Domain-Driven Design & REST

Slides of the talk I gave at Spring I/O 2016.

@springcentral

Transcript

1. DDD & REST
   Domain-Driven APIs for the web
   / olivergierke
   Oliver Gierke


   View Slide

2. View Slide

3. Background
   3


   View Slide

4. 4
   Spring Data
   Repositories &

   Aggregates
   Spring HATEOAS
   Hypermedia

   for Spring MVC
   Spring Data REST


   View Slide

5. REST ≠

   CRUD via HTTP
   5


   View Slide

6. What does it take to
   bridge the worlds of
   DDD & REST?
   “
   6


   View Slide

7. View Slide

8. 8
   http://www.infoq.com/minibooks/domain-driven-design-quickly


   View Slide

9. View Slide

10. View Slide

11. Implementing
    Domain-Driven
    Design
    10


    View Slide

12. Value objects
    11


    View Slide

13. Stringly typed code
    12
    public class Customer {
    private Long id;
    private String firstname, lastname, email;
    …
    }


    View Slide

14. Stringly typed code
    13
    public class SomeService {
    public void createUser(String firstname,

    String lastname, String email) {
    …
    }
    }


    View Slide

15. 14
    public class Customer {
    private Long id;
    private Firstname firstname;
    private Lastname lastname;
    private EmailAddress emailAddress;
    …
    }


    View Slide

16. Value Objects are a

    PITA to build in

    some languages.
    15


    View Slide

17. Still, they’re worth it.
    16
    See „Power Use of Value Objects in DDD“ by Dan Bergh Johnsson.


    View Slide

18. Lombok — putting the
    spice back into Java.
    17


    View Slide

19. 18
    @Value
    public class Customer {
    UUID id = UUID.randomUUID();
    Firstname firstname;
    Lastname lastname;
    EmailAddress email;
    @Value
    static class EmailAddress {
    String value;
    }
    }


    View Slide

20. AutoValue
    19
    Project website on GitHub.


    View Slide

21. Key opponents:
    Mapping libraries

    that need to

    (de)serialize them.
    20


    View Slide

22. Entities &
    Repositories
    21


    View Slide

23. 22
    Order
    LineItem
    Product
    Invoice
    Customer
    Payment Address
    Email


    View Slide

24. 22
    Order
    LineItem
    Product
    Invoice
    Customer
    Payment Address
    Email


    View Slide

25. Entity +

    Repository =

    Aggregate
    23


    View Slide

26. Aggregates form nice
    representation
    boundaries.
    24


    View Slide

27. Aggregates become

    the key things

    to refer to.
    25


    View Slide

28. Don’t get trapped by
    datastore thinking.
    26


    View Slide

29. Try to avoid

    bi-directional
    relationships.
    27


    View Slide

30. Bounded Context
    28


    View Slide

31. Order
    LineItem
    Product
    Invoice
    Customer
    Payment Address


    View Slide

32. 30
    Shipping
    Accounting
    Catalog
    Orders
    User

    Registration


    View Slide

33. 30
    Shipping
    Accounting
    Catalog
    Orders
    User

    Registration
    Accounting
    Payment information
    Billing Address
    Shipping
    Shipping address
    Customer
    Product


    View Slide

34. Domain Events
    31


    View Slide

35. 32
    Level 0: No events at all


    View Slide

36. 32
    Level 0: No events at all
    Level 1: Explicit operations


    View Slide

37. If you’re calling two
    setters in a row, you’re
    missing a concept.
    33


    View Slide

38. 34
    Level 0: No events at all
    Level 1: Explicit operations


    View Slide

39. 34
    Level 0: No events at all
    Level 1: Explicit operations
    Level 2: Some operations as events


    View Slide

40. Domain events as

    state transitions.
    35


    View Slide

41. Expose important

    events to interested
    parties via feeds.
    36


    View Slide

42. 37
    Level 0: No events at all
    Level 1: Explicit operations
    Level 2: Some operations as events


    View Slide

43. 37
    Level 0: No events at all
    Level 1: Explicit operations
    Level 2: Some operations as events
    Level 3: Event Sourcing


    View Slide

44. REST
    38


    View Slide

45. Representation
    design matters
    39


    View Slide

46. Aggregates
    Identifiable

    Referable

    Scope of consistency
    40


    View Slide

47. Resources
    Identifiable

    Referable

    Scope of consistency
    41


    View Slide

48. Hypermedia
    42


    View Slide

49. Serving data and
    navigation information

    at the same time.
    43


    View Slide

50. Trading domain
    knowledge with protocol
    complexity in clients.
    44


    View Slide

51. Reducing decisions in
    clients to whether a

    link is present or not.
    45


    View Slide

52. Prefer explicit

    state transitions over
    poking at your resources
    using PATCH.
    46


    View Slide

53. Translate domain
    concepts into web-
    appropriate ones.
    47


    View Slide

54. 48
    Aggregate Root /
    Repository
    Collection / Item
    Resources
    IDs URIs
    @Version ETags
    Last Modified
    Property
    Last Modified
    Header
    Relations Links


    View Slide

55. RESTBucks
    payment
    expected
    preparing
    cancelled
    ready completed
    1
    2
    3
    4
    5 6


    View Slide

56. Method URI Action Step
    POST /orders Create new order 1
    POST/PATCH /orders/{id}
    Update the order
    (only if "payment expected")
    2
    DELETE /orders/{id}
    Cancel order
    (only if "payment expected")
    3
    PUT /orders/{id}/payment
    Pay order
    (only if "payment expected")
    4
    Barista preparing the order
    GET /orders/{id} Poll order state 5
    GET /orders/{id}/receipt Access receipt
    DELETE /orders/{id}/receipt Conclude the order process 6


    View Slide

57. Method Resource type Action Step
    POST orders Create new order 1
    POST/PATCH update Update the order 2
    DELETE cancel Cancel order 3
    PUT payment Pay order 4
    Barista preparing the order
    GET order Poll order state 5
    GET receipt Access receipt
    DELETE receipt Conclude the order process 6


    View Slide

58. 52
    GET /orders
    {
    „_links“ : {
    „cancel“ : { „href“ : … },
    …
    „createdDate“ : …,
    „status“ : „Payment expected“
    …
    }


    View Slide

59. 53
    GET /orders
    {
    „_links“ : {
    „cancel“ : { „href“ : … },
    …
    „createdDate“ : …,
    „status“ : „Payment expected“
    …
    }


    View Slide

60. 54
    “Internationalize

    all user facing text.


    View Slide

61. Aaaargh!
    55


    View Slide

62. 56
    GET /orders
    {
    „_links“ : {
    „cancel“ : { „href“ : … },
    …
    „createdDate“ : …,
    „status“ : „Payment expected“
    …
    }


    View Slide

63. Spring
    RESTBucks
    57


    View Slide

64. Web
    Service
    Repository
    -
    Orders
    Spring Data
    Spring Data

    REST
    Payment
    Spring Data
    Manual

    implementation
    Manual

    implementation


    View Slide

65. JacksonCustomizations
    Externalize tweaks to the
    general JSON design
    59


    View Slide

66. Spring Data REST

    for the CRUDdy parts.
    60


    View Slide

67. ResourceProcessor
    To conditionally sneak
    links into the default
    representation.
    61


    View Slide

68. Resources
    62
    Spring RESTBucks

    https://github.com/olivergierke/spring-restbucks
    Benefits of Hypermedia APIs

    http://olivergierke.de/2016/04/benefits-of-hypermedia/index.html


    View Slide

69. Questions?
    63


    View Slide
