PHP Microservice Development by the Example of a Mail Service

This talk was given on 2016-09-29 for the PHP Usergroup Munich at Scandio.

The main topic of this talk are queue systems in various PHP frameworks and how they differ.

Transcript

1. PHP Microservice Development by the Example of a Mail Service PHP UG Munich / 2016-09-28 / Max Kleucker / Scandio GmbH
2. SMTP SMTP SMTP Application 1 Application 2 Application X
3. SMTP CONFIGS SMTP CONFIGS EVERYWHERE
4. Ƙ SMTP Application 1 Application 2 Application X
5. Microservice Application 1 Ƙ Mailer Service
6. Application 1 Ƙ { Mailer Service REST
 Endpoint Business Logic Mail Delivery SMTP
7. Ƙ { Mailer Service REST
 Endpoint Business Logic Mail Delivery
8. Ƙ { Mailer Service REST
 Endpoint Business Logic Mail Delivery Queue
9. Why a Queue? • Substituting the Mail Delivery with a Mail Catcher • Additional Delivery mechanisms • Asynchronous if there are larger mail batches to be sent
10. Queues The focus of this talk.
11. Producer Consumer Queue creates a message fetches messages Queues Basics
12. "Vanilla" PHP • AMQP-Lib (https://github.com/php-amqplib/php-amqplib)
13. $connection = new AMQPStreamConnection('rabbitmq', 5672, 'guest', 'guest'); $channel = $connection->channel(); $channel->queue_declare('send_mail', false, false, false, false); $msg = new AMQPMessage('{"property": "value"}'); $channel->basic_publish($msg, '', 'send_mail'); $channel->close(); $connection->close(); PHP Enqueue a Message
14. { "property": "value" } PHP Message Payload
15. $connection = new AMQPStreamConnection('localhost', 5672, 'guest', 'guest'); $channel = $connection->channel(); $channel->queue_declare('send_mail', false, false, false, false); $callback = function($msg) { echo "Received ". $msg->body. "\n"; }; $channel->basic_consume('send_mail', '', false, true, false, false, $callback); while(count($channel->callbacks)) { $channel->wait(); } PHP Process a Message
16. Laravel • Using Laravel Queues and Jobs • vladimir-yuldashev/laravel-queue-rabbitmq
17. Laravel → RabbitMQ # .env QUEUE_DRIVER=rabbitmq RABBITMQ_HOST=rabbit1 RABBITMQ_PORT=5672 RABBITMQ_VHOST=/ RABBITMQ_LOGIN=guest RABBITMQ_PASSWORD=guest RABBITMQ_QUEUE=mailqueue Laravel
18. Job Definition namespace App\Jobs; class SendEmail implements ShouldQueue { use InteractsWithQueue, Queueable, SerializesModels; protected $mail; public function __construct(Mail $mail) { $this->mail = $mail; } } Laravel
19. $mail = new \App\Mail(); $mail->receiver = 'admin@example.com'; $mail->subject = 'This is an email!'; $mail->body = 'Moar awesome text.'; $job = new \App\Jobs\SendEmail($mail); dispatch($job->onQueue('mailqueue')); Laravel Enqueue a Message
20. Laravel Enqueue a Message $mail = new \App\Mail(); $mail->receiver = 'admin@example.com'; $mail->subject = 'This is an email!'; $mail->body = 'Moar awesome text.'; $job = new \App\Jobs\SendEmail($mail); dispatch($job->onQueue('mailqueue'));
21. Laravel Enqueue a Message $mail = new \App\Mail(); $mail->receiver = 'admin@example.com'; $mail->subject = 'This is an email!'; $mail->body = 'Moar awesome text.'; $job = new \App\Jobs\SendEmail($mail); dispatch($job->onQueue('mailqueue'));
22. Laravel Enqueue a Message $mail = new \App\Mail(); $mail->receiver = 'admin@example.com'; $mail->subject = 'This is an email!'; $mail->body = 'Moar awesome text.'; $job = new \App\Jobs\SendEmail($mail); dispatch($job->onQueue('mailqueue'));
23. { "job": "Illuminate\\Queue\\CallQueuedHandler@call", "data": { "commandName": "App\\Jobs\\SendEmail", "command": "O:18:\"App\\Jobs\\SendEmail\":5:{s: 7:\"\u0000*\u0000mail\";O:45:\"Illuminate\\Contracts\\Database\ \ModelIdentifier\":2:{s:5:\"class\";s:8:\"App\\Mail\";s:2:\"id\";N;}s: 6:\"\u0000*\u0000job\";N;s:10:\"connection\";N;s:5:\"queue\";s: 9:\"mailqueue\";s:5:\"delay\";N;}" } } Laravel Message Payload
24. Laravel Message Payload { "job": "Illuminate\\Queue\\CallQueuedHandler@call", "data": { "commandName": "App\\Jobs\\SendEmail", "command": "O:18:\"App\\Jobs\\SendEmail\":5:{s: 7:\"\u0000*\u0000mail\";O:45:\"Illuminate\\Contracts\\Database\ \ModelIdentifier\":2:{s:5:\"class\";s:8:\"App\\Mail\";s:2:\"id\";N;}s: 6:\"\u0000*\u0000job\";N;s:10:\"connection\";N;s:5:\"queue\";s: 9:\"mailqueue\";s:5:\"delay\";N;}" } }
25. Laravel Process a Message class SendEmail implements ShouldQueue { use InteractsWithQueue, Queueable, SerializesModels; protected $mail; public function __construct(Mail $mail) { $this->mail = $mail; } public function handle() { $payload = $this→mail; } }
26. class SendEmail implements ShouldQueue { use InteractsWithQueue, Queueable, SerializesModels; protected $mail; public function __construct(Mail $mail) { $this->mail = $mail; } public function handle() { $payload = $this->mail; } } $ php artisan queue:work Laravel Process a Job
27. • Job-Object is used for creating and processing messages • Difficult if you want to use it between different applications • Data is persisted in the database, not available in the message • Low configuration overhead, easy to use Laravel Summary
28. Symfony • Using Base Symfony 3 Install • php-amqplib/rabbitmq-bundle
29. Symfony Symfony → RabbitMQ # app/config/config.yml old_sound_rabbit_mq: connections: default: host: 'rabbitmq' port: 5672 user: 'guest' password: 'guest' vhost: '/' lazy: false connection_timeout: 3 read_write_timeout: 3 producers: send_mail: connection: default exchange_options: {name: 'send-mail', type: direct} queue_options: {name: 'send-mail'} consumers: send_mail: connection: default exchange_options: {name: 'send-mail', type: direct} queue_options: {name: 'send-mail'} callback: send_mail_service
30. Symfony Enqueue a Message $mail = new Mail(); $mail->receiver = 'admin@example.com'; $mail->subject = 'This is an email!'; $mail->body = 'Moar awesome text.'; $this->get('old_sound_rabbit_mq.send_mail_producer') ->publish(serialize($mail));
31. Symfony Enqueue a Message $mail = new Mail(); $mail->receiver = 'admin@example.com'; $mail->subject = 'This is an email!'; $mail->body = 'Moar awesome text.'; $this->get('old_sound_rabbit_mq.send_mail_producer') ->publish(serialize($mail));
32. O:21:"AppBundle\Entity\Mail":3:{s:8:"receiver";s: 17:"admin@example.com";s:7:"subject";s:17:"This is an email!";s:4:"body";s:18:"Moar awesome text.";} Symfony Message Payload
33. namespace AppBundle\Consumer; class SendMailConsumer implements ConsumerInterface { public function execute(AMQPMessage $msg) { $payload = $msg->getBody(); } } Symfony Process a Message • Must be registered as Service in Symfony
34. namespace AppBundle\Consumer; class SendMailConsumer implements ConsumerInterface { public function execute(AMQPMessage $msg) { $payload = $msg->getBody(); } } Symfony Process a Message $ bin/console rabbitmq:consumer -w send_mail
35. • More configuration necessary • Able to create and handle "bare" messages • Better suited when talking with other software Symfony Summary
36. Queues Summary • As always: Differentiation between comfort (Laravel) and power (Vanilla PHP, Symfony) • Personal Opinion: Better to stay close to independent messages
37. So, how is our Mailer-Service going?
38. Thank you. !
