Google Beacon Platform, JavaScript Electronics & The Internet of Things

This presentation was given at GDG DevFest Nairobi, Strathmore University on the 14th January 2017. It covers Google Beacon Platform, Intel Architecture, JavaScript Electronics & The Internet of Things. More: https://medium.com/iot-5g-extreme-ideas-lab/iot-at-devfest-nairobi-8bf898cc4149#.94phcix8f

Transcript

1. Good Afternoon Nairobi 1
2. Ngesa N. Marvin
3. Ngesa N. Marvin Student-Telecomm Engineering IoT Champion for GDGs, SSA
4. Ngesa N. Marvin Student-Telecomm Engineering @Ngesa254 IoT Champion for GDGs, SSA
5. About Me ISP @Ngesa254 https://medium.com/iot-5g-extreme-ideas-lab
6. Intel
7. GDG Community Organizer
8. My last 4 years (or so) • IoT become a word • Open Source Electronics • Got an Edison board • Cellular tech, Antennas & Automation, Control systems • Started playing with Angular 2, Socket.io, Node Js, & Jonny 5 • Firebase, HTML5 & Bootstrap 8
9. The Internet of Things
10. 10 • Connect • Read • Send • Process • Store • Analyze • Query
11. IoT Architecture Gateway Cloud Wireless Networks Device Device Device
12. Cloud Architecture Gateway Wireless Networks Frontend Backend Frontend Backend Backend
13. Introduction Electronics
14. • Bits and Volts • Analogue Inputs/Outputs • Digital Inputs/Outputs • Pulse Width Modulation • Hardware Interfacing
15. IoT Hardware Not every device is created equal or is meant for the same task
16. Arduino 101 Arduino 101 Runs Arduino Firmata and RTOS Zephyr Computing cores • 32-bit x86 core, Intel Quark SE SoC (Curie) 32Mhz • ARC core (DSP + sensor hub) Storage/memory • 196 kB flash memory • 24 kB SRAM Operating voltage • 3.3V (5V tolerant) operating voltage Input/output • I2C master • SPI • UART • 6 ADC pins • 4x PWM capable I/O pins • 14 GPIO (4 PWM capable) pins Communication/sensor • Bluetooth LE • 6-axis Accelerometer/gyroscope Price: ~30$
17. Quark™ MDK D2000 Quark™ Microcontroller Developer Kit D2000 Runs proprietary RTOS and RTOS Zephyr Computing cores • 32-bit Intel Quark D2000 SoC 32Mhz (with low-power mode) Storage/memory • 32KB flash memory • 8KB OTP flash • 4KB data flash • 8KB SRAM Operating voltage • 2.0V-3.3V operating voltage (can function at 1.8V without comparator support) • Fits coin cells of 2.0V-3.6V, or regulated 2.5V-5V Input/output • USB 2.0 Type Micro-B • I2C master • SPI master/slave • UART • 19 ADC/Comparator pins • 2 PWM pins • 25 GPIO pins Sensors • Accelerometer/Magnetometer Price: ~15$
18. Intel Edison Module Edison Compute Module + Arduino Board / Mini Breakout Board Runs Ostro OS and Google Brillo, Linux based operating systems. Computing cores • Dual-core 32-bit Intel Atom x86 core 500Mhz • 32-bit Intel Quark SoC 100Mhz Storage/memory • 4 GB flash memory + microSD on Arduino board • 1 GB DDR memory Operating voltage • 1.8V for compute module and mini breakout board • 3.3V (5V tolerant) operating voltage Input/output (for Arduino board) • USB 2.0 - 1 OTG Controller • I2C master (2 controllers) • SPI • UART (2 Controllers: 1 full flow control, 1 RX/TX) Price: ~50$ (Compute module), ~60$ (incl. Mini breakout board), ~90$ (incl. Arduino Board)
19. Intel Edison Module Input/output (for Arduino board) • USB 2.0 - 1 OTG Controller • I2C master (2 controllers) • SPI • UART (2 Controllers: 1 full flow control, 1 RX/TX) • 6 ADC pins • 20 GPIO (4 PWM capable) pins Communication • Full Bluetooth 4.0 support • Integrated Wi-Fi certified in 68 countries Price: ~50$ (Compute module), ~60$ (incl. Mini breakout board), ~90$ (incl. Arduino Board)
24. IoT Sensors
28. With multiple smart objects around us, installing an app for each doesn't scale And how to discover objects close by, without being buzzed at and annoyed? 28
30. Google Beacon Platform + + The Physical Web Beacon Eddystone
31. How does it work? Beacon Smartphone Cloud Urls
32. Other Beacon Protocols Beacon • iBeacon • Estimote Connectivity • Estimote Location • Estimote Telemetry • Nearable
33. Example Beacon Smartphone Cloud Urls
34. Google Beacon Platform • Eddystone • Nearby API • Proximity Beacon API
35. Google Beacon Platform • Provision • Registration • Management
36. 36 • Beacon technology based on BLE and the Eddystone protocol • Allows for discovering objects in the proximity, represented by URLs (Physical Web) • Users have to ask to see objects to avoid pestering people • Secure (no tracking) as URLs are processed via a proxy; HTTPS only • Fully open design; for instance supported by Opera which operates their own proxy Eddystone and Physical Web is a great solution
37. 37 Allows for finding objects and services around you Supported by Chrome (iOS and Android) and Opera And it is in use today!
38. 38 Case story - Proxama http://marketingland.com/london-buses-test-first-consumer-experience-physical-web- 170529 Proxama's Physical Web enabled PWA in use in London
39. Retail Beacons • Store Proximity • Check in • Product Information • Check-out
43. 43 Where Else Can It Work? Many possibilities Many Opportunities Your Imagination
44. Emerging Web Standards(Connectivity) • Web Bluetooth • Web NFC • Web USB
45. IoT Software & Languages
46. 46 Already, 53% of mobile developers are involved in IoT development (VisionMobile) Majority of these have no embedded background, and are not used to C, manual memory management, etc. How do we give them the tools these smart people need JavaScript looks like a nice candidate Mobile Developers will do IoT
47. 47 Why [not] Node? • Fast, very fast • Consistent • Asynchronous • Event-based • Scalable • Top 1 language in the world • Large Community JavaScript looks like a nice candidate
48. 48 Hardware is blocking and synchronous
49. 49 Streams & Buffers DATA BUFFER DATA PASSED ON AND PROCESSED STREAM
50. 50 SocketIo SERVER CLIENT REQUEST RESPONSE SOCKET PACKETS
51. 51 Big Deal
52. Jonny five
54. KENYA BOARD INITIALIZATION app.js
55. 55 Demo Time: Let’s try it live! KENYA Hardware Required Edison Board/Arduino 6 LEDs 6 220 ohm resistors hook-up wires breadboard
56. 56 Demo Time: Let’s try it live! KENYA dancehall.js
57. KENYA Demo Time: Let’s try it live! ldr.js
58. KENYA DRIVING SERVO MOTORS servo.js
59. KENYA PING SENSORS (ULTRASOUND) sonar.js
60. KENYA BUILT IN OBJECTS
61. Intel XDK IoT Edition & Grove Indoor Environment Kit
62. Overview of “libmraa” and “libupm”
63. Libmraa Defines the capabilities of GPIO pins, Autodetection of Gen 1, Gen 2 and Edison Arduino boards Libupm Defines the interaction of high level sensors. Buttons, Buzzers, LCD, LED, Light Sensor, Servos, Rotary Angle Sensor, Relays, Sound Sensors, temperature sensors … more are added continually. Purpose of Each Library
64. 64 Libmraa – Object API (node.js) Playing with GPIO is easy
65. 65 https://medium.com/iot-5g-extreme-ideas-lab JavaScript Electronics is awesome, makes internet of things a joy For more demos and articles
66. 66 IoT GDE RESOURCES For more demos and articles Article on Google's developer site: https://developers.google.com/web/updates/2016/03/web-enabled-internet-of- things?hl=en https://medium.com/@urish @kennethrohde
67. IoT Operating System
68. IoT Networks
69. IoT Cloud and Analytics
70. GCP & x86 Architecture Gateway Intel Edison Johnny five Wireless Networks Firebase + Express
71. 71 Data Logging firesketch.js
73. Frontend Gateway Wireless Networks Cloud Socket.iO Angular 2 Message Queue Stream Processing Time Series Database Firebase Pub/Sub Dataflow Big Table
75. Any Q Me.loveQuestions==true #DevFestNairobi #Ask5GIoT @Ngesa254
76. 76 What next? • Improve the algorithm • Add more sensors • Give it a goal • Give it personality • Make the hardware better (Better chassis, stronger motors, etc)
77. What will you make? /do awesome! @Ngesa254 #DevFestNairobi16
