1. SERVERLESS APPLICATIONS WHERE HAVE ALL THE SERVERS GONE?
2. WHY? As a dev team, we should focus on delivering code, not maintaining the infrastructure to run that code. Programmers bring value when they write code.
3. WE JUST WANT TO CODE!
4. PROBLEMS WITH MANAGING YOU OWN SERVERS • Team needs to have skills to manage IT infrastructure • What server size? • Which OS version? • When do we patch OS? • How do we patch OS?  downtime! • Tuning server performance • How much remaining capacity do we have? • Handling server failures • Servers are highly underutilized • Pay even if you’re not running any workload – pay for time, not for the actual work
5. KEY BENEFITS OF SERVERLESS APPROACH Zero administration No provisioning Focus on business value Allows rapid innovation Seamless scaling
6. MONOLITHIC ARCHITECTURE Presentation tier Business logic tier Database tier
7. MICROSERVICES ARCHITECTURE Fleet of microservices ! ! !
8. Monolithic ◦ Hard to make changes ◦ Tight coupling between components ◦ Hard to understand interdependencies ◦ Partial deployments impossible ◦ Either all works or nothing works ◦ Shared data store ◦ Shared codebase – teams are overlapping WHY MICROSERVICES? Microservices ◦ Separation of responsibilites between components – easier to understand ◦ Individually deployable pieces ◦ Easier to test functionalities in isolation ◦ No sharing of code ◦ No sharing of data ◦ Graceful degradation of service
9. What if we could just focus on solving the business problems and let someone else run the code and do all heavy lifting for us...
10. CLOUD MAKES IT POSSIBLE! Data store Caching Networking Content delivery Compute Security Monitoring and logging Messaging and queues Streaming
11. SERVERLESS BUILDING BLOCKS API Gateway Lambda
12. AWS API GATEWAY • Public API as a service • Handles authorization, access control, monitoring, API version management • Highly scalable, highly resilient service • Scales dynamically to handle ANY load • Seamless integration with AWS services (like Lambda or Kinesis) or any custom HTTP endpoint • Caching out of the box • Charging per million API calls ($3.50 per million API calls) + traffic out
13. AWS LAMBDA • Function As A Service • Event-driven serverless compute service • Triggered by: API gateway call, SNS notification, Kinesis stream, S3 object upload, CloudWatch alarm, Amazon Echo.... • Pay only for running time (in 100ms increments) • Never pay for idle! • Don’t worry about overprovisioning or underprovisioning • Automatically scales to handle ANY load • Supports Node.JS, Python, Java and C# from today!! • Your code is secured – encrypted at rest • Monitoring out of the box
14. AWS LAMBDA LIMITATIONS • Functions must complete execution in 300 sec • Allocated memory from 128 MB up to 1.5 GB (in 64 MB increment) • Available CPU power proportional to allocated memory • 500 MB of non-persistent disk space • Function size (with dependencies) less than 50 MB • Execution is stateless, but beware – containers are reused! • Latency on first request
15. EXAMPLE #1 (Serverless backend) Back end Users
16. EXAMPLE #1 (Serverless backend) Back end logic Back end data Users
17. EXAMPLE #1 (Serverless backend) Back end logic Back end data Web clients Mobile clients Services HTTP / REST
18. EXAMPLE #1 (Serverless backend) Web clients Mobile clients Services AWS API Gateway AWS Lambda AWS DynamoDB AWS CloudFront
19. EXAMPLE #1 (Serverless backend) Web clients Mobile clients Services AWS API Gateway AWS Lambda AWS DynamoDB AWS CloudFront AWS S3
20. EXAMPLE #1 (Serverless backend) Web clients Mobile clients Services AWS API Gateway AWS Lambda AWS DynamoDB AWS CloudFront AWS S3 AWS S3 AWS SNS
21. EXAMPLE #1 (Serverless backend) Services AWS API Gateway AWS Lambda AWS DynamoDB AWS CloudFront AWS S3 AWS S3 AWS SNS
22. EXAMPLE #2 (Hybrid backend) Web clients Mobile clients Services AWS API Gateway AWS Lambda AWS DynamoDB AWS CloudFront AWS EC2 AWS EC2
23. EXAMPLE #3 (Serverless stream processing) Mobile clients AWS Kinesis Streams AWS DynamoDB AWS S3 AWS EMR AWS Lambda AWS Redshift
24. WHO IS SERVERLESS FOR? • Do you need high performance at ANY scale? • Can you afford unpredictable running costs? • Do you need to individually deploy ony pieces of your application? • Do you need to be able to experiment and iterate quickly with parts of your application? • Are you building microservices?
25. MICROSERVICES UTOPIA
26. MICROSERVICES UTOPIA
27. “ If you can’t build a modular monolith, what makes you think microservices is the answer?
28. WHAT’S THE CURRENT STATE? • Technology not mature enough • No well-proven patterns to follow, everyone is still experimenting • No mature frameworks to help us build and deploy • Still only few players in the game (AWS Lambda, Azure Functions, Google Cloud Functions, IBM OpenWisk, Webtask.io....) • Harder to develop and test locally • Do you really need this architecture? • In some cases it’s cheaper to run a fleet of EC2s
29. IT’S NOT ALWAYS CHEAPER Lambda 10 x m3.large Pricing model First million executions free, each additional million $0.20 $95 / month for each instace Our monthly cost $2,162 $950 Our yearly cost $25,944 $11,400 • 100 exeucutions / sec • Each execution lasts 1 sec • Each execution is allocated 512 MB of memory $14,500 difference per year!
30. THANK YOU!
