1. Angular Performance Checklist
   Minko Gechev
   github.com/mgechev
   twitter.com/mgechev
   blog.mgechev.com


   View Slide

2. github.com/mgechev
   twitter.com/mgechev
   blog.mgechev.com
   About
   deprecated


   View Slide

3. View Slide

4. Hold on for the
   second edition!


   View Slide

5. Inspirational thought about programming
   https://flic.kr/p/bmgpJT
   Agenda
   Network performance
   Runtime performance


   View Slide

6. Inspirational thought about programming
   https://flic.kr/p/bmgpJT
   Agenda
   Network performance
   Runtime performance


   View Slide

7. Network Performance


   View Slide

8. • Service Workers
   • Bundling
   • Minification & Dead code elimination
   • Tree-shaking
   • AoT compilation
   • Compression
   Network Performance


   View Slide

9. View Slide

10. Build a “Hello world” Angular 2 Application
    with minimal size


    View Slide

11. Build a “Hello world” Angular 2 Application
    with minimal size


    View Slide

12. View Slide

13. “Hello world” in Angular 2


    View Slide

14.












    index.html


    View Slide

15.












    index.html


    View Slide

16. app.component.ts
    import { Component } from '@angular/core';
    @Component({
    selector: 'my-app',
    template: 'Hello world!'
    })
    export class AppComponent {}


    View Slide

17. import { NgModule } from '@angular/core';
    import { BrowserModule } from '@angular/platform-browser';
    import { AppComponent } from './app.component';
    @NgModule({
    imports: [BrowserModule],
    bootstrap: [AppComponent],
    declarations: [AppComponent],
    })
    export class AppModule {}
    app.module.ts


    View Slide

18. main.ts
    import { platformBrowserDynamic } from
    '@angular/platform-browser-dynamic';
    import { AppModule } from './app.module';
    platformBrowserDynamic().bootstrapModule(AppModule);


    View Slide

19. View Slide

20. Service Workers


    View Slide

21. - Jake Archibald
    “ServiceWorker is a background worker, it
    gives us a JavaScript context to add features
    such as push messaging, background sync,
    geofencing and network control.”


    View Slide

22. - Jake Archibald
    “ServiceWorker is a background worker, it
    gives us a JavaScript context to add features
    such as push messaging, background sync,
    geofencing and network control.”


    View Slide

23. Service Worker
    Network


    View Slide

24. Service Worker
    Network
    GET /i.gif


    View Slide

25. Service Worker
    Network
    GET /i.gif


    View Slide

26. Service Worker
    Network


    View Slide

27. Service Worker
    Network


    View Slide

28. We can think of service workers as
    proxy in the browser


    View Slide

29. index.html


    ...

    ...
    <br/>navigator.serviceWorker<br/>.register('cache-network.sw.js');<br/>




    View Slide

30. cache-network.sw.js
    importScripts('./system-config.js');
    self.addEventListener('install', event => {
    event.waitUntil(
    caches.open('mysite-v3').then(cache =>
    cache.addAll([
    'zone.js'
    // etc
    ])));
    });
    self.addEventListener(‘fetch', event => {
    event.respondWith(caches
    .match(event.request).then(response =>
    response || fetch(event.request)));
    });


    View Slide

31. cache-network.sw.js
    importScripts('./system-config.js');
    self.addEventListener('install', event => {
    event.waitUntil(
    caches.open('mysite-v3').then(cache =>
    cache.addAll([
    'zone.js'
    // etc
    ])));
    });
    self.addEventListener('fetch', event => {
    event.respondWith(caches
    .match(event.request).then(response =>
    response || fetch(event.request)));
    });


    View Slide

32. cache-network.sw.js
    importScripts('./system-config.js');
    self.addEventListener('install', event => {
    event.waitUntil(
    caches.open('mysite-v3').then(cache =>
    cache.addAll([
    'zone.js'
    // etc
    ])));
    });
    self.addEventListener('fetch', event => {
    event.respondWith(caches
    .match(event.request).then(response =>
    response || fetch(event.request)));
    });


    View Slide

33. cache-network.sw.js
    importScripts('./system-config.js');
    self.addEventListener('install', event => {
    event.waitUntil(
    caches.open('mysite-v3').then(cache =>
    cache.addAll([
    'zone.js'
    // etc
    ])));
    });
    self.addEventListener('fetch', event => {
    event.respondWith(caches
    .match(event.request).then(response =>
    response || fetch(event.request)));
    });


    View Slide

34. Angular Mobile Toolkit
    makes it easier


    View Slide

35. index.html


    ...

    <br/>navigator.serviceWorker<br/>.register('/worker-basic.js');<br/>




    View Slide

36. ngsw-manifest.json
    {
    "static": {
    "urls": {
    "zone.js": "00ea1da4192a2030f9ae023de3b3143ed647bbab",
    "Reflect.js": "c48ea7a8ab46d67174f708d2464a46aa523d218d",
    "bundle.js": "25afd671e9ad333887e2ef79b34297125a6a0b6a"
    },
    "_generatedFromWebpack": true
    }
    }


    View Slide

37. You can
    generate the manifest
    with webpack!


    View Slide

38. Bundling


    View Slide

39. “…standard practice aiming to reduce the
    number of requests that the browser
    needs to perform in order to deliver the
    application requested by the user”


    View Slide

40. View Slide

41. View Slide

42. Less requests,
    so latency has smaller impact


    View Slide

43. $ browserify -s main main.js > bundle.js


    View Slide

44. …one big blocking request


    View Slide

45. …one big blocking request


    View Slide

46. …okay but
    that’s a “Hello world” app


    View Slide

47. “Hello world” app in Angular 2


    View Slide

48. “Hello world” app in Angular 2


    View Slide

49. Minification & Dead Code Elimination


    View Slide

50. Minification & dead code elimination
    • Mangling
    • Rename variable names
    • Rename property names
    • others…
    • Compression
    • Dead code elimination
    • Compress property access
    • Compress expressions
    • Pure functions
    • others…


    View Slide

51. Dead code elimination


    View Slide

52. dummy.js
    function answer() {
    const expr = true;
    if (expr) {
    return 42;
    }
    return 1.618;
    }
    console.log(answer());


    View Slide

53. function answer() {
    const expr = true;
    if (true) {
    return 42;
    }
    return 1.618;
    }
    console.log(answer());
    dummy.js


    View Slide

54. function answer() {
    const expr = true;
    if (true) {
    return 42;
    }
    return 1.618;
    }
    console.log(answer());
    dummy.js


    View Slide

55. console.log(42);
    dummy.js


    View Slide

56. Usually we can get rid of
    small portions
    of unused code


    View Slide

57. $ uglifyjs bundle.js --output bundle.min.js
    $ ls bundle.min.js
    524K Oct 15 18:41 bundle.min.js


    View Slide

58. $ uglifyjs bundle.js --output bundle.min.js
    $ ls bundle.min.js
    524K Oct 15 18:41 bundle.min.js


    View Slide

59. $ uglifyjs bundle.js --output bundle.min.js
    $ ls bundle.min.js
    524K Oct 15 18:41 bundle.min.js


    View Slide

60. View Slide

61. 3x smaller
    but it’s still huge…


    View Slide

62. Bundling CommonJS Modules


    View Slide

63. module.exports.pow =
    (num, pow) => Math.pow(num, pow);
    module.exports.log2 =
    num => Math.log2(num);
    index.js
    math.js
    const pow = require('./math').pow;
    console.log(pow(2, 3));


    View Slide

64. module.exports.pow =
    (num, pow) => Math.pow(num, pow);
    module.exports.log2 =
    num => Math.log2(num);
    index.js
    math.js
    const pow = require('./math').pow;
    console.log(pow(2, 3));


    View Slide

65. module.exports.pow =
    (num, pow) => Math.pow(num, pow);
    module.exports.log2 =
    num => Math.log2(num);
    index.js
    math.js
    const pow = require('./math').pow;
    console.log(pow(2, 3));


    View Slide

66. bundle.js
    module.exports.pow =
    (num, pow) => Math.pow(num, pow);
    module.exports.log2 =
    num => Math.log2(num);
    const pow = require('./math').pow;
    console.log(pow(2, 3));


    View Slide

67. Why is that?


    View Slide

68. bundle.js
    const readFile =
    require('fs').readFileSync;
    const funcName =
    readFile('name.txt')
    .toString().trim();
    const fn = require('./math')[funcName];
    console.log(fn(2, 42));


    View Slide

69. bundle.js
    const readFile =
    require('fs').readFileSync;
    const funcName =
    readFile('name.txt')
    .toString().trim();
    const fn = require('./math')[funcName];
    console.log(fn(2, 42));


    View Slide

70. bundle.js
    const readFile =
    require('fs').readFileSync;
    const funcName =
    readFile('name.txt')
    .toString().trim();
    const fn = require('./math')[funcName];
    console.log(fn(2, 42));


    View Slide

71. CommonJS modules are
    Hard for Static Code Analysis because
    they are dynamic


    View Slide

72. ES2015 modules are
    static so they can be
    statically analyzed easier


    View Slide

73. foo.js
    index.js
    export foo = () => 'foo';
    export bar = () => 'bar';
    import { foo } from './foo';
    console.log(foo());


    View Slide

74. export foo = () => 'foo';
    export bar = () => 'bar';
    import { foo } from './foo';
    console.log(foo());
    foo.js
    index.js


    View Slide

75. export foo = () => 'foo';
    export bar = () => 'bar';
    import { foo } from './foo';
    console.log(foo());
    foo.js
    index.js


    View Slide

76. export foo = () => 'foo';
    export bar = () => 'bar';
    import { foo } from `./${foo}`;
    console.log(foo());
    foo.js
    index.js


    View Slide

77. export foo = () => 'foo';
    export bar = () => 'bar';
    import { foo } from `./${foo}`;
    console.log(foo());
    foo.js
    index.js


    View Slide

78. bundle.js
    let foo = () => 'foo';
    console.log(foo());


    View Slide

79. ES2015 modules
    • Exports are always static
    • Identifiers
    • Default exports
    • Imports are always static
    • Strings as paths
    • Importing specific symbols referenced by their identifiers
    • Wildcard (the entire module)
    • Importing the default export


    View Slide

80. Tree-shaking


    View Slide

81. …dropping unused exports


    View Slide

82. Tooling
    • Rollup.js
    • Supports ES2015 modules
    • Has plugin for commonjs
    • Webpack 2
    • Performs tree-shaking over ES2015
    • Google Closure Compiler
    • Limited ES2015 modules support
    • Can use TypeScript type annotations with tsickle


    View Slide

83. Lets roll it up!


    View Slide

84. $ rollup -c config.js -o bundle.es2015.js
    $ tsc --target es5 --allowJs bundle.es2015.js
    $ uglifyjs bundle.js --output bundle.min.js
    $ ls bundle.min.js
    502K Oct 15 18:41 bundle.min.js


    View Slide

85. $ rollup -c config.js -o bundle.es2015.js
    $ tsc --target es5 --allowJs bundle.es2015.js
    $ uglifyjs bundle.js --output bundle.min.js
    $ ls bundle.min.js
    502K Oct 15 18:41 bundle.min.js


    View Slide

86. $ rollup -c config.js -o bundle.es2015.js
    $ tsc --target es5 --allowJs bundle.es2015.js
    $ uglifyjs bundle.js --output bundle.min.js
    $ ls bundle.min.js
    502K Oct 15 18:41 bundle.min.js


    View Slide

87. $ rollup -c config.js -o bundle.es2015.js
    $ tsc --target es5 --allowJs bundle.es2015.js
    $ uglifyjs bundle.js --output bundle.min.js
    $ ls bundle.min.js
    502K Oct 15 18:41 bundle.min.js


    View Slide

88. $ rollup -c config.js -o bundle.es2015.js
    $ tsc --target es5 --allowJs bundle.es2015.js
    $ uglifyjs bundle.js --output bundle.min.js
    $ ls bundle.min.js
    502K Oct 15 18:41 bundle.min.js


    View Slide

89. View Slide

90. tree-shaking
    templates


    View Slide

91.

    Existing users:

    Login here


    How many directives do we have here?


    View Slide

92.

    Existing users:

    Login here


    How many directives do we have here?


    View Slide

93. @Component({
    selector: 'div.bp-logo',
    template: '{{ hero.name }}'
    })
    class SuperheroComponent {
    @Input() hero: Superhero;
    }
    superhero.component.ts


    View Slide

94.

    Existing users:

    Login here


    How many directives do we have here?


    View Slide

95. At Runtime we know which directives are
    used in our templates


    View Slide

96. app.component.ts
    import { Component } from '@angular/core';
    @Component({
    selector: 'my-app',
    template: 'Hello world!'
    })
    export class AppComponent {}


    View Slide

97. NgIf, NgFor and other
    useless directives are still in our bundle



    View Slide

98. We Cannot Truly Tree-Shake an Angular
    Application?


    View Slide

99. …of course we can…


    View Slide

100. Introducing
     ngc


     View Slide

101.

     Existing users:

     Login here




     View Slide

102. import { NgIf, AppElement, TemplateRef_ } from "…";
     ...
     this._anchor_11 =
     r.createTemplateAnchor(this._el_5,(null as any));
     this._appEl_11 = AppElement(11,5,this,this._anchor_11);
     this._TemplateRef_11_5 =
     TemplateRef_(this._appEl_11, HeaderComponent1);
     this._NgIf_11_6 =
     NgIf(this._appEl_11.vcRef, this._TemplateRef_11_5);
     this._text_12 =
     r.createText(this._el_5,'\n ',(null as any));
     ...


     Existing users:

     Login here




     View Slide

103. import { NgIf, AppElement, TemplateRef_ } from "…";
     ...
     this._anchor_11 =
     r.createTemplateAnchor(this._el_5,(null as any));
     this._appEl_11 = AppElement(11,5,this,this._anchor_11);
     this._TemplateRef_11_5 =
     TemplateRef_(this._appEl_11, HeaderComponent1);
     this._NgIf_11_6 =
     NgIf(this._appEl_11.vcRef, this._TemplateRef_11_5);
     this._text_12 =
     r.createText(this._el_5,'\n ',(null as any));
     ...


     Existing users:

     Login here




     View Slide

104. Angular’s
     Ahead-of-Time (AoT)
     compilation


     View Slide

105. AoT Brings
     • Easy drop of unused components in bundle
     • Code which is easy for dead-code elimination
     • Fast initial rendering
     • Components are distributed pre-compiled
     • Allows us to drop compiler from bundler
     • We compile ahead of time so we don’t need it runtime


     View Slide

106. $ ./node_modules/.bin/ngc -p tsconfig.json
     $ rollup -c config.js -o bundle.es2015.js
     $ tsc --target es5 --allowJs bundle.es2015.js
     $ uglifyjs bundle.js --output bundle.min.js
     $ ls bundle.min.js
     210K Oct 15 18:41 bundle.min.js


     View Slide

107. $ ./node_modules/.bin/ngc -p tsconfig.json
     $ rollup -c config.js -o bundle.es2015.js
     $ tsc --target es5 --allowJs bundle.es2015.js
     $ uglifyjs bundle.js --output bundle.min.js
     $ ls bundle.min.js
     210K Oct 15 18:41 bundle.min.js


     View Slide

108. $ ./node_modules/.bin/ngc -p tsconfig.json
     $ rollup -c config.js -o bundle.es2015.js
     $ tsc --target es5 --allowJs bundle.es2015.js
     $ uglifyjs bundle.js --output bundle.min.js
     $ ls bundle.min.js
     210K Oct 15 18:41 bundle.min.js


     View Slide

109. $ ./node_modules/.bin/ngc -p tsconfig.json
     $ rollup -c config.js -o bundle.es2015.js
     $ tsc --target es5 --allowJs bundle.es2015.js
     $ uglifyjs bundle.js --output bundle.min.js
     $ ls bundle.min.js
     210K Oct 15 18:41 bundle.min.js


     View Slide

110. View Slide

111. Disclaimer
     ngc will not always decrease your bundle size.
     For large to medium applications the produced from the compilation
     JavaScript increases the app size.


     View Slide

112. Compression


     View Slide

113. Client Server


     View Slide

114. Client Server
     GET /app.js
     Accept-Encoding: deflate, br


     View Slide

115. Client Server
     GET /app.js
     Accept-Encoding: deflate, br
     HTTP/1.1 200 OK
     Content-Encoding: br
     …


     View Slide

116. Client Server
     GET /app.js
     Accept-Encoding: deflate, br
     HTTP/1.1 200 OK
     Content-Encoding: br
     …
     bro --decompress app.js


     View Slide

117. Popular algorithms
     • Deflate
     • Widely supported algorithm
     • Gzip + checksum in header/footer
     • Brotli
     • Similar runtime performance compared to deflate
     • Provides more dense compression compared to deflate
     • Not widely supported


     View Slide

118. $ bro --force --input b.js --output b.brotli
     $ ls b.brotli
     39K Oct 15 18:38 b.brotli


     View Slide

119. $ bro --force --input b.js --output b.brotli
     $ ls b.brotli
     39K Oct 15 18:38 b.brotli


     View Slide

120. $ bro --force --input b.js --output b.brotli
     $ ls b.brotli
     39K Oct 15 18:38 b.brotli


     View Slide

121. View Slide

122. 36x smaller
     compared to the initial bundle!


     View Slide

123. View Slide

124. …all this in angular-cli
     # build an app with env config
     ng build --prod --env=prod
     …in angular-seed
     # build with AoT
     npm run build.prod.exp


     View Slide

125. Resources:
     • mgv.io/ng-perf-checklist
     • mgv.io/build-ng-prod
     • mgv.io/mb-toolkit
     • github.com/angular/angular-cli
     • mgv.io/ng-seed


     View Slide

126. mgv.io/perf-checklist-feedback


     View Slide

127. Thank you!
     github.com/mgechev
     twitter.com/mgechev
     blog.mgechev.com


     View Slide
