Angular Toolset Support

The tooling support of the modern web frameworks advances constantly. It helps us with managing boilerplates, having more efficient and automated build process. It even helps us be more consistent and confident during our development cycle, with techniques such as static code analysis! Angular is designed with tooling in mind from the beginning! Static typing, ES2015 modules and many decisions on architectural level allow development of sophisticated tools. Such tools help us be more productive during our development process. In this talk we're going to make an overview of the toolset support for Angular. We'll briefly describe Angular CLI, Codelyzer and many other projects that can be an essential part of our development workflow!

Transcript

1. ngular
   Minko Gechev
   github.com/mgechev
   twitter.com/mgechev
   blog.mgechev.com
   toolset support (extended)
   https://flic.kr/p/fipdcK


   View Slide

2. github.com/mgechev
   twitter.com/mgechev
   blog.mgechev.com
   About
   deprecated


   View Slide

3. View Slide

4. Hold on for the
   second edition!


   View Slide

5. agenda


   View Slide

6. View Slide

7. What’s Angular?


   View Slide

8. View Slide

9. View Slide

10. View Slide

11. View Slide

12. View Slide

13. Here
    Here
    Here


    View Slide

14. View Slide

15. View Slide

16. View Slide

17. View Slide

18. View Slide

19. View Slide

20. View Slide

21. Angular Tooling
    • Angular’s AoT compiler
    • TypeScript compiler
    • Testing
    • Unit testing
    • e2e testing
    • Coverage
    • Module loader
    • Bundler
    • Provides bundling and tree shaking
    • Linter
    • TypeScript and CSS
    • Minifier
    • Minification & deadcode elimination
    • Service workers


    View Slide

22. • Angular’s AoT compiler
    • TypeScript compiler
    • Testing
    • Unit testing
    • e2e testing
    • Coverage
    • Module loader
    • Bundler
    • Provides bundling and tree shaking
    • Linter
    • TypeScript and CSS
    • Minifier
    • Minification & deadcode elimination
    • Service workers
    Angular Tooling


    View Slide

23. • Angular’s AoT compiler
    • TypeScript compiler
    • Testing
    • Unit testing
    • e2e testing
    • Coverage
    • Module loader
    • Bundler
    • Provides bundling and tree shaking
    • Linter
    • TypeScript and CSS
    • Minifier
    • Minification & deadcode elimination
    • Service workers
    Angular Tooling


    View Slide

24. • Angular’s AoT compiler
    • TypeScript compiler
    • Testing
    • Unit testing
    • e2e testing
    • Coverage
    • Module loader
    • Bundler
    • Provides bundling and tree shaking
    • Linter
    • TypeScript and CSS
    • Minifier
    • Minification & deadcode elimination
    • Service workers
    Angular Tooling


    View Slide

25. • Angular’s AoT compiler
    • TypeScript compiler
    • Testing
    • Unit testing
    • e2e testing
    • Coverage
    • Module loader
    • Bundler
    • Provides bundling and tree shaking
    • Linter
    • TypeScript and CSS
    • Minifier
    • Minification & deadcode elimination
    • Service workers
    Angular Tooling


    View Slide

26. • Angular’s AoT compiler
    • TypeScript compiler
    • Testing
    • Unit testing
    • e2e testing
    • Coverage
    • Module loader
    • Bundler
    • Provides bundling and tree shaking
    • Linter
    • TypeScript and CSS
    • Minifier
    • Minification & deadcode elimination
    • Service workers
    Angular Tooling


    View Slide

27. • Angular’s AoT compiler
    • TypeScript compiler
    • Testing
    • Unit testing
    • e2e testing
    • Coverage
    • Module loader
    • Bundler
    • Provides bundling and tree shaking
    • Linter
    • TypeScript and CSS
    • Minifier
    • Minification & deadcode elimination
    • Service workers management/generation
    Angular Tooling


    View Slide

28. Where to start?
    https://flic.kr/p/pcf4cU


    View Slide

29. angular-cli


    View Slide

30. ng new hello-world


    View Slide

31. angular-cli
    • Quick bootstrap of projects
    • Scaffolding of:
    • Components
    • Services
    • …
    • Uses Webpack
    • Support for mobile toolkit, material, etc.


    View Slide

32. # serves the application
    ng serve
    # generate new component
    ng g component my-new-component
    # build an app with env config
    ng build --prod --env=prod
    ng build --dev --env=dev
    CLI 101


    View Slide

33. angular-seed


    View Slide

34. View Slide

35. View Slide

36. View Slide

37. @ludohenin @TheDonDope
    @d3viant0ne
    @Shyam-Chen @NathanWalker


    View Slide

38. git clone git@github.com/mgechev/angular-seed


    View Slide

39. angular-seed
    • Modular statically typed build
    • Multiple apps in the same project
    • Well maintained & easy to update
    • AoT compilation support
    • Unit & e2e testing
    • Test coverage
    • tslint and codelyzer


    View Slide

40. # build & start the dev server
    npm start
    # test the app
    npm t
    # build with env config
    npm run build.prod --env-config custom
    # build with AoT
    npm run build.prod.exp
    Seed 101


    View Slide

41. Other starters
    • angular2-webpack-starter
    • Webpack based
    • angular2-seed-advanced
    • NativeScript, Electron, etc.
    • Based on angular-seed


    View Slide

42. Development process and experience
    https://flic.kr/p/daxeMY


    View Slide

43. Typical JavaScript experience


    View Slide

44. Angular is…
    • Built with TypeScript
    • Designed with tooling in mind


    View Slide

45. View Slide

46. We already have
    • Superset of JavaScript
    • Compile time type checking


    View Slide

47. Analyzable templates
    https://flic.kr/p/irHwLW


    View Slide

48. Angular 1




    View Slide

49.

    Angular 1


    View Slide

50.



    Angular 1


    View Slide

51.



    Angular 1


    View Slide

52.

    Angular 2


    View Slide

53.



    Angular 2


    View Slide

54. Angular 2 Component
    @Component({
    selector: 'hero-details',
    template: `


    Age: {{ formatAge(hero.age) }}

    `
    })
    class HeroDetailsComponent {
    hero: Superhero;
    formatAge(age: number) {
    // ...
    }
    }


    View Slide

55. Does property exist
    @Component({
    selector: 'hero-details',
    template: `


    Age: {{ formatAge(hero.age) }}

    `
    })
    class HeroDetailsComponent {
    hero: Superhero;
    formatAge(age: number) {
    // ...
    }
    }


    View Slide

56. Type checking
    @Component({
    selector: 'hero-details',
    template: `


    Age: {{ formatAge(hero.age) }}

    `
    })
    class HeroDetailsComponent {
    hero: Superhero;
    formatAge(age: number) {
    // ...
    }
    }


    View Slide

57. Advanced type checking
    @Component({
    selector: 'hero-details',
    template: `


    Age: {{ formatAge(hero.age) }}

    `
    })
    class HeroDetailsComponent {
    hero: Superhero;
    formatAge(age: number) {
    // ...
    }
    }


    View Slide

58. github.com/mgechev/
    codelyzer


    View Slide

59. “Codelyzer contains set of rules that provide
    automated alignment to the Angular Style Guide
    & improvement of our development experience”


    View Slide

60. View Slide

61. View Slide

62. Why not
    instant feedback*


    View Slide

63. View Slide

64. Trusted by
    • Angular team
    • jQWidgets
    • ng2-bootstrap


    View Slide

65. View Slide

66. Language Service
    • Syntax highlighting in templates
    • Syntax and semantic error reporting
    • Auto-completion in templates


    View Slide

67. AoT
    compilation


    View Slide

68. How Angular works?


    View Slide

69. Disclaimer
    The description is simplified and does not completely
    align with the actual implementation.


    View Slide

70. component.ts
    import { Component } from '@angular/core';
    @Component({
    selector: 'my-app',
    template: `
    Hello {{ name }}!

    Summary of the awesome app!

    `
    })
    export class Component {
    name: string;
    }


    View Slide

71. interface InternalComponent {
    create();
    detectChanges();
    destroy();
    }
    internal-component.ts
    For more information: http://bit.ly/2dsk6z5


    View Slide

72. class InternalComponent {
    create() {
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));
    }
    //...
    }
    create method


    View Slide

73. class InternalComponent {
    create() {
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));
    }
    //...
    }
    create method

    Hello {{ name }}!

    Summary of the awesome app!




    View Slide

74. class InternalComponent {
    create() {
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));
    }
    //...
    }
    create method

    Hello {{ name }}!

    Summary of the awesome app!




    View Slide

75. class InternalComponent {
    create() {
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));
    }
    //...
    }
    create method

    Hello {{ name }}!

    Summary of the awesome app!




    View Slide

76. class InternalComponent {
    create() {
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));
    }
    //...
    }
    create method

    Hello {{ name }}!

    Summary of the awesome app!




    View Slide

77. class InternalComponent {
    create() {
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));
    }
    //...
    }
    create method


    View Slide

78. const template = `
    Hello {{ name }}!

    Summary of the awesome app!

    `;
    header
    h1 p
    TextNode
    TextNode
    Interp
    Expr
    Template to AST


    View Slide

79. header
    h1 p
    TextNode
    TextNode
    Interp
    Expr
    create()
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));

    Hello {{ name }}!

    Summary of the awesome app!




    View Slide

80. header
    h1 p
    TextNode
    TextNode
    Interp
    Expr
    create()
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));

    Hello {{ name }}!

    Summary of the awesome app!




    View Slide

81. header
    h1 p
    TextNode
    TextNode
    Interp
    Expr
    create()
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));

    Hello {{ name }}!

    Summary of the awesome app!




    View Slide

82. this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));

    Hello {{ name }}!

    Summary of the awesome app!


    header
    h1 p
    TextNode
    TextNode
    Interp
    Expr
    create()


    View Slide

83. this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));

    Hello {{ name }}!

    Summary of the awesome app!


    header
    h1 p
    TextNode
    TextNode
    Interp
    Expr
    create()


    View Slide

84. this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));

    Hello {{ name }}!

    Summary of the awesome app!


    header
    h1 p
    TextNode
    TextNode
    Interp
    Expr
    create()


    View Slide

85. this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));

    Hello {{ name }}!

    Summary of the awesome app!


    header
    h1 p
    TextNode
    TextNode
    Interp
    Expr
    create()


    View Slide

86. this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    this.p =
    r.createElement(this.header, 'p');
    r.createText(this.p,
    'Summary of the awesome app!'));

    Hello {{ name }}!

    Summary of the awesome app!


    header
    h1 p
    TextNode
    TextNode
    Interp
    Expr
    create()


    View Slide

87. detectChanges()
    class InternalComponent {
    //...
    detectChanges() {
    let val = interpolate('Hello',
    this.context.name, '!');
    if (this.binding !== val) {
    r.createText(this.h1, val);
    this.binding = val;
    }
    }
    //...
    }


    View Slide

88. You can bind
    ONLY to public
    members


    View Slide

89. What about
    encapsulation


    View Slide

90. encapsulation
    tsc demo.component.ts --stripInternal
    TypeScript will omit
    name from the d.ts files
    @Component({
    selector: 'my-app',
    template: `...`
    })
    export class Component {
    /** @internal */
    name: string = 'Iron Man';
    }


    View Slide

91. --stripInternal
    import { Component } from 'library';
    const cmp = new Component();
    // Property 'name' does not exist on type 'Component'.
    cmp.name = 'Captain America';


    View Slide

92. Why do we need to generate
    detectChanges?


    View Slide

93. Scope.prototype.$digest = function () {
    'use strict';
    var dirty, watcher, current, i;
    do {
    dirty = false;
    for (i = 0; i < this.$$watchers.length; i += 1) {
    watcher = this.$$watchers[i];
    current = this.$eval(watcher.exp);
    if (!Utils.equals(watcher.last, current)) {
    watcher.last = Utils.clone(current);
    dirty = true;
    watcher.fn(current);
    }
    }
    } while (dirty);
    for (i = 0; i < this.$$children.length; i += 1) {
    this.$$children[i].$digest();
    }
    };
    Traditional CD
    http://bit.ly/2dS0d7P


    View Slide

94. CD with codegen
    • Easier to reason about
    • Obviously fast
    • Inline caching performance boost
    • VM friendly code


    View Slide

95. View Slide

96. If the codegen happens at build
    time, it’s called AoT; if it happens
    at runtime, it’s called JiT


    View Slide

97. AoT Brings
    • Easy drop of unused components in bundle
    • Code which is easy for dead-code elimination
    • Fast initial rendering
    • Components are distributed pre-compiled
    • Allows us to drop compiler from bundler
    • We compile ahead of time so we don’t need it runtime


    View Slide

98. import { interpolate, Renderer, ... } from "…";
    ...
    create() {
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    //...
    }
    ...
    vs

    Hello {{ name }}!

    Summary of the awesome app!




    View Slide

99. import { interpolate, Renderer, ... } from "…";
    ...
    create() {
    this.header =
    r.createElement('header');
    this.h1 =
    r.createElement(this.header, 'h1');
    this.binding = interpolate('Hello',
    this.context.name, '!');
    r.createText(this.h1, this.binding);
    //...
    }
    ...

    Hello {{ name }}!

    Summary of the awesome app!


    vs


    View Slide

100. AoT generated code has explicit imports
     so the bundler knows what the app uses


     View Slide

101. Introducing ngc


     View Slide

102. ./node_modules/.bin/ngc -p tsconfig.json


     View Slide

103. ngc is a wrapper over tsc


     View Slide

104. ngc will produce
     • *.ngfactory.ts
     • *.css.shim.ts
     • *.metadata.json


     View Slide

105. *.ngfactory.ts contains the
     “internal components” we described


     View Slide

106. *.css.shim.ts contains the scoped
     component styles


     View Slide

107. *.metadata.json contains component
     metadata (i.e., Angular specific
     decorators)


     View Slide

108. {
     "decorators": [{
     "expression": {
     "__symbolic": "reference",
     "module": "@angular/core",
     "name": "Component"
     },
     "arguments": [{
     "selector": "sd-app",
     "templateUrl": "app.html"
     }]
     }]
     }
     @Component({
     selector: 'sd-app',
     templateUrl: 'app.html',
     })
     export class AppComponent {}
     app.ts *app.metadata.json


     View Slide

109. ngc compatible
     third-party libraries must be distributed
     with *.metadata.json


     View Slide

110. AoT
     compiled application has a slightly
     different bootstrap mechanism


     View Slide

111. JiT bootstrap
     import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
     import { AppModule } from './app.module';
     platformBrowserDynamic().bootstrapModule(AppModule);


     View Slide

112. import { platformBrowser } from '@angular/platform-browser';
     import { AppModuleNgFactory } from './app.module.ngfactory';
     platformBrowser().bootstrapModule(AppModule);
     JiT bootstrap
     AoT bootstrap
     import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
     import { AppModule } from './app.module';
     platformBrowserDynamic().bootstrapModule(AppModule);


     View Slide

113. View Slide

114. Resources
     • Angular CLI
     • AoT in Angular 2
     • Building an Angular 2 Application for Production
     • 2.5X Smaller Angular 2 Apps with GCC
     • Codelyzer


     View Slide

115. mgv.io/ngtool-feedback


     View Slide

116. Thank you!
     github.com/mgechev
     twitter.com/mgechev
     blog.mgechev.com


     View Slide
