Spring HATEOAS – Hypermedia APIs with Spring

Slides about how to build hypermedia based APIs with Spring HATEOAS. Presented at SpringOne 2019 in Austin, TX.

Transcript

1. Spring HATEOAS –
   Hypermedia APIs with Spring
   Oliver Drotbohm, Greg Turnquist



   October 7–10, 2019
   Austin Convention Center


   View Slide

2. View Slide

3. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Spring HATEOAS helps building

   hypermedia-based, REST web
   services with Spring MVC.


   View Slide

4. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Spring HATEOAS helps building

   hypermedia-based, REST web
   services with Spring MVC.
   What does that even mean? !


   View Slide

5. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   What is Hypermedia?


   View Slide

6. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   {
   "createdAt" : "…",
   "lineItems" : [ … ],
   "total" : …,
   …
   }
   5
   Application data


   View Slide

7. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   {
   "_links" : {
   "self" : {
   "href" : "…",
   },
   "customer" : {
   "href" : "…"
   },
   …
   },
   "createdAt" : "…",
   "lineItems" : [ … ],
   "total" : …,
   …
   "_embedded" : {
   "customer" : { … }
   }
   }
   6
   Hypermedia
   Elements
   Application data


   View Slide

8. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Hypermedia Elements
   Static Related resources
   Static IANA link relations (self)


   View Slide

9. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   {
   "_links" : {
   "self" : {
   "href" : "…",
   },
   "customer" : {
   "href" : "…"
   },
   …
   },
   "createdAt" : "…",
   "lineItems" : [ … ],
   "total" : …,
   …
   "_embedded" : {
   "customer" : { … }
   }
   }
   "self" : {
   "href" : "…",
   },
   "customer" : {
   "href" : "…"
   },
   10
   Hypermedia
   Elements
   Application data
   IANA link relations
   Static relationships


   View Slide

10. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Hypermedia Elements
    Static
    Dynamic
    Related resources
    Static IANA link relations (self)
    Links representing the resource's state


    View Slide

11. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    {
    "_links" : {
    "self" : {
    "href" : "…",
    },
    "payment" : {
    "href" : "…"
    },
    …
    },
    "createdAt" : "…",
    "lineItems" : [ … ],
    "total" : …,
    …
    "_embedded" : {
    "customer" : { … }
    }
    }
    "self" : {
    "href" : "…",
    },
    "payment" : {
    "href" : "…"
    },
    13
    Hypermedia
    As
    The
    Engine
    Of
    Application
    State
    Appears only if the

    order can be paid!


    View Slide

12. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Why Hypermedia?


    View Slide

13. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    RESTBUCKS
    payment
    expected
    preparing
    cancelled
    ready completed
    1
    2
    3
    4
    5 6
    From: REST In Practice – O'Reilly
    Sample code @ GitHub: Spring RESTBucks


    View Slide

14. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    RESTBUCKS
    payment
    expected
    preparing
    cancelled
    ready completed
    1
    2
    3
    4
    5 6
    7


    View Slide

15. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Order cancellation policy
    Demo


    View Slide

16. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Spring HATEOAS


    View Slide

17. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Representation Models
    Links & Affordances
    Media types
    Client support


    View Slide

18. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Representation Models
    General support ResourceSupport
    Item resource

    e.g. /customer/{id}
    Resources
    Resource
    Collection resource

    e.g. /customers
    0.x


    View Slide

19. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    General support RepresentationModel
    Item resource

    e.g. /customer/{id}
    CollectionRepresentationModel
    EntityRepresentationModel
    Collection resource

    e.g. /customers
    Representation Models 1.0


    View Slide

20. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Links & Affordances
    var link = new Link("/something");



    assertThat(link.getHref()).isEqualTo("/something");

    assertThat(link.getRel()).isEqualTo(IanaLinkRelations.SELF);

    link = new Link("/something", "my-rel");



    assertThat(link.getHref()).isEqualTo("/something");

    assertThat(link.getRel()).isEqualTo(LinkRelation.of("my-rel"));
    Plain link with

    self relation
    Dedicated

    relation


    View Slide

21. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Links & Affordances
    var link = new Link("/{segment}/something{?parameter}");



    assertThat(link.isTemplated()).isTrue();

    assertThat(link.getVariableNames()).contains("segment", "parameter");

    var values = Map.of("segment", "path",

    "parameter", 42);


    assertThat(link.expand(values).getHref())

    .isEqualTo("/path/something?parameter=42");
    Template

    variables
    Expand the template

    using the given values


    View Slide

22. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Links & Affordances
    @Controller
    class PersonController {
    @GetMapping("/people")
    HttpEntity showAll() { … }
    @GetMapping("/people/{person}")
    HttpEntity show(@PathVariable Long person) { … }
    }


    View Slide

23. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Links & Affordances
    import static org.sfw.hateoas.server.mvc.WebMvcLinkBuilder.*;
    var link = linkTo(methodOn(PersonController.class).show(2L))

    .withRel("people");


    assertThat(link.getRel()).isEqualTo(LinkRelation.of("people"));
    assertThat(link.getHref()).endsWith("/people/2");
    Type-safe reference to the controller method


    View Slide

24. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Links & Affordances
    @Value

    class PaymentForm {

    CreditCardNumber number;

    }

    class PaymentController {



    @PutMapping("/order/{id}/payment")

    ResponseEntity> submitPayment(@PathVariable("id") Order order,

    @RequestBody PaymentForm form) { … }

    }
    Lombok's @Value to generate constructor
    Inbound payload is a PaymentForm


    View Slide

25. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Links & Affordances
    @Controller
    class PaymentMetadataController {
    @GetMapping(path = "/docs/payment", …)
    ResponseEntity> getPaymentMetadata() {
    var selfLink = ….andAffordance(
    afford(methodOn(PaymentController.class).submitPayment(…)));
    return ResponseEntity.ok(new RepresentationModel <>(selfLink));
    }
    }
    Adds affordance metadata to the link by inspecting the method


    View Slide

26. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Links & Affordances
    var methodInvocation = methodOn(EmployeeController.class).all();

    var link = Affordances.of(linkTo(methodInvocation).withSelfRel())

    .afford(HttpMethod.POST)

    .withInputAndOutput(EmployeeDTO.class)

    .withName("create")

    .andAfford(HttpMethod.GET)

    .withOutput(EmployeeDTO.class)

    .addParameters(

    QueryParameter.optional("name"),

    QueryParameter.optional("role"))

    .withName("search").toLink();
    POST to the resource to

    create a new Employee
    Access all Employees

    and potentially filter


    View Slide

27. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    asdasd
    Media types
    Representation model
    Jackson customizations
    JSON Output
    +


    View Slide

28. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Affordance model factory
    Jackson customizations
    asdasd
    Media types
    JSON Output
    +


    View Slide

29. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAL-FORMS
    An example


    View Slide

30. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Links & Affordances
    var model = new EntityResourceModel <>(order);







    model.addLink(linkTo(…).withRel("restbucks:payment"));
    Create representation model
    Add links pointing to controller methods


    View Slide

31. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAL-FORMS
    {
    "_links" : {
    "restbucks:payment" : { … },
    }
    }
    What are we supposed

    to do with this?


    View Slide

32. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Links & Affordances
    public @Bean CurieProvider curieProvider() {
    return new DefaultCurieProvider("restbucks",
    UriTemplate.of("/docs/{rel}"));
    }
    The link namespace
    Where to find docs

    describing semantics


    View Slide

33. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAL-FORMS
    {
    "_links" : {
    "restbucks:payment" : { … },
    "curies" : [{
    "name" : "restbucks",
    "href" : "http: //api.acme.com/docs/{rel}",
    "templated" : true
    }]
    }
    }
    "Find metadata about the payment resource at

    http://…/docs/payment!"
    What are we supposed

    to do with this?


    View Slide

34. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAL-FORMS
    {
    …
    "_templates" : {
    "default" : {
    "method" : "put",
    "properties" : [{
    "name" : "number"
    }]
    }
    }
    }
    Use an HTTP PUT request.
    Provide a field named „number“.


    View Slide

35. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAL-FORMS
    @Value
    class PaymentForm {
    CreditCardNumber number;
    }
    class PaymentController {
    @PutMapping("/order/{id}/payment")
    ResponseEntity> submitPayment(@PathVariable("id") Order order,

    @RequestBody PaymentForm form) { … }
    }
    Source for form details
    PUT derived from this


    View Slide

36. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAL-FORMS
    @Value
    class PaymentForm {
    CreditCardNumber number;
    }
    We need to expose the pattern


    View Slide

37. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAL-FORMS
    @Value
    class PaymentForm {
    CreditCardNumber number;
    }
    @Bean HalFormsConfiguration halFormsConfiguration() {
    HalFormsConfiguration configuration = new HalFormsConfiguration();
    return configuration.registerPattern(CreditCardNumber.class,
    CreditCardNumber.REGEX);
    }
    Expose the pattern to the

    Jackson customizations


    View Slide

38. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAL-FORMS
    {
    …
    "_templates" : {
    "default" : {
    "method" : "put",
    "properties" : [{
    "name" : "number",
    "regex" : "[0-9]{16}"
    }]
    }
    }
    }
    Use an HTTP PUT request.
    Provide a field named „number“

    matching the given pattern.


    View Slide

39. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAL-FORMS
    Demo


    View Slide

40. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Hypermedia Elements
    Inline resource Separate resource
    No additional requests
    Metadata repeatedly
    transmitted
    Cachability
    Additional requests


    View Slide

41. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Media types
    JSON-LD, JSON-API
    Contributions welcome!
    HAL

    http://bit.ly/hal-spec2
    0.x
    1.0
    Collection+JSON

    http://bit.ly/collection-json-spec
    1.0
    ALPS

    http://bit.ly/alps-spec
    0.x
    1.0
    HAL / HAL+FORMS

    http://bit.ly/hal-forms
    UBER

    http://bit.ly/uber-spec


    View Slide

42. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    How to create a

    custom media type?


    View Slide

43. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Custom media types
    interface HypermediaMappingInformation {
    List getMediaTypes();
    default Module getJacksonModule() { … }
    default ObjectMapper configureObjectMapper(ObjectMapper mapper) {…}
    }
    The media types you

    want to support.
    A Jackson module to

    customize output
    OR a custom ObjectMapper

    for advanced needs


    View Slide

44. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Custom media types
    public interface AffordanceModelFactory {
    MediaType getMediaType();
    AffordanceModel getAffordanceModel(String name,

    Link link,

    HttpMethod httpMethod,

    InputPayloadMetadata inputType,
    List queryMethodParameters,

    PayloadMetadata outputType);
    }
    Build a media-type

    specific model


    View Slide

45. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Custom media types
    META-INF/spring.factories
    org.sfw.hateoas.mediatype.AffordanceModelFactory=\
    com.acme.MyCustomAffordanceModelFactory
    Look at the existing

    ones for inspiration!


    View Slide

46. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Client support
    var uri = URI.create("http: //localhost:8080/api/");

    var traverson = new Traverson(uri, MediaTypes.HAL_JSON);

    var name = traverson.follow("movies", "movie", "actor")

    .withTemplateParameters(Map.of("user", 27))

    .toObject("$.name");


    View Slide

47. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Client support
    var content =

    "{'_links' : {'payment' : {'href' : '/orders/1/payment'}}}";

    var discoverer = new HalLinkDiscoverer();

    var link = discoverer.findLinkWithRel("payment", content);

    assertThat(link.getRel(), is("payment"));

    assertThat(link.getHref(), is("/orders/1/payment"));

    var discoverers = context.getBean(LinkDiscoverers.class);

    var discoverer =

    discoverers.getLinkDiscovererFor(MediaTypes.HAL_JSON);
    Media-type specific

    discoverer
    All available ones

    in the context


    View Slide

48. Klient
    https://github.com/odrotbohm/klient


    View Slide

49. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Miscellaneous
    RepresentationModelAssembler

    I18N support in media types

    LinkRelationProvider API

    Migration script 0.x

    Kotlin extensions


    View Slide

50. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Thanks!
    Oliver Drotbohm ƀ odrotbohm@pivotal.io / odrotbohm


    View Slide

51. Unless otherwise indicated, these slides are © 2013-2019 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Resources
    Rest beyond the obvious


    View Slide
