Hello CocosSharp

Transcript

1. Hello CocosSharp Developer Evangelist @mikebluestein Mike Bluestein
2. “CocosSharp blends the power of the Cocos2D programming model with C# and the .NET Framework…the API has been designed to follow C# and .NET idioms.” Miguel de Icaza Xamarin
3. “It’s so cool” Mike Bluestein Xamarin
4. Cross Platform
5. What Makes Up the Game • Application • Scenes • Layers • Sprites • Actions • Other cool stuff - Particle systems, audio, physics …
6. CocosSharp API
7. CCApplication • Creates and initializes the graphics device • Sets the application delegate • Starts the game
8. var app = new CCApplication ();
 app.ApplicationDelegate = new GoneBananasApplicationDelegate ();
 app.StartGame (); CCApplication
9. • Handles application lifecycle • Similar to UIApplicationDelegate in iOS • Set the application’s content folder • Load the main window’s first scene CCApplicationDelegate
10. public virtual void ApplicationDidEnterBackground (CCApplication application)

 public virtual void ApplicationDidFinishLaunching (CCApplication application, CCWindow mainWindow)

 public virtual void ApplicationWillEnterForeground (CCApplication application)
 CCApplicationDelegate
11. Content Folder Project Folder Containing Resources ▪ Fonts ▪ Sounds ▪ Images
 Set via application’s ContentRootDirector application.ContentRootDirectory = "Content";
12. CCDirector Window.DefaultDirector.ReplaceScene (GameLayer.GameScene (Window)); • Available via Window.DefaultDirector • Manages any additional scene loading
13. CCDirector
14. CCDirector
15. CCScene • Manages game logic for various portions of the game • Contains layers (CCLayer)
16. CCScene • Manages game logic for various portions of the game • Contains layers (CCLayer)
17. CCLayer • Added to scene • Contains node tree (sprites, labels, menus, etc) • Schedule method to run code at repeated interval • Creates the scene for which it is a child
18. CCLayer var scene = new CCScene (mainWindow);
 var layer = new GameStartLayer ();
 scene.AddChild (layer);

 return scene;

19. • Sprites are nodes that create images in the game • Image file must be in Content folder • Include high definition image using -hd convention CCSprite
20. • Efficient sprite loading • Renders all children CCSpriteBatch
21. CCAction • Actions perform tasks on nodes • For example, animating sprites • Can run multiple actions sequentially using CCSequence
22. CCTouch • Encapsulates a touch on the screen • Set TouchEnabled to true in layer • Override touch methods in layer ▪ TouchesBegan, TouchesMoved, TouchesEnded, etc
23. Accelerometer • Available via CCAccelerometer • Access with Window.Accelerometer
24. Window.Accelerometer.Enabled = true;
 var listener = new CCEventListenerAccelerometer();
 listener.OnAccelerate = DidAccelerate;
 AddEventListener (listener);

 public void DidAccelerate(CCEventAccelerate accelEvent)
 {
 accelEvent.Acceleration.X;
 accelEvent.Acceleration.Y;
 accelEvent.Acceleration.Z;
 }
 Accelerometer
25. Audio • SimpleAudioEngine.SharedEngine ▪ Sound Effects ▪ Background Sound • Pause/Resume background sound in CCApplicationDelegate ▪ Pause when app enters background ▪ Resume when app enters foreground
26. Drawing Primitives • CCDrawNode • Draw lines, polygons, circles, etc …
27. var draw = new CCDrawNode();

 draw.DrawPolygon(
 star,
 star.Length,
 new CCColor4F(1, 0, 0, 0.5f), 1,
 new CCColor4F(0, 0, 1, 1));

 Drawing Primitives
28. Particle Systems • Graphical effects by rendering a set of particles • Several built in - smoke, galaxy, rain, … • Can add custom particle systems
29. var sun = new CCParticleSun (pt);
 sun.StartColor = new CCColor4F (CCColor3B.Red);
 sun.EndColor = new CCColor4F (CCColor3B.Yellow); Particle Systems
30. var sun = new CCParticleSun (pt);
 sun.StartColor = new CCColor4F (CCColor3B.Red);
 sun.EndColor = new CCColor4F (CCColor3B.Yellow); Particle Systems
31. Parallax • CCParallaxNode • Children move at different relative speeds
32. Parallax • CCParallaxNode • Children move at different relative speeds
33. var parallaxClouds = new CCParallaxNode {
 Position = new CCPoint (0, h)
 };

 float yRatio1 = 1.0f;
 float yRatio2 = 0.5f;

 parallaxClouds.AddChild (cloud1, 0,
 new CCPoint (1.0f, yRatio1),
 new CCPoint (100, -100 + h - (h * yRatio1)));

 parallaxClouds.AddChild (cloud2, 0,
 new CCPoint (1.0f, yRatio2),
 new CCPoint (250, -200 + h - (h * yRatio2))); Parallax
34. Effects • Lots of visual effects • Waves, Twirl, Lens3D, Shuffle Tiles, … • Implemented using actions
35. var flipx = new CCFlipX3D(t);
 CCFiniteTimeAction flipx_back = flipx.Reverse();
 var delay = new CCDelayTime (2);

 return new CCSequence(flipx, delay, flipx_back); Effects
36. Physics • 2D Rigid Body Physics • C# port of Box2D • world, body, shape, fixture
37. var def = new b2BodyDef ();
 …
 b2Body body = world.CreateBody (def);
 var circle = new b2CircleShape ();
 …
 var fd = new b2FixtureDef ();
 fd.shape = circle;
 …
 body.CreateFixture (fd); Physics
38. Demo
39. Gone Bananas Demonstrates Many CocosSharp Features ▪ Parallax ▪ Particles ▪ Touch handling ▪ Physics ▪ Sprite creation ▪ Actions ▪ Scene transitions ▪ Sprite sheet animation ▪ Sprite batching
40. CocosSharp Resources • Source - github.com/mono/CocosSharp • Samples - github.com/mono/cocos-sharp-samples
41. Thank You! Mike Bluestein @mikebluestein
