Rethinking Strings

Ruby strings serve two distinct purposes: the representation of textual data and the representation of binary data. These two use cases generally require different operations, but today they're both accessible via String. Combining the two creates a discoverability issue and can be error-prone. Many String operations have no logical meaning for arbitrary binary data. Having to use strings with a special encoding to pass binary data around is a non-obvious solution and hampers Ruby's usability. Moreover, binary data can sometimes look like ASCII text, which may help build false trust in code with logic errors. Such errors are nuanced and difficult to debug.

This talk takes a high-level look at Ruby's strings and encodings, highlighting potentially problematic areas and suggesting ways to improve. While the emphasis is on the logical interface for text and binary data, we'll also look at the performance ramifications of the current design and how that might improve as well.

Transcript

1. Rethinking Strings Kevin Menard 2023-05-13 kevin.menard@shopify.com
2. About Me 2021 2008 2014
5. You String me Round Primary way to communicate data to users Web templates Email processing Log output Common exchange format for API calls Configuration data
6. …Right Round Metaprogramming send, __send__ instance_variable_{get,set} method_missing respond_to?, respond_to_missing?
7. Rethinking Strings
8. ByteList: TruffleRuby Strings 1.0 Straightforward port of CRuby strings to TruffleRuby Pulled in Ruby source from Rubinius, reimplement C++ in Java Use JRuby’s ByteList to support efficient substring Worked… but not great for JIT compilation
9. Ropes: TruffleRuby Strings Reloaded (2.0) Reimplement with ropes Presented at RubyKaigi in 2016 Uses trees of lazy operations rather than byte manipulation Persistent data structure; easy to reuse Overhead for the tree, but could share memory easier a b c a b c x y z x y z LeafNode a b c LeafNode x y z ConcatNode
10. Rope Performance Lazy operations ERB does a lot of concatenations but only needs end result Immutability Cache code range and string length Can cheaply derive new code ranges and string lengths String#setbyte presents pathological case Setting each byte turns tree into linked list
11. TruffleString: TruffleRuby Strings Revolutions (3.0) Blended approach Ropes generally, but mutable byte storage when needed (work in progress) More storage strategies Improved efficiency in polyglot applications
12. A History of Strings Better than a time machine!
15. String API Text-oriented • Case conversion • Substring/index • Strip whitespace • Concatenation • Transcode Byte-oriented • Buffer pre-allocation • Direct byte setting • Byte indices • Byte slicing • Encoding override Modern? Legacy?
16. Strings Today Support mutable & immutable operations Or imperative and functional if you’d prefer Encoding-aware without single system encoding Encoding can be changed: System-wide (at start-up or runtime) On a per-file basis On a per-String basis Automatic encoding conversion (transcoding)
17. Encodings
18. The Meaning of Bytes encode(bytes) → code point Takes in a sequence of bytes Outputs a code point encode(code points) → character Takes in a sequence of code points Outputs a grapheme cluster (“character”) encode(encode(bytes)) → character
19. Bytes, Bytes, Baby bytes = [0xC2, 0xA9] 1 s = bytes.pack("C*") 2 3 s.dup.force_encoding("UTF-8") # => © 4 s.dup.force_encoding("Shift_JIS") # => ﾂｩ 5
20. Encoding.list.size # => 103
21. Encoding.name_list .size # => 175
22. Default Encodings Name Usage UTF-8 General purpose strings US-ASCII Symbols, regex, and numbers ASCII-8BIT (BINARY) Data read from I/O and binary data
23. ASCII-8BIT
24. ASCII-8BIT ≠ US-ASCII
25. Encoding::ASCII_8BIT.names # => ["ASCII-8BIT", "BINARY"]
26. Encoding::ASCII_8BIT .ascii_compatible? # => true
27. 'abc'.b.ascii_only? # => true
28. 'abc'.b.encoding # => #<Encoding:ASCII-8BIT>
29. Code Ranges
30. Code Range Values Name Usage Unknown String needs to be scanned 7 Bit • Encoding is ASCII-compatible • All bytes are 0x00 - 0x7F (ASCII-only) Valid • Bytes map correctly in encoding • String is not ASCII-only Broken Bytes don’t map correctly in encoding
31. Code Range Values Name Usage Unknown — 7 Bit str.ascii_only? Valid str.valid_encoding? && !str.ascii_only? Broken !str.valid_encoding?
32. Binary Data
33. How can we Represent Binary Data? Bytes are just integer values in 0x00 - 0xFF We could use an Array of Integer …but it’s not space efficient require 'objspace' 1 2 ObjectSpace.memsize_of([0x2A] * 1) # => 160 3 ObjectSpace.memsize_of([0x2A] * 1024) # => 8,232 4 ObjectSpace.memsize_of([0x2A] * 1024 ** 2) # => 8,388,648 5
34. How can we Represent Binary Data? Let’s use Ruby 1.8 strings require 'objspace' 1 2 ObjectSpace.memsize_of('*'.b * 1) # => 40 3 ObjectSpace.memsize_of('*'.b * 1024) # => 1,065 4 ObjectSpace.memsize_of('*'.b * 1024 ** 2) # => 1,048,617 5 6 ('*' * 1024 ** 2).bytesize # => 1,048,576 7 # (Δ: 41 bytes) 8
35. require 'zlib' 1 compressed = Zlib::Deflate.deflate('aasy') 2 # => "x\x9CKL,\xAE\x04\x00\x04\n\x01\xAF" 3 4 compressed.encoding # => #<Encoding:ASCII-8BIT> 5 compressed.ascii_only? # => false 6 compressed.valid_encoding? # => true 7
36. require 'zlib' 1 compressed = Zlib::Deflate.deflate('aasy') 2 # => "x\x9CKL,\xAE\x04\x00\x04\n\x01\xAF" 3 4 compressed.encoding # => #<Encoding:ASCII-8BIT> 5 compressed.ascii_only? # => false 6 compressed.valid_encoding? # => true 7 8 compressed.lines 9 # => ["x\x9CKL,\xAE\x04\x00\x04\n", "\x01\xAF"] 10
37. require 'zlib' 1 compressed = Zlib::Deflate.deflate('aasy') 2 # => "x\x9CKL,\xAE\x04\x00\x04\n\x01\xAF" 3 4 compressed.encoding # => #<Encoding:ASCII-8BIT> 5 compressed.ascii_only? # => false 6 compressed.valid_encoding? # => true 7 8 compressed.lines 9 # => ["x\x9CKL,\xAE\x04\x00\x04\n", "\x01\xAF"] 10 11 compressed.succ 12 # => "x\x9CKM,\xAE\x04\x00\x04\n\x01\xAF" 13
38. Binary Data ≠ Strings
39. Working with Binary Strings s1 = '' 1 s2 = String.new 2
40. Working with Binary Strings s1 = '' 1 s2 = String.new 2 3 s1 == s2 # => true 4
41. Working with Binary Strings s1 = '' 1 s2 = String.new 2 3 s1 == s2 # => true 4 5 s1 << 0x80 6 s2 << 0x80 7
42. Working with Binary Strings s1 = '' 1 s2 = String.new 2 3 s1 == s2 # => true 4 5 s1 << 0x80 6 s2 << 0x80 7 8 s1 == s2 # => false 9
43. Working with Binary Strings s1 = '' 1 s2 = String.new 2 3 s1 == s2 # => true 4 5 s1 << 0x80 6 s2 << 0x80 7 8 s1 == s2 # => false 9 10 s1.bytes # => [194, 128] 11 s2.bytes # => [128] 12
44. Working with Binary Strings String.new ≠ '' (empty string literal) String.new defaults to ASCII-8BIT/BINARY '' uses default internal encoding (UTF-8 in this case) String#<< takes codepoint values, not bytes 0x80 is a codepoint that takes two bytes in UTF-8 0x80 is a “codepoint” that takes 1 byte in BINARY
45. What About IO::Buffer? Can store and efficiently work with binary data … but people think it’s only for IO It still relies on ASCII-8BIT/BINARY encodings at boundaries Supports more than bytes, making it harder to use Not exposed to users File.read(<n>) does not return a buffer Zlib::Deflate.deflate does not return a buffer
46. Broken Strings
47. Broken Strings A String’s bytes have no mapping in the associated encoding Ruby hands you a broken string IO.read File.read You break the string yourself String#setbyte String#force_encoding
48. Scaling Images in Ruby image = File.read(File.expand_path("~/ruby.png")) 1 image.encoding # => #<Encoding:UTF-8> 2 image.ascii_only? # => false 3
49. Scaling Images in Ruby image = File.read(File.expand_path("~/ruby.png")) 1 image.encoding # => #<Encoding:UTF-8> 2 image.ascii_only? # => false 3 4 image.upcase # => input string invalid (ArgumentError) 5
50. Scaling Images in Ruby image = File.read(File.expand_path("~/ruby.png")) 1 image.encoding # => #<Encoding:UTF-8> 2 image.ascii_only? # => false 3 4 image.upcase # => input string invalid (ArgumentError) 5 6 image.valid_encoding? # => false 7
51. Scaling Images in Ruby image = File.read(File.expand_path("~/ruby.png")) 1 image.encoding # => #<Encoding:UTF-8> 2 image.ascii_only? # => false 3 4 image.upcase # => input string invalid (ArgumentError) 5 6 image.valid_encoding? # => false 7 8 image.force_encoding(Encoding::BINARY) 9 image.valid_encoding? # => true 10
52. Scaling Images in Ruby image = File.read(File.expand_path("~/ruby.png")) 1 image.encoding # => #<Encoding:UTF-8> 2 image.ascii_only? # => false 3 4 image.upcase # => input string invalid (ArgumentError) 5 6 image.valid_encoding? # => false 7 8 image.force_encoding(Encoding::BINARY) 9 image.valid_encoding? # => true 10 11 bigger_image = image.upcase # => Victory! 12
53. Broken Strings s = 'très' 1 s.encoding #=> #<Encoding:UTF-8> 2 s.size #=> 4 3 4 s.force_encoding('US-ASCII') #=> "tr\xC3\xA8s" 5 6 s.encoding #=> #<Encoding:US-ASCII> 7 s.valid_encoding? #=> false 8 s.size #=> 5 9
54. Can we fix this in Ruby?
55. Proposals for Ruby 3.3+
56. Caveats Backwards compatibility is important Phased-in approach Issue a warning Raise an exception (controllable via flag) Deprecate, but maybe never remove
57. 1. Invert ASCII-8BIT and BINARY
58. 'abc'.b.encoding 1 # => #<Encoding:BINARY> 2 Instead of 'abc'.b.encoding 1 # => #<Encoding:ASCII-8BIT> 2
59. 2. Remove ASCII compatibility from BINARY
60. 3. Eagerly handle broken strings
61. > Break apart the text and byte-oriented APIs
62. 4. Return IO::Buffer in IO calls
63. 5. Add a ByteList type
64. Add a ByteList type Much smaller API for working with a list of bytes None of the text-oriented API Simplifies String to work only with text More efficient No encoding compatibility checks appending bytes Safer << would not be a code point
65. > Make it harder to break strings
66. 6. Deprecate String#setbyte
67. 7. Deprecate #force_encoding
68. Deprecate String#force_encoding It’s unfortunately misused and has a narrow use case The primary use case is reading from IO and overriding the encoding Users actually use it to: “Fix” encoding exceptions (Checking after with String#valid_encoding? never happens) As a faster transcoding operation
69. Re-cap
70. Ruby strings are complex Difficult to optimize Difficult for Rubyists to work with API makes it too easy to corrupt data Automatic transcoding masks errors
71. Broken strings are often a logic error Lazily discovering them masks error origin Users often corrupt data trying to “fix” them Also hinder optimizations Inefficient UTF-8 character boundary detection
72. A proper binary data interface benefits all Simpler string API Fixes a leaky abstraction Easier target for text-oriented optimizations Normalizes encoding logic No more special handling for one specific encoding Faster & simpler binary data handling Far less error-prone for Rubyists Easier target for byte-oriented optimizations
73. Resources Code Ranges: A Deeper Look at Strings https://shopify.engineering/code-ranges-ruby-strings Specializing Ropes for Ruby https://dl.acm.org/doi/abs/10.1145/3237009.3237026 A Tale of Two String Representations RubyKaigi 2016 Rename ASCII-8BIT encoding to BINARY Ruby Feature #18576 Feature Request: Byte Arrays for Ruby 3 Ruby Feature #13166
74. Thank you for your time  kevin.menard@shopify.com  @nirvdrum  @nirvdrum@ruby.social
