  1. Unleashing the Power of
    Azure VMware Solution
    Phil Huang
    Senior Cloud Solution Architect
    2022/12/22
    VMware User Group

    View Slide

  2. View Slide

  3. View Slide

  4. 黃秉鈞 Phil Huang
    講師介紹
    • 現任 Microsoft Senior Cloud Solution Architect
    • 曾任 VMware / Red Hat 解決方案架構師
    • Cloud Native Taiwan User Group 社群志工
    • blog.pichuang.com.tw
    • www.youtube.com/@pichuang-tw

    View Slide

  5. High Level Architecture
    Azure VMware Solution

    View Slide

  6. Azure VMware Solution 原生運作於 Azure Data Center 內
    留給露臉講師
    3rd-party
    solutions
    Azure Services
    Azure Active
    Directory
    Azure
    Security
    Azure SQL
    Database
    Azure
    Monitor
    Azure Arc
    Artificial
    Intelligence
    VMware vSphere
    Storage
    Network
    On-Premises Datacenter
    vCenter
    Azure Portal and Azure Resource Manager
    Azure Backbone Network
    Azure VMware Solution
    vSphere ESXi
    vSAN
    NSX
    vCenter
    3rd-party
    solutions
    • AVS is comprehensive VMware environment on Azure infrastructure.
    • Run VMware workloads natively as an Azure service.
    • Manage and secure applications across VMware environments and Microsoft Azure.
    ESXi
    ExpressRoute
    地端 VMware 既有設定、
    選擇遷移和擴展方式
    Azure 網路連線選擇

    View Slide

  7. Azure VMware Solution 供裝於 Azure 特定硬體資源上
    Azure VMware Solution
    會放置於專用硬體伺服器上運作
    Azure VMware Solution
    會放置於專用硬體伺服器上運作
    • AVS 單一叢集啟動台數為最少 3 台專用硬體伺服器,
    最多 16 台實體機
    • AVS 叢集與 Azure 既有共享硬體資源完全隔離
    • 以 Hyperconverged 形式部署,包含 Compute (ESXi)、
    Network (NSX)、Storage (vSAN)、Management
    (vCenter) 等 VMware 軟體於上
    Ref: https://docs.microsoft.com/en-us/azure/azure-vmware/faq
    https://docs.microsoft.com/en-us/azure/azure-vmware/concepts-private-clouds-clusters
    Type AV36
    CPU 36 Cores (2.3GHz)
    Memory 576 GB
    Storage Cache 3.2 TB NVMe
    Storage Data 15.4 TB SATA SSD
    Network
    2 * Mellanox ConnectX-4
    Dual Port 25 GbE*
    * RoCE v2 Enabled

    View Slide

  8. 透過 Azure Portal 部屬 Azure VMware Solution
    Software Version / Edition (2022.12)
    vCenter 7.0 u3c Standard
    ESXi 7.0 u3c Enterprise Plus
    NSX 3.1.2 Advanced
    vSAN 7.0 u3c Enterprise
    HCX 4.4.2 Advanced*
    Ref: https://docs.microsoft.com/en-us/azure/azure-vmware/faq
    https://docs.microsoft.com/en-us/azure/azure-vmware/concepts-private-clouds-clusters
    * HCX Enterprise Edition available on demand
    • AVS 部署將透過 Azure Portal 上直接供裝
    • AVS 已預先定義好 /22 網段內所需之 IP 分配,無須
    更改
    • AVS 部署過程包含下列但不限於
    • 專用硬體供裝、設定
    • VMware 必需之軟體安裝
    • VMware 網路與 Azure 網路基本介接
    該網段不能與雲地任何網段重疊

    View Slide

  9. 無須對個別組件設定網路,全自動部署設定 IP 及網段
    Azure Portal

    View Slide

  10. Scale a ESXi Node
    Add 1 Host: ~20 mins
    Ref: https://microsoft.github.io/PartnerResources/skilling/infrastructure/avs-hands-on-labs-lab-11

    View Slide

  11. Canada
    Central
    North Central US
    North Europe
    West Europe
    Southeast Asia (Singapore)
    Japan East
    Australia
    East
    West US
    East US
    UK South
    South
    Central US
    Australia Southeast
    Central US
    UK West
    Canada East
    Brazil South
    Japan West
    France
    Germany West Central
    East US 2
    East Asia (Hong Kong)
    South Africa North
    Azure VMware Solution Available by Region
    Updated 2022/8

    View Slide

  12. 如果你想要評估 Azure VMware Solution 怎麼建立...
    https://youtu.be/A1a3rVz7zyk
    https://labs.hol.vmware.com/HOL/catalogs/lab/10713

    View Slide

  13. How to use Azure Network
    to meet the needs of AVS?
    Azure VMware Solution

    View Slide

  14. Azure Hub-Spoke Network Design

    View Slide

  15. Azure VMware Solution 提供 2 種內部連線方式
    留給露臉講師
    Customer
    Edge
    Router
    ER
    Gateway
    Azure VNet
    NSX ESXi
    vCenter
    vSAN
    Azure
    Native
    Services
    AVS <->
    Azure Services
    AVS <-> On-prem
    Azure Bare-Metal Dedicated
    Infrastructure
    NSX vSAN
    ESXi
    vCenter
    HCX
    AVS
    D-MSEE
    ExpressRoute Global Reach
    or
    Azure vWAN
    MSEE: Microsoft Enterprise Edge
    D-MSEE: Dedicated MSEE
    Ref: https://docs.microsoft.com/zh-tw/azure/expressroute/expressroute-introduction
    Azure Services
    <-> On-prem
    • 資料不對外: 使用 Azure 相關服務不須經過
    Internet,包含但不限於
    • Azure VMware Solution
    • Microsoft 365
    • Azure Services
    • Azure VMware Solution 2 種內部連線方式
    1. Azure ExpressRoute
    2. Azure ExpressRoute Global Reach (客戶需
    有 Azure ExpressRoute Circuit 才能使用)
    VPN
    Gateway
    Customer VPN Server
    ExpressRoute (from Customer)
    ExpressRoute Global Reach
    ExpressRoute (from AVS D-MSEE)
    IPSec IKE S2S VPN
    從地端連到 Azure VMware Solution 的 3 個做法 Azure VMware Solution 提供的 2 種內部連線方式
    VMware
    SD-WAN vEdge
    VMware SD-WAN

    View Slide

  16. Azure Native Service Azure VMware Solution
    Multi Cloud eXchange
    On-premise Data Center
    VCF
    CE
    Router PE
    Router
    PE-MSEE MSEE
    MPLS ExpressRoute
    1000MBps (Fiber)
    Internet
    / MPLS
    S2S VPN
    D-MSEE
    ExpressRoute (a.k.a. ER)
    ExpressRoute Global Reach (a.k.a. ER GR)
    S2S VPN Connection
    ExpressRoute
    10Gbps
    從地端連上 Azure VMware Solution 的 3 種做法
    End-to-End Underlay Networking
    Ref: https://docs.microsoft.com/zh-tw/azure/expressroute/expressroute-introduction
    CE: Customer Edge
    MSEE: Microsoft Enterprise Edge Router
    PE-MSEE: Provider Edge MSEE
    VMware
    SD-WAN vEdge
    VMware SD-WAN Circuit
    3 種從地端連入的方式:
    1. Azure ExpressRoute
    2. S2S VPN
    3. VMware SD-WAN

    View Slide

  17. 評估參考影片 (1/2)
    https://youtu.be/JVgR50tdlxo https://youtu.be/F9voykz0Brs

    View Slide

  18. 評估參考影片 (2/2)
    https://youtu.be/A16Oh26a5q4

    View Slide

  19. What can you do on AVS
    and Azure?
    Azure VMware Solution
    Extend and Run

    View Slide

  20. Extend and Run: 基於 Azure VMware Solution 的延伸使用
    AVS
    Add-on
    預設包含在 AVS 授權內? 可否選購? License 來源?
    HCX 已包含 HCX Advanced 授權 可選 HCX Enterprise Microsoft
    SRM 無包含 可 VMware
    HCX: Hybrid Cloud eXtension
    SRM: Site Recovery Manager
    BYOL: Bring Your Own License
    • HCX: 將內部部署環境延伸至雲端,可在不同環
    境之間順暢地搬遷 VM
    • SRM: 透過自動化簡化管理,並確保快速且高度
    可預測的復原時間 (RTO)

    View Slide

  21. 商務持續性和災害復原決策樹
    Ref: https://docs.microsoft.com/zh-tw/azure/cloud-adoption-framework/scenarios/azure-vmware/eslz-business-continuity-and-disaster-recovery
    • 針對 AVS 上層 Workload,建議使用
    VMware Site Recovery Manager (SRM) 進
    行工作負載轉換,其次選用 Azure Site
    Recovery 來確保 RTO

    View Slide

  22. 使用 VMware Hybrid Cloud eXtension (HCX)
    VMware L2 Network Extension
    • 加速採用混合雲: 於 vSphere 6.x 與 AVS 之間啟用基於 HCX
    vMotion 的多種遷移方式,例如用於大規模遷移的 Bulk
    Migration 及更進階的 Replication Assisted vMotion (RAV) 等
    • 混合雲網路優化: 實現地端與 AVS 之間的 L2 Network Extension
    (NE),且遷移同時需要保持 IP 和 MAC 不變;且同時基於 L3 路
    由基礎上,可利用 WAN Optimization (WO) 最優化壓縮流量,
    加速傳輸及節省所需流量
    * Enterprise Edition Only, 且僅支援 vSphere 6.5 U3F+ / vSphere 6.7u3+
    Ref: VMware HCX Migration Types
    VMware HCX - Technical Overview

    View Slide

  23. Ref: https://microsoft.github.io/PartnerResources/skilling/infrastructure/avs-hands-on-labs-lab-12

    View Slide

  24. VMware HCX 遷移方式及軟體版本要求
    vMotion Bulk Migration Cold Migration
    Replication Assisted
    vMotion (RAV)
    系統停機時間 無 僅在切換的時候重開機 有 Downtime 發生 無
    HCX 版本 Advanced Advanced Advanced Enterprise
    地端軟體版本*
    vCenter 6.5+
    vSphere 6.5+
    vCenter 6.5+
    vSphere 6.5+
    vCenter 6.5+
    vSphere 6.5+
    vCenter 6.5+
    vSphere 6.5+
    虛擬交換器選擇** vSS, vDS, Cisco Nexus 1000v vSS, vDS, Cisco Nexus 1000v vSS, vDS, Cisco Nexus 1000v vSS, vDS, Cisco Nexus 1000v
    頻寬最小要求 100Mbps 以上 - − 100Mbps 以上
    WAN 優化 (WAN
    Optimization, WO)
    是 (壓縮、重複數據刪除) 是 (壓縮、重複數據刪除) 是 (壓縮、重複數據刪除) 是 (壓縮、重複數據刪除)
    L2 延伸 (Network
    Extension, NE)

    可 (可在沒有 L2 延伸的狀況
    下使用)
    可 (可在沒有 L2 延伸的狀況下
    使用)

    Virtual Machine HW Ver. 9+ 7+ 9+ 9+
    補充*** - 每 1 個 Service Mesh 最多 1 次
    遷移 1 台 VM
    - 每 1 個 Service Mesh 最多 1 次
    可搬遷 200 台 VM
    - 無網路頻寬要求
    - 每 1 個 Service Mesh 最多 1 次遷
    移 1 台 VM
    - 無網路頻寬要求
    - 無須 L2 NE 即可使用
    - 每 1 個 Service Mesh 最多 1 次
    可搬遷 200 台 VM
    - 可不停機遷移
    VMware KB 82702:HCX Support Policy for Legacy vSphere Environment VMware HCX 4.4 Configuration Limits

    View Slide

  25. 使用 HCX Mobility Optimized Networking (MON)
    • 未開啟 MON: 有 Hairpinning 議題,若於
    AVS 上需進行 L3 流量處哩,則預設需回到
    on-premise Router 進行路由交換,會產生來
    回 Latency / Traffic 之流量浪費
    • 開啟 MON: 透過 HCX MON 能力,若偵測到
    路由於同一個 T0 Gateway 之下,則可以直
    接於當地進行流量傳輸,無須回到 on-
    premise Router,可大幅節省 Latency /
    Traffic

    View Slide

  26. 使用 VMware Site Recovery Manager (SRM) 執行 BCDR
    Ref: https://docs.microsoft.com/zh-tw/azure/azure-vmware/disaster-recovery-using-vmware-site-recovery-manager
    https://vmc.techzone.vmware.com/resource/designlet-site-recovery-manager-azure-vmware-solution#summary-and-considerations
    https://docs.vmware.com/tw/Site-Recovery-Manager/8.3/com.vmware.srm.install_config.doc/GUID-4ACAA37F-CEF5-45A2-BB89-FC134024D1AF.html
    • 支援 2 種常見使用 SRM 案例
    1. VCF (on-premise) to AVS
    2. AVS to AVS
    • 支援 3 種類型的 BCDR 計畫
    1. 計畫性移轉 (Planned
    Migration)
    2. 災害復原 (Disaster recovery)
    3. Active-Active 雙向保護
    (Bidirectional Protection)
    • 採用 SRM 的 RPO 為 5 分鐘或更高
    vSphere Replication NFC

    View Slide

  27. Configuration Replication
    • RPO 設定最低為 5 分鐘,
    最高為 24 小時

    View Slide

  28. 網路評估參考影片
    https://youtu.be/WVFKdY9eNSI https://labs.hol.vmware.com/HOL/catalogs/lab/10895

    View Slide

  29. Azure Native IaaS and PaaS
    Azure VMware Solution
    Leverage and Collaborate

    View Slide

  30. 從 Azure VMware Solution 與 Azure 原生服務直接連接使用
    留給露臉講師
    ER
    Gateway
    vHub
    Azure Bare-Metal Dedicated
    Infrastructure
    NSX vSAN
    ESXi
    vCenter
    HCX
    AVS
    D-MSEE
    or
    Azure vWAN
    MSEE: Microsoft Enterprise Edge
    D-MSEE: Dedicated MSEE
    Ref: https://docs.microsoft.com/zh-tw/azure/expressroute/expressroute-introduction
    On-premise VCF
    VNet Peering
    VNet Spoke

    View Slide

  31. 152 Services + 58 Regions
    Ref: https://azurecharts.com/overview?m=adv

    View Slide

  32. Learning
    Azure VMware Solution
    Appendix

    View Slide

  33. Azure VMware 解決方案文件
    Ref: https://docs.microsoft.com/zh-tw/azure/azure-vmware/

    View Slide

  34. 1. Azure VMware 解決方案簡介
    2. 部署 Azure VMware 解決方案以準備將 VMware 資源移轉到 Azure
    3. 將內部部屬 VMware 資源移轉到 Azure VMware 解決方案
    4. 使用 VMware Site Recovery Manager 和 Azure VMware 解決方案,部屬災害復原
    在 Azure VMware 解決方案上執行 VMware 資源
    Microsoft Learn
    Ref: https://docs.microsoft.com/zh-tw/learn/paths/run-vmware-workloads-azure-vmware-solution/

    View Slide

  35. Learning Plan Resources for Azure VMware Solution (AVS)
    Microsoft Partner Resources
    Ref: https://microsoft.github.io/PartnerResources/azure/infrastructure/azure-vmware-solution

    View Slide

  36. Invent with purpose.

    View Slide

  37. Network Traffic
    Azure VMware Solution
    Appendix

    View Slide

  38. Network Overview of Azure VMware Solution
    留給露臉講師
    Customer
    Edge
    Router
    ER
    Gateway
    Azure VNet
    NSX ESXi
    vCenter
    vSAN
    Azure
    Native
    Services
    Azure Bare-Metal Dedicated
    Infrastructure
    NSX vSAN
    ESXi
    vCenter
    HCX
    AVS
    D-MSEE
    ExpressRoute Global Reach
    or
    Azure vWAN
    MSEE: Microsoft Enterprise Edge
    D-MSEE: Dedicated MSEE
    VPN
    Gateway
    Customer VPN Server
    ExpressRoute (from Customer)
    ExpressRoute Global Reach
    ExpressRoute (from AVS D-MSEE)
    IPSec IKE S2S VPN

    View Slide

  39. VM on On-premise VCF <-(ER)-> VM on AVS 連線流量路線
    留給露臉講師
    Customer
    Edge
    Router
    ER
    Gateway
    Azure VNet
    NSX ESXi
    vCenter
    vSAN
    Azure
    Native
    Services
    Azure Bare-Metal Dedicated
    Infrastructure
    NSX vSAN
    ESXi
    vCenter
    HCX
    AVS
    D-MSEE
    or
    Azure vWAN
    MSEE: Microsoft Enterprise Edge
    D-MSEE: Dedicated MSEE
    VPN
    Gateway
    Customer VPN Server
    ExpressRoute (from Customer)
    ExpressRoute Global Reach
    ExpressRoute (from AVS D-MSEE)
    IPSec IKE S2S VPN
    最佳路線

    View Slide

  40. VM on On-premise VCF <-(S2S VPN)-> VM on AVS 連線流量路線
    留給露臉講師
    Customer
    Edge
    Router
    ER
    Gateway
    Azure VNet
    NSX ESXi
    vCenter
    vSAN
    Azure
    Native
    Services
    Azure Bare-Metal Dedicated
    Infrastructure
    NSX vSAN
    ESXi
    vCenter
    HCX
    AVS
    D-MSEE
    or
    Azure vWAN
    MSEE: Microsoft Enterprise Edge
    D-MSEE: Dedicated MSEE
    VPN
    Gateway
    Customer VPN Server
    ExpressRoute (from Customer)
    ExpressRoute Global Reach
    ExpressRoute (from AVS D-MSEE)
    IPSec IKE S2S VPN
    轉介 S2S VPN

    View Slide

  41. VM on AVS <-> Azure Native Services 連線流量路線
    留給露臉講師
    Customer
    Edge
    Router
    ER
    Gateway
    Azure VNet
    NSX ESXi
    vCenter
    vSAN
    Azure
    Native
    Services
    Azure Bare-Metal Dedicated
    Infrastructure
    NSX vSAN
    ESXi
    vCenter
    HCX
    AVS
    D-MSEE
    or
    Azure vWAN
    MSEE: Microsoft Enterprise Edge
    D-MSEE: Dedicated MSEE
    VPN
    Gateway
    Customer VPN Server
    ExpressRoute (from Customer)
    ExpressRoute Global Reach
    ExpressRoute (from AVS D-MSEE)
    IPSec IKE S2S VPN

    View Slide

  42. VM on AVS <-> Azure Native Services 連線流量路線
    留給露臉講師
    Customer
    Edge
    Router
    ER
    Gateway
    Azure VNet
    NSX ESXi
    vCenter
    vSAN
    Azure
    Native
    Services
    Azure Bare-Metal Dedicated
    Infrastructure
    NSX vSAN
    ESXi
    vCenter
    HCX
    AVS
    D-MSEE
    or
    Azure vWAN
    MSEE: Microsoft Enterprise Edge
    D-MSEE: Dedicated MSEE
    VPN
    Gateway
    Customer VPN Server
    ExpressRoute (from Customer)
    ExpressRoute Global Reach
    ExpressRoute (from AVS D-MSEE)
    IPSec IKE S2S VPN

    View Slide
