM_INST_RETIRED_ALL • NUMA: Remote Memory Accesses (RMA), Local Memory Accesses (LMA), RMA/LMA ratio • https://01.org/numatop/ • https://github.com/01org/numatop 305
318. Cache Partitioning: Index-Based & Way-Based Giovani Gracioli, Ahmed Alhammad, Renato Mancuso, Antônio Augusto Fröhlich, and Rodolfo Pellizzoni. 2015. "A Survey on Cache Management Mechanisms for Real-Time Embedded Systems." ACM Comput. Surv. 48, 2, Article 32 (November 2015), 36 pages. 306
319. Cache Partitioning: CPU Support Giovani Gracioli, Ahmed Alhammad, Renato Mancuso, Antônio Augusto Fröhlich, and Rodolfo Pellizzoni. 2015. "A Survey on Cache Management Mechanisms for Real-Time Embedded Systems." ACM Comput. Surv. 48, 2, Article 32 (November 2015), 36 pages. 307
320. Cache Partitioning & Intel: CAT & CMT Cache Monitoring Technology and Cache Allocation Technology https://github.com/01org/intel-cmt-cat A. Herdrich, E. Verplanke, P. Autee, R. Illikkal, C. Gianos, R. Singhal, and R. Iyer, “Cache QoS: From concept to reality in the Intel Xeon processor E5-2600 v3 product family,” in Intl. Symp. on High Performance Computer Architecture (HPCA), Mar. 2016. 308
321. Cache Partitioning != Cache Access Timing Isolation H. Yun and P. Valsan, "Evaluating the Isolation Effect of Cache Partitioning on COTS Multicore Platforms", International Workshop on Operating Systems Platforms for Embedded Real-Time Applications (OSPERT) 2015. 309
322. Cache Partitioning != Cache Access Timing Isolation H. Yun and P. Valsan, "Evaluating the Isolation Effect of Cache Partitioning on COTS Multicore Platforms", International Workshop on Operating Systems Platforms for Embedded Real-Time Applications (OSPERT) 2015. 310
323. Cache Partitioning != Cache Access Timing Isolation H. Yun and P. Valsan, "Evaluating the Isolation Effect of Cache Partitioning on COTS Multicore Platforms", International Workshop on Operating Systems Platforms for Embedded Real-Time Applications (OSPERT) 2015. 311
324. Cache Partitioning != Cache Access Timing Isolation https://github.com/CSL-KU/IsolBench Prathap Kumar Valsan, Heechul Yun, Farzad Farshchi. "Taming Non-blocking Caches to Improve Isolation in Multicore Real-Time Systems." IEEE Intl. Conference on Real-Time and Embedded Technology and Applications Symposium (RTAS), IEEE, 2016. 312
325. Cache Partitioning != Cache Access Timing Isolation • Shared: MSHRs (Miss information/Status Holding Registers) / LFBs (Line Fill Buffers) • Contention => cache space partitioning != cache access timing isolation Prathap Kumar Valsan, Heechul Yun, Farzad Farshchi. "Taming Non-blocking Caches to Improve Isolation in Multicore Real-Time Systems." IEEE Intl. Conference on Real-Time and Embedded Technology and Applications Symposium (RTAS), IEEE, 2016. 313
326. Cache Partitioning != Cache Access Timing Isolation • mutiple MSHRs support multiple outstanding cache-misses • the number of MSHRs determines the MLP of the cache • local MLP - outstanding misses one core can generate • global MLP - parallelism of the entire shared memory hierarchy (i.e., shared LLC and DRAM) • "the aggregated parallelism of the cores (the sum of local MLP) exceeds the parallelism supported by the shared LLC and DRAM (global MLP) in the out-of-order architectures" Prathap Kumar Valsan, Heechul Yun, Farzad Farshchi. "Taming Non-blocking Caches to Improve Isolation in Multicore Real-Time Systems." IEEE Intl. Conference on Real-Time and Embedded Technology and Applications Symposium (RTAS), IEEE, 2016. 314
327. Shared Resource (MSHRs) & Prefetching: Xeon Phi Zhenman Fang, Sanyam Mehta, Pen-Chung Yew, Antonia Zhai, James Greensky, Gautham Beeraka, and Binyu Zang. "Measuring Microarchitectural Details of Multi- and Many-core Memory Systems Through Microbenchmarking." ACM Transactions on Architecture and Code Optimization (TACO 2015). Volume 11, Issue 4, Article 55, January 2015. 315
328. Shared Resource (MSHRs) & Prefetching: SNB Zhenman Fang, Sanyam Mehta, Pen-Chung Yew, Antonia Zhai, James Greensky, Gautham Beeraka, and Binyu Zang. "Measuring Microarchitectural Details of Multi- and Many-core Memory Systems Through Microbenchmarking." ACM Transactions on Architecture and Code Optimization (TACO 2015). Volume 11, Issue 4, Article 55, January 2015. 316
329. Weighted Speedup A. Snavely and D. M. Tullsen, “Symbiotic jobscheduling for simultaneous multithreading processor,” in Proceedings of the International Conference on Architectural Support for Programming Languages and Operating Systems (ASPLOS), Nov. 2000, pp. 234– 244. S. Eyerman and L. Eeckhout, “Restating the Case for Weighted-IPC Metrics to Evaluate Multiprogram Workload Performance,” in Computer Architecture Letters, vol. 13, no. 2, 2014.317
330. The Number of Cycles Sam Van den Steen; Stijn Eyerman; Sander De Pestel; Moncef Mechri; Trevor E. Carlson; David Black-Schaffer; Erik Hagersten; Lieven Eeckhout, “Analytical Processor Performance and Power Modeling using Micro-Architecture Independent Characteristics,” Transactions on Computers (TC) 2016. C - #cycles, N - #instructions, Deff - effective dispatch rate, mbpred - #branch mispredictions, cres - branch resolution time, cfe - front-end pipeline depth, mILi - #instruction fetch misses at each level i in the cache hierarchy, cLi - access latency to each cache level, ROB - size of the Reorder Buffer, mLLC - #number of LLC load misses, cmem - memory access time, cbus - memory bus transfer and waiting time, MLP - amount of memory-level parallelism, PhLLC - LLC hit chain penalty 318
331. Roofline Model: Potential "Auto-tuning Performance on Multicore Computers," S. Williams, PhD, 2008. 319
332. Roofline Model: Optimization "Auto-tuning Performance on Multicore Computers," S. Williams, PhD, 2008. 320
333. Cache-aware Roofline model "Cache-aware Roofline model: Upgrading the loft." Aleksandar Ilic, Frederico Pratas, Leonel Sousa, IEEE Computer Architecture Letters, vol. 13, no. 1, pp. 1-1, Jan.-June, 2014. 321
334. Cache-aware Roofline model "Cache-aware Roofline model: Upgrading the loft." Aleksandar Ilic, Frederico Pratas, Leonel Sousa, IEEE Computer Architecture Letters, vol. 13, no. 1, pp. 1-1, Jan.-June, 2014. 322
335. Roofline Model: Microarchitectural Bottlenecks "Extending the Roofline Model: Bottleneck Analysis with Microarchitectural Constraints." Victoria Caparros and Markus Püschel Proc. IEEE International Symposium on Workload Characterization (IISWC), pp. 222-231, 2014. 323
336. Roofline Model: Microarchitectural Bottlenecks "Extending the Roofline Model: Bottleneck Analysis with Microarchitectural Constraints." Victoria Caparros and Markus Püschel Proc. IEEE International Symposium on Workload Characterization (IISWC), pp. 222-231, 2014. 324
337. C++ Standards: C++11 & C++14 Atomic Operations & Concurrent Memory Model http://en.cppreference.com/w/cpp/atomic http://github.com/MattPD/cpplinks/blob/master/atomics.lockfree.memory_model.md "The C11 and C++11 Concurrency Model" by Mark John Batty: http://www.cl.cam.ac.uk/~mjb220/thesis/ Move semantics https://isocpp.org/wiki/faq/cpp11-language#rval http://thbecker.net/articles/rvalue_references/section_01.html http://kholdstare.github.io/technical/2013/11/23/moves-demystified.html scoped_allocator (stateful allocators support) https://isocpp.org/wiki/faq/cpp11-library#scoped-allocator http://en.cppreference.com/w/cpp/header/scoped_allocator https://accu.org/content/conf2012/JonathanWakely-CXX11_allocators.pdf https://accu.org/content/conf2013/Frank_Birbacher_Allocators.r210article.pdf 325
338. C++ Standards: C++11, C++14, and C++17 reducing the need for conditional compilation via macros and template metaprogramming constexpr https://isocpp.org/wiki/faq/cpp11-language#cpp11-constexpr https://isocpp.org/wiki/faq/cpp14-language#extended-constexpr if constexpr http://en.cppreference.com/w/cpp/language/if#Constexpr_If 326
339. C++17 Standard std::string_view http://en.cppreference.com/w/cpp/string/basic_string_view interoperatbility with C APIs (e.g., sockets) without extra allocations / copies std::aligned_alloc (C11) http://en.cppreference.com/w/cpp/memory/c/aligned_alloc aligned uninitialized storage allocation (vectorization) Hardware interference size http://eel.is/c++draft/hardware.interference http://en.cppreference.com/w/cpp/thread/hardware_destructive_interference_size portable cache line size information (e.g., padding to avoid false sharing) Extended allocators & polymorphic memory resources http://en.cppreference.com/w/cpp/memory/polymorphic_allocator http://stackoverflow.com/questions/38010544/polymorphic-allocator-when- and-why-should-i-use-it http://boost.org/doc/libs/release/doc/html/container/extended_functionality.html 327
340. C++ Core Guidelines P: Philosophy • P.9: Don't waste time or space. Per: Performance • Per.3: Don't optimize something that's not performance critical. • Per.6: Don't make claims about performance without measurements. • Per.7: Design to enable optimization • Per.18: Space is time. • Per.19: Access memory predictably. • Per.30: Avoid context switches on the critical path https://isocpp.github.io/CppCoreGuidelines/CppCoreGuidelines#S-performance https://github.com/isocpp/CppCoreGuidelines/blob/master/CppCoreGuidelines.md#S-performance 328
341. Takeaway: It depends! • Memory access cost: latency / bandwidth? 329
342. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? 329
343. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency 329
344. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency • miss-penalty: overlap, independence 329
345. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency • miss-penalty: overlap, independence • prefetch: convert cold misses to pending hits (tradeoffs: BW, MSHR) 329
346. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency • miss-penalty: overlap, independence • prefetch: convert cold misses to pending hits (tradeoffs: BW, MSHR) • Branch cost? 329
347. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency • miss-penalty: overlap, independence • prefetch: convert cold misses to pending hits (tradeoffs: BW, MSHR) • Branch cost? • branch-predictability x branch-penalty 329
348. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency • miss-penalty: overlap, independence • prefetch: convert cold misses to pending hits (tradeoffs: BW, MSHR) • Branch cost? • branch-predictability x branch-penalty • branch-penalty != branch-count x branch-resolution-time 329
349. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency • miss-penalty: overlap, independence • prefetch: convert cold misses to pending hits (tradeoffs: BW, MSHR) • Branch cost? • branch-predictability x branch-penalty • branch-penalty != branch-count x branch-resolution-time • branch-penalty: predictability (entropy), interval length / window drain, dependence (latency, critical path, how many ops feed the branch, how many are fed by the branch), instruction locality 329
350. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency • miss-penalty: overlap, independence • prefetch: convert cold misses to pending hits (tradeoffs: BW, MSHR) • Branch cost? • branch-predictability x branch-penalty • branch-penalty != branch-count x branch-resolution-time • branch-penalty: predictability (entropy), interval length / window drain, dependence (latency, critical path, how many ops feed the branch, how many are fed by the branch), instruction locality • Branches vs. Predicated Execution - penalty vs. overhead 329
351. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency • miss-penalty: overlap, independence • prefetch: convert cold misses to pending hits (tradeoffs: BW, MSHR) • Branch cost? • branch-predictability x branch-penalty • branch-penalty != branch-count x branch-resolution-time • branch-penalty: predictability (entropy), interval length / window drain, dependence (latency, critical path, how many ops feed the branch, how many are fed by the branch), instruction locality • Branches vs. Predicated Execution - penalty vs. overhead • misprediction cost vs. useless work 329
352. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency • miss-penalty: overlap, independence • prefetch: convert cold misses to pending hits (tradeoffs: BW, MSHR) • Branch cost? • branch-predictability x branch-penalty • branch-penalty != branch-count x branch-resolution-time • branch-penalty: predictability (entropy), interval length / window drain, dependence (latency, critical path, how many ops feed the branch, how many are fed by the branch), instruction locality • Branches vs. Predicated Execution - penalty vs. overhead • misprediction cost vs. useless work • easy-to-predict vs. hard-to-predict 329
353. Takeaway: It depends! • Memory access cost: latency / bandwidth? • Cache miss cost? • miss-penalty != miss-count x miss-latency • miss-penalty: overlap, independence • prefetch: convert cold misses to pending hits (tradeoffs: BW, MSHR) • Branch cost? • branch-predictability x branch-penalty • branch-penalty != branch-count x branch-resolution-time • branch-penalty: predictability (entropy), interval length / window drain, dependence (latency, critical path, how many ops feed the branch, how many are fed by the branch), instruction locality • Branches vs. Predicated Execution - penalty vs. overhead • misprediction cost vs. useless work • easy-to-predict vs. hard-to-predict • cmov & tradeoffs: converting control dependencies to data dependencies 329
354. Takeaways Principles Data structures & data layout - fundamental part of design CPUs & pervasive forms parallelism • can support each other: PLP, ILP (MLP!), TLP, DLP Balanced design vs. bottlenecks Overlapping latencies Sharing-contention-interference-slowdown Yale Patt's Phase 2: Break the layers: • break through the hardware/software interface • harness all levels of the transformation hierarchy 330
355. Phase 2: Harnessing the Transformation Hierarchy Yale N. Patt, Microprocessor Performance, Phase 2: Can We Harness the Transformation Hierarchy https://youtube.com/watch?v=0fLlDkC625Q 331
356. Break the Layers Yale N. Patt, Microprocessor Performance, Phase 2: Can We Harness the Transformation Hierarchy https://youtube.com/watch?v=0fLlDkC625Q 332
357. Pigeonholing has to go Yale N. Patt at Yale Patt 75 Visions of the Future Computer Architecture Workshop: "Are you a software person or a hardware person?" I'm a person this pigeonholing has to go We must break the layers Abstractions are great - AFTER you understand what's being abstracted Yale N. Patt, 2013 IEEE CS Harry H. Goode Award Recipient Interview — https://youtu.be/S7wXivUy-tk Yale N. Patt at Yale Patt 75 Visions of the Future Computer Architecture Workshop — https://youtu.be/x4LH1cJCvxs 333
358. Resources http://www.agner.org/optimize/ https://users.ece.cmu.edu/~omutlu/lecture-videos.html https://github.com/MattPD/cpplinks/ 334
359. Slides https://speakerdeck.com/mattpd 335
360. Thank You! Questions? 336
