  1. The magic behind
    HTTP/2

    View Slide

  2. @r31gN_
    JS Instructor
    GDE

    View Slide

  3. View Slide

  4. A brief history

    View Slide

  5. HTTP/1.0 (year 1996)
    ● Made a new connection for every request
    ○ Overhead
    ○ 3 packets for setup
    ○ 4 packets for termination
    ○ https://tools.ietf.org/search/rfc1945

    View Slide

  6. HTTP/1.1 (year 1997)
    ● Persistent connections
    ○ Reuse the connection for multiple requests
    ○ Still one request at a time
    ● Pipelined connections
    ○ Multiple requests at a time
    ○ Requests are served in FIFO order (slow requests are blocking)
    ○ Recommendation not to use it (Chromium project)

    View Slide

  7. HTTP/1.0 HTTP/1.1 HTTP/1.1 Pipelining

    View Slide

  8. Best practices
    ● Fewer files
    ○ JS/CSS concatenation
    ○ Image sprites
    ● Inline stuff
    ○ JS/CSS
    ○ Data URI for images
    ● Domain sharding
    ○ ~ 6 connections per domain
    ○ Share assets across multiple domains

    View Slide

  9. Best practices DOWNSIDES
    ● Fewer files
    ○ Download and parse unnecessary content
    ● Inline stuff
    ○ Prevents caching
    ● Domain sharding
    ○ Each connection adds overhead
    ○ Race conditions

    View Slide

  10. HTTP/2

    View Slide

  11. HTTP/2 in one slide
    ● Binary framing layer
    ● Request/response multiplexing
    ● Other features
    ○ Prioritisation
    ○ Flow control
    ○ Server push
    ● Only one TCP connection
    ● Header compression (HPACK)

    View Slide

  12. View Slide

  13. Streams, messages, frames
    ● Stream: bidirectional flow of bytes which may carry one
    or more messages
    ● Message: a complete sequence of frames that map to a
    request/response
    ● Frame: smallest unit of communication in HTTP/2,
    containing a frame header, which at a minimum identifies
    the stream to which the frame belongs

    View Slide

  14. View Slide

  15. View Slide

  16. Stream prioritisation
    ● Each stream may be given an integer between 1 and 256
    ● Each stream may depend on other streams
    ● The combination of dependencies and weights will result
    in a prioritisation tree
    ● This is used to prioritise CPU/memory allocation

    View Slide

  17. R
    A B
    W - 12 W - 4

    View Slide

  18. C
    A B
    W - 12 W - 4
    R
    W - 1

    View Slide

  19. Flow control
    ● Mechanism to prevent the sender from overwhelming the
    receiver
    ● ~ TCP Flow Control (but it was not granular enough)
    ● HTTP/2 does not implement an algorithm, but provides
    building blocks for this
    ○ Is directional
    ○ Is credit based
    ○ Cannot be disabled
    ○ It is hop-by-hop (an intermediary node can decide other algorithms)

    View Slide

  20. Server push
    ● Serve more than one response per request (even if client
    did not request specifically)
    ● Server builds dependency graph based on referer header
    ● Server push streams are initiated by the PUSH_PROMISE
    frame (contain the HTTP headers of the promised resource)
    ● Client can opt to reject the stream (RST_STREAM frame)
    ● This is an optimisation over HTTP/1.1 inlining assets
    strategy (which was always forced)

    View Slide

  21. HPACK compression format
    ● Headers are now compressed (including cookies!)
    ● Based on a shared compression context that both client
    and server understand (Huffman code)
    ● Has a static and a dynamic table
    ○ Static table is used for common HTTP header fields
    ○ Dynamic table is initially empty, but gets progressively built

    View Slide

  22. Best practices
    ● No more concatenation
    ○ No more cache churn issues
    ○ Only download what is needed
    ● No more inlining
    ○ Better caching
    ● No more domain sharding
    ○ Better resource utilisation

    View Slide

  23. View Slide

  24. https://github.com/http2/http2
    -spec/wiki/Implementations

    View Slide

  25. Keep on smiling because you
    are the most beautiful people
    when you do.

    View Slide

  26. Q&A

    View Slide

  27. Thank you!
    @r31gN_

    View Slide
