Run Containerized Database SQL Server 2017 Linux

The talk demonstrated the ease with which SQL Server 2017 running on Linux can be containerised. The demo application will showed a basic Web API interfacing with SQL Server 2017 running inside docker containers. The fully integrated API along with containerized database was deployed to managed Kubernetes cluster running on Azure using Azure Container Service (AKS). Persistent data management was handled using Azure Disk attached to Kubernetes cluster using the StatefulSets feature.

Transcript

1. Running Containerized Database SQL Server 2017 Linux Nilesh Gule
2. $whoami { “name” : “Nilesh Gule”, “title” : “Architect”, “website” : “https://www.HandsOnArchitect.com", “github” : “https://github.com/NileshGule" “twitter” : “@nileshgule”, “linkedin” : “https://www.linkedin.com/in/nileshgule”, “email” : “nileshgule@gmail.com", “likes” : “Technical Evangelism, Cricket” }
3. Agenda - SQL Server 2017 Linux container - .Net Core Web API with containerized database - Container deployment to Azure Kubernetes Service (AKS) - State Management with Persistent Data Volumes
4. Application Overview
5. SQL Server 2017 Linux
6. Getting Started with SQL Server 2017 Linux container Env variables - ACCEPT_EULA - SA_PASSWORD
7. Containerize App
8. Docker-compose
9. Managed Kubernetes Cluster (AKS) on Azure
10. Kubernetes cluster resources Resources - Network Security Group - Virtual Machine - Virtual Network - Public IP - Load balancer
11. Kubernetes Open-source system for automating deployment, scaling, and management of containerized application across clusters of machines Basic Objects - Namespace - Pod - Volume - Service Controllers - ReplicaSet - Deployment - StatefulSet - DemonSet
12. Kubernetes - Deployment - Desired state definitions for pods and replica sets - Defines - version of container images - Resource limits - volumes for data persistence - number of replicas - update strategy - Metadata to interact with resources
13. Kubernetes - StatefulSet - Use StatefulSets when data loss is unacceptable - Useful when replicas are needed for availability or scalability, and the replicas need stable volume mounts across restarts - Often used when deploying database workloads that store their state on external storage providers - With StatefulSets a crash of pod or cluster does not result in data loss
14. State Management with Persistent Volume
15. Persistent Volumes Node1 Node 2 Node 3 Node1 Node 2 Node 3 Node1 Node 2 Node 3 Node1 Node 2 Node 3 Without PV With PV
16. Persistent Volume - Storage class & PVC - StorageClass provides the specifications of the external persistent storage - PersistenceVolumeClaim (PVC) ensures that data is stored on an external storage device outside the Kubernetes cluster
17. Demo - AKS Deployment
18. - AKS Cluster Kubernetes Service nileshgule/sqlclient nileshgule/techtalksapi microsoft/mssql-linux-server - nileshgule/sqlclient nileshgule/techtalksapi microsoft/mssql-linux-server Service Discovery External Communication - Loadbalancer Nodeport AKS Cluster
19. Summary - Spin container - Interact using Web API & Postman - Persistent Storage - PVC - Deployment - StatefulSets - K8s secrets - 2 Node cluster
20. References ✴ Demo code - https://github.com/NileshGule/DataDaySG-2018 ✴ SQL 2017 Supported features on Linux - https://docs.microsoft.com/en-us/sql/linux/sql-server-linux-editions-and- components-2017?view=sql-server-linux-2017 ✴ SQL Server 2017 comparisons - https://www.microsoft.com/en-us/sql-server/sql-server-2017-comparison ✴ Unsupported features - https://docs.microsoft.com/en-us/sql/linux/sql-server-linux-release-notes?view=sql-server- linux-2017#Unsupported ✴ Azure Kubernetes Service (AKS) - https://azure.microsoft.com/en-us/services/kubernetes-service/ ✴ Docker getting started - https://docs.docker.com/get-started/ ✴ Docker Compose V3 - https://docs.docker.com/compose/compose-file/#build ✴ Kubernetes Basics - https://kubernetes.io/docs/tutorials/kubernetes-basics/ ✴ Azure Kubernetes objects - https://msft.social/TIRUaN ✴ Kubernetes secrets - https://kubernetes.io/docs/concepts/configuration/secret/ ✴ https://www.handsonarchitect.com/2018/01/integrate-sql-server-2017-linux-with.html
21. Thank you very much https://github.com/NileshGule/DataDaySG-2018 Code with Passion and Strive for Excellence
22. Q&A
