Practical Cryptography : Data Encryption

Transcript

1. Jérémy Courtial Data encryption Practical cryptography
2. Password hashing breaking news
3. Final impl. on the way Winner : Argon2 Goal: find a new password hashing algorithm Password Hashing Competition
4. Now back to the subject
5. Confidentiality Hide things
6. Authentication Ensure thing’s owner
7. Integrity Check things
8. The Cryptography Club’s Rules
9. Rule #1 Don’t reinvent crypto
10. Rule #2 Don’t reinvent crypto
11. Be aware of the Kerckhoffs Principle Rule #3
12. « The enemy knowns the system »
13. Forget about « security through obscurity »
14. The key is the secret
15. Data Encryption
16. Not messing up Cipher stuff Keys management Challenges
17. Key Management
18. Should be easy to retrieve Must be kept secret (from Rule #3) Maximum entropy Key Properties
19. Con: must be shared between actors Pro: shorter keys, ie. better performances Opposed to asymmetric keys (obviously…) Symmetric Key
20. Network services (ex: Vault) OS level container (ex: Keychain) Specialised hardware (ex: HSM) Key Storage
21. Better : no storage
22. But don’t count on him for entropy or reliability Ask the user BaaS : Brain as a Service No Storage
23. Sounds like a password hash no ? How to address brute force and rainbow tables ? Derive a password into a key Password- Based Derivation
24. Password-Based Derivation KDF( password, salt, cost ) = key
25. Do not store the result ! The key only live in memory Derived when need Key Derivation
26. Password KDF(pwd)
27. Specialised stored encrypted by the Master Key 1 Master Key N Specialised Keys On key per usage Key Rules
28. Password KDF(pwd) Setup
29. Encrypt Sub Key 1 Master Key Data Encryption Encrypted Keys database
30. Password KDF(pwd) Next connections
31. Decrypt Master Key 6B693D6A1 398424A … Sub Key 1
32. Data Encryption
33. data encryption
36. What’s just happen ??
37. Know what you’re doing APIs are usually terrible and don’t help Stack Overflow is not a way to learn crypto Data Encryption
38. The harder part : use it correctly Choose a mode (if relevant) Choose an algorithm Encryption : How to ?
39. What about certifications ? Good cryptanalysis, well implemented Symmetric encryption algorithm Which algorithm ?
40. Won’t save you RGS (ANSSI) in France FIPS for US & international Certifications See keylength.com
41. Have a doubt ? A E S dvance crypton tandard
42. Cryptography History 2001 NIST select Rijndael as AES Crypto. Dark Ages Brave new world* *For at least a week or two
43. Most studied algorithm, no realistic attack Universally supported « Nobody ever get fired for choosing AES » AES
44. Choose your AES mode (You thought it was that simple ?)
46. blabla blabla blabla blabla not ECB blabla blabla blabla blabla blabla blabla blabla blabla not OCB blabla blabla block cipher blabla blabla blabla blabla blabla blabla blabla blabla blabla blabla blabla CBC blabla blabla blabla blabla blabla blabla blabla padding blabla blabla blabla CTR blabla blabla blabla blabla blabla blabla blabla blabla stream cipher blabla blabla counter blabla blabla blabla blabla blabla blabla Please stop It’s already 18h no ? I want to die… I will never do crypto…
47. Just tell me what to choose…
48. What do we need ? Confidentiality
49. What do we need ? Confidentiality Not just
50. How to detect tampering ? Some modes are very malleable Attacks are rarely read-only Cipher text tampering
51. What do we need ? Confidentiality
52. What do we need ? Confidentiality, Authentication, Integrity
53. What do we need ? Authenticated Encryption
54. Automatically checks before decrypting Computes an auth tag along the cipher text New recommended encryption scheme AE
55. Plain text Cipher Cipher text MAC MAC function AE : encrypt
56. Cipher text Cipher Plain text MAC MAC MAC function = ? AE : decrypt
57. Block cipher in counter mode Recommended by the NIST Dedicated AES mode AES GCM
58. What if I don’t have GCM ? Do It Yourself style* *Not recommended
59. One key for each algorithm A MAC function : HMAC (at least SHA-256) A good AES mode : CBC or CTR What you need
60. One rule Encrypt-Then-Mac
61. HMAC_update (IV, key1) 1 AES_encrypt (data, key2, IV) = cipher text 2 HMAC_update (cipher text, key1) 3 concat ( IV + cipher text + MAC) 5 HMAC_final () = MAC 4
62. Prevent messages reordering Encrypt-then-MAC each piece Chunk it in small pieces What about large data ?
63. A word about IVs Depends of your AES mode …
65. Not a secret, can be stored along the cipher text CTR/GCM : never reuse a key + nonce combinaison CBC : unique per msg and unpredictable aka. random IV / Nonce
66. Done ?
67. Nope
68. Forget all of this
69. In fact, if you type the letters « A-E-S » you’ve already lost
70. Treat crypto primitives like plutonium not AAA batteries
71. Attackers have a lot of imagination One error can invalidate your whole system Using crypto primitives is incredibly tricky Why ?
72. Attacks Timing attacks Extension length Padding oracle Preimage attacks Cache timing
74. Avoid OpenSSL Choose mature OSS lib, carefully audited Only use high-level crypto library The right tools
75. Don’t write a line before extensive learning Errors messages are information Be careful not leaking information The right use
76. Bindings exist in multiple languages Carefully designed to be safe and easy to use Currently the most lib recommended by experts NaCl/ LibSodium
77. New kid in the block, so no certification Stream cipher, good perf. even in software NaCl’s underlying primitives Chacha20/ Salsa20
78. Perish in flames Huuu… Keyczar in Java, Python, C++ Alternatives
79. It will hurt By crypto experts Every line of crypto should be audited Audit
80. Be prepared for JS WebCryptocalypse Watch out for CAESAR competition All I’ve said will probably be wrong in some months Stay tuned
81. Bibliography Cryptography Engineering by N. Ferguson & B. Schneier Some cryptographers to follow - Adam Langley (imperialviolet.org) - Matthew Green (blog.cryptographyengineering.com) - Thomas Ptacek (@tqbf & tptacek on Hacker News) - JP Aumasson (@veorq) http://www.cryptofails.com https://cryptocoding.net/
82. Thank you Questions ? To be continued…
