How to make DR-ready system with Amazon Aurora Global Database

APJ Open Mic - May (in AWS Community Builders)

Transcript

1. How to make DR-ready system
   with Amazon Aurora Global Database
   Minoru Onda @minorun365
   So#ware engineer
   KDDI Corpora1on & KDDI Agile Development Center Corpora1on
   A W S C O M M U N I T Y B U I L D E R S
   A PJ O P E N M I C – M AY


   View Slide

2. > Minoru Onda @minorun365
   So,ware Engineer / KDDI & KAG (Concurrently)
   Co-lead in communiCes
   • JAWS-UG SRE Branch
   • JAWS DAYS 2022
   Awards
   • KDDI Cloud SAMURAI 2021
   • KDDI Cloud Ambassadors 2021
   $ whoami


   View Slide

3. Do you love Amazon Aurora?


   View Slide

4. Off course I love!
   😍


   View Slide

5. • Distributed instances
   • Fast replicaCon in 3AZ storage
   • Autoscaling of replicas and volumes
   docs.aws.amazon.com/AmazonRDS/latest/AuroraUserGuide/Aurora.Overview.html
   Amazon Aurora is cloud-na3ve RDB


   View Slide

6. Customer service applicaCon in mobile shops
   Where I am using Aurora


   View Slide

7. Hosted on EKS and connecCong with many on-prem systems
   Where I am using Aurora
   VPC
   Tokyo region
   EKS
   on EC2 Aurora
   iPads on shops
   Private network
   Private network
   On-prem workloads
   DX
   DX


   View Slide

8. We faced huge outage of DX on 2021, and started mulC-region planning
   Started DR planning a?er Direct Connect outage
   VPC
   Tokyo region
   EKS
   on EC2 Aurora
   iPads on shops
   Private network
   Private network
   On-prem workloads
   DX
   DX


   View Slide

9. © 2023, Amazon Web Services, Inc. or its affiliates. All rights reserved.
   Then, how to enable BCP?


   View Slide

10. Clarify your requirements!
    • Recovery Cme objecCve (RTO)
    • Recovery point objecCve (RPO)
    Basic strategies of disaster recovery (DR) on AWS
    aws.amazon.com/jp/blogs/architecture/disaster-recovery-dr-architecture-on-aws-part-i-strategies-for-recovery-in-the-cloud/


    View Slide

11. Select best-suit plan with your requirement
    • Backup & restore
    • Pilot light
    • Warm standby
    • MulC-site acCve/acCve
    Basic strategies of disaster recovery (DR) on AWS
    aws.amazon.com/jp/blogs/architecture/disaster-recovery-dr-architecture-on-aws-part-i-strategies-for-recovery-in-the-cloud/


    View Slide

12. Select best-suit plan with your requirement
    • Backup & restore
    • Pilot light
    • Warm standby
    • MulC-site acCve/acCve
    We chose it!
    Basic strategies of disaster recovery (DR) on AWS
    aws.amazon.com/jp/blogs/architecture/disaster-recovery-dr-architecture-on-aws-part-i-strategies-for-recovery-in-the-cloud/
    ☝


    View Slide

13. And don’t worry!
    It’s easy to make your system
    mul/-region 😚


    View Slide

14. And don’t worry!
    It’s easy to make your system
    mul/-region 😚
    ...excluding Database 🥶


    View Slide

15. © 2023, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Why database is difficult on mul:-region?


    View Slide

16. When you have mulCple DB like...
    • To get High-Availability
    • To make DR-ready
    • To enable Blue/Green deployment
    “You build mul<-DB,
    you run it consistently!”
    Difficul3es on mul3ple database
    Werner Vogels on Wikipedia,
    however he never says above


    View Slide

17. Popular soluCons for make DBs consistent:
    From applica+on
    • 2 phase commit (2PC)
    • Saga pe8ern
    Difficul3es on mul3ple database
    From database
    • Logical replica+on
    • Phisical replica+on


    View Slide

18. Popular soluCons for make DBs consistent:
    From applica+on
    • 2 phase commit (2PC)
    • Saga pe8ern
    Difficul3es on mul3ple database
    From database
    • Logical replica+on
    • Phisical replica+on
    ☝
    You can use it easily
    with Amazon Aurora!


    View Slide

19. Yes that’s Global Database


    View Slide

20. © 2023, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    What is Global Database?


    View Slide

21. • Storage replicaCon across regions
    • High performance with phisical volume replicaCon
    Amazon Aurora Global Database
    Aurora cluster (primary)
    Tokyo region
    Writer & readers
    Cluster volumes
    Aurora cluster (secondary)
    Osaka region
    Readers
    Cluster volumes
    ‎ ‎ ‎
    Outbound
    replica4on


    View Slide

22. Supported engines:
    On Aurora MySQL
    • Ver 2.11+ (minor versions)
    Amazon Aurora Global Database
    On Aurora PostgreSQL
    • Ver 11.17+ (minor versions)
    • Ver 12.12+ (minor versions)
    • Ver 13.8+ (minor versions)
    • Ver 14.5+ (minor versions)


    View Slide

23. Just click “Add AWS Region” on exisCng cluster, that’s it 👍
    How to use Global Database


    View Slide

24. © 2023, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Demo 1: Enable Global Database


    View Slide

25. Conguratula*ons 🎉
    It’s global now.
    ...is that all??
    🥳


    View Slide

26. No, it’s just a beginning...
    What you shoud do
    on actual disaster maBers!


    View Slide

27. © 2023, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Two op:ons for failover Global Database


    View Slide

28. We have 2 opCons for failover regions in Global Database
    Planned failover (managed)
    • One-click on console
    • Cannot used on emergency
    What should you do on disaster?
    Unplanned failover
    • Manual opera9on with steps
    • Available even on disaster


    View Slide

29. We have 2 opCons for failover regions in Global Database
    Planned failover (managed)
    • One-click on console
    • Cannot used on emergency
    What should you do on disaster?
    Unplanned failover
    • Manual opera9on with steps
    • Available even on disaster
    👇
    Use it first!


    View Slide

30. When you run Global Database on Tokyo (primary) and Osaka (secondary) ...
    Opera3on steps on disaster
    Aurora cluster (primary)
    Tokyo region
    Aurora cluster (secondary)
    Osaka region
    ‎ ‎ ‎
    Primary


    View Slide

31. Disaster occured!
    Opera3on steps on disaster
    Aurora cluster (primary)
    Tokyo region Osaka region
    ‎ ‎ ‎ Aurora cluster (secondary)


    View Slide

32. Then you shoud remove secondary cluster from Global Database
    Opera3on steps on disaster
    Aurora cluster (primary)
    Tokyo region
    Aurora cluster (standalone)
    Osaka region
    Remove from
    Global DB


    View Slide

33. A,er disaster past, you can rebuild Global Database from Osaka (new-primary)
    Opera3on steps a?er disaster
    Aurora cluster (old)
    Tokyo region
    Aurora cluster (primary)
    Osaka region
    Aurora cluster (secondary)
    ‏ ‏ ‏
    Rebuild GDB
    Primary


    View Slide

34. © 2023, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Demo 2: Unplanned failover on emergency


    View Slide

35. A,er disaster past, you can rebuild Global Database from Osaka (new-primary)
    Opera3on steps a?er disaster
    Aurora cluster (old)
    Tokyo region
    Aurora cluster (primary)
    Osaka region
    Aurora cluster (secondary)
    ‏ ‏ ‏
    Rebuild GDB
    Primary


    View Slide

36. On peaceful day, you can switch back regions with managed planned failover
    Opera3on steps a?er disaster
    Aurora cluster (old)
    Tokyo region
    Aurora cluster (secondary)
    Osaka region
    Aurora cluster (primary)
    ‎ ‎ ‎
    Managed
    failover
    Primary


    View Slide

37. © 2023, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Demo 3: Planned failover (managed)


    View Slide

38. © 2023, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    What I learned by using Global Database
    on produc:on


    View Slide

39. Make DR opera3on flowchart beforehand!
    Disaster occured!


    View Slide

40. Make DR opera3on flowchart beforehand!
    Disaster occured! Decide to ac4vate DR


    View Slide

41. Make DR opera3on flowchart beforehand!
    Disaster occured! Decide to ac4vate DR
    Check health of Osaka
    cluster using SQL


    View Slide

42. Make DR opera3on flowchart beforehand!
    Disaster occured! Decide to ac4vate DR
    Check health of Osaka
    cluster using SQL
    Shut requests out
    by enabling redirect


    View Slide

43. Make DR opera3on flowchart beforehand!
    Disaster occured! Decide to ac4vate DR
    Check health of Osaka
    cluster using SQL
    Shut requests out
    by enabling redirect
    Check replica4on lag


    View Slide

44. Make DR opera3on flowchart beforehand!
    Disaster occured! Decide to ac4vate DR
    Check health of Osaka
    cluster using SQL
    Shut requests out
    by enabling redirect
    Check replica4on lag
    Modify DNS record to
    switch Aurora endpoints


    View Slide

45. Make DR opera3on flowchart beforehand!
    Disaster occured! Decide to ac4vate DR
    Check health of Osaka
    cluster using SQL
    Shut requests out
    by enabling redirect
    Check replica4on lag
    Modify DNS record to
    switch Aurora endpoints
    Unplanned failover
    on Global Database


    View Slide

46. Make DR opera3on flowchart beforehand!
    Disaster occured! Decide to ac4vate DR
    Check health of Osaka
    cluster using SQL
    Shut requests out
    by enabling redirect
    Check replica4on lag
    Modify DNS record to
    switch Aurora endpoints
    Unplanned failover
    on Global Database
    Chack health of app
    on Osaka


    View Slide

47. Make DR opera3on flowchart beforehand!
    Disaster occured! Decide to ac4vate DR
    Check health of Osaka
    cluster using SQL
    Shut requests out
    by enabling redirect
    Check replica4on lag
    Modify DNS record to
    switch Aurora endpoints
    Unplanned failover
    on Global Database
    Chack health of app
    on Osaka
    within RTO


    View Slide

48. In my case...
    • Automated all the operaCons with Exastro (Japanese so,ware)
    • Separeted operaCons by group, making it easy to go flexible with situaCon
    • Using Ansible for included operaCons of on-prem network components
    You will make mistake on emergency. Automate it!


    View Slide

49. If you can, plan regular training with all the stakeholders
    • OperaCons team
    • Infrastructure developers (including DBA)
    • ApplicaCon developers
    • Management (who can decide to acCvate DR)
    And prac3ce DR opera3ons regularly!


    View Slide

50. Thank you!
    Minoru Onda
    How to make DR-ready system
    with Amazon Aurora Global Database Give me your feedback!


    View Slide
